  1. Home/
  2. Acrox Technologies Co., Ltd./
  3. PRDMU28

PRDMU282.4 G wireless mouse

Acrox Technologies Co., Ltd.
2.4 G wireless mouse - FCC ID PRDMU28 - Acrox Technologies Co., Ltd.
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Oct 19, 2014
Application Purpose
Original Equipment
Date of Application
Oct 19, 2014
Equipment Note
2.4 G wireless mouse
Frequency Range
2408.00000000 - 2474.00000000
Company
Acrox Technologies Co., Ltd.
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

2.4GHz Wireless Mouse USER'S GUIDE Ver.:1.00 CAUTION: To use this product properly, please read the user's guide before installing. 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2 Functional Introduction 1. Left button 2. Right button 6. Win Key (LED Indicator) 3. Scrolling Wheel 8. Battery Cover 4. Forward 9. Connect Button 5. Backward 10. ON/OFF Switch Forward Press this button to view the next page in your Internet browser. Backward Press this button to view the previous page in your Internet browser. Win Key Windows button for one-touch access to the Start screen 3 Installing the batteries Step 1: Take the battery cover off. Step 2: Insert the battery as shown inside the battery compartment. Step 3: Replace the cover. Step 4: Turn on power switch **Warning: *Please insert the battery with the correct position according to the instruction labeled on the mouse. Step 5: If you need to travel with your wireless mouse, made sure you turn off the POWER SWITCH. Pull AA Battery X 1 4 Setup the Mouse 1. Insert the battery into the mouse, then follow the steps below. 2. In the meantime, to open the mouse under the cover, take the nano receiver out. 3. Then press the connect button on the mouse. If the mouse does not work after 10 seconds, pair them again. 4. The LED indicator on mouse flashes steadily when it is in pairing mode and stops blinking when it is successfully paired with the receiver. 7. When low battery, the battery indicator on the mouse will start to blink. *LED Indicator LED is on for 3 sec. Power ON LED Blinks for 3 times During Pairing (LED OFF when paired or failed after 10 sec.) LED Blinks for 10 sec. Low Battery Warning LED Indicator

Cover Letter(s)

AcroxTechnologiesCo.,Ltd. 4F.,No.89,MinshanSt.,NeihuDist.,TaipeiCity114,Taiwan,R.O.C --------------------------------------------------------------------------------------------------------------------- FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:PRDMU28 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName SchematicsPRDMU28_FCCID_Schematics.pdf BlockDiagramPRDMU28_FCCID_BlockDiagram.pdf OperationalDescriptionPRDMU28_FCCID_OperationalDescription.pdf Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. Sincerely, AcroxTechnologiesCo.,Ltd. ------------------------- (GavinHsieh) (ProductManager)

Cover Letter(s)

AcroxTechnologiesCo.,Ltd. 4F.,No.89,MinshanSt.,NeihuDist.,TaipeiCity114,Taiwan,R.O.C -------------------------------------------------------------------------------- (FCCID:PRDMU28) POWEROFATTORNEY DATE:2014-10-17 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 ToWhomItMayConcern: We,theundersigned,herebyauthorizeShenzhenSEM.TestTechnologyCo.,Ltd. JandySoonourbehalf,toapplytotheFederalCommunicationsCommissiononour equipment.AnyandallactscarriedoutbyShenzhenSEM.TestTechnologyCo.,Ltd. JandySoonourbehalfshallhavethesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct. We,AcroxTechnologiesCo.,Ltd,arenotsubjecttoadenialoffederal benefitspursuanttoSection5301oftheAnti-DrugActof1988,21USC853a,and nopartytotheapplicationissubjecttoadenialoffederalbenefitspursuant tothatsection. Sincerely, AcroxTechnologiesCo.,Ltd. ------------------------- (GavinHsieh) (ProductManager)

External Photos

Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 EUT View 3

ID Label/Location Info

Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: PRDMU28 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

ID Label/Location Info

Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: PRDMU28 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

Internal Photos

Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 RF Antenna Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 Solder Board-Component View 2 Solder Board-Component View 3 Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 Solder Board-Component View 4 Solder Board-Component View 5

Test Report

Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I PAGE 1 OF 24 FCC PART 15.249 FCC Part 15C Measurement and Test Report For Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C FCC ID: PRDMU28 FCC Rule(s): FCC Part 15.249 Product Description: 2.4 G wireless mouse Tested Model: GOI Report No.: STR14098241I Tested Date: 2014-09-29 to 2014-10-13 Issued Date: 2014-10-13 Tested By: Jason Su / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so / PSQ Manager Prepared By: Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, P.R.C.(518101) Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen SEM.Test Technology Co., Ltd. Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I PAGE 2 OF 24 FCC PART 15.249 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 3 1.2 TEST STANDARDS ................................................................................................................................................... 4 1.3 TEST METHODOLOGY ............................................................................................................................................. 4 1.4 TEST FACILITY ....................................................................................................................................................... 4 1.5 EUT SETUP AND TEST MODE ................................................................................................................................. 5 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 6 3. ANTENNA REQUIREMENTS ................................................................................................................................ 7 3.1 STANDARD APPLICABLE ......................................................................................................................................... 7 3.2 TEST RESULT.......................................................................................................................................................... 7 4. RADIATED EMISSIONS ......................................................................................................................................... 8 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................................. 8 4.2 STANDARD APPLICABLE ......................................................................................................................................... 8 4.3 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 8 4.4 TEST PROCEDURE ................................................................................................................................................... 9 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION .............................................................................................. 9 4.6 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 10 4.7 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 10 5. OUT OF BAND EMISSIONS ................................................................................................................................. 19 5.1 STANDARD APPLICABLE ....................................................................................................................................... 19 5.2 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 19 5.3 TEST PROCEDURE ................................................................................................................................................. 19 5.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 19 5.5 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 19 6. EMISSION BANDWIDTH ..................................................................................................................................... 22 6.1 STANDARD APPLICABLE ....................................................................................................................................... 22 6.2 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 22 6.3 TEST PROCEDURE ................................................................................................................................................. 22 6.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 22 6.5 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 22 Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I PAGE 3 OF 24 FCC PART 15.249 1. GENERAL INFORMATION 1.1 Product Description for Equipment Un…

Text truncated - open the document above for the full version.

Test Setup Photos

Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Radiation Emission Test Setup (Below 30MHz) Radiation Emission Test Setup (30MHz to 1GHz) Acrox Technologies Co., Ltd. Model: GOI REPORT NO.: STR14098241I FCC PART 15.249 Radiation Emission Test Setup (Above 1GHz)

Contact Information

Applicant

Gavin Hsieh(Product Manager)
[email protected]886-2-2796-5888Fax: 886-2-2793-8999

Test Firm

Shenzhen SEM.Test Technology Co., Ltd.Jandy So
[email protected]086-755-33663308Fax: 086-755-33663309

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.47 GHz-
