PID # 121364/5-109103 Rev. 100421 2.4GHz Wireless Keyboard & Mouse Model #: KB5800W/KBL5900W User’s Manual 2 All brand name and trademarks are the property of their respective owners USER’S RECORD: To provide quality customer service and technical support, it is suggested that you keep the following information as well as your store receipt and this user’s manual. Date of Purchase: ________________________________ Model Number: ________________________________ Product Rev Number (located below the UPC on the package): ____________________ FCC RADIATION NORM: FCC This equipment has been tested and found to comply with limits for Class B digital device pursuant to Part 15 of Federal Communications Commission (FCC) rules. FCC Compliance Statement These limits are designed to provide reasonable protection against frequency interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed or used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in television reception, which can be determined by turning the equipment off and on. The user is encouraged to try and correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected to.
Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION! The Federal Communications Commission warns the user that changes or modifications to the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 3 PACKAGE CONTENTS: Your new Keyboard will ship with the following items: - 2.4GHz Wireless Keyboard, Mouse - 2 AA Batteries for Mouse - 2 AAA Batteries for Keyboard - User’s Manual - Warranty Information SYSTEM REQUIREMENTS: Please be sure that you meet all of the system requirements below to avoid difficulties during installation: - PC & Mac ® Compatibles - Windows ® 2000, XP, and Vista - Mac ® OS 10.3 and above - An Available PS/2 Port 4 INSTALLING THE BATTERIES: 1. Pull the Battery Compartment Release Latch at the bottom of your mouse and remove the Battery Compartment Cover from your mouse. 2. Install two AA batteries into your mouse following the battery orientation guide in the battery bay. 3. Replace the Battery Compartment Cover back onto your mouse until it securely locks. 4. Press the Battery Compartment Cover Release Latch at the bottom of your keyboard and remove the Battery Compartment Cover from your keyboard. 5 5. Install two AAA batteries into your keyboard following the battery orientation guide in the battery bay. 6. Replace the Battery Compartment Cover back onto your keyboard until it securely locks. The LED indicator on your keyboard will light up for 3 seconds after the batteries are installed successfully. 6 INSTALLATION: NOTE: The pictures shown in this User’s Manual are for demonstration purposes only. Your computer or product may look slightly different. 1. Plug the Nano Receiver at the bottom of your mouse into an available USB port on your computer. 2. Turn on your computer. 3. Your computer will detect and install the necessary drivers automatically. 4. Your new keyboard is now ready to be used. 7 HOT KEYS DESCRIPTION: Windows ® Vista Hot Keys Gadgets Open and Close Gadgets window Zoom - Zoom out Zoom + Zoom in Flip 3D Open Flip 3D mode Media Player Hot Keys Media Player on Open the media player. Volume down Press to turn volume down. Volume up Press to turn volume up. Mute Press to mute the sound. Play / Pause Play / Pause Previous Press to play the previous audio or video file when multimedia is playing Next Press to play the next audio or video file when multimedia is playing Internet & Application Hot Keys Homepage Start the default Web browser and load the home page Mail Box Start the default email software My Favorite Open my favorite window in Internet Explorer ® My Computer Open “My Computer” Search Open the Search panel Calculator Start Calculator MCE Hot Keys MCE Start Media Center On Live TV Live TV Record TV Record TV Key Lock Key Lock NOTE: Functions of hot keys depend on support of your computer’s motherboard and settings of the operating system. 8 WARRANTY INFORMATION: Gear Head, LLC warrants that this product shall be free from defects in materials and workmanship for the reasonable lifetime of the product. If the product is defective, Gear Head, LLC’s sole obligation under this warranty shall be at its election, subject to the terms of this warranty, to repair or replace any parts deemed defective. This warranty is for the exclusive benefit of the original purchaser and is not assignable or transferable. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE TERMS OF THIS WARRANTY, UNLESS OTHERWISE PROHIBITED BY LAW. Exclusions To the fullest extent permitted by law, Gear Head, LLC expressly disclaims and excludes from this warranty any liability for damages, including but not limited to general, special, indirect, incidental, consequential, aggravated, punitive or exemplary damages, and economic loss (even if Gear Head™ is informed of their possibility), third party claims against you, including for any loss or damages, and claims or damages related to loss of, or, damage to, your records or data. This warranty does not…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT

Label Location

Page 2 Page 3 Page 4 Page 5

FCC ID:PRDOPWIRWMW06 Report No.: RF990618C04 Operational Description This device is a Wireless Mouse. The transmitter of the EUT is powered by 3Vdc from batteries (1.5V AAA x 2). The antenna is printed antenna. The other instruction, please have a look at the users manual.

Report No.: RF990618C04 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO. :RF990618C04 MODEL NO. :GA8 (refer to item 3.1 for more details) RECEIVED :Jun. 18, 2010 TESTED :Jun. 21, 2010 ISSUED :Jun. 24, 2010 APPLICANT : Acrox Technologies Co., Ltd ADDRESS : 4F., No. 89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. ISSUED BY : Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS : No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION : No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 23 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990618C04 2 Report Format Version 3.0.1 Table of Contents 1. CERTIFICATION ...........................................................................................................3 2. SUMMARY OF TEST RESULTS ...................................................................................4 2.1 MEASUREMENT UNCERTAINTY ................................................................................4 3. GENERAL INFORMATION............................................................................................5 3.1 GENERAL DESCRIPTION OF EUT..............................................................................5 3.2 DESCRIPTION OF TEST MODES................................................................................6 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ...........................................................6 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ................................7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ...............................................8 3.4 DESCRIPTION OF SUPPORT UNITS ..........................................................................8 4. TEST TYPES AND RESULTS .......................................................................................9 4.1 RADIATED EMISSION MEASUREMENT .....................................................................9 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................................9 4.1.2 TEST INSTRUMENTS ................................................................................................10 4.1.3 TEST PROCEDURES ................................................................................................. 11 4.1.4 DEVIATION FROM TEST STANDARD ....................................................................... 11 4.1.5 TEST SETUP ..............................................................................................................12 4.1.6 EUT OPERATING CONDITIONS ................................................................................12 4.1.7 TEST RESULTS ..........................................................................................................13 4.2 BAND EDGES MEASUREMENT ................................................................................18 4.2.1 LIMITS OF BAND EDGES MEASUREMENT .............................................................18 4.2.2 TEST INSTRUMENTS ................................................................................................18 4.2.3 TEST PROCEDURE ...................................................................................................18 4.2.4 DEVIATION FROM TEST STANDARD .......................................................................18 4.2.5 EUT OPERATING CONDITION ..................................................................................18 4.2.6 TEST RESULTS ..........................................................................................................19 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................................21 6. INFORMATION ON THE TESTING LABORATORIES ................................................22 7. APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.........................................................................................23 Report No.: RF990618C04 3 Report Format Version 3.0.1 1. CERTIFICATION PRODUCT: Wireless Mouse MODEL NO.: GA8 (refer to item 3.1 for more details) BRAND: ACROX APPLICANT: Acrox Technologies Co., Ltd TESTED: Jun. 21, 2010 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 The above equipment (model: GA8) have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Jun. 24, 2010 Andrea Hsia / Specialist TECHNICAL ACCEPTANCE : , DATE :Jun. 24, 2010 Responsible for RF Long Chen / Senior Engineer APPROVED BY : , DATE :Jun. 24, 2010 Gary Chang / Assistant Manager Report No.: RF990618C04 4 Report Format Version 3.0.1 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULTREMARK 15.207 Conducted Emission Test NA Power supply is 3Vdc from batteries. 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 15.209 PASS Meet the requirement of limit. Minimum passing margin is -4.7dB at 4880.00MHz. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty le…
