PRL-IWE3200IEEE 802.11g HotSpot Access Gateway

IWE3200 HotSpot Gateway User’s Guide Version: 1.0 Last Updated: 08/22/2006 i Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated ra- dio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is en- couraged to try to correct the interference by one of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, (example – use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environ- ment. This equipment should be installed and operated with minimum distance 20 cm between the ra- diator & your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any inter- ference received, including interference that may cause undesired operation. ii R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Termi- nal Equipment and Satellite Earth Station Equipment) as of April 8, 2000. Safety This equipment is designed with the utmost care for the safety of those who install and use it. How- ever, special attention must be paid to the dangers of electric shock and static electricity when work- ing with electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to ensure the safe use of the equipment. EU Countries Intended for Use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, Portugal, Spain, Sweden, The Neth- erlands, and United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states Norway and Swit- zerland. EU Countries Not Intended for Use None. iii Table of Contents 1. Introduction ......................................................................................................................... 1 1.1. Overview ...................................................................................................................1 1.2. Features.................................................................................................................... 2 1.3. LED Definition........................................................................................................... 7 1.4. Feature Comparison ................................................................................................. 7 2. First-Time Installation and Configuration ............................................................................ 8 2.1. Selecting a Power Supply Method ............................................................................ 8 2.2. Mounting the IWE3200 on a Wall ............................................................................. 9 2.3. Preparing for Configuration..................................................................................... 10 2.3.1. Connecting the Managing Computer and the IWE3200 ............................... 10 2.3.2. Changing the TCP/IP Settings of the Managing Computer .......................... 11 2.4. Configuring the IWE3200........................................................................................ 11 2.4.1. Entering the User Name and Password ....................................................... 11 2.4.2. SETUP WIZARD Step 1: Selecting an Operational Mode............................ 12 2.4.3. SETUP WIZARD Step 2: Configuring TCP/IP Settings ................................ 13 2.4.4. SETUP WIZARD Step 3: DHCP Server Settings ......................................... 15 2.4.5. SETUP WIZARD Step 4: Configure IEEE 802.11 Settings .......................... 15 2.4.6. Configuring User Authentication Settings ..................................................... 16 2.4.7. Configuring RADIUS Settings....................................................................... 20 2.5. Deploying the IWE3200 .......................................................................................... 21 2.6. Setting up Client Computers ................................................................................... 22 2.6.1. Configuring IEEE 802.11-Related Settings .................................................. 22 2.6.2. Configuring TCP/IP-Related Settings ........................................................... 23 2.7. Confirming the Settings of the IWE3200 and Client Computers ............................. 23 2.8. Using Web-Based Network Management........................…

Text truncated - open the document above for the full version.

Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. External Photos Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C.

<=. .::.. WirelessInternetAccessServerAppliance Model: IWE3200FCCID:PRL-IWE3200 ThisdevicecomplieswithPart15oftheFCCRulesOperation is subjecttothefollowingtwoconditions:(1)Thisdevice maynotcauseharmfulinterference,and(2)thisdevice mustacceptinterferencereceived,includinginterference thatmaycauseundesiredoperation. WirelessInternetAccess ~ ServerAppliance CE 0 6811i' ~IWE3200\..!..I DCl2V::-:lA PIN:IWE3200-S0S36P 1111111111111111111111111111 CSOPF0460001 WirelessMulti-WANRouter MadeinTaiwan --

MPE Prediction FCC Rule: 15.247(b)(5) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See §1.1307(b)(1) of this Chapter. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average time (minutes) (A)Limits For Occupational / Control Exposures 30-300 61.4 0.613 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 PG S = -------------- 4πR² where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 17.48 (dBm) Maximum peak output power at antenna input terminal: 55.9 (mW) Antenna gain(maximal): 2.0 (dBi) Prediction distance: 20 (cm) Prediction frequency: 2462 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.0 (mW/cm²) Power density at prediction frequency: 0.017826 (mW/cm²) The manual instruct the user to install and operate the device in a minimum distance of 20 cm between antenna and the users body.

ETS Dr.Genz Taiwan PS Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679 A2LA Cert.No.: 2300.01 PTCRB Accredited Type Certification Test House FCC TEST-REPORT FCC Part 15 C for IEEE 802.11 b device FCC ID: PRL-IWE3200 Test report no.: W6M20607-7205-C-1 ETS DR.GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. PHONE 886-2-66068877 FAX 886-2-66068879 Registration number: W6M20607-7205-C-1 FCC ID: PRL-IWE3200 ETS Dr.Genz Taiwan PS Co., Ltd. 1 of 33 TABLE OF CONTENTS 1GENERAL INFORMATION ..........................................................................................................2 1.1 N OTES..........................................................................................................................................2 1.2 T ESTING LABORATORY................................................................................................................3 1.2.1Location ..............................................................................................................................3 1.2.2Details of accreditation status ............................................................................................3 1.3 D ETAILS OF APPROVAL HOLDER...................................................................................................3 1.4 A PPLICATION DETAILS.................................................................................................................4 1.5 G ENERAL INFORMATION OF TEST ITEM........................................................................................4 1.6 T EST STANDARDS.........................................................................................................................5 2TECHNICAL TEST .........................................................................................................................6 2.1 S UMMARY OF TEST RESULTS........................................................................................................6 2.2 T EST ENVIRONMENT....................................................................................................................6 2.3 T ESTEQUIPMENT LIST.................................................................................................................7 2.4 G ENERAL TESTPROCEDURE........................................................................................................9 3TEST RESULTS (ENCLOSURE) ................................................................................................11 3.1 P EAKOUTPUT POWER (TRANSMITTER) ......................................................................................12 3.2 E QUIVALENT ISOTROPIC RADIATED POWER................................................................................13 3.2.1Transmitter........................................................................................................................13 3.3 RF E XPOSURE COMPLIANCE REQUIREMENTS............................................................................13 3.4 T RANSMITTER RADIATEDEMISSIONS IN RESTRICTED BANDS....................................................14 3.5 S PURIOUSEMISSIONS(TX) .........................................................................................................15 3.6 M INIMUM 6 DBBANDWIDTH.....................................................................................................18 3.7 P EAKPOWER SPECTRAL DENSITY.............................................................................................19 3.8 RADIATEDEMISSION FROM DIGITAL PARTANDRECEIVER L.O. ...............................................20 3.9 P OWER LINE CONDUCTED EMISSION.........................................................................................23 APPENDIX ..............................................................................................................................................25 A PPENDIXA...........................................................................................................................................26 A PPENDIXB...........................................................................................................................................27 A PPENDIXC...........................................................................................................................................28 A PPENDIXD...........................................................................................................................................29 A PPENDIXE ...........................................................................................................................................30 A PPENDIXF ...........................................................................................................................................31 A PPENDIXG...........................................................................................................................................32 A PPENDIXH...........................................................................................................................................33 Registration number: W6M20607-7205-C-1 FCC ID: PRL-IWE3200 ETS Dr.Genz Taiwan PS Co., Ltd. 2 of 33 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is…

Text truncated - open the document above for the full version.

ETS Dr.Genz Taiwan PS Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679 A2LA Cert.No.: 2300.01 PTCRB Accredited Type Certification Test House FCC TEST-REPORT FCC Part 15 C for IEEE 802.11 g device FCC ID: PRL-IWE3200 Test report no.: W6M20607-7205-C-2 ETS DR.GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. PHONE 886-2-66068877 FAX 886-2-66068879 Registration number: W6M20607-7205-C-2 FCC ID: PRL-IWE3200 ETS Dr.Genz Taiwan PS Co., Ltd. 1 of 33 TABLE OF CONTENTS 1 GENERAL INFORMATION ..........................................................................................................2 1.1 N OTES..........................................................................................................................................2 1.2 T ESTING LABORATORY................................................................................................................3 1.2.1Location ..............................................................................................................................3 1.2.2Details of accreditation status ............................................................................................3 1.3 D ETAILS OF APPROVAL HOLDER...................................................................................................3 1.4 A PPLICATION DETAILS.................................................................................................................4 1.5 G ENERAL INFORMATION OF TEST ITEM........................................................................................4 1.6 T EST STANDARDS.........................................................................................................................5 2TECHNICAL TEST .........................................................................................................................6 2.1 S UMMARY OF TEST RESULTS........................................................................................................6 2.2 T EST ENVIRONMENT....................................................................................................................6 2.3 T ESTEQUIPMENT LIST.................................................................................................................7 2.4 G ENERAL TESTPROCEDURE........................................................................................................9 3TEST RESULTS (ENCLOSURE) ................................................................................................11 3.1 P EAKOUTPUT POWER (TRANSMITTER) ......................................................................................12 3.2 E QUIVALENT ISOTROPIC RADIATED POWER................................................................................13 3.2.1Transmitter........................................................................................................................13 3.3 RF E XPOSURE COMPLIANCE REQUIREMENTS............................................................................13 3.4 T RANSMITTER RADIATEDEMISSIONS IN RESTRICTED BANDS....................................................14 3.5 S PURIOUSEMISSIONS(TX) .........................................................................................................15 3.6 M INIMUM 6 DBBANDWIDTH.....................................................................................................18 3.7 P EAKPOWER SPECTRAL DENSITY.............................................................................................19 3.8 RADIATEDEMISSION FROM DIGITAL PARTANDRECEIVER L.O. ...............................................20 3.9 P OWER LINE CONDUCTED EMISSION.........................................................................................23 APPENDIX ..............................................................................................................................................25 A PPENDIXA...........................................................................................................................................26 A PPENDIXB...........................................................................................................................................27 A PPENDIXC...........................................................................................................................................28 A PPENDIXD...........................................................................................................................................29 A PPENDIXE ...........................................................................................................................................30 A PPENDIXF ...........................................................................................................................................31 A PPENDIXG...........................................................................................................................................32 A PPENDIXH...........................................................................................................................................33 Registration number: W6M20607-7205-C-2 FCC ID: PRL-IWE3200 ETS Dr.Genz Taiwan PS Co., Ltd. 2 of 33 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that i…

Text truncated - open the document above for the full version.

Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Set Up Photos Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. POE mode Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Adaptor mode Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. RF mode Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. POE mode Registration number: W6M20607-7205 ETS DR. GENZ TAIWAN PS CO., LTD. 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU, TAIPEI 114, TAIWAN, R.O.C. Adaptor mode
