PT2AG1000PROAresGate 1000 Wireless Router

Published August 2001 AresGate 1000 Wireless Router User’s Installation Guide COPYRIGHT & TRADEMARKS Copyright © 2001 ARESCOM, Inc. All rights reserved. ARESCOM, ARESCOM AresGate are trademarks of ARESCOM, Inc. Microsoft and Windows 95/98/2000/NT/ Me are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. All other trademarks and registered trademarks belong to their respective companies. ARESCOM, Inc. has the right to make revisions and to change the contents of this document without any obligation to provide prior notice of such revisions and changes. ARESCOM has the right to make improvements or changes in the product(s) and/or software(s) described in this documentation. No part of this documentation or software may be reproduced or distributed in any form without prior written permission from ARESCOM, Inc. LIMITED WARRANTY ARESCOM Inc. (“ARESCOM”) warrants that its hardware products are free from defects in materials and workmanship. Subjected to the conditions and limitations set forth below, ARESCOM will, at its option, either repair or replace any part of its product(s) that prove defective by reason of improper workmanship or materials. Repaired or replacement products will be provided by the equipment provider, and will be either new or refurbished to be functionally equivalent to new. This warranty does not cover any damage to this product that results from accident, abuse, misuse, natural or personal disaster, or any unauthorized disassembly, repair, or modification. ARESCOM products are covered by this warranty for a period of one (1) year from the date of purchased. THIS WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHERS, WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. ARESCOM SPECIFICALLY DISBLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PRUPOSE AND AGAINST INFRINGEMENT. No ARESCOM dealer, agent or employee is authorized to make any modification, extension or addition to this warranty. This warranty covers only repair or replacement of defective ARESCOM products. ARESCOM is not liable for, and does not cover under warranty, any costs associated with servicing and/or the installation of ARESCOM products. 1 Table of Contents Table of ContentsTable of Contents Table of Contents 1.BEFORE YOU BEGIN Introduction ........................................................................................ 3 Product Models .................................................................................. 3 Features ............................................................................................. 3 Package Includes............................................................................... 4 Diagram of the AresGate 1000 .......................................................... 4 Application Scenarios ........................................................................ 7 2.HARDWARE INSTALLATION Setup Instructions ............................................................................ 11 Antenna Attachment ........................................................................ 11 Connect to the Ethernet ................................................................... 11 Connect the 56K Analog Modem ..................................................... 12 Connect the Analog Phone .............................................................. 13 Connect to the Power Adapter ......................................................... 13 3.CONFIGURING YOUR ROUTER Basic Configuration .......................................................................... 15 SETUP....................................................................................... 15 WIRELESS ................................................................................ 18 PPPoE ....................................................................................... 20 56K MODEM ............................................................................. 21 STATUS ..................................................................................... 22 Advanced Configuration................................................................... 24 PORT MAPPING ....................................................................... 24 IP ROUTING.............................................................................. 27 IP FILTERING............................................................................ 29 2 AresGate 1000 User’s Installation Guide UPGRADE ................................................................................. 32 4.TCP/IP PROTOCOL CONFIGURATION Installing TCP/IP in Windows® 95/98/Me ......................................... 33 Installing TCP/IP in Windows® 2000 ................................................ 35 Installing TCP/IP in Windows® NT ................................................... 36 5.TROUBLESHOOTING WAN Link LED Flashing................................................................... 38 Cannot Connect to the AresGate Router ......................................... 38 Cannot Connect to the Wireless Lan Interface ................................ 39 APPENDIX GLOSSARY ..................................................................................... 40 PRODUCT INFORMATION ............................................................. 44 FCC Statement .......................................................................... 44 FCC Part 68 Requirements ....................................................... 45 Tech Support ............................................................................. 45 BEFORE YOU BEGIN BEFORE YOU BEGIN 3 1.BEFORE YOU BEGIN 1.1 Introduction The state of the art ARESCOM AresGate™ 1000 Series Wireless Access Point router is specifically designed for the application in a variety of SOHO network environments: If you already have a high speed ADSL or Cable modem i…

Text truncated - open the document above for the full version.

AA BB CC DD EE 4 4 3 3 2 2 1 1 ARESCOM AG1000PRO BLOCK DIAGRAM Antenna PCMCIA Header/PC Card 802.11B WLAN Interface RJ45WAN RJ45LAN RJ11LINE RJ11PHONE RJ11POWERPLUG RJ11POWERSW 56K MODEMMODULE ETHERNETPHY ETHERNETPHY CLOCK20M Hz CLOCK20M Hz MOTOROLAMPC850SAR CLOCK4M Hz FLASH1MBSDRAM4MB POWERSECTION:+5V,+3.3V. USBPHY USBCONN MODEMBUZZER Internalclock:48M Hz Inter nal clock: 28.224M Hz AG1000PROARESCOM INC 11 Tuesday, August 14, 2001 BLOCK DIAGRAM B 1.1 TitleSize Document Number Rev Date: Sheet of

EUT - Front View EUT - Rear View

FCC ID Label Proposed Label Location on EUT Bottom Side of EUT FCC Warning Statement The device shall bear the following FCC statement. If the EUT is so small or for such use that it is not practicable to place the statement on it, the statement shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. However, the FCC identifier or the unique identifier, as appropriate, must be displayed on the device. “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.” Proposed FCC ID Location This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interface, and (2) this device must accept any interference received, including interference that may cause undesired operations. Caution: To comply with FCC RF exposure requirements, a separation distance of at least 8 inches (20cm) must be maintained between the antenna of this and all persons. FCC ID: PT2ND1760 FCC ID: PT2AG1000pro

EUT - Component View EUT - Solder View

AresGate 1000 WirelessLAN IP Router Product Specifications Version 2.0 Revision 1 February 9, 2001 ARESCOM, Inc. AresGate 1000 Confidential Product Specification V2.0 Revision 1 1 ARESCOM AresGate TM 1000 is an IP router with multiple LAN interface support: IEEE 802.11b Wireless LAN, Ethernet & USB (option), and multiple WAN interface options: either Ethernet or 56K analog modem. 1.0 Software Specifications 1.1 Routing • RIP1 & RIP2 and static routing • Support DHCP Server and Client on all the Ethernet, Wireless LAN and USB interface – Automatic assignment and reception of IP Address, Mask, Default Gateway, and DNS servers address to workstation (RFC 2131, RFC 2132) 1.2 Bridging • Transparent Bridging among Ethernet, Wireless LAN and USB • Bridge Filters – MAC-address based • Support up to 510 MAC learning addresses 1.3 WAN Protocol • Classical IP (RFC 1577) • PPPoE: PPP over Ethernet • PPP (RFC 1661) 1.4 Internet Access Sharing • NAT/PAT (RFC 1631) proxy supports unlimited multi-user sharing via Ethernet LAN • NAT (Network Address Translation) supports PAT (Port Address Translation) for server hosting (i.e. Web, FTP, Mail, etc.), multimedia applications (i.e., NetMeeting, CuSeeMe, ICQ, etc.), and Internet gaming (i.e. Quake, Diablo, StarCraft, etc.). • NAT supports Microsoft PPTP VPN • Auto DNS (Domain Name Server) • Support Public (registered) and Private (unregistered) IP addresses simultaneously with Static/NAT mixed mode 1.5 Security • PAP (RFC 1334), CHAP (RFC 1994), and MS-CHAP user authentication • Password control for Windows GUI, and Telnet port management • IP packet filtering Firewall • PPP username and password control • WEP (wired equivalent privacy) and user password authentication for Wireless LAN 1.6 Network Management • Web-based GUI • Wizard – Setup (LAN interface, WAN interface, PPPoE, DHCP, Password) • Status – Port link/activity status display, connect/disconnect, traffic counters, DHCP table, routing table and event log. • Advanced Management – Filtering tools, Port Mapping, Static/Dynamic routing, Firmware Upgrade (via FTP). • Command Line User Interface: Telnet access ARESCOM, Inc. AresGate 1000 Confidential Product Specification V2.0 Revision 1 2 2.0 Network Interface Specifications 2.1 WAN Interfaces • One Ethernet 10BaseT RJ-45 port (IEEE 802.3) • 56K analog modem 2.2 Wired LAN Interface • One Ethernet 10BaseT RJ-45 port (IEEE 802.3) • One USB port (Universal Serial Bus Spec. v.1.1) (Optional) 2.3 Wireless LAN Interface • IEEE 802.11b compliant • Operating in the unlicensed 2.4GHz ISM band • Operation Frequency/Channels ß North America/FCC: 2.412~2.462 GHz (11 channels) ß Japan TELEC: 2.412~2.472 GHz (14 channels) • Modulation Technique: Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK) • Media Access Protocol: CSMA/CA with ACK • Dynamic Rate Shifting: 11, 5.5, 2 and 1Mbps 3.0 Hardware Specifications 3.1 LEDs • One for POWER • One for DIAG • One for 56k modem: Link CD/Act • One for Ethernet WAN: Link/Act • One for Ethernet LAN: Link/Act • One for Wireless LAN: Link/Act • One for USB (option): Link/Act 3.2 Mechanical • Dimensions: 9.5” (w) x 6.5” (d) x 1.4” (h) • Weight: 13.5 oz. 3.3 Operating Environment • Operating temperature range: 0°C to 40°C (32°F to 104°F) • Operating humidity range: 0% to 95% non-condensing 3.4 Power (external power adapter) • Input: 100 – 240 VAC, 47-63 Hz • Output: 5VDC, 2A • Power consumption: 7 watts nominal 3.5 Compliance / Regulatory • EMI: FCC Part15 Class B & Part 15C, CE EN55022 Class B • Immunity: CE EN50082 • Safety: EN60950

Arescom INC. Part Number: 230AG1000PROMB1.1 Description : AG1000PRO Main Board Released: 08/01/2001 15:30 USA Revision: B1.1 By: Hubert Tsou NoPart NumberSpecificationLocationQtyProcessApproved Vendor List (Manufacturer / Part No) 1109000000149PCB /AresGate1000_Main Rev B1.01CAM 2101040000319CAP 0.01U /SMD 0603 16v +-10% X7RC33,C34,C38,C39,C52,C56,C607SMDPDC, TEAM YOUNG 3101040000174CAP 0.1U /SMD 0603 16v +-10% X7R C9,C10,C19,C20,C21,C22,C23,C24,C25,C26,C27 C28,C29,C30,C31,C32,C35,C36,C37,C40,C41, C42,C43,C44,C45,C46,C51,C55,C59,C61,C62, C63, C65,C66,C67,C68,C69,C70,C801 39SMDWALSIN 4102040000006CAP 10U Electrolytic /Dip 16v +-20% size=4x7mm, 105 degree C4,C8,C11,C13,C14,C15,C16,C64,C802,C80310DIPTAYEH, LUXON 5102040000024CAP 0.001U /DIP 1Kv +-10%, PPNC51DIPGOLD TRAIN 6101040000440CAP 10P /SMD 0603 16v +-5% COGC17,C182SMDPDC, TEAM YOUNG, WALSIN 7101040000357CAP 15P /SMD 0603 16v +-5% COGC47,C48,C49,C504SMDPDC, TEAM YOUNG, WALSIN 8101040000417CAP 100P /SMD 0603 16v +-5% COGC53,C54,C57,C584SMDPDC, TEAM YOUNG, WALSIN 9102040000009CAP 470U Electrolytic /Dip 16v +-20% 105 degree size:8x11mm C1,C2,C33DIPTAYEH, LUXON 10102040000030CAP 22U Electrolytic /Dip 16v +-20% 105 degree size: 4x7mm C61DIPTAYEH, LUXON 11101040000441CAP 6800P /SMD 0805 50v +-10% X7RC121SMDPDC, TEAM YOUNG, WALSIN 12102100000008LED / W:4.7 +-0.2mm H:7.3 +-0.3mm /Green /Round / Flangeless/Dip /Right Angle LD1,LD3,LD4,LD5,LD75DIP 13102100000009LED / W:4.7 +-0.2mm H:7.3 +-0.3mm /Yellow /Round / Flangeless/Dip /Right Angle LD21DIP 14102020000115CON PCMCIA HEADER w/ 4 Screws /DipCON1 1DIPLeoco Corp. / 1279STC*H0V 16102020000131 Header 10x2 H:11.7mm /pitch 2.54X2.54mm /straight/normal/male JP11DIPAmphenol 17102020000032 Header 8x2 TCD128 H:11.7mm /pitch 2.54X2.54mm /straight/normal/male JP21DIPAmphenol 18102020000001CON RJ11 50u in. (6p4c/4pin) /DipJ5,J62DIPKINSUN, FOXLINK 19102020000061CON RJ45 50u in.(8p8c/8pin) Low Profile (Shield) /DipJ2,J32DIPKINSUN, FOXLINK 20102020000003CON JACK Narrow Axis /2.0mm Power Conn /DipJ11DIPTOUKE 22101180000012IND Ferrite Bead 1U 120 ohms @100MHZ 200mA +-25% /SMD 0805 L4,L5,L63SMDMINGSTAR, STEWARD 23102180000013IND FB Ferrite Bead /DipL1,L22DIPGotop Technology / R6H-Y7-3.0 Page 1 of 3 Confidential Arescom INC. Part Number: 230AG1000PROMB1.1 Description : AG1000PRO Main Board Released: 08/01/2001 15:30 USA Revision: B1.1 By: Hubert Tsou NoPart NumberSpecificationLocationQtyProcessApproved Vendor List (Manufacturer / Part No) 24102180000002IND FB-1 Ferrite Bead /Dip 3.5x6x0.65mmL31DIPMINGSTAR, STEWARD 25101030000001RES 0 /SMD 00805 1/8w +-5%R25,R26,R120,R121,R122,R123,R124,R125, R126,R127 10SMDYAGEO,WALSIN,TEAMYANG 26101030000284RES 4.7K /SMD 0603 1/16w +-5%R6,R7,R8,R10,R11,R33,R34,R35,R40,R41,R42, R45,R46,R51,R52,R53,R56,R57,R61,R62,R63, R64,R65,R66 24SMDYAGEO,WALSIN,TEAMYANG 27101030000272RES 10K /SMD 0603 1/16w +-5%R93,R94,R1103SMDYAGEO,WALSIN,TEAMYANG 29101030000273RES 0 /SMD 0603 1/16w +-5%R9,R12,R13,R28,R29,R32,R103,R111,R8019SMDYAGEO,WALSIN,TEAMYANG 30101030000286RES 10 /SMD 0603 1/16w +-5%R14,R15,R16,R17,R18,R226SMDYAGEO,WALSIN,TEAMYANG 31101030000260RES 49.9 /SMD 0603 1/16w +-1%R38,R43,R49,R544SMDYAGEO,WALSIN,TEAMYANG 32101030000418RES 62 /SMD 0603 1/16w +-1%R36,R37,R47,R484SMDYAGEO,WALSIN,TEAMYANG 33101030000350RES 68.1 /SMD 0603 1/16w +-1%R11SMDYAGEO,WALSIN,TEAMYANG 34101030000276RES 100 /SMD 0603 1/16w +-5%R58,R59,R60,R67,R69,R72,R88,R89,R91,R95, R96,R97,R99,R100,R101,R102 16SMDYAGEO,WALSIN,TEAMYANG 35101030000351RES 115 /SMD 0603 1/16w +-1%R51SMDYAGEO,WALSIN,TEAMYANG 36101030000415RES 150 /SMD 0603 1/16w +-5%R2,R3,R43SMDYAGEO,WALSIN,TEAMYANG 37101030000275RES 1K /SMD 0603 1/16w +-5%R39,R44,R50,R55,R82,R84,R85,R908SMDYAGEO,WALSIN,TEAMYANG 39101030000417RES 330K /SMD 0603 1/16w +-5%R211SMDYAGEO,WALSIN,TEAMYANG 40101030000416RES 10M /SMD 0603 1/16w +-5%R19,R202SMDYAGEO,WALSIN,TEAMYANG 41101190000002RESP 33-B 8P 4R/Absol Res Network Size /SMD 0603RN1,RN2,RN3,RN44SMDYAGEO,WALSIN,TEAMYANG 42101190000004RESP 10K-10A 10p 8R/Common Res Network /SMD 1206RP1,RP2,RP4,RP5,RP6,RP7,RP8,RP98SMDYAGEO,WALSIN,TEAMYANG 43102110000006SWT Mini Rocker Power SwitchSW11DIPDaily Well / 4MS1R202M6QE 44101010000110IC CPU MOT850 /PBGA-256 JEDECU21BGAMotorola / XPC850SRZT50B 45101010000116IC 74LCX125 /SMD SOIC-14U181SMDFAIRCHILD, PHILIP, TI 46101010000132IC 74LCX245 /SMD TSSOP-20U17,U19,U20,U21,U23,U246SMDFAIRCHILD, PHILIP, TI 47101010000362IC 28F800C3BA110 /SMD TSOP-48 Flash memeoryU31SMDIntel / 28F800C3BA110 48101010000111IC DS1233AZ-10 /SMD SOT-223U11SMDDallas Semiconductor / DS1233AZ-10 101010000305IC V6300 O /SMD SOT-223EM Microelectronic Marin SA / V6300 O 49101010000114IC DS2401Z /SMD SOT-223U61SMDDallas Semiconductor / DS2401Z 50101010000115IC MTD214 /SMD SOJ-28 300milU11,U122SMDMyson Technology / MTD214 52101010000104IC L1084S, 5v to 3.3v Regulator /SMDQ11SMDEcenter / Niko / L1084S 53101010000331IC 74LVT273 3.3v /SMD TSSOP-20U151SMDFairchild, Philip, TI Page 2 of 3 Confidential Arescom INC. Part Number: 230AG1000PROMB1.1 Description : AG1000PRO Main Board Released: 08/01/2001 15:30 USA Revision: B1.1 By: Hubert Tsou NoPart NumberSpecificationLocationQtyProcessApproved Vendor List (Manufacturer / Part No) 101010000390IC 74LVX273 3.3v /SMD TSSOP-20SMDFairchild 101010000391IC 74LVTH273 3.3v /SMD TSSOP-20SMDTI 54102010000052IC 16PT-12D /DipU13,U142DIPYCL / 16PT-12D 55101010000109IC SDRAM 1Mx16 /SMD TSOP-50U7,U82SMDESMT / M12L16161A-7T 56101010000118IC LM386 OP /SMD MSOP-8U261SMDNational / LM386MM-1 57102250000001BUZZERBZ11DIP 58102230000009OSC 4MHZ /Half Size /Dip O/P 3.3vOSC11DIPSSP 59102170000004XTAL 32.768K T38 /Tuning Fork Size /DipY11DIPSSP 60102170000012XTAL 20M 49US /11.1X4.6/3.5 /DIPX1,X22DIPTXC Page 3 of 3 Confidential

AA BB CC DD EE 4 4 3 3 2 2 1 1 MOTOROLA MPC850 MAIN BOARD56K MODEM WLAN ARESCOM AG1000PROPCB P/N : 109000000143 Reversion History: 1. Flash Byte swap. Rev1.0 to 2.0: 2. EMI improvement in ETHERNET. Revison : B 1.1 Rev2.0 to B 1.1 : 1. Change Project name from ARESGATE 1000 to ARESGATE 1000 PRO2. Low the height of JP1 and JP2. AG1000PROARESCOM INC 19 Thursday, August 02, 2001 HEADER B 1.1 TitleSize Document Number Rev Date: Sheet of 55 44 33 22 11 D D C C B B A A 1. ADJ3. Input2. Output DNP Instead of U1 (NIKO) POWER B 1.1 AG1000PRO 29 Thursday, August 02, 2001 ARESCOM TitleSize Document Number Rev Date: Sheet of VCC5 SW_PIN1 PORESETN PORESETN P3,4 VCC3 VCC5 VCC3 VCC3 C7 OPEN(0.047uF) L1R6H-Y7-3.0 R64.7K L2R6H-Y7-3.0 + C3 470uF 16V C5 0.001uF,1KV SW1 PWR_SWITCH 123 45 123 45 Q1L1084S-ADJ3.3 1 3 2 R168.1 1%R5115 1% + C4 10uF,16V + C6 22uF 16V + C1 470uF 16V R4150 R3150 U1 DS1233A-10 1 234 GND RESETNVCCGND R2150 + C2 470uF 16V J1JACK 1 23 55 44 33 22 11 D D C C B B A A MPC850SAR B 1.1 AG1000PRO 39 Thursday, August 02, 2001 ARESCOM TitleSize Document Number Rev Date: Sheet of D0D3D6D4D5D7D10D8D13D9D11D12D15D14D16D18D21D19D17D22D25D24D20D23D30D27D28D31D29D26D2D1 D[0..31] VDDSYNTRSTNDSDODSDITMSUTO_D5UTO_D6UTO_SOCUTO_D7UTO_TXENUTO_CLKUTO_D4 PIN_PD8 UTO_D1UTO_D2UTO_RXENUTO_D3USBTXPUSBRXNETHER_CRS_0UTO_RCAVUTL_WRNUTO_TCAVPIN_P856KM_RTSETHER_T XEN_0 56KM_RI ETHER_TXEN_1 56KM_TxD56KM_RxDETHER_RD_156KM_DTR56KM_DSRETHER_RD_0ETHER_TD_0USBOENUSBRXDETHER_TD_1ID_DATADSCK IRQ7 IRQ1 IRQ0 IRQ6 BBN BGN BRN MODCK2 MODCK1 PIN_E9 PIN_D8 PIN_C10 PIN_D10 PIN_B10 PIN_E8 VFLS1 VFLS0 PIN_C9 PIN_E6 PIN_D5 EXTCLK SYSCLK_O XFC EXTAL XTAL HRESETN SRESETN RSTCONFN PORESETN PIN_D13 PIN_C14 PIN_E12 GPL2 GPL3 GPL1 GPL0 BS_AB3 BS_AB2 BS_AB1 PIN_C16 BS_AB0 PIN_D15 CS0N CS1N CS2N CS3N CS5N CS4N PIN_G16 RWN BURSTN TSN PIN_F16 PIN_B14 IRQ4 BIN TEAN IRQ2 TAN PIN_E5PIN_D4PIN_E4PIN_D3 TRSTN GPL0GPL1GPL2GPL3BS_AB0BS_AB1BS_AB2BS_AB3CS1NCS4NCS0NHRESETNSRESETNMODCK1SYSCLK XTAL UTO_D[1..7] RSTCONFN IRQ1IRQ7PORESETNBGNIRQ6BBNIRQ0CS2NCS5NCS3NBRNPIN_F16PIN_G16PIN_C16TSNBURSTNPIN_B14RWNIRQ2TEANBINTANPIN_D13PIN_E12PIN_C14IRQ4PIN_E8PIN_D5PIN_C9PIN_E6PIN_B10VFLS1PIN_C10VFLS0PIN_D8PIN_E9PIN_D10 56KM_CD PIN_D15 A20A6A31A25A26A30A17A18A21A13A15A8A11A19A29A14A27A24A7A10A28A9A16A23 A[6..31] A22A12 AA EXTALUSBRXPUSBTXN TMS EXTCLK_O SYSCLK_O SYSCLK CS3N XFC VDDSYN EXTCLK VDDSYN EXTCLK_O MODCK2 ETHER_COL_1ETHER_CRS_156KM_CTS PIN_PD15 56KM_RI UTL_AD1PIN_R13PIN_U15ETHER_COL_0 D[0..31] P4,5,7,9 UTO_SOC P8 UTO_RXEN P8 UTO_RCAV P8,9 UTL_WRN P8 UTO_TCAV P8 DSDO P9 DSDI P9 DSCK P9 ETHER_RD_0 P6 ETHER_TXEN_0 P6 ETHER_CRS_0 P6 GPL1 P4,5GPL2 P5GPL3 P5BS_AB0/IORDN P4,5,9BS_AB1/IOWRN P5,9BS_AB2/OEN P5,9BS_AB3/WEN P5,9SYSCLK P5CS4N P5,8CS0N P4,8CS1N P8SRESETN P9HRESETN P7,9GPL0 P5 UTO_D[1..7] P8 ETHER_CRS_1 P6 ETHER_TD_1 P6 PIN_D4 P8PIN_E5 P8PIN_E4 P8PIN_D3 P8 PORESETN P2,4IRQ7 P8IRQ1 P8IRQ0 P8FRZ P8,9BBN P8BRN P8CS5N P5REGN P9PIN_F16 P8RWN P4,8,9BURSTN P8PIN_B14 P8TSN P8TAN P8TEAN P8BIN P8POE_B P9BGN P8IRQ4 P8PIN_E12 P8WAIT_BN P8,9PIN_D13 P8IRQ2 P8PIN_C14 P8PIN_C9 P8IOIS16BN P8,9VFLS0 P9VFLS1 P9CD1_BN P8,9CD2_BN P8,9SPKR_BN P8,9STSCHG_BN P8,9IREQ_BN P8,9PIN_E6 P8 ID_DATA P4 A[6..31] P4,5,9 ETHER_TCLK_0 P6 ETHER_RCLK_0 P6 ETHER_COL_1 P6 ETHER_TD_0 P6 PIN_P8 P8 ETHER_RD_1 P6 UTO_CLK P8 UTO_TXEN P8 CS2N P7CE1_BN P9CE2_BN P9CS3N USBTXN P7 USBTXP P7 USBOEN P7 USBRXD P7 USBRXN P7 USBRXP P7 RESET_B P9 ETHER_RCLK_1 P6 ETHER_TCLK_1 P6 ETHER_TXEN_1 P6 56KM_CD P8 56KM_RxD P8 56KM_TxD P8 56KM_CTS P8 56KM_RI P8 56KM_RTS P8 56KM_DTR P8 56KM_DSR P8 ETHER_LINK_0 P6 ETHER_LINK_1 P6 UTL_AD1 P8 PIN_R13 P8 PIN_U15 P8 ETHER_COL_0 P6 VCC3 VCC3 VCC3 VCC3 VCC3VCC3 VCC3 VCC3 VCC3 R14 10 R1910M R2010M C1710pF R16 10 C18 10pF R17 10 OSC1 4M HZ 14 58 NCGND OUT VCC R7 4.7K L382mH C190.1uF R15 10 C100.1uF C200.1uF + C1110uF,16V R104.7K R21330K C210.1uF C126800PF\0805 C220.1uF R12 0R + C8 10uF,16V C230.1uF R13 0R C90.1uF C240.1uF MPC850 PBGA (JEDEC) PRELIMINARY PART SYMBOL 04 MAY 98 U2 N2M2K3K2M3J2G2F2N3L3L4L2N5N4K4K5J3L5J4H3H4G3J5M5G4H5F5M4G5F3E3F4D4E5 R16R15U16U15R13 P12 U12U11 T10 T8 R8 P8 T6 T17 U17R14U14 T11 R10 T9 P9 U6 P7 R7U5 T5 U4R6 T4 P6 U3R5U2 T3T2 R3R4 P5 P15 T7 U7R9U9 U10 P11 T14T15T16 R17 C7 E7 E9 D8 D10 C10 B10 E8 D9 B9 C9 D5 E6 B7 E2 C3 B6 B5 C5 C6 D6 C4 D13 C14 E12 E15 D16 D17 F14 G14 E16 F17 E17 C16 D15 E13 B15 C15 B16 C17 E14 P4 P3 P2 B11 B12 D11 C12 R12 P13 T12T13 U13 U8 K17 H2 B8B3B2B4 C2 G16 F16 D14 C11 B14 E11 B13 D12 C13 E10 C8 B17D7F15K14P10P14R2R11N14P16P17N16M14N17N15M15M16M17L15L14H14L16K16K15H15J16J14J15G15L17H17J17H16G17 F6 F7 F8 F9 F10 F11 F12 F13 G6 G13 H6 H13 J6 J13 K7 K8 K9 K10 K11 K12 L7 L8 L9 L10 L11 L12 M7 M8 M9 M10 M11 M12 E4D3D2 G7 G8 G9 G10 G11 G12 H7 H8 H9 H10 H11 H12 J7 J8 J9 J10 J11 J12 K6 K13 L6 L13 M6 M13 N6 N7 N8 N9 N10 N11 N12 N13 D0D1D2D3D4D5D6D7D8D9 D10D11D12D13D14D15D16D17D18D19D20D21D22D23D24D25D26D27D28D29D30D31 DP0/IRQ3 DP1/IRQ4 PB[30]/SPICLK/TXD3PB[29]/SPIMOSI/RXD3PB[28]/SPIMISO/BRGO3PB[27]/I2CSDA/BRG01PB[26]/I2CSCL/BRGO2PB[25]/SMTXD1/TXD3PB[24]/SMRXD1/RXD3PB[23]/SDACK1/SMSYN1PB[22]/SDACK2/SMSYN2PB[19]/L1ST1PB[18]/RTS2/L1ST2PB[17]/L1ST3PB[16]/L1RQA/L1ST4PC[15]/RXCAV/DREQ1/L1ST5PC[14]/DREQ2/RTS2/L1ST6PC[13]/L1ST7/RTS3PC[12]/TXCAV/L1RQA/L1ST8PC[11]/USBRXPPC[10]/TGATE1/USBRXNPC[9]/CTS2PC[8]/CD2/TGATE1PC[7]/USBTXPPC[6]/USBTXNPC[5]/L1TSYNCA/SDACK1/CTS3PC[4]/L1RSYNCA/CD3PD[15]/UTPB[0]PD[14]/UTPB[1]PD[13]/UTPB[2]PD[12]/UTPB[3]PD[11]/RXENBPD[10]/TXENBPD[9]/UTPCLKPD[8]PD[7]/UTPB[4]PD[6]/UTPB[5]PD[5]/UTPB[6]PD[4]/UTPB[7]PD[3]/SOCPB[31]/SPISELPA[4]/CLK4/TOUT2/TIN4PA[5]/CLK3/BRGO2/L1TCLKA/TIN2PA[6]/CLK2/TOUT1/TIN3PA[7]/CLK1/BRGO1/L1RCLKA/TIN1PA[8]/L1RXDA/SMTXD2PA[9]/L1TXDA/SMRXD2PA[12]/TXD2PA[13]/RXD2PA[14]/USBOEPA[15]/USBRXD OP3/MODCK2/DSDO OP2/MODCK1/STS IP_B7/PTR/AT3 IP_B6/DSDI/AT0 IP_B5/LWP1/VF1 IP_B4/LWP0/VF0 IP_B3/IWP2/VF2 IP_B2/IOIS16_B/AT2 IP_B1/IWP1/VFLS1 IP_B0/IWP0/VFLS0 ALE_B/DSCK/AT1 WAIT_B TEXP EXTCLK CLKOUT XFC EXTAL XTAL SRESET HRESET RSTCONF PORESET GPL_A5 UPWAITB/GPL_B4 UPWAITA/GPL_A4/AS GPL_A3/GPL_B3 GPL_A2/GPL_B2 OE/GPL_A1/GPL_B1 GPL…

Text truncated - open the document above for the full version.

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC Part 15 Subpart C EMI MEASUREMENT AND TEST REPORT For Arescom, Inc. 3541 Gateway Blvd. Fremont, CA 94538 FCC ID: PT2AG1000pro October 5, 2001 This Report Concerns: Original Report Equipment Type: AresGate 1000 Wireless Router Test Engineer: Jeff Lee Test Date: August 28, 2001 Reviewed By: John Y. Chan – Engineering Manager Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94085 Tel: (408) 732-9162 Fax: (408) 732 9164 Arescom, Inc. FCC ID: PT2AG1000pro Report # R0108152 Page 2 of 33 FCC Part 15.247 Test Report TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................................4 1.2 OBJECTIVE................................................................................................................................................................................4 1.3 TEST METHODOLOGY..............................................................................................................................................................4 1.4 TEST FACILITY.........................................................................................................................................................................4 1.5 TEST EQUIPMENT LIST............................................................................................................................................................5 1.6 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................................5 1.7 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS...............................................................................................................5 1.8 HOST SYSTEM CONFIGURATION LIST AND DETAILS..........................................................................................................6 1.9 EXTERNAL I/O CABLING LIST AND DETAILS......................................................................................................................6 2 - SYSTEM TEST CONFIGURATION AND REQUIREMENT....................................................................................7 2.1 DESCRIPTION OF TEST CONFIGURATION..............................................................................................................................7 2.2 CONFIGURATION OF TEST SYSTEM.......................................................................................................................................7 2.3 EQUIPMENT MODIFICATION...................................................................................................................................................7 3 – SUMMARY OF TEST RESULTS.......................................................................................................................................8 4 - CONDUCTED OUTPUT POWER MEASUREMENT..................................................................................................9 4.1 STANDARD APPLICABLE.........................................................................................................................................................9 4.2 MEASUREMENT PROCEDURE..................................................................................................................................................9 4.3 MEASUREMENT RESULT.........................................................................................................................................................9 4.4 TEST EQUIPMENT.....................................................................................................................................................................9 5 – 6 DB BANDWIDTH OF EMISSIONS..............................................................................................................................10 5.1 STANDARD APPLICABLE.......................................................................................................................................................10 5.2 MEASUREMENT PROCEDURE................................................................................................................................................10 5.3 MEASUREMENT DATA...........................................................................................................................................................10 6 – SPURIOUS EMISSION........................................................................................................................................................14 6.1 STANDARD APPLICABLE.......................................................................................................................................................14 6.2 MEASUREMENT PROCEDURE................................................................................................................................................14 6.3 MEASUREMENT UNCERTAINTY...........................................................................................................................................14 6.4 EUT SETUP.............................................................................................................................................................................15 6.5 SPECTRUM ANALYZER SETUP..............................................................................................................................................15 6.6 TEST PROCEDURE................................................................…

Text truncated - open the document above for the full version.

Conducted Emission Setup Photograph – Front View Conducted Emission Setup Photograph –Rear View Radiated Emission Setup Photograph – Front View Radiated Emission Setup Photograph – Rear View
