PU9USDUniversal Smart Drive

Universal Smart Drive ( U S D) 1. Introduction Incredibly easy to transfer and store data from Pc to Pc, Pc to Mac, Mac to Mac and Mac to PC. Universal Smart Drive is a small and simple plug-n-play mobile flash memory device on the Windows and Mac OS which utilizes a standard USB port. - operates as a removable hard drive on your computer. - does not require software drivers*. (for Windows 98, driver installation required) - allows for the data to be easily transferred across different OS platforms (ie. PC to Mac and vice versa) just by plugging USD into the USB port on your computer. - contains various memory capacities ranging from 16MB to 1GB. - has 2 color illumination (red and green) easily to find device status. 2. Features l No driver (installation software) required* (for Windows 98, driver installation required) l Hot Plug and Play via USB port on PC and Mac. l Cross platforms between PC and Mac and vice versa. l Supports USB 1.1 l Supports OS : Windows98/SE, Windows ME. Windows 2000, Windows XP, Mac 8.6 or higher l Capacities: 16MB/32MB/64MB/96MB/128MB/256MB/512MB/1GB l Compact, Light Weight and Durable. l 2 color illumination to indicate data transferring status Green : Device connected, Red : Data transferring l 10-years of data retention. l Accessories : Extension cable (1M), neck strap, Windows 98 installation CD, user manual and warranty card. * Installation program is required for Windows 98/SE. This program is supplied with the USD or can be downloaded from our website (www.universalsmartdrive.net). 3 . System Requirements IBM PC/AT or compatible Desktop / Notebook / Sub-Notebook / Laptop computers / Mac (Pentium @ 100MHz or better) with USB ports. 4. Driver Installation for Windows98 Windows98 SE 4.1 Before installation of the drivers, check first that the USB controller of your computer is working well. Open the “control panel” “System Properties” ”Device manager”, then check if it shows “Universal Serial Bus controllers” and see if they are in good working condition. If your computer does not have USB controller, then the USB device will not work. 4.2 Insert the supplied installation software to “CD-ROM Drive” in PC, and plug the USD into PC’s USB port. A “SB Mass storage Device” has been found and the following dialog box “Add New Hardware Wizard” will show up onto your screen. Then press “Next”. 4.3 Dialog box shows how Windows searches for the USD drivers. Choose “ Search for the best driver..” and press “Next” button. SB Mass storage Device 4.4 Dialog box shows where to locate the USD drivers. Select item “CD-ROM drive”. Press “Next” button. 4.5 Dialog box shows that Windows has located the USD driver in drive ‘D’. And press “Next” button. 4.6 Dialog box shows that Windows has finished the installation of the USD driver. Press “Finish” button. When the above steps have been successfully completed, another Controller drivers should be installed as same steps as above from 4.2 to 4.6. Now all drivers and controllers have been installed into your system. You should see the Removable Disk icon appearing in the window when you activate the “My Computer” icon. Now your are ready to easily transfer data between your USD and computer. SB Mass storage Device D:\USB_MSD.INF SB Mass Storage Device SB Mass storage Device 5. How to use ? The USD functions as a removable disk drive on your computer. When you insert the USD to the USB port of your PC or Mac, then the “removable disk” icon will appear in the “My Computer Folder”. You can use the USD the same way as a Floppy disk or a Hard drive on your computer. When you pull out the USD from the USB port, the above icon will disappear. You can find if the USD controller is installed properly by clicking onto “Control Panel” - “System Properties” - “device manager”. 6. Caution 1) When you remove the USD from the USB port, make sure that the Red illumination on the USD is not flashing. This is to ensure that files/data will not be lost. Even if the dialog box on your computer shows that the data transfer is finished. 2) In Windows ME, Windows 2000 and Windows XP, the safe procedure will be to double click on the icon located at the bottom right hand corner of your screen and to follow instructions before removing. 7. Specifications Supported OS Windows 98/SE, Windows ME, Windows 2000, Windows XP and Mac 8.6 or higher Power Supply USB Bus-powered (4.5V to 5.5V) Capacities 16MB/32MB/64MB/128MB/256MB/512MB/1 Gig Data Retention 10 years Illumination Green : device connected Red : Data receiving or transmitting Data Reading/Writing Speed Max 12Mbits/sec (depending on PC system) Operating Temperature 0°C ~ +50°C Storage Temperature -20°C ~ +80°C Dimension (LxWxH) 88mm x 25mm x 11mm Weight 16g Certification Warranty 1 year limited liability warranty 8. Warranty Disclosure Your Universal Smart Drive comes with a one year hardware warranty. We warrants the Universal Smart Drive against defects in material and workmanship. This warranty applies only to the original purchase of the Universal Smart Drive and is not transferable. This warranty does not cover any incompatibilities due to user’s computer, hardware, software or any other related system configuration in which the Universal Smart Drive interfaces. Proof of purchase will be required before any warranty consideration by us. This warranty does not apply to any failure or deficiency which has been caused by misuse, neglect, alternation, improper installation or handling, unauthorized repair or modification, improper testing, accident or causes external to the Universal Smart Drive, such as, but not limited to, excessive heat or humidity, power failure or improper installation or removal of the device. FCC NOTICE NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal- lation. This equipmen…

Text truncated - open the document above for the full version.

KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 1 of 2 External photo-Front KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 2 of 2 External photo-Rear

Korea Technology Institute Co., Ltd. Page 1 of 1 Label location

Korea Technology Institute Co., Ltd. Page 1 of 1 FCC ID Sample Label Model Number: Universal Smart Drive FCC ID : PU9USD STORMBLUE CO.,LTD. Made in Korea This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 1 of 2 Internal photo-Front KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 2 of 2 Internal photo-Rear

KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 1 of 12 Test Report Test Report No.:KTI01E-F0731 Registration No.:99058 Applicant:STORMBLUE CO.,LTD. Applicant Address:3 rd Floor 144-9 Doksan-Dong Kumchun-Gu Seoul 153-011 Korea Product:Universal Smart Drive FCC ID:PU9USDModel No.Universal Smart Drive Receipt No.:KTI20010827Date of receipt:Aug, 27, 2001 Date of Issue:Aug, 28, 2001 Testing location Korea Technology Institute Co., Ltd. 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea Test Standards:ANSI. C63.4 : 1992 Rule Parts:FCC Part 15, Subpart B Equipment Class:JBP Test Result:The above mentioned product has been tested and passed. Prepare by: J. H. LeeTested by: S. B. Kim/ EngineerApproved by: G. C. Min/ President Signature DateSignature DateSignature Date Other Aspects : Abbreviations : OK, Pass=passed Fail=failed N/A=not applicable ♠ This test report is not permitted to copy partly without our permission. ♠ This test result is dependent on only equipment to be used. ♠ This test result is based on a single evaluation of one sample of the above mentioned. ♠ This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. ♠ We certify this test report has been based on the measurement standards that is traceable to the national or international standards. KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 2 of 12  Contents  1. 2. 3. 4. 5. 6. Annex1 Annex2 Contents List of Tables List of Figures List of Photographs General Test Site 2.1 Location 2.2 List of Test and Measurement Instruments 2.3 Test Data 2.4 Test Environment Description of the tested samples 3.1 Rating and Physical characteristics 3.2 Submitted documents Measureme nt cond itio ns 4.1 Modes of operation 4.2 Additional equipments 4.3 Uncertainty 4.4 Test Setup Emission Test 5.1 Conducted Emissions 5.2 Radiated Emissions Photographs of the Test Set-up Label Photographs of EUT 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6 6 6 7 8 8 9 11 13 14~16  List of Tables Table 1 List of test and measurement equipment Table 2 Test Data. Radiated Emissions  List of Photographs Photograph 1 Setup for Conducted Emissions Photograph 2 Setup for Radiated Emissions 4 10 11 12 Korea Technology Institute Co., Ltd. Page 3 of 12 KTI01E-F0934 FCC ID : PU9USD 1. General This equipment has been show n to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by Korea Technology Institute Co., LTD. And were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site Korea Technology Institute Co., LTD 2.1 Location 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea The Test Site is in compliance with ANSI C63.4/1992 for measurement of radio Interference. Korea Technology Institute Co., Ltd. Page 4 of 12 KTI01E-F0934 FCC ID : PU9USD 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment • Conducted Emissions Kind of Equipment Type S/N Calibrated until Spectrum Analyzer R3261C 61720427 11.2001 Field Strength Meter ESPC 832827/011 4.2002 LISN ESH3-Z5 8254601019 5.2002 LISN KNW407 8-1097-7 11.2001 Pulse limiter ESH3Z2 357.8810.52 11.2001 Conducted Cable N/ A N/ A 11.2001 • Radiated Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESPC 832827/011 11.2001 Spectrum Analyzer R3261C 61720427 11.2001 Pre Amplifier 8447D 2944A06874 11.2001 KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 5 of 12 KTI01E-F0934 FCC ID : PU9USD 3. Description of the tested samples The EUT is Universal smart Drive. 3.1 Rating and Physical Characteristics Supported OS Windows 98/SE, Windows ME, Windows 2000, Windows XP and Mac 8.6 or higher Power Supply USB Bus-powered (4.5V to 5.5V) Capacities 16MB/32MB/64MB/128MB/256MB/512MB/1 Gig Data Retention 10 years Illumination Green : device connected Red : Data receiving or transmitting Data Reading/Writing Speed Max 12Mbits/sec (depending on PC system) Operating Temperature 0°C ~ +50°C Storage Temperature -20°C ~ +80°C Dimension (LxWxH) 88mm x 25mm x 11mm Weight 16g Certification Warranty 1 year limited liability warranty 3.2 Submitted Documents KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 6 of 12 KTI01E-F0934 FCC ID : PU9USD 4. Measurement Conditions Testing Input Voltage: AC 220V. 4.1 Modes of Operation The EUT was in the following operation mode during all testing; 1. Data back up in memory 2. ‘H’ pattern display 4.2 Additional Equipment DEVICE TYPE Manufacturer M/N S/N FCC ID PC COMPAQ COMPUTER CORPORATION Deskpro EXM 6F13JC8JN619 - Monitor Samsung Electronics 750S P223HVAR502035 - Keyboard COMPAQ COMPUTER CORPORATION KB-9963 B26960GBUKKOVW - Mouse logitech M-S48a None JNZ201213 Mouse SEJIN ELECTRON INC. SMB-400 0CIM004047 GJJS965M3 Printer Hewlett Packard C4569A SG78M1H0CF - 4.3 Uncertainty 1) Radiated disturbance UC (Combined standard Uncertainty) = ± 1.8dB Expanded uncertainty U=Kuc K = 2 4 U = ± 3.6dB 2) Conducted disturbance UC = ± 0.88dB U = K uc= 2 xUc = ± 1.8dB KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 7 of 12 4.4 Test setup Computer Mouse_2 Keyboard Monitor Mouse_1 Printer EUT POWER LINE KTI01E-F0934 FCC ID : PU9USD Korea Technology Institute Co., Ltd. Page 8 of 12 5. EMISSION Test 5.1 Conducted Emissions Result : Pass The line-conducted facility is located inside a 2.3M x 3.5M x 5.5M shielded closure. The shielding effectiveness of the shielded room is in accordance with MIL-Std-285 or NSA 605-05. A 1m x 1.5m wooden table 80cm. High is placed 80cm away from the vertical wall and 1.5m away from the side wall of the shielded room. R&S Model ESH3-Z5(10kHz-30MHz) …

Text truncated - open the document above for the full version.

Korea Technology Institute Co., Ltd. Page 1 of 2 6. Photograph of the Test Set-Up Photograph 1 : Setup for radiated Emissions Korea Technology Institute Co., Ltd. Page 2 of 2 Photograph 2 : Setup for Conducted Emissions
