PUC-ERX10Remote Control Transmitter

Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

[email protected] www.adt.com.tw ADVANCE DATA TECHNOLOGY CORPORATION FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) FOR THE FOLLOWING EQUIPMENT: PRODUCT NAME: BUILT-IN ELECTRIC FIREPLACE ON/OFF REMOTE CONTROL (Receiver Part) MODEL NO.: ERX10 TRADE NAME: EZESTART IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47 PART 15 REGULATION. THE RESULTS OF ELECTROMAGNETIC EMISSION EVALUATION ARE SHOWN IN THE REPORT NO.: D920318R05 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND, (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THE FOLLOWING LOCAL MANUFACTURER/IMPORTER IS RESPONSIBLE FOR THIS DECLARATION： ManufacturerUSA Local Representative Company name: TRACKING TECHNOLOGY CORP. To Be Determined. Address: 620 WEBER STREET NORTH, WATERLOO , ONTARIO CANADA Contact Person: Mark Margetts Title: Engineer Manager Tel/Fax: Tel: +1-519-883-0998 Fax: +1-519-883-0995

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Label Location

Page 3 Page 4

FCC ID: PUC-ERX10 ADT No.920318R05 Operational Description The transmitter of the EUT (BUILT-IN ELECTRIC FIREPLACE ON/OFF REMOTE CONTROL) is powered by a 12VDC battery. The transmitter uses printed antenna and designed to operate on a fixed frequency at 433.92MHz. There is one button trigger the encoder IC (IC101) which produces the digital control signals and will modulate the carrier signal. The carrier signal is generated by a SAW oscillator / Amplifier circuit then coupled to the printed antenna. This 433MHz transmitter device is operated by manual and activate time is less than 5 second after being released.

FCC ID: PUC-ERX10 Report No.: RF920318R05 1 Issued: Mar. 31, 2003 FCC TEST REPORT REPORT NO.: RF920318R05 MODEL NO.: ERX10 RECEIVED: Mar. 18, 2003 TESTED: Mar. 19 ~ Mar. 22, 2003 APPLICANT:TRACKING TECHNOLOGY CORP. ADDRESS: 602 WEBER STREET NORTH, WATERLOO, ONTARIO, CANADA ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 21 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 ILAC MRA FCC ID: PUC-ERX10 Report No.: RF920318R05 2 Issued: Mar. 31, 2003 Table of Contents 1.CERTIFICATION..............................................................................................3 2.SUMMARY OF TEST RESULTS .....................................................................4 3.GENERAL INFORMATION..............................................................................5 3.1GENERAL DESCRIPTION OF EUT ................................................................5 3.2DESCRIPTION OF TEST MODES ..................................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .................................6 3.4DESCRIPTION OF SUPPORT UNITS ............................................................6 4.RADIATED EMISSION MEASUREMENT........................................................7 4.1LIMITS OF RADIATED EMISSION MEASUREMENT .....................................7 4.2TEST INSTRUMENT .......................................................................................9 4.3TEST PROCEDURE......................................................................................10 4.4DEVIATION FROM TEST STANDARD..........................................................10 4.5TEST SETUP................................................................................................. 11 4.6EUT OPERATING CONDITION..................................................................... 11 4.7TEST RESULT...............................................................................................12 5.20dB OCCUPIED BANDWIDTH MEASUREMENT .......................................17 5.1LIMITS OF 20dB OCCUPIED BANDWIDTH MEASUREMENT.....................17 5.2TEST INSTRUMENTS...................................................................................17 5.3TEST PROCEDURES ...................................................................................17 5.4DEVIATION FROM TEST STANDARD..........................................................18 5.5TEST SETUP.................................................................................................18 5.6TEST RESULTS ............................................................................................18 6.PHOTOGRAPHS OF THE TEST CONFIGURATION ....................................20 7.INFORMATION ON THE TESTING LABORATORIES ..................................21 FCC ID: PUC-ERX10 Report No.: RF920318R05 3 Issued: Mar. 31, 2003 1. CERTIFICATION PRODUCT :BUILT-IN ELECTRIC FIREPLACE ON/OFF REMOTE CONTROL BRAND NAME :EZESTART MODEL NO : ERX10 APPLICANT :TRACKING TECHNOLOGY CORP. STANDARDS :47 CFR Part 15, Subpart C (Section 15.231), ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility from Mar. 19 ~ Mar. 22, 2003. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: PUC-ERX10 Report No.: RF920318R05 4 Issued: Mar. 31, 2003 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestN/A Power supply is 12VDC from batteries 15.209 15.231(b) Radiated Emission TestPASS Minimum passing margin is –12.1dBuV at 433.88MHz 15.231(c)20dB Occupied BandwidthPASS Meet the requirement of limit NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: PUC-ERX10 Report No.: RF920318R05 5 Issued: Mar. 31, 2003 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT BUILT-IN ELECTRIC FIREPLACE ON/OFF REMOTE CONTROL MODEL NO. ERX10 POWER SUPPLY12VDC from Battery MODULATION TYPEASK CARRIER FREQUENCY OF EACH CHANNEL 433.92 MHz BANDWIDTH OF EACH CHANNEL NA NUMBER OF CHANNEL1 ANTENNA TYPEPrinted antenna DATA CABLENA I/O PORTSNA NOTE: For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: PUC-ERX10 Report No.: RF920318R05 6 Issued: Mar. 31, 2003 3.2 DESCRIPTION OF TEST MODES One channels is provided to this EUT: ChannelFrequency 1433.92 MHz 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a BUILT-IN ELECTRIC FIREPLACE ON/OFF REMOTE CONTROL. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC 47 CFR Part 15, Subpart C. (15.231) ANSI C63.4 : 1992 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS NA FCC ID: PUC-ERX10 Report No.: RF920318R05 7 Issued: Mar. 31, 2003 4. RADIATED EMISSION MEASUREMENT 4.1 LIMITS OF RADIATED EMISSION MEASUREMENT According to 15.231 the field strength of emissions from intentional radiators operated under these frequencies bands shall not exceed the following: Field Strength of FundamentalField Strength of Spurious Fundamental Frequency (MHz)…

Text truncated - open the document above for the full version.

FCC ID: PUC-ERX10 Report No.: RF920318R05 20 Issued: Mar. 31, 2003 6. PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
