PUCTTC2001SHSecurity/ Remote Control Transmitter

Tracking Technology Corp.

Click to zoom

Application Details

Equipment Class: DSC - Part 15 Security/Remote Control Transmitter
Date of Grant: Sep 17, 2001
Application Purpose: Original Equipment
Date of Application: Sep 17, 2001
Equipment Note: Security/ Remote Control Transmitter
Frequency Range: 314.50000000 - 315.50000000
Company: Tracking Technology Corp.
Country: Canada

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

USER’S MANUAL

Block Diagram

External Photos

ID Label/Location Info

Label Drawing (M/N: ERX15-A) (M/N: RFRC10-A) (Size of 2:1) FCC ID: PUCTTC2001SH Model: EXR15-A This device complies with FCC Rules Part15. Operation of this device is subject to the following 2 conditions: (1) This device may not cause any harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID: PUCTTC2001SH Model: RFRC10-A This device complies with FCC Rules Part15. Operation of this device is subject to the following 2 conditions: (1) This device may not cause any harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

ID Label/Location Info

Internal Photos

Operational Description

Schematics

Test Report

Tracking Technology Corp. FCC ID: PUCTTC2001SH Page 1 of 27 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F01043 Prepared For : Tracking Technology Corp. 620 Weber St. N. Weterloo Ontario Canada Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F01043 Date of Test : Aug 06~Sept 01, 2001 Date of Report : Sept 03, 2001 Application for FCC Certification On behalf of Tracking Technology Corp. Radio Remote Controller Model No.: ERX15-A RFRC10-A FCC ID: PUCTTC2001SH Tracking Technology Corp. FCC ID: PUCTTC2001SH Page 2 of 27 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F01043 TABLE OF CONTENTS Page 1 GENERAL INFORMATION...................................................................................................... 4 1.1 Description of Equipment Under Test .................................................................................... 4 1.2 Description of Test Facility .................................................................................................... 5 1.3 Measurement Uncertainty ...................................................................................................... 5 2 RADIATED EMISSION TEST................................................................................................... 6 2.1 Test Equipment ...................................................................................................................... 6 2.2 Block Diagram of Test Setup .................................................................................................6 2.3 Radiated Emission Limit ........................................................................................................ 7 2.4 Test Configuration ................................................................................................................. 7 2.5 Operating Condition of EUT ..................................................................................................7 2.6 Test Procedures...................................................................................................................... 7 2.7 Test Results ........................................................................................................................... 8 3 FUNDAMENTAL AND SPURIOUS EMISSIONS TEST ....................................................... 10 3.1 Test Equipment .................................................................................................................... 10 3.2 Block Diagram of Test Setup ............................................................................................... 10 3.3 Fundamental and spurious Emission Limit ........................................................................... 10 3.4 Test Configuration ............................................................................................................... 10 3.5 Operating Condition of EUT ................................................................................................ 11 3.6 Test Procedures.................................................................................................................... 11 3.7 Test Results ......................................................................................................................... 12 4 BANDWIDTH MEASUREMENT ............................................................................................ 16 4.1 Test Equipment .................................................................................................................... 16 4.2 Bandwidth Limit .................................................................................................................. 16 4.3 Test Results ......................................................................................................................... 16 5 OPERATION DESCRIPTION ................................................................................................. 17 APPENDIX I Plot of the Pulse Train.............................................................................................. 18 APPENDIX II Plot of the Occupied Bandwidth............................................................................. 25 Tracking Technology Corp. FCC ID: PUCTTC2001SH Page 3 of 27 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F01043 TEST REPORT FOR FCC CERTIFICATION Applicant : Tracking Technology Corp. Manufacturer : Tai Cang San Hua Electrical Equipment Co. EUT Description : Radio Remote Controller (A) Model No.: (B) Serial No.: (C) Power Supply: ERX15-A 2# DC 9V RFRC10-A 2# DC 9V (D) Work Frequency: 315MHz Test Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C OCTOBER 1998 AND FCC/ANSI C63.4-1992 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. and Audix Technology (Shenzhen) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C limits. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Aug 06~Sept 01, 2001 Prepared by : Test Engineer : Stella Tang / Assistant Rain Liang / Engineer Reviewer : Approved Signatory : Byron Kwo / Supervisor Alex Chiu / Assistant Manager Tracking Technology Corp. FCC ID: PUCTTC2001SH Page 4 of 27 Audix Technology (Shanghai) Co., Ltd. Report No.ACI-F01043 1 GENERAL INFORMATION 1.1 Description…

Text truncated - open the document above for the full version.

Test Report

ATTACHMENT A DDITIONAL D ATA FOR THE A TTITUDE – S TAND Tracking Technology Corp. Radio Remote Controller Model No.: ERX15-A RFRC10-A FCC ID: PUCTTC2001SH Tracking Technology Corp. FCC ID: PUCTTC2001SH Page 1 of 4 Audix Technology (Shanghai) Co., Ltd. FUNDAMENTAL AND SPURIOUS EMISSIONS TEST (Additional Data for the Attitude – Stand) 1. Test Results <PASS> The frequency and amplitude of the highest radiated emission relative the limit is reported. All the emissions not reported below are too low against the FCC limit. EUT : Radio Remote Controller Temperature : 20.8°C Model No. : RFRC10-A Humidity : 53% Test Mode : Transmitting mode (Stand) Date of Test : Oct 30, 2001 Polarization Frequency (MHz) Antenna Factor (dB/m) Cable Loss (dB) Preamp Factor (dB) Correction factor (dB) Meter Reading dB(μV) Emission Level dB(μV/m) Limits dB(μV/m) Margin (dB) 314.943 14.65 2.59 25.27 -2.062 74.70 64.608 75.62 11.012 628.400 21.17 3.94 26.70 -2.062 50.91 47.258 55.62 8.362 936.700 24.58 4.72 26.37 -2.062 47.20 48.068 55.62 7.552 Horizontal 1259.958 26.07 3.56 35.47 -2.062 48.10 40.198 55.62 15.422 314.943 14.65 2.59 25.27 -2.062 66.80 56.708 75.62 18.912 628.490 21.17 3.94 26.70 -2.062 43.17 39.518 55.62 16.102 936.700 24.58 4.72 26.37 -2.062 40.20 41.068 55.62 14.552 Vertical 1259.958 26.07 3.56 35.47 -2.062 45.20 37.298 55.62 18.322 NOTE 1 – All readings are Peak values. NOTE 2 – Emission Level = Meter Reading + Antenna Factor + Cable Loss – Preamp Factor + Correction Factor NOTE 3 – Correction factor is calculated by averaging the sum of the pulse train. Correction Factor = 20lg (25.08/31.8) = -2.062dB TEST ENGINEER: ______________ (RAIN LIANG) Tracking Technology Corp. FCC ID: PUCTTC2001SH Page 2 of 4 Audix Technology (Shanghai) Co., Ltd. EUT : Radio Remote Controller Temperature : 20.8°C Model No. : ERX15-A Humidity : 53% Test Mode : Transmitting mode (Stand) Date of Test : Oct 30, 2001 Polarization Frequency (MHz) Antenna Factor (dB/m) Cable Loss (dB) Preamp Factor (dB) Correction factor (dB) Meter Reading dB(μV) Emission Level dB(μV/m) Limits dB(μV/m) Margin (dB) 315.013 14.65 2.59 25.27 -14.563 75.92 53.327 75.62 22.293 623.210 21.06 3.92 26.70 -14.563 45.80 29.517 55.62 26.103 932.680 24.52 4.71 26.38 -14.563 36.90 25.187 55.62 30.433 Horizontal 1250.171 26.06 3.54 35.47 -14.563 39.70 19.267 55.62 36.353 315.013 14.65 2.59 25.27 -14.563 60.72 38.127 75.62 37.493 623.210 21.06 3.92 26.70 -14.563 43.31 27.027 55.62 38.593 938.900 24.65 4.72 26.37 -14.563 50.10 38.537 55.62 17.083 Vertical 1250.171 26.06 3.54 35.47 -14.563 36.50 16.067 55.62 39.553 NOTE 1 – All readings are Peak values. NOTE 2 – Emission Level = Meter Reading + Antenna Factor + Cable Loss – Preamp Factor + Correction Factor NOTE 3 – Correction factor is calculated by averaging the sum of the pulse train. Correction Factor = 20lg (5.64/30.2) = -14.563dB TEST ENGINEER: ______________ (RAIN LIANG) Note: The resolution bandwidth used for the bandwidth test is 9kHz. Tracking Technology Corp. FCC ID: PUCTTC2001SH Page 3 of 4 Audix Technology (Shanghai) Co., Ltd. 2. Test Set-Up Photos 2.1 Radiated Emission Test (Attitude: Stand) H ORIZONTAL (M/N: ERX15-A) V ERTICAL (M/N: ERX15-A) Tracking Technology Corp. FCC ID: PUCTTC2001SH Page 4 of 4 Audix Technology (Shanghai) Co., Ltd. H ORIZONTAL (M/N: RFRC10-A) V ERTICAL (M/N: RFRC10-A)

Test Setup Photos
