PUNDTP-800Cellular CDMA WLL Phone

DTP-800/DTP-1900 Operating Manual 1 1. Introduction Thank you for purchasing this product. Please check whether the product package contains the following items. If there are missing items, please call the service center. 1. Phone 2. Power Supply(SMPS) 3. Antenna 4. Installation Panel 5. User’s Manual 6. Power Cord 7. Screws DTP-800/DTP-1900 Operating Manual 2 1.1 Installation Procedure Connect the DC jack to the back panel of phone as shown in the figure below. Connect the plug of the SMPS to a power outlet and to SMPS for the phone. Turn power on by moving the switch button to the right as shown following figure, and then the phone is initialized with power-up sound. DTP-800/DTP-1900 Operating Manual 3 Adjust the antenna direction until the maximum Antenna power sign is displayed on the LCD screen. (Each bar indicates the received signal strength. The more bars mean the higher signal strength, the better service condition.) See 2.1 Power-Up / Power-Down 1.2 Installation of the Wall Bracket Before finalizing the precise location of the phone, please perform the signal strength test to find the best location after the unit is assembled. In case of the concrete wall, make 3mm holes with a drill at the marked location and attach the Installation Panel. When install mounting screws, do not screw in all the way. Leave 2mm space between the screw head and the installed panel. On the bottom of the phone, please find the wall mounting slots(A1 ~A4). Install A1 and A2 onto the top screws. And then push the wall mounting slots A3 and A4 onto the bottom screws so that the phone is finally seated. DTP-800/DTP-1900 Operating Manual 4 1.3 Panel Overview LCDAntenna Up/Down Button STORE Button MSG/VAS & Clear Button Dial Button SND/RDL Button MicrophoneSpeaker Button Earpiece DND/MUTE & RCL Button Menu Button Figure: 1.2 - 1 DTP-800/DTP-1900 Operating Manual 5 Antenna RF ConnectorPower SwitchDC Power JackSerial Port Figure : 1.2 - 2 DTP-800/DTP-1900 Operating Manual 6 1.4 Safety Instructions Basic safety precautions should always be followed to reduce the risk when using this unit. · Read and follow all instructions marked on the product. · Do not disassemble this unit to reduce the risk of electric shock. When the unit is subsequently used, incorrect reassembly can cause electric shock. When service is required take the unit to an authorized service center. · Do not hold or contact the antenna while a call. · Do not overload the wall outlets and the extension cord. · Do not use this product near the water and never spill any liquid on the unit. This may result in the risk of fire or electric shock. · Do not place this product on unstable location (cart, stand or table). This may result in the risk of serious damage if this product may fall. · Do not cover slots and openings on the unit. This product is provided for ventilation and protection against overheating. Do not place this product near the heater or radiator where proper ventilation is not provided. · This product should be operated from the type of power source marked on the product. If you are not sure of the type of power available, consult with your dealer or local power company. · Never push objects of any kind into this product, since this may result serious voltage short. It can result in the risk of fire or electric shock. · During thunderstorms, avoid using this product. There may be a remote risk of an electric shock from lighting. · Unplug this product from the wall outlets and refer servicing to an authorized service center under the following conditions: - When the power supply plug is damaged or frayed. - If liquid has been spilled into this product. - If this product has been exposed to water or rain. - If this product does not work properly when the operating instruction are followed. - If this product has been dropped or damaged. - If this product exhibits a distinct change in performance. DTP-800/DTP-1900 Operating Manual 7 2. Before Using 2.1 Power-Up / Power-Down 2.1.1 General Power-Up Manufacturer’s logo will be displayed for 1 second when the power is turned on. The screen (figure 2.1.1-2) will be displayed with the power-up sound. f the phone receives the signal from the Service Provider, the screen displays the default date and time set by factory. (figure 2.1.1-3) 11:11 am Nov 11 (Sun) DOWTEL WIRELESS PHONE DTP-800/DTP-1900 Operating Manual 8 2.1.2 No Service If “No Service” message is appeared like the figure 2.1.2, the location where the phone is installed may be the area of which the signal from the Service Provider is not delivered to the phone. If the number of bar beside the Ant. symbol on the screen in figure 2,1,1- 3 is small, it means the received signal strength is weak. < Reference 2.3.1 RSSI Icon> In this case, adjust the direction of antenna until the number of bar is displayed as many as possible. If the condition like figure 2.1.2 is continued or the number of bar is small despite of changing the direction of antenna, please ask the service center. 2.1.3 Registration Required If “Registration Required” message is appeared like figure 2.1.3, it means this phone cannot be registered to the Service Provider. In this case, report to the Service Provider immediately. No Service Required Registration DTP-800/DTP-1900 Operating Manual 9 2.1.4 Power Two types power is used in this phone. - AC power : 100 ~ 270 V - Internal Battery If the AC power is suddenly disconnected to the phone by a power failure or any reason, the power source is automatically changed from AC power to internal battery. When the status of power switch of the phone is turned on, the phone normally works as long as you disconnect the AC power. If you don’t want the power entirely, you must turn off the power switch. DTP-800/DTP-1900 Operating Manual 10 2.2 Keypad As shown in the figure below, there are 12-Dial Button and 10-Function Button in this phone. Figure : 2.2.1 2.2.1 DND/MUTE & RCL DND/MUTE - Use this button to set on/off the [DND(Do …

Text truncated - open the document above for the full version.

Dowtelecom Inc. 4th F/L, Woosong Bldg., 361-10, Yatap-Dong, Bundang-Gu, Seongnam-Si, Gyunggi-Do, Korea Tel : +82 31 701 8962 , Fax : +82 31 701 8964 Date : August 30,2001 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality FCC ID : PUNDTP-800 In reference to the application under FCC ID: PUNDTP-800, and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Document titled " Block Diagram" Document titled " Schematics “ Document titled " Circuit Description “ Document titled " Operational Description “ Document titled " Antenna Specification “ Document titled " Part Lists “ Document titled " Tune-up Procedure “ The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Name :Seoung Chul, Ju Title : Senior Research Engineer Company : Dowtelecom Inc

Dowtelecom Inc. 4th F/L, Woosong Bldg., 361-10, Yatap-Dong, Bundang-Gu, Seongnam-Si, Gyunggi-Do, Korea Tel : +82 31 701 8962 , Fax : +82 31 701 8964 Date : August 30,2001 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality FCC ID : PUNDTP-800 In reference to the application under FCC ID: PUNDTP-800, and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Document titled " Block Diagram" Document titled " Schematics “ Document titled " Operational Description “ Document titled " Antenna Specification “ Document titled " Part Lists “ Document titled " Tune-up Procedure “ The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Name :Seoung Chul, Ju Title : Senior Research Engineer Company : Dowtelecom Inc

PROPOSED FCC ID LABEL AND LOCATION FCC ID LABEL DOWTELECOM INC. This device complies with Part 22 of FCC rules. FCC ID: PUNDTP-800

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for CELLULAR CDMAWLL TERMINAL MODEL: DTP800 FCC ID: PUNDTP-800 SEPTEMBER 12, 2001 REPORT NO: 01I0933-2 Prepared for DOWTELECOM INC. 4 TH Floor, Woosong Bldg. 361-10, Yatap-Dong Bundang-Gu, Seongnam-Si, Gyunggi-Do, Korea Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 01U0933-1 DATE: SEPT 6, 2001 FCC ID: PUNDTP-800 EUT: CELLULAR CDMA WLL TERMINAL Page 2 of 30 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Dates of Tests: SEPTEMBER 6, 2001 Report No: 01U0933-2 Test Sample is a: Pre-Production Unit Tx Frequency: 824MHz to 849MHz Rx Frequency: 869MHz to 894MHz Max. RF Output Power: 25dBm (0.316 Watt) (Conducted) RF Exposure Categories: General Population/Uncontrolled Application Type: Certification FCC Classification: Licensed Base Station for Part 22 (H) FCC Rule Part(s): § 2.1093; ET Docket 93.62 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. CCS certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). APPLICANT: DOWTELECOM INC. 4 TH Floor, Woosong Bldg. 361-10, Yatap-Dong Bundang-Gu, Seongnam-Si, Gyunggi-Do, Korea TRADE NAME: DOWTELECOM INC. MODEL: DTP800 SERIAL NUMBER: N/A (PRE-PRODUCTION) FCC ID: PUNDTP-800 CATEGORY: MOBILE DEVICE REPORT NO: 01U0933-1 DATE: SEPT 6, 2001 FCC ID: PUNDTP-800 EUT: CELLULAR CDMA WLL TERMINAL Page 3 of 30 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION.............................................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC..........5 3. DOSIMETRIC ASSESSMENT SETUP.........................................................................6 3.1. MEASUREMENT SYSTEM DIAGRAM....................................................................................................................7 3.2. SYSTEM COMPONENTS...........................................................................................................................................8 3.3. EUT ARRANGEMENT...............................................................................................................................................12 4. EUT TUNE-UP PROCEDURE......................................................................................14 5. EVALUATION PROCEDURE.......................................................................................15 5.1. SIMULATED TISSUE LIQUID PARAMETER CONFIRMATION........................................................................15 5.2. SYSTEM ACCURACY VERIFICATION..................................................................................................................15 5.3. SAR EVALUATION PROCEDURE.........................................................................................................................17 5.4. EXPOSURE LIMIT.....................................................................................................................................................18 6. RESULTS.........................................................................................................................19 7. REFERENCES................................................................................................................24 8. APPENDIX.......................................................................................................................25 8.1. EUT PHOTOS.............................................................................................................................................................25 8.2. EQUIPMENTS LIST & CALIBRATION INFO.........................................................................................................27 8.3. IEEE SCC-34/SC-2 P1528 RECOMMENDED TISSUE DIELECTRIC PARAMETERS.................................28 8.4. EQUIPMENTS CALIBRATION CERTIFICATE.....................................................................................................29 REPORT NO: 01U0933-1 DATE: SEPT 6, 2001 FCC ID: PUNDTP-800 EUT: CELLULAR CDMA WLL TERMINAL Page 4 of 30 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written…

Text truncated - open the document above for the full version.

FCC CFR47 PART 22 SUBPART H CERTIFICATION REPORT FOR CELLULAR CDMA WLL PHONE MODEL: DTP800 FCC ID: PUNDTP-800 REPORT NUMBER: 01I0933-1 ISSUE DATE: AUGUST 30, 2001 Prepared for DOWTELECOM INC. 4 TH FLOOR, WOOSONG BLDG. 361-10, YATAP-DONG, BUNDANG-GU, SEONGNAM-SI, GYUNGGI-DO, KOREA Prepared by COMPLIANCE CERTIFICATION SERVICES, INC. d.b.a. COMPLIANCE ENGINEERING SERVICES, INC. 561F Monterey Road, Morgan Hill, Ca 95037-9001 U.S.A. TEL: (408) 463-0885 FAX: (408) 463-0888 TABLE OF CONTENT PAGE NO FCC CERTIFICATION INFORMATION.....................................................................3 TEST RESULT CERTIFICATION................................................................................6 EUT DESCRIPTION........................................................................................................7 TEST FACILITY...............................................................................................................7 ACCREDITATION AND LISTING................................................................................7 MEASURING INSTRUMENT CALIBRATION...........................................................7 TEST EQUIPMENT LIST...............................................................................................8 FCC PART 15 TEST RESULTS......................................................................................9 TESTED SYSTEMS DETAILS.....................................................................................9 CONFIGURATION BLOCK DIAGRAM...................................................................10 EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION..................................10 RADIATED EMISSION..............................................................................................11 CONDUCTED EMISSION..........................................................................................12 LINE CONDUCTION PLOT.......................................................................................13 SETUP PHOTOS..........................................................................................................14 FCC PART 2 CERTIFICATION TEST RESULTS:...................................................18 SECTION 2.1046: RF POWER OUTPUT...................................................................19 SECTION 2.1047: MODULATION CHARACTERISTICS.......................................23 SECTION 2.1049: OCCUPIED BANDWIDTH..........................................................24 SECTION 2.1051: SPURIOUS EMISSION AT ANTENNA TERMINAL................26 SECTION 2.1053: FIELD STRENGTH OF SPURIOUS RADIATION.....................31 SECTION 2.1055: FREQUENCY STABILITY..........................................................34 SECTION 22.355: FREQUENCY STABILITY..........................................................34 SETUP PHOTOS..........................................................................................................35 ATTACHMENTS EUT PHOTOGRAPHS PROPOSED FCC ID LABEL FORMAT TECHINCAL DESCRIPTION & TUNE UP PROCEDURE REQUEST OF CONFIDENTIALITY LETTER INSTALLATION & SERVICE MANUAL BLOCK DIAGRAM, SCHEMATIC DIAGRAM & PART LIST Project No# 01I0933-1 Date: AUGUST 30, 2001 EUT: CELLULAR CDMAWLL PHONE FCC ID: PUNDTP-800 Page 3 of 60 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. FCC CERTIFICATION INFORMATION The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 2.1033(c)(1): Applicant: DOWTELECOM INC. 4 TH Floor, Woosong Bldg. 361-10, Yatap-Dong Bundang-Gu, Seongnam-Si, Gyunggi-Do, Korea Contact person: Mr. Seoung Chul Ju/Senior Engineer Telephone number: 482-031-701-8962 2.1033(c)(2) FCC ID: PUNDTP-800 2.1033(c)(3) Instructions/Installation Manual Refer to Attachment: Installation and Service manual. 2.1033(c)(4) Type of emissions 1M25F9W 2.1033(c)(5) Frequency Range Transmit: 824MHz to 849MHz Receive: 869MHz to 894MHz 2.1033(c)(6) Range of Operation Power < -50dBm, 0.00001WATTS. 25dBm, 0.316WATTS. See Attachment: Technical Description section 2.983(d)(3) Means for variation of operating power. 2.1033(c)(7) Maximum Power Rating 25dBm (0.316WATTS) Project No# 01I0933-1 Date: AUGUST 30, 2001 EUT: CELLULAR CDMAWLL PHONE FCC ID: PUNDTP-800 Page 4 of 60 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2.1033(c)(8) Applied voltage and currents into the final transistor elements See Attachment: Technical Description section 2.983(d)(5) DC voltage and current of final amplifying device. 2.1033(c)(9) Tune-up/Optimizations Procedure See Attachment: Technical Description section 2.983(d)(9) Tune-up procedure over the power range. 2.1033(c)(10) Complete Circuit Diagrams and Functional Diagram Functional diagram: See Attachment: Technical Description section 2.983(d)(12) Description of modulation system used. Complete circuit diagrams: See Attachment: Schematics and parts list. 2.1033(c)(10a) Means for Frequency Stabilization See Attachment: Technical Description section 2.983(d)(10) Description of frequency determining and stabilizing circuitry.. 2.1033(c)(10b) Means for Suppressing of Spurious radiation. See Attachment: Technical Description section 2.983(d)(11) Description of circuit emulated for suppression of spurious radiations. 2.1033(c)(10c) Means for Limiting Modulation. See Attachment: Technical Des…
