PW9DA5815Mass Movement Detector

e2v technologies (uk) limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v technologies plc 19 th July 2004 Radio Frequency Investigation ltd Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ Dear Sir / Madam FCC submission PW9DA5815 There is no User Manual for the 2MS as it is manufactured to the customer specifications, is automatic in its operation, and requires no user control. Yours Faithfully Samantha Ridler BEng MIEE Compliance Engineer

e2v technologies (uk) limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v technologies plc 19 th July 2004 Radio Frequency Investigation ltd Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ Dear Sir / Madam FCC submission PW9DA5815 - Confidentiality This letter is to comply with 47CFR 0.457 (d)(2) regarding confidential material. We request that the following documents within this FCC submission be confidential on the grounds that they contain proprietary information that would not normally be shared with competitors: Exhibit 4 – Block Diagram Exhibit 5 – Schematics Exhibit 12 – Operation Description Yours faithfully Samantha Ridler BEng MIEE Compliance Engineer

90.0 ±0.480.0 ±0.5 F 72.0 ±0.5 17.0 ±0.5 20.0 ±0.2 9.20 ±0.30 ASSEMBLE IN CONJUNCTION WITH LBF 5817-C21/001 REQUIREMENTS @ 20±10°C FREQUENCY:- 2448MHz TO 2452MHz SENSITIVITY:- 21.1dB TO 22.5dB CURRENT:- 3.5 ± 0.5 mA POWER:- -5dB TO +5dB TEMPERATURE:- +25 ±10°C SUPPLY:- +12 ±0.5 VOLTS SPECIFICATION 4 1 3 2 10.0±3.0 24.0±3.0 ALL DIMENSIONS IN mm UNLESS OTHERWISE STATED. IMPERIAL AND AUXILIARY DIMENSIONS IN BRACKETS. DIMENSIONS AND TOLERANCES APPLY TO THE MANUFACTURED PART INCLUDING ANY FINISH THIS DOCUMENT SPECIFIES. REMOVE ALL BURRS AND SHARP EDGES. FOR GENERAL MANUFACTURING INSTRUCTIONS SEE CP5-3-5. FOR EXPLANATION OF DRAWING TERMS AND SYMBOLS REFER TO BS:8888 OR BS:308. ©e2v technologies limited 2003. A Limited Company Registered in England No. 432014. Registered Office: 106 Waterhouse Lane, Chelmsford CM1 2QU, UK. Holding Company: e2v holdings limited. This document is supplied by e2v technologies limited on the express understanding that it is to be treated as confidential and that it may not be copied, used or disclosed to others in whole or in part for any purpose except as authorised in writing by e2v technologies limited. MACHINED FINISH (BS:1134) UNLESS OTHERWISE STATED SHOULD THIS DRAWING BE DISTRIBUTED ELECTRONICALLY, THE DATA CONTAINED MUST BE CHECKED WITHIN THE DIMENSIONAL CONSTRAINTS SHOWN BEFORE TRANSFER TO ANY FORM OF COMPUTER AIDED MANUFACTURE. THIRD ANGLE PROJECTION GENERAL TOLERANCE UNLESS OTHERWISE STATED ANGULAR ±LINEAR ± A3 5063b-2 APPROVED CHECKED DRAWN MODELLED FINISH MATERIAL SCALE SHEETOF PROJECT SAFETY OFFICER (PSO)SECURITY CLASSIFICATION 1 1 2 2 3 3 4 4 5 5 6 6 AA BB CC DD Carholme Road, Lincoln, Lincolnshire LN1 1SF United Kingdom DATE ECRREVISION DOCUMENT IDENTITY TITLE e2v technologies limited autocad a A0364D FINAL ASSEMBLY 7274809-12-03 11 1:1 D FARLEY COMMERCIAL IN CONFIDENCE

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: e2v Technologies Ltd DA5819 2.4 GHz Mass Movement Sensor To: FCC Part 15.245 Test Report Serial No: RFI/MPTE2/RP46778JD01A Supersedes Test Report Serial No: RFI/MPTE1/RP46778JD01A This Test Report Is Issued Under The Authority Of Richard Jacklin, Operations Director: pp Tested By: Steven Wong Checked By: Nigel Davison Report Copy No: PDF01 Issue Date: 04 January 2005 Test Dates: 09 November 2004 to 11 November 2004 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE2/RP46778JD01A Page 2 of 26 Issue Date: 04 January 2005 Test Of: e2v Technologies Ltd DA5819 2.4 GHz Mass Movement Sensor To: FCC Part 15.245 This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE2/RP46778JD01A Page 3 of 26 Issue Date: 04 January 2005 Test Of: e2v Technologies Ltd DA5819 2.4 GHz Mass Movement Sensor To: FCC Part 15.245 Table of Contents 1. Customer Information...................................................................................................4 2. Equipment Under Test (EUT) .......................................................................................5 3. Test Specification, Methods and Procedures.............................................................8 4. Deviations from the Test Specification .......................................................................9 5. Operation of the EUT During Testing ........................................................................10 6. Summary of Test Results ...........................................................................................11 7. Measurements, Examinations and Derived Results ................................................12 8. Measurement Methods ...............................................................................................20 9. Measurement Uncertainty ..........................................................................................23 Appendix 1. Test Equipment Used ................................................................................24 Appendix 2. Test Configuration Drawings....................................................................25 Test Report Serial No: RFI/MPTE2/RP46778JD01A Supersedes Test Report Serial No: RFI/MPTE1/RP46778JD01A RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE2/RP46778JD01A Page 4 of 26 Issue Date: 04 January 2005 Test Of: e2v Technologies Ltd DA5819 2.4 GHz Mass Movement Sensor To: FCC Part 15.245 1. Customer Information Company Name: e2v technologies Ltd Address: 106 Waterhouse Lane Chelmsford Essex CM1 2QU Contact Name: Ms Samantha Ridler RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE2/RP46778JD01A Page 5 of 26 Issue Date: 04 January 2005 Test Of: e2v Technologies Ltd DA5819 2.4 GHz Mass Movement Sensor To: FCC Part 15.245 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the customer: 2.1. Identification of Equipment Under Test (EUT) Brand Name: e2v Technologies Model Name or Number: DA5819 Unique Type Identification: 011 Serial Number: DA5819-011-041903-00006 FCC ID Number: PW9DA5815 Country of Manufacture: UK Date of Receipt: 09 November 2004 2.2. Description of EUT The equipment under test is an e2V Technologies volumetric microwave Doppler radar sensor (movement sensor) that operates at 2.45 GHz in the ISM band. The unit is intended for security/alarm applications such as the protection of the interior of a vehicle against any unauthorised entry or other domestic security alarm systems. 2.3. Modifications Incorporated In EUT During the course of testing the EUT was not modified. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE2/RP46778JD01A Page 6 of 26 Issue Date: 04 January 2005 Test Of: e2v Technologies Ltd DA5819 2.4 GHz Mass Movement Sensor To: FCC Part 15.245 2.4. Additional Information Related to Testing Power Supply Requirement: Nominal 12VDC external supply Intended Operating Environment: In Vehicle Equipment Category: Mobile Type of Unit: Transceiver Interface Ports: DC Supply/Alarm Output/Program Input interface (4 Pin) Transmit Frequency Range: n/a Single Channel Channel ID Channel Number Channel Frequency (MHz) Transmit Channels Tested: Single Channel N/A 2450 Receive Frequency Range: n/a Single Channel Channel ID Channel Number Channel Frequency (MHz) Receive Channels Tested: Single Channel N/A 2450 Occupied Bandwidth: 0.5 MHz Highest Unintentionally Generated Frequency: 2450 MHz RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE2/RP46778JD01A Page 7 of 26 Issue Date: 04 January 2005 Test Of: e2v Technologies Ltd DA5819 2.4 GHz Mass Movement Sensor To: FCC Part 15.245 2.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description: Programming Box Brand Name: None Stated Model Name or Number: None Stated Serial Number: None Stated Cable Length and Type: 165 cm, 5 pin female Connected to Port: Program Input interface via the Interface box Description: Interface Box Brand Name: None Stated Model Name or Number: None Stated Serial Number: None Stated Cable Length and Type: 24 cm, 4 pin female Connected to Port: DC Supply/Alarm Output/Program Input interface (4 Pin) RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/MPTE2/RP46778JD01A Page 8 of 26 Issue Date: 04 January 2005 Test Of: e2v Technologies Ltd DA5819 2.4 GHz Mass Movement Sensor To: FCC Part 15.245 3. Test Specification, Methods and Procedures 3.1. Test Specification Reference: FCC Part 15 Subpart C: 200…
