ARGUS 1 3 Firefighters’ Solid-State Through Smoke Vision System User’s Manual and Warranty Terms Argus 1 - Trademark licensed from Argus Industries, Inc. #e2v technologies limited 2003DAS702198AA, Issue 2 SAFETY NOTES ARGUS 1 3 THERMAL IMAGING CAMERA and CHARGER/BATTERY PACKS Please read before use This product is an aid to fire and rescue operations in smoke and darkness. It is not intended as a replacement for standard firefighting techniques. Users must ensure that all established procedures are followed. This equipment is not certified as intrinsically safe and therefore must not be operated in flammable or explosive atmospheres. Neglecting the above may result in injury or death. An auto-iris adjusts sensitivity allowing very hot scenes to be viewed. This circuitry also protects the camera from damage. To avoid damage: " The camera should be switched on before entering a fire situation and remain on until after exit. " When switched off, the camera should not be directed towards very hot objects, e.g. the sun. We recommend that it is stored in the supplied case or storage mount. WARNINGSindicate a hazard. Failure to appreciate the hazard could result in personal injury or death. Do not proceed until the hazard is understood. CAUTIONSindicate a hazard. Failure to appreciate the hazard could result in severe damage to the unit. Do not proceed until the hazard is understood. Notesprovide useful information. WARNINGS Electrical hazards Do not remove the cover of the charger, or disassemble the charger power lead or rechargeable pack. There are no user serviceable parts within the charger, charger lead or the rechargeable pack. Charger misuse The charger must only be used for the charging of rechargeable packs; do not insert any other item into the charger. The charger must not be used to charge primary cells; the charger will not accept the primary cell pack. Do not use a damaged charger. Do not attempt to charge damaged packs. Disposal The Ni-MH cells contained within the pack must be disposed of in accordance with local regulations. Do not incinerate. Do not attempt to charge damaged packs. Environmental The charger must not be subjected to water spray, rain or immersion. CAUTION The Camera and Rechargeable Battery System are despatched from e2v technologies in a safe condition. Any unauthorised modifications may compromise safety and invalidate the warranty. The Camera and Rechargeable Battery System are designed to be safe when used in accordance with the instructions provided. e2v technologies does not accept responsibility for damage or injury resulting from failure to follow the instructions provided. All matters arising which relate to the safety of products should be reported immediately, in writing, giving full details to The Product Safety Officer at e2v technologies. NOTE The Argus 1 3 BST thermal image camera contains an export-controlled component and may not be shipped to another country without the prior approval of the US Government, which should be requested from e2v technologies. Introduction ARGUS 1 3Thermal Imager The Argus 1 3 thermal imager is brought to you by e2v technologies, the world leader in through smoke vision systems. e2v technologies, with over 18 years experience in firefighters’ thermal imaging, continues to produce high quality, affordable systems designed exclusively for the fire and rescue services. Argus 1 3 uses the latest high resolution, solid-state FPA detector or microbolometer technology to provide superb quality images under the most arduous conditions while retaining the class-leading ergonomics of the previous Argus 1 systems. Through the proper use of this Argus 1 3 system, the user will be able to: .See through dense smoke and darkness. .Detect and display the relative temperatures of objects within the scene. .Locate the seat and spread of the fire. .Move swiftly in search and rescue of casualties. .See in zero visibility conditions. .Significantly improve safety and mobility. Argus 1 3 is designed to withstand the high temperatures, knocks and driving spray often encountered in the firefighting environment. 1 Argus 1 3 has also been designed with the following features: .Capture of 26 images. .Time and date. .2x zoom. .Ambient temperature measurement. .Choice of 8 colour palettes. .Spot temperature (optional). .Internal video transmitter (optional). This manual contains information covering operation of the system and operating techniques, user maintenance and care of the product, complete with a full technical specification. 2 Contents Page 1 Camera....................... 4 1.1 GETTING STARTED..................4 1.2 DISPLAY GRAPHICS..................6 1.3 OPERATING NOTES..................8 2 Standard Functions.................. 11 2.1 IMAGE CAPTURE.................. 11 2.2 ZOOM...................... 11 2.3 TIME AND DATE.................. 11 2.4 AMBIENT TEMPERATURE............... 12 3 Optional Functions.................. 13 3.1 SPOT TEMPERATURE MEASUREMENT.......... 13 3.2 TRANSMITTER................... 13 3.3 RECEIVER KITS................... 14 4 Remote Control Functions............... 16 5 Software...................... 18 6 Cleaning, Maintenance and Replacement Parts........ 26 7 Specifications.................... 29 8 Battery and Charger.................. 31 8.1 BATTERY..................... 31 8.2 BATTERY CHARGER................. 32 9 Warranty Terms................... 33 9.1 EXPRESS WARRANTY................ 33 9.2 EXCLUSIVE REMEDY................ 34 9.3 EXCLUSION OF CONSEQUENTIAL DAMAGES....... 34 3 1 Camera 1.1 GETTING STARTED .In the case with this manual you will find the camera, a pair of handles, a neckstrap, remote control, two rechargeable battery packs, battery charger with mains and DC leads, two AA battery packs, customer software and data lead. .Check that the rechargeable batteries are fully charged before use and the battery packs contain LR6 type batteries (if supplied). Open battery door and insert the battery pack …

Text truncated - open the document above for the full version.

5130A T:\Products\Cameras\Argus3\compliance\FCC\Submissions\PW9P4466-T2\Exhibit 2 - Attestation Statement\Letter_atte e2v technologies limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v holdings limited 19 th August 2003 BABT Claremont House 34 Molesey Road Walton on Thames Surrey KT12 4RQ Dear Sirs Re: FCC Submission PW9P4466-T2 – Attestation statement In accordance with BABT 735, an Attestation Statement is not required for this class of equipment. Yours faithfully, Neil R. Barker C.Eng. MIEE MIEEE MSEE Manager Compliance Engineering

5130A T:\Products\Cameras\Argus3\compliance\FCC\Submissions\PW9P4466-T2\Exhibit 13 - Cover Letters\Letter_authorisat e2v technologies limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v holdings limited 19 th August 2003 BABT Claremont House 34 Molesey Road Walton on Thames Surrey KT12 4RQ Dear Sirs We, e2v technologies limited, hereby authorize TÜV Product Service Limited, Segensworth Road, Fareham, Hampshire, United Kingdom, PO15 5RH, to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. I further certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. Section 862. This authorization expires on 19 th August 2004. Yours faithfully, Neil R. Barker C.Eng. MIEE MIEEE MSEE Manager Compliance Engineering

5130A T:\Products\Cameras\Argus3\compliance\FCC\Submissions\PW9P4466-T2\Exhibit 13 - Cover Letters\Letter_confidenti e2v technologies limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v holdings limited 19 th August 2003 BABT Claremont House 34 Molesey Road Walton on Thames Surrey KT12 4RQ Dear Sirs Re: FCC Submission PW9P4466-T2 - Confidentiality This letter is to comply with 47 CFR 0.457(d)(2) pertaining to confidential material. We request that the following documents regarding this submission for FCC ID PW9P4466-T2 be kept confidential: Exhibit 5 - Schematics The material above contains technical data pertaining only to the camera function of the equipment and not to the radio part, which is covered by the FCC ID of the radio module. This information would customarily be guarded from competitors as it discloses aspects of the design that are commercially sensitive. Yours faithfully, Neil R. Barker C.Eng. MIEE MIEEE MSEE Manager Compliance Engineering

5130A T:\Products\Cameras\Argus3\compliance\FCC\Submissions\PW9P4466-T2\Exhibit 13 - Cover Letters\Letter_Product_N e2v technologies limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v holdings limited 19 th August 2003 BABT Claremont House 34 Molesey Road Walton on Thames Surrey KT12 4RQ Dear Sirs Re: FCC Submission PW9P4466-T2 – Product Name This submission is made in respect of the radio apparatus element of this product. The product is one of a range of products known generically as Argus® 3. Some items within this submission may relate to the generic product, but are true to the individual product model. Argus® trademark licensed from Argus Industries Inc. Yours faithfully, Neil R. Barker C.Eng. MIEE MIEEE MSEE Manager Compliance Engineering

5130A T:\Products\Cameras\Argus3\compliance\FCC\Submissions\PW9P4466-T2\Exhibit 11 - RF Exposure\Letter_rf_exposu e2v technologies limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v holdings limited 19 th August 2003 BABT Claremont House 34 Molesey Road Walton on Thames Surrey KT12 4RQ Dear Sirs Re: FCC Submission PW9P4466-T2 – RF Exposure We consider that requirements for RF exposure measurements are not applicable to this equipment for the reasons stated below. 1. The maximum power stated for the radio module is 350mW (ref FCC ID : JRR24TA-901R) 2. The camera utilises a 3dB pad in the feed to the antenna to reduce antenna mismatching. This reduces the maximum power to 250mW. 3. The camera is used in a hand-held portable mode whereby it is normally operated at a distance of about 300mm from the head or trunk (see external photo, Argus_use, included in Exhibit 3). Yours faithfully, Neil R. Barker C.Eng. MIEE MIEEE MSEE Manager Compliance Engineering

5130A T:\Products\Cameras\Argus3\compliance\FCC\Submissions\PW9P4466-T2\Exhibit 13 - Cover Letters\Letter_test_repo e2v technologies limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v holdings limited 19 th August 2003 BABT Claremont House 34 Molesey Road Walton on Thames Surrey KT12 4RQ Dear Sirs Re: FCC Submission PW9P4466-T2 – Test Report This submission includes a copy of Test Report 610823r6 pertaining to PW9P4466-S-T2 as Exhibit 6. We submit that the results of this report are equally valid for this submission as the only difference is the spot temperature measurement option. Only the version with this option was tested as this represents the more complex equipment, which would thus present the worst case from an EMC aspect. Yours faithfully, Neil R. Barker C.Eng. MIEE MIEEE MSEE Manager Compliance Engineering

5130A T:\Products\Cameras\Argus3\compliance\FCC\Submissions\PW9P4466-T2\Exhibit 13 - Cover Letters\Letter_test_setup e2v technologies limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v holdings limited 19 th August 2003 BABT Claremont House 34 Molesey Road Walton on Thames Surrey KT12 4RQ Dear Sirs Re: FCC Submission PW9P4466-T2 – Test setup photographs The test setup photographs pertaining to this submission are included within the Technical Report, Exhibit 6. Yours faithfully, Neil R. Barker C.Eng. MIEE MIEEE MSEE Manager Compliance Engineering

Argus®3 Compliance Label N32050A Issue 1 Page 1 of 1 Approved B. Mistry © e2v technologies limited 2003 A Limited Company Registered in England No. 432014 Registered Office: 106 Waterhouse Lane, Chelmsford CM1 2QU, UK Holding Company: e2v holdings limited This document is supplied by e2v technologies limited on the express understanding that it is to be treated as confidential and that it may not be copied, used or disclosed to others in whole or in part for any purpose except as authorised in writing by e2v technologies limited. Printed copy will not be maintained unless distributed by Design Services INSCRIPTION: SIZE: See sample below Height: 30mm Width: 45.2mm COLOUR: Text : Black Background : White MATERIAL: Lexan(r) FR60 UL file no. E61257(r) Gauge 0.250mm NOTES: None SAMPLE: Argus® - Trademark licensed from Argus Industries, Inc. DOCUMENT AMENDMENT RECORD Issue Issue Date Change Request Reasons for Change 1 15 Aug 2003 411/7951 First Issue.

5130A T:\Products\Cameras\Argus3\compliance\FCC\Submissions\PW9P4466-T2\Exhibit 10 - Tune Up Procedure\Letter_tune e2v technologies limited Registered in England No. 432014 Registered office: 106 Waterhouse Lane Chelmsford CM1 2QU United Kingdom UK holding company: e2v holdings limited 19 th August 2003 BABT Claremont House 34 Molesey Road Walton on Thames Surrey KT12 4RQ Dear Sirs Re: FCC Submission PW9P4466-T2 – Tune-up procedure This equipment employs a radio module that is bought complete and has no set up following integration into this equipment. The radio module is already approved (FCC ID : JRR24TA-901R). This application is made because the radio module is completely integrated into the camera and employs a different antenna configuration from the one that was employed in the original FCC submission for the module. Reference should be made to the original submission for any factory tune-up of the radio module. Yours faithfully, Neil R. Barker C.Eng. MIEE MIEEE MSEE Manager Compliance Engineering

TEST REPORT FCC Part 90 Testing in support of the Application for Grant of Equipment Authorisation of the P4466/S/T2 Argus 3 Thermal Imaging Camera FCC ID: PW9P4466-S-T2 Report Number OO610823-6August 2003 TÜV Product Service Limited Segensworth Road, Fareham Hampshire, United Kingdom PO15 5RH Telephone: +44 (0) 1329 443300 Website: www.tuvps.co.uk Report Number OO610823-6Page 1 of 12 Equipment:P4466/S/T2 Argus 3 Thermal Imaging Camera FCC ID:PW9P4466-S-T2 Specification:47 CFR 90: 2002 Prepared for:E2V Technologies 106 Waterhouse Lane Chelmesford Essex CM1 2QU Manufacturer’s Representative:G Ball Approved by: C GOULD UKAS EMC Signatory Dated:21-08-03 Start of Test:23 rd June 2003 Completion of Test:23 rd June 2003 Report Distribution:E2VCopy No. 1 BABTCopy No’s. 2 & 3 Copy No: ENGINEERING STATEMENT I ATTEST: the measurements shown in this report were made in accordance with the procedures indicated, and that the emissions from this equipment were found to be within the applicable limits. I assume full responsibility for the accuracy and completeness of these measurements. On the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 2, and Part 90 of the FCC Rules under normal use and maintenance. P J Harrison Test Engineer FCC ID: PW9P4466-S-T2 Report Number OO610823-6Page 2 of 12 Table of Contents Page No STATUS...........................................................................................................................................................3 INTRODUCTION ............................................................................................................................................4 LOCATION OF TESTING............................................................................................................................... 4 TEST EQUIPMENT AND ANCILLIARIES USED FOR TEST......................................................................4 DESCRIPTION OF EQUIPMENT UNDER TEST.........................................................................................5 LIST OF PERFORMED MEASUREMENTS .................................................................................................5 RADIATED EMISSIONS ................................................................................................................................6 TEST SETUP PHOTOGRAPH ......................................................................................................................8 SYSTEM MEASUREMENT UNCERTAINTY................................................................................................9 COPYRIGHT STATEMENT ...........................................................................................................................10 FCC SITE COMPLIANCE LETTER .......................................................................................................ANNEX A FCC ID: PW9P4466-S-T2 Report Number OO610823-6Page 3 of 12 STATUS OBJECTIVETo undertake measurements to determine the Equipment Under Test's (EUT's) compliance with the specification. MANUFACTURING DESCRIPTIONThermal Imaging Camera APPLICANTE2V Technologies 106 Waterhouse Lane Chelmesford Essex CM1 2QU United Kingdom TYPE NUMBERP4466/S/T2 MANUFACTURERS MODEL NUMBERArgus 3 SERIAL NUMBER19 TEST SPECIFICATION NUMBER47 CFR Part 90: 2002 REGISTRATION NUMBERY610823 QUANTITY OF ITEMS TESTEDOne SECURITY CLASSIFICATION OF EUTUnclassified INCOMING RELEASEDeclaration of Build Status SERIAL NUMBER DATE DISPOSALHeld pending disposal REFERENCE NUMBERN/A DATEN/A START OF TEST23 rd June 2003 FINISH OF TEST23 rd June 2003 TEST ENGINEERSP J Harrison RELATED DOCUMENTSANSI C63.4 2001. Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. Public Notice DA 00-705, March 2000 FCC ID: PW9P4466-S-T2 Report Number OO610823-6Page 4 of 12 INTRODUCTION The information contained within this report is intended to show verification of compliance of the E2V Argus 3 Thermal Imaging Camera to the requirements of FCC Specification Part 90. The unit supplied for testing was a handheld P4466/S/T2 Argus 3 Thermal Imaging Camera The terminal utilizes the Microtek Electronics Inc. Minilink 2.4TA-901R module (FCC ID: JRR24TA-901R) to offer data connectivity. This report details testing carried out in accordance with: • 47 CFR Part 90. 210, Radiated Spurious Emissions LOCATION OF TESTING BABT Engineer, Phillip J Harrison, conducted all testing at the premises BABT, Segensworth Road, Fareham, Hampshire, PO15 5RH. Radiated Emissions measurements were performed in a 3 metre Anechoic Chamber. A complete site description is on file with the FCC Laboratory Division, Registration Number: 90987. See Annex A. TEST EQUIPMENT AND ANCILLARIES USED FOR TEST InstrumentManufacturerType NoEMC NoCal to Screened EnclosureSiemensEAC 543002533TU Turntable & ControllerHD GmbHHD 0502528TU Antenna MastEmco10512182TU Antenna Mast ControllerEmco10502090TU Test ReceiverHewlett Packard8542E228613 Dec 03 Bilog AntennaChaseCBL 6143286011 Apr 04 Spectrum AnalyserHewlett Packard8562A228205 Apr 04 Horn (1 - 18GHz)EMCO3115239729 Jun 03 Horn (18 – 40GHz)Advanced MicrotekAM180HA-K-TU2294520 May 04 Bandpass FilterRLL ElectronicsF100-4000-S-R1081TU Signal GeneratorHewlett Packard8672A41126 Feb 04 Low Noise Amplifier (1 - 8GHz)MiteqAMF-3D-001080-18-13P2457TU Low Noise Amplifier (8 - 18GHz)AvantekAWT 180361081TU Low Noise Amplifier (18 - 26GHz) AvantekAMT-26177-332072TU Attenuator 10dBMarconi6534/31494 Attenuator 3dBHewlett Packard8491B15108TU BarometerDiplex-1938TU HygrometerRotronicA1INV406628 Nov 03 Table 1 Note(s) 1)All items are calibrated annually except where labelled TU (Traceability Unscheduled). These items are calibrated within the test configurations using calibrated equipment. FCC ID: PW9P4466-S-T2 Report Number OO610823-6Page 5 of 12 DESCRIPTION OF EQUIPMENT UNDER TEST The P4466/S/T2 Argus…
