PXITR-G1202Dual Band GSM Cellular Phone

Sony Ericsson Mobile Communications Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Dec 08, 2002
Application Purpose: Original Equipment
Date of Application: Dec 08, 2002
Equipment Note: Dual Band GSM Cellular Phone
Frequency Range: 1850.20000000 - 1909.80000000
Company: Sony Ericsson Mobile Communications Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Mobile Phone T316 1 ContentsGetting started 3Make and receive the first call.Getting to know your phone 6Key functions, quick keys, entering letters and characters.Personalizing your phone 14Choose ring signal, theme and other settings.Calling 23Use the phone book, call options.Setting up mobile Internet 34Set up WAP and e-mail.Messaging 40Chat, e-mail, text and pictures.Using mobile Internet 47WAP browser, bookmarks. More features 51Data, events, alarm clock, stopwatch, timer, games.Security 55SIM card lock, phone lock.Troubleshooting 56Why doesn’t the phone work the way I want?Additional information 59Sony Ericsson Consumer web site, safe and efficient use, warranty, declaration of conformity.Icons 69What do the icons mean?Index 73 2 Sony EricssonFirst edition (September 2002)This manual is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.© 2002 Sony Ericsson Mobile Communications AB All rights reserved.Publication number: AE/LZT 123 1 7 15 P1A Please note:Some of the services in this manual are not supported by all networks. This also applies to the GSM International Emergency Number 112 . Please contact your network operator or service provider if you are not sure whether you can use a particular service or not. Please read the Guidelines for safe and efficient use and the Limited warranty chapters before you use your mobile phone.The marble logo is a trademark of Sony Ericsson Mobile Communications AB. Sony is a trademark of Sony Corporation and Ericsson is a trademark of Telefonaktiebolaget L M Ericsson.T9™ Text Input is a trademark or a registered trademark of Tegic Communications.T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide. Getting started 3 Getting startedAbout this user’s guideFor ease of reference, the “Getting to know your phone” chapter gives a quick overview of the main functions of the phone, shortcuts and general information. More information and downloads are available at www.SonyEricsson.com/ or wap.SonyEricsson.com/ . Available servicesSome services and functions described in this user’s guide are network- or subscription-dependent. Because of this, some menus may not be available in your phone. This symbol indicates that a service or function is network or subscription-dependent. Please consult your network operator for more information about your subscription. The SIM cardWhen you register as a subscriber with a network operator, you get a SIM (Subscriber Identity Module) card. The SIM card contains a computer chip that keeps track of your phone number, the services included in your subscription, and your phone book information, among other things.Tip: Check if your information is saved to the SIM card before you remove it from another phone. For example, phone book entries may be saved in the phone memory.AssemblyBefore you can use your phone you need to: • Insert the SIM card.• Attach and charge the battery. See “SIM card and battery information” on page 4.Note: Always turn off the phone and detach the charger before you insert or remove a SIM card. 4 Getting st arted SIM card an d battery informati on It may take up t o 30 minut es before an i con appears when charg ing. 1. Insert th e S IM car d. M ake sure th e SIM card is placed und er the silvery holders. 2. Place the ba ttery on t he ba ck of the pho ne with the conne ctors fa cing each other. 3. Place the ba ck cover into the bottom of t he phone an d push the top until it clicks into place. 4. Co nne ct the ch arger to the phon e a t th e fl ash s ymbol. The fl ash symbol on the cha rger pl ug m ust face upw ard s. 5. It may t ake up to 30 minut es be for e the ba ttery charging icon ap pears i n the di splay. 6. Wait ap prox imately 4 hours or un til the icon indicates that the bat tery is fully ch arged. If yo u do not see the battery i con a fter this time, press a ny ke y or t he joystick to activate th e d isplay. 7. Re move the ch arger by tilting t he plug upwards. Note : You ha ve to insert the SIM card and char ge the bat tery before yo u can use the ph one . ≈ 30 mi n. ≈ 4 h . Getting started 5 Making and receiving callsTo turn on the phone • Press and hold NO until you hear a tone. • Enter your PIN (Personal Identity Number), if you have one for your SIM card.Your PIN is provided by your network operator.If you make a mistake while entering your PIN, delete the wrong number by pressing . If your PIN starts with the same digits as an emergency number, for example 911, the digits are not hidden with an * when you enter them. This is so that you can see and call an emergency number without entering a PIN. See “Emergency calls” on page 24 for more information.Note: If you enter the wrong PIN three times in a row, the SIM card is blocked and the message PIN blocked appears. To unblock it, you need to enter your PUK (Personal Unblocking Key). Your PUK is provided by your network operator.To make and receive calls • Enter the area code and phone number, and press YES to make the call . • Press NO to end the call. • When the phone rings, press YES to answer the call. On/off My Network 12:18 Welcome PIN: 6 Getting to know your phone Getting to know your phoneKey functions Vo l u m e key Increase/decrease the earpiece volume during a call. Scroll through menus, lists and text. Enter the Status menu in standby. Slide …

Text truncated - open the document above for the full version.

Users Manual

LZT 123 4598/29 R1 Important InformationTHIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.This mobile phone model T316 has been designed to comply with applicable safety requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed to not exceed the limits for exposure to radio freque ncy (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These limits establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by international scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a safety margin designed to assure the safety of all persons, regardless of age and health.The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.* Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to us e only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (i.e., at the ear and worn on the body) as re quired by the FCC for each model. The highest SAR value as reported to the FCC for this model phone when tested for use at the ear is 0.75 W/kg and when worn on the body is 0.61 W/kg. Body worn measurements are made while the phone is in use and worn on the body with an Ericsson or Sony Ericsson accessory. Accessories can significantly affect SAR compliance. The Federal Communication Commission requires that some manufacturers' accessories be tested, and Sony Ericsson has done so with respect to its products. Sony Ericsson has only tested Ericsson and Sony Ericsson original accessories in conjunction with Sony Ericsson phones. It is therefore recommended that only Ericsson and Sony Ericsson original accessories be used in conjunction with Sony Ericsson phones. The FCC has granted an Equipment Authorizat ion for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR levels of various phones, all mobile phones granted an FCC equipment authorization meet the government requirement for safe exposure. SAR information on this model phone is on file with the FCC and can be found under the Display Grant sectio n of http://www.fcc.gov/oet/fccid after searching on FCC ID PXITR-G1202. Additional information on Specific Absorption Rates (SAR ) can be found on the Cellular Telecommunications & Internet Associ ation (CTIA) web-site at http:// phonefacts.net/ . * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The standard incorporates a margin of safety to give additional protection for the public and to account for any variations in measurements.

Cover Letter(s)

Sony Ericsson Mobile Communications (USA) Inc. 7001 Development Drive RTP, North Carolina 27709 November 18, 2002 American TCB, Inc 6731 Whittier Ave McLean, VA 22101 Subject:FCC Certification for FCC ID: PXITR-G1202 Model: T316 To Whom It May Concern: This letter is in request of certification for the above mentioned FCC Identifier. This mobile is designed for use in Cellular and PCS bands of North American GSM systems. The transceiver operates in the 800 MHz Domestic Public Cellular Radiotelephone Communications Services per Part 22 and in the 1900 MHz Domestic Public Cellular Radiotelephone Communications Services per Part 24. This product contains DCS 1800 capability. DCS 1800(European) system is not used nor operational in North America. Sony Ericsson Inc. requests confidentiality under 47 CFR 0.459 for the following exhibits listed: Exhibit 4Block diagrams Exhibit 5Schematics Exhibit 10Parts list/tune-up procedure Exhibit 12Operational description This request is in order to protect Sony Ericsson’s proprietary techniques. Sincerely, Pierre A. Chery Technical Manager Certification & Type ApprovalTel No:(919) 472-1697 Research Triangle Park, NCFax No:(919) 472-6382

Cover Letter(s)

Sony Ericsson Mobile Communications (USA) Inc. 7001 Development Drive RTP, North Carolina 27709 February 11, 2003 American Telecommunications Certification Body Inc. 6731 Whittier Ave McLean, VA 22101 Attention: Equipment Authorization Branch Subject: Response to FCC Comments for FCC ID: PXITR-G0702 Reference: Sony Ericsson Model T306 Dear Mr. Graff: The attached pages contain responses to FCC comments concerning application for FCC certification of Sony Ericsson model T306 bearing FCC ID: PXITR-G0702. Please note that these responses are equally valid for model T316 bearing FCC ID: PXITR-G1202. If you have any questions and/or comments, please don’t hesitate to make contact. Sincerely, Pierre Chery Technical Manager, Type Approval Research Triangle Park, NC Tel No: (919) 472-1697 Fax No:(919) 472-6382 [email protected] Sony Ericsson Mobile Communications (USA) Inc. 7001 Development Drive RTP, North Carolina 27709 Request for additional information – Dated 01/02/03 from FCC Martin Perrine > To: William Graff > From: Martin Perrine > [email protected] > FCC Equipment Authorization Branch > > Re: FCC ID: PXITR-G0702 > > Applicant: Sony Ericsson Mobile Communications Inc. > > Date of Original Email: 01/02/2003 > > Subject: Request for additional information > > In regards to your recent TCB grant referenced above we kindly request > that you provide the following additional information. > 1) Explanation of reference level in and details of setup for Occupied BW plots. Plots suggests a maximum power of approximately 20 dBm. Other documents suggests power of 29.2, and 30.1 dBm for 800 and 1900 MHZ respectively. The test lab forgot to account for a 10dB pad in the RF path. This was the reason for the discrepancy. Please see attached updated bandwidth plots. > 2) Clarification of the use of "SAR manual insert" under EAS exhibit 8. This statement could not be located in the user manual. Also, body-worn accessory language in the statement is not acceptable. It could be easily understood by a user to mean all SE accessories can be used. The language in the full user manual exhibit is acceptable for a body-worn statement. Page 62 of user manual(EAS exhibit 8) states “ A separate leaflet with SAR information for this mobile phone model is included with the material that comes with this mobile phone”. The included SAR leaflet is based on CTIA requirements. The SAR insert text language(including body-worn) is as suggested by CTIA and has been in use for a few years. > > 3) Confirmation that tested body-worn accessories contain no metal > parts. Grant comments suggests this. Please revise grant comment > accordingly. Based on Supplement C(edition 01-01) to OET Bulleting 65, grant comment need not specifically address body-worn accessories metallic content or body separation distance for SAR tested accessories. Page 41 calls out examples of text and “1. For a product that has the potential to be used in a body worn configuration and has been tested Sony Ericsson Mobile Communications (USA) Inc. 7001 Development Drive RTP, North Carolina 27709 and certified with specific accessory device(s):” The text to used is “For body worn operation, this phone has been tested and meets the FCC RF ... use of other other accessories may not ensure compliance with FCC RF guidelines”. Sony Ericsson therefore recommend the body worn statement on the grant be worded as similar to earlier certified products, where the text used was “...SAR compliance for body-worn operating configuration is limited to the specific belt-clips/holsters/accessories tested for this filing...” See for example FCC ID: AXATR-413-A2.

Cover Letter(s)

dward From: Chery, Pierre A [[email protected]] Sent: Wednesday, April 23, 2003 6:09 AM To: [email protected]; [email protected] Cc: Bowen, Patrick L; Chery, Pierre A Subject: RE: PXITR-G1202 comments from FCC Page 1 of 2Message 4/23/2003 Hey Dennis, The attached were answered some time ago, see attached correspondences. Item 4 I haven't seen before. Item 4 /// The reason for the change in ID is that the customers did not want to have the same FCC ID, otherwise all aspects are the same. Filed exhibits are also the same. Any questions don't hesitate. Regards, Pierre -----Original Message----- From: dward [mailto:[email protected]] Sent: Tuesday, April 22, 2003 3:50 PM To: Chery, Pierre A Cc: Bowen, Patrick L Subject: PXITR-G1202 comments from FCC HI Pierre / Patrick Can you believe it? The FCC still has some questions dating from Feb. Please respond to these questions as soon as possible. As soon as you provide the answers I can upload them to the FCC site. Thanks Dennis From FCC To: William Graff [email protected] From: Martin Perrine [email protected] FCC Equipment Authorization Branch Re: FCC ID: PXITR-G1202 Applicant: Sony Ericsson Mobile Communications Inc. Correspondence Number: 6419 731 Confirmation Number: TC680429 Date of Original E-Mail: 01/03/2003 Subject: Request for additional information In regards to your recent TCB grant referenced above we kindly request that you provide the following additional information. 1) Explanation of reference level in and details of setup for Occupied BW plots. Plots suggests a maximum power of approximately 20 dBm. Other documents suggests power of 29.x, and 30.x dBm for 800 and 1900 MHZ respectively. 2) Clarification of the use of "SAR manual insert" under EAS exhibit 8. This statement could not be located in the user manual. Also, body-worn accessory language in the statement is not acceptable. It could be easily understood by a user to mean all SE accessories can be used. The language in the full user manual exhibit is acceptable for a body-worn statement. 3) Confirmation that no accessory covers mentioned on page 59 of 77 of the user manual contain metallic components/paint. 4) Strong justification for duplication of results for EMC and SAR results with FCC ID PXITR-G0702 recently granted. Provide justification that FCC IDs are identical equipment. The same serial numbers were used for testing under both grants. Retest as appropriate. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal pursuant to Section 2.917(c). DO NOT Reply to this email by using the Reply button. In order for your response to be processed expeditiously, you must upload your response via the Internet at www.fcc.gov, E-Filing, OET TCB Electronic Filing, TCB Login, Submit Correspondence. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Page 2 of 2Message 4/23/2003

External Photos

APPLICANT:FCC ID: SONY ERICSSON MOBILE COMMUNICATIONS INCPXITR-G1202 © 2002 Sony Ericsson Mobile Communications Inc. APPLICANT:FCC ID: SONY ERICSSON MOBILE COMMUNICATIONS INCPXITR-G1202 © 2002 Sony Ericsson Mobile Communications Inc. APPLICANT:FCC ID: SONY ERICSSON MOBILE COMMUNICATIONS INCPXITR-G1202 © 2002 Sony Ericsson Mobile Communications Inc.

ID Label/Location Info

Internal Photos

RF Exposure Info

REPORT 1 (14) Prepared (also subject responsible if other)No. SEM/CV/PF/P Dulce Altabella EUS/CV/R-01:1061/REP ApprovedChecked SEM/CV/PF/P Dulce AltabellaDA2002-2-07B U:\FCC Submittals\Fcc_G1202 (T316)\XHIBIT11\Source\SAR Meas Spec.doc EN SAR Measurement Specification of Wireless Handsets Contents 1Introduction...........................................................................................................................................................2 2References.............................................................................................................................................................2 3Physical quantities, units and constants................................................................................................................3 4Definitions............................................................................................................................................................4 5Measurement system.............................................................................................................................................4 5.1General............................................................................................................................................................4 5.2Phantom...........................................................................................................................................................4 5.3SAR measurement equipment.........................................................................................................................5 5.4Scanning system..............................................................................................................................................5 5.5Wireless device holder.....................................................................................................................................5 5.6Other equipment..............................................................................................................................................5 6Protocol for SAR assessment................................................................................................................................6 6.1Measurement preparation................................................................................................................................6 6.2Tests to be performed......................................................................................................................................6 6.3Measurement procedure...................................................................................................................................6 6.4Post processing................................................................................................................................................6 7Measurement uncertainty......................................................................................................................................6 Annex A. Tissue simulating material preparation.........................................................................................................8 A.1Preparation of liquid........................................................................................................................................8 A.2Preparation procedure......................................................................................................................................9 A.3Tissue liquid maintenance.............................................................................................................................10 Annex B. Dielectric property measurements..............................................................................................................10 B.1Equipment......................................................................................................................................................10 B.2Procedure for testing brain simulating liquid.................................................................................................10 B.3Dielectric parameters.....................................................................................................................................11 Annex CSAR measurement protocol....................................................................................................................11 C.1Peak spatial-average SAR assessment...........................................................................................................11 C.2SAR measurement procedure........................................................................................................................12 C.2.1Initial setup.........................................................................................................................................12 C.2.2Measurement procedure......................................................................................................................13 C.2.3Post measurement procedure..............................................................................................................13 Annex D. Measurement system validation.................................................................................................................13 REPORT 2 (14) Prepared (also subject responsible if other)No. SEM/CV/PF/P Dulce Altabella EUS/CV/R-01:1061/REP ApprovedChecked SEM/CV/PF/P Dulce AltabellaDA2002-2-07B U:\FCC Submittals\Fcc_G1202 (T316)\XHIBIT11\Source\SAR Meas Spec.doc EN 1. Introduction and Scope It is our policy that all RF transmitting products shall comply with existing recommendations, standards and regulations on human exposure to electromagnetic fields. In the reference section below, the most important RF safety guidelines are listed [4-11]. If no national standard or regulation is available in a country, the international recommendation from ICNIRP [4] sh…

Text truncated - open the document above for the full version.

RF Exposure Info

APPLICANT: Sony Ericsson Mobile Communications Inc. FCC ID: PXITR-G1202 REPORT 1(67) Prepared (also subject responsible if other)No. SEM/CV/PF/P Dulce Altabella SEM/CB/D-02:0419/REP ApprovedChecked SEM/CV/PF/P Dulce AltabellaDAC U:\FCC Submittals\Fcc_G1202 (T316)\XHIBIT11\Source\SAR report.doc E E E x x h h i i b b i i t t 1 1 1 1 Exhibit 11: SAR Test Report of Portable Cellular Phone FCC ID: PXITR-G1202 model: T316 Date of test: Date of Report: November 15, 2002 October 21, 2002 Laboratory: SAR Testing Laboratory Sony Ericsson Mobile Communications, Inc. 7001 Dev…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jasen Kolev(GSM Type Approval)

[email protected]919-472-6631Fax: 919-472-1380

Technical Contact

Sony Ericsson Mobile Communications (USA) IncPierre A Chery

[email protected]919 472 1697

7001 Development Drive · Research Triangle Park, North Carolina · United States

Non-Technical Contact

Sony Ericsson Mobile Communications (USA) IncPierre A Chery

[email protected]919 472 1697

Test Firm

Intertek Testing ServicesDavid Schramm

[email protected]678-775-2400Fax: 678-775-2401

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	660.00 mW	255KGXW	2.5 ppm

Confidentiality

Long Term

Grant Notes

Power Output is ERP for Part 22 and EIRP for Part 24. SAR compliance for body worn operating configuration is limited to the specific belt-clips/holsters/accessories tested for in this filing and must provide at least 7mm separation between the device and the users body. Users must be informed of the body worn reqirements for satisfying RF exposure compliance. The highest reported SAR values are: Head: 0.75W/kg; Body-worn 0.61W/kg. This device contains DCS1800 MHz functions that are not operational in U.S. Territories. This filing is only applicable for GSM800 MHz Part 22 and GSM1900 MHz PCS operations.
