PXTPFD-01Integrity Pendant FD

Daviscomms Confidential Daviscomms Organization Chart Pendant FD User Guide Freedom to live life your way Medical Alert Systems providingIndependence and peace of mind. Daviscomms Confidential Daviscomms Organization Chart Pendant FD User Guide Freedom to live life your way How Pendant FD works 1. Press the emergency button of pendant FD. 2. Your information and location are sent to the Emergency Operators. 3. Emergency operators establishes two-ways communication and assesses the situation. 4. Emergency operator contacts a neighbor, family member or emergency services based on specific need. Use Case 1 : EMERGENCY BUTTON press Daviscomms Confidential Daviscomms Organization Chart Pendant FD User Guide Freedom to live life your way Use Case 2 : Fall DetectionWhen you experience a fall in the shower or car par k anywhere you are out of reach of a cell phone, pe ndant FD can send the signal for help in faster. Fall detect with and without cancellation 1. If you experience a fall , pendant FD waits twent y seconds to confirm that the user did not get back up. Pendant FD broadcasts Fall Detect RF signal. If no cancellatio n is received after twenty seconds, pendant FD will establish full alarm. The alarm is sent to Emergency Operators. Em ergency operator will assist based on specific need . 2. If you experience a fall , pendant FD waits twe nty seconds to confirm that the user did not get ba ck up. Pendant FD broadcasts Fall Detect RF signal. If you presses and holds the Pendant for five seconds, the LED wi ll be turn off and the alarm will be cancelled. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Test Report Report No. : EP350715 SPORTON International Inc. PAGE NUMBER : B1 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Jun. 17, 2013 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT FCC Test Report Report No. : EP350715 SPORTON International Inc. PAGE NUMBER : B2 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Jun. 17, 2013 FAX : 886-3-327-0973

FCC Test Report Report No. : EP350715 SPORTON International Inc. PAGE NUMBER : B2 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Jun. 17, 2013 FAX : 886-3-327-0973 FCC Test Report Report No. : EP350715 SPORTON International Inc. PAGE NUMBER : B3 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Jun. 17, 2013 FAX : 886-3-327-0973 FCC Test Report Report No. : EP350715 SPORTON International Inc. PAGE NUMBER : B4 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Jun. 17, 2013 FAX : 886-3-327-0973 RF Module FCC Test Report Report No. : EP350715 SPORTON International Inc. PAGE NUMBER : B5 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Jun. 17, 2013 FAX : 886-3-327-0973 FCC Test Report Report No. : EP350715 SPORTON International Inc. PAGE NUMBER : B6 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Jun. 17, 2013 FAX : 886-3-327-0973 RF Antenna

FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : 1 of 26 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Equipment : Integrity Pendant FD Brand Name : MobileHelp Model No. : PFD-01 FCC ID : PXTPFD-01 Standard : 47 CFR FCC Part 15.231 Operating Band : 433.92 MHz Operation : Manually operated within 5 sec FCC Classification : DSC Applicant : Integrity Tracking LLC, dba MobileHelp 3701 FAU Blvd., Suite 300, Boca Raton FL 33431, USA Manufacturer : Daviscomms (Malaysia) Sdn Bhd Plot 18, Lorong Perusahaan Maju 1, Kawasan, Perusahaan Perai 4, 13600 Perai, Malaysia The product sample received on May 08, 2013 and completely tested on May 27, 2013. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Wayne Hsu / Assistant Manager FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : 2 of 26 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Table of Contents 1 GENERAL DESCRIPTION ............................................................................................................... 5 1.1 Information ........................................................................................................................................ 5 1.2 Testing Applied Standards ................................................................................................................ 7 1.3 Testing Location Information ............................................................................................................. 7 1.4 Measurement Uncertainty ................................................................................................................. 8 2 TEST CONFIGURATION OF EUT .................................................................................................... 9 2.1 The Worst Case Modulation Configuration ........................................................................................ 9 2.2 Test Channel Frequencies Configuration ........................................................................................... 9 2.3 The Worst Case Measurement Configuration .................................................................................... 9 2.4 Test Setup Diagram ........................................................................................................................ 10 3 TRANSMITTER TEST RESULT ..................................................................................................... 11 3.1 AC Power-line Conducted Emissions .............................................................................................. 11 3.2 Emission Bandwidth ........................................................................................................................ 13 3.3 Fundamental Emissions .................................................................................................................. 15 3.4 Transmitter Radiated Unwanted Emissions ..................................................................................... 17 3.5 Operation Restriction ...................................................................................................................... 23 4 TEST EQUIPMENT AND CALIBRATION DATA ............................................................................. 25 APPENDIX A. TEST PHOTOS APPENDIX B. PHOTOGRAPHS OF EUT FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : 3 of 26 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna Requirement Antenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions - FCC 15.207 N/A 3.2 15.231(c) Emission Bandwidth 54.60 kHz Fc(70~900MHz): BW ” fc x 0.25% Complied 3.3 15.231(b)/(e) Fundamental Emissions [dBuV/m at 3m]: 62.19 (Margin 18.64dB) average [dBuV/m at 3m]: average: 75.62 Complied 3.4 15.231(b)/(e) Transmitter Radiated Unwanted Emissions [dBuV/m at 3m]: 2742.000MHz 46.60 (Margin 7.40dB) - PK FCC 15.231 (b)/(e) or FCC 15.209, whichever limit permits higher field strength. Complied 3.5 15.231(a)/(e) Operation Restriction Operated time and silent time are less than limits. Manually operated within 5 sec Complied The “N/A” is Not Available. FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : 4 of 26 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Revision History Report No. Version Description Issued Date FR350715 Rev. 01 Initial issue of report Jun. 17, 2013 FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : 5 of 26 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range (MHz) Modulation Ch. Frequency (MHz) Channel Number Fundamental Field Strength (dBuV/m) Co-location 433.92 ASK 433.92 1 62.19 N/A Note 1: Field strength performed average level at 3m. Note 2: Co-location, Co-location is generally defined as simultaneously transmitting (co-transmitting) antennas within 20 cm of each other. 1.1.2 Antenna Information Antenna Category Integral antenna (antenna permanently attached) External antenna (dedicated antennas) ; Unique antenna connector 1.1.3 Type of EUT Identify EUT EUT Serial Number N/A Presentation of Equipment Production ; Pre-Production ; Prototype Type of EUT Stand-alone Combined (EUT where the radio part is fully integrated within another device) Combined Equipment - Brand Name / Model No.: ...…

Text truncated - open the document above for the full version.

FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : A1 of A4 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Appendix A. Test Photos FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : A2 of A4 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : A3 of A4 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR350715 SPORTON INTERNATIONAL INC. Page No. : A4 of A4 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 For radiated emissions above 1GHz FRONT VIEW REAR VIEW
