PY3-FVM318Wireless Router

SM-FVM318NA-0 October 2002 NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA Phone 1-888-NETGEAR Reference Manual for the Model FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall Reference Manual FVM318.book Page i Wednesday, September 18, 2002 5:20 PM FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. ii © 2002 by NETGEAR, Inc. All rights reserved. Trademarks NETGEAR and Auto Uplink are trademarks or registered trademarks of Netgear, Inc. Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders. Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. EN 55 022 Declaration of Conformance This is to certify that the FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022 Class B (CISPR 22). FVM318.book Page ii Wednesday, September 18, 2002 5:20 PM iii Bestätigung des Herstellers/Importeurs Es wird hiermit bestätigt, daß dasFVM318 Cable/DSL ProSafe Wireless VPN Security Firewall gemäß der im BMPT-AmtsblVfg 243/1991 und Vfg 46/1992 aufgeführten Bestimmungen entstört ist. Das vorschriftsmäßige Betreiben einiger Geräte (z.B. Testsender) kann jedoch gewissen Beschränkungen unterliegen. Lesen Sie dazu bitte die Anmerkungen in der Betriebsanleitung. Das Bundesamt für Zulassungen in der Telekommunikation wurde davon unterrichtet, daß dieses Gerät auf den Markt gebracht wurde und es ist berechtigt, die Serie auf die Erfüllung der Vorschriften hin zu überprüfen. Certificate of the Manufacturer/Importer It is hereby certified that the FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall has been suppressed in accordance with the conditions set out in the BMPT-AmtsblVfg 243/1991 and Vfg 46/1992. The operation of some equipment (for example, test transmitters) in accordance with the regulations may, however, be subject to certain restrictions. Please refer to the notes in the operating instructions. Federal Office for Telecommunications Approvals has been notified of the placing of this equipment on the market and has been granted the right to test the series for compliance with the regulations. Voluntary Control Council for Interference (VCCI) Statement This equipment is in the second category (information equipment to be used in a residential area or an adjacent area thereto) and conforms to the standards set by the Voluntary Control Council for Interference by Data Processing Equipment and Electronic Office Machines aimed at preventing radio interference in such residential areas. When used near a radio or TV receiver, it may become the cause of radio interference. Read instructions for correct handling. Technical Support Refer to the Support Information Card that shipped with your FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall. World Wide Web NETGEAR maintains a World Wi…

Text truncated - open the document above for the full version.

Reference Manual for the Model FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall 4-28Virtual Private Networking FVM318.book Page 28 Wednesday, September 18, 2002 5:20 PM Managing Your Network5-1 Chapter 5 Managing Your Network This chapter describes how to perform network management tasks with your FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall. Network Management Information The FR328S provides a variety of status and usage information which is discussed below. Viewing Router Status and Usage Statistics From the Main Menu, under Maintenance, select Router Status to view the screen in Figure 5-1. Figure 5-1: Router Status screen FVM318.book Page 1 Wednesday, September 18, 2002 5:20 PM Reference Manual for the Model FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall 5-2Managing Your Network The Router Status menu provides a limited amount of status and usage information. From the Main Menu of the browser interface, under Maintenance, select Router Status to view the status screen, shown in Figure 5-1. This screen shows the following parameters: Ta b le 5-1.Menu 3.2 - Router Status Fields Field Description System NameThis field displays the Host Name assigned to the firewall in the Basic Settings menu. Firmware VersionThis field displays the firewall firmware version. WAN PortThese parameters apply to the Internet (WAN) port of the firewall. MAC AddressThis field displays the Ethernet MAC address being used by the Internet (WAN) port of the firewall. IP AddressThis field displays the IP address being used by the Internet (WAN) port of the firewall. If no address is shown, the firewall cannot connect to the Internet. DHCPIf set to None, the firewall is configured to use a fixed IP address on the WAN. If set to Client, the firewall is configured to obtain an IP address dynamically from the ISP IP Subnet MaskThis field displays the IP Subnet Mask being used by the Internet (WAN) port of the firewall. Domain Name Servers (DNS) This field displays the DNS Server IP addresses being used by the firewall. These addresses are usually obtained dynamically from the ISP. LAN PortThese parameters apply to the Local (WAN) port of the firewall. MAC AddressThis field displays the Ethernet MAC address being used by the Local (LAN) port of the firewall. IP AddressThis field displays the IP address being used by the Local (LAN) port of the firewall. The default is 192.168.0.1 IP Subnet MaskThis field displays the IP Subnet Mask being used by the Local (LAN) port of the firewall. The default is 255.255.255.0 DHCPIf set to OFF, the firewall will not assign IP addresses to local PCs on the LAN. If set to ON, the firewall is configured to assign IP addresses to local PCs on the LAN. FVM318.book Page 2 Wednesday, September 18, 2002 5:20 PM Reference Manual for the Model FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall Managing Your Network5-3 Click on the “Show Statistics” button to display firewall usage statistics, as shown in Figure 5-2 below: Figure 5-2.Router Statistics screen This screen shows the following statistics:. Ta b le 5-2.Router Statistics Fields FieldDescription WAN, LAN, or Serial Port The statistics for the WAN (Internet), LAN (local), and Serial ports. For each port, the screen displays: StatusThe link status of the port. TxPktsThe number of packets transmitted on this port since reset or manual clear. RxPktsThe number of packets received on this port since reset or manual clear. CollisionsThe number of collisions on this port since reset or manual clear. Tx B/sThe current line utilization—percentage of current bandwidth used on this port. Tx B/sThe average line utilization —average CLU for this port. Up TimeThe time elapsed since this port acquired link. System up TimeThe time elapsed since the last power cycle or reset. Poll IntervalSpecifies the intervals at which the statistics are updated in this window. Click on Stop to freeze the display. FVM318.book Page 3 Wednesday, September 18, 2002 5:20 PM Reference Manual for the Model FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall 5-4Managing Your Network Viewing Attached Devices The Attached Devices menu contains a table of all IP devices that the firewall has discovered on the local network. From the Main Menu of the browser interface, under the Maintenance heading, select Attached Devices to view the table, shown in Figure 5-3 Figure 5-3: Attached Devices menu For each device, the table shows the IP address, NetBIOS Host Name, if available, and the Ethernet MAC address. Note that if the firewall is rebooted, the table data is lost until the firewall rediscovers the devices. To force the firewall to look for attached devices, click the Refresh button. FVM318.book Page 4 Wednesday, September 18, 2002 5:20 PM Reference Manual for the Model FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall Managing Your Network5-5 Viewing, Selecting, and Saving Logged Information The firewall will log security-related events such as denied incoming service requests, hacker probes, and administrator logins. If you enabled content filtering in the Block Sites menu, the Logs page shows you when someone on your network tried to access a blocked site. If you enabled e-mail notification, you'll receive these logs in an e-mail message. If you don't have e-mail notification enabled, you can view the logs here. An example is shown below. Figure 5-4: Security Logs menu FVM318.book Page 5 Wednesday, September 18, 2002 5:20 PM Reference Manual for the Model FVM318 Cable/DSL ProSafe Wireless VPN Security Firewall 5-6Managing Your Network Log entries are described in Ta b le 5-5 Log action buttons are described in Ta b le 5-6 Selecting What Information to Log Besides the standard information listed above, you can choose to log additional information. Those optional selections are as follows: •All incoming and outgoing traffic •Attempted access to blocked site •Connections to the Web-based interface of this Router Ta b le 5-5:Security Lo…

Text truncated - open the document above for the full version.

(Ver:0.1)2002/19/17 Argus Corp. FCC Certificate Only FVM318 System Block Diagram ARM 7 S3C4510B01 SDRAM 4M*16 Ethernet WAN RTL8019AS SYSTEM BUS 10/100 8 Port Switch BCM5317KQM SYSTEM BUS RJ-45 *8 RJ-45 SDRAM 4M*16 MII POWER Ckt 5V 3.3V 2.5V CLOCK Ckt (Hz) 12M 20M 25M Reset Ckt 2.5V 3.3V 3.3V 3.3V 5V FLASH 512k*16 DC 12V/1.2A SafeNet 1741 SYSTEM BUS CPLD ALC3032 Intersil PRISM 2.5 3.3V SYSTEM BUS PCMCIA

Netgear Incorporated FCC ID: PY3-FVM318 4500 Great America Parkway, Santa Clara, CA 95054 Federal Communications Commission Oct. 29, 2002 Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Schematics The above materials contain trade secrets and proprietary information not customarily Released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Netgear Incorporated

Report No.: 029L116FI Page : 1 of 12 Version:1.0 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 029L116FI Page : 2 of 12 Version:1.0 (3) EUT Photo (4) EUT Photo

Netgear Incorporated 4500 Great America Parkway, Santa Clara, CA 95054 TEL: (408) 907 8000 FCC ID.: PY3-FVM318 FCC ID AND DoC Label The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below. Netgear Incorporated NETGEAR M/N: FVM318 TESTED TO COMPLY WITH FCC STANDARDS FOR HOME OR OFFICE USE S/N: Made in Taiwan Wireless Router Model No.: FVM318 F F C C C C I I D D : : P P Y Y 3 3 - - F F V V M M 3 3 1 1 8 8 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan

Report No.: 029L116FI Page : 1 of 12 Version:1.0 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 029L116FI Page : 2 of 12 Version:1.0 (3) EUT Photo (4) EUT Photo Report No.: 029L116FI Page : 3 of 12 Version:1.0 (5) EUT Photo (6) EUT Photo Report No.: 029L116FI Page : 4 of 12 Version:1.0 (7) EUT Photo (8) EUT Photo Report No.: 029L116FI Page : 5 of 12 Version:1.0 (9) EUT Photo (10) EUT Photo Report No.: 029L116FI Page : 6 of 12 Version:1.0 (11) EUT Photo (12) EUT Photo Report No.: 029L116FI Page : 7 of 12 Version:1.0 (13) EUT Photo (14) EUT Photo Report No.: 029L116FI Page : 8 of 12 Version:1.0 (15) EUT Photo (16) EUT Photo Report No.: 029L116FI Page : 9 of 12 Version:1.0 (17) EUT Photo (18) EUT Photo Report No.: 029L116FI Page : 10 of 12 Version:1.0 (19) EUT Photo (20) EUT Photo Report No.: 029L116FI Page : 11 of 12 Version:1.0 (21) EUT Photo (22) EUT Photo Report No.: 029L116FI Page : 12 of 12 Version:1.0 (23) EUT Photo (24) EUT Photo

Report No. 029L116FI Page: 6of 42 Version:1.0 1.2. Operational Description EUT is a Wireless Router with 11 channels. This device provided four kind of transmitting speed 1,2,5.5 and 11Mbps. The device of RF carrier is DQPSK, DB PSK and CCK. The device adapts direct sequence spread spectrum modulation. The Connector antenna was scolded on PCB provides diversity function to improve the receiving function. This Broadband Wireless Router is an IEEE 802.11b Wireless LAN adapter. It allows your computer to connect to a wireless network and to share resources, such as files or printers without being bound to the network wires. Operation in 2.4GHz Direst Sequence Spread Spectrum (DSSS) radio transmission, the Broadband Wireless Router transfers data at speeds up to 64/128-bit Wired Equivalent Protection (WEP) algorithm is used. In addition, its standard compliance ensures that it can communicate with any 802.11b network.

IW-151 2.4GHz Swivel Antenna : 2.4~2.5GHz : 50 Ohms nominal : 2.0 : 5dBi : Omni : Vertical : SMA (male) : Polyurethane : Polycarbonate : Black : -20 : -30 TECHNICAL DATA Electrical Properties Frequency Range Impedance VSWR Gain Radiation Polarization Standard Connector Mechanical Properties Antenna Cover Swivel Mechanism Color Operation Temp Storage Temperature VSWR Frequency: 2.45GHz Frequency: 2.45GHz Return Loss Unit: mm 2001.7 E-Plane Field Patterns H-Plane Field Patterns

Report No. 029L116FI Page: 1of 42 Version:1.0 Test Report Product Name : Wireless Router Model No.: FVM318 FCC ID.: PY3-FVM318 Applicant : Netgear Incorporated Address : 4500 Great America Parkway, Santa Clara, CA 95054 Date of Receipt : Sep. 16, 2002 Date of Test : Sep. 26, 2002 Report No. : 029L116FI The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 029L116FI Page: 3of 42 Version:1.0 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................6 1.3. Tested System Datails....................................................................................................................7 1.4. Configuration of tested System .....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................10 2.4. Test Procedure .............................................................................................................................11 2.5. Test Result of Conducted Emission.............................................................................................12 3. Peak Power Output ...................................................................................................................13 3.1. Test Equipment............................................................................................................................13 3.2. Test Setup ....................................................................................................................................13 3.3. Limits ..........................................................................................................................................13 3.4. Test Result of Peak Power Output...............................................................................................14 4. RF Exposure Evaluation ...........................................................................................................15 4.1. Fries Formula ..............................................................................................................................15 4.2. EUT Operation condition ............................................................................................................15 4.3. Test Result of RF Exposure Evaluation.......................................................................................16 5. Radiated Emission .....................................................................................................................17 5.1. Test Equipment............................................................................................................................17 5.2. Test Setup ....................................................................................................................................17 5.3. Limits ..........................................................................................................................................18 5.4. Test Procedure .............................................................................................................................19 5.5. Test Result of Radiated Emission................................................................................................20 5.6. .........................................................................................................................................................................23 6. Band Edge ..................................................................................................................................26 6.1. Test Equipment............................................................................................................................26 6.2. Test Setup ....................................................................................................................................26 6.3. Limits ..........................................................................................................................................27 6.4. Test Procedure .............................................................................................................................27 6.5. Test Result of Band Edge ............................................................................................................28 7. Occupied Bandwidth .................................................................................................................30 7.1. Test Equipment......................................................................................................................…

Text truncated - open the document above for the full version.

Report No.: 029L116FI Page : 1of 4 Version:1.0 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test (Mode 1) Back View of Conducted Test (Mode 1) Report No.: 029L116FI Page : 2of 4 Version:1.0 Front View of Conducted Test (Mode 2) Back View of Conducted Test (Mode 2) Report No.: 029L116FI Page : 3of 4 Version:1.0 Front View of Radiated Test Back View of Radiated Test Report No.: 029L116FI Page : 4of 4 Version:1.0 Front View of High Frequency Radiated Test
