PY305100001Wireless USB 2.0 802.11g Adapter

202-10026-01 202-10026-01 Version 2.0 May 2004 NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA User Manual for the NETGEAR WG111v2 54 Mbps Wireless USB 2.0 Adapter Regulatory Approvals FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica- tions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). Channel The Wireless Channel sets the radio frequency used for communication. Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best performance. In the USA and Canada, 11 channel are available. If using multiple Access Points, it is better if adjacent Access Points use different Channels to reduce interference. In "Infrastructure" mode, Wireless Stations normally scan all Channels, looking for an Access Point. If more than one Access Point can be used, the one with the strongest signal is used. (This can only happen within an ESS.) If using "Ad-hoc" mode (no Access Point), all Wireless stations should be set to use the same Channel. However, most Wireless stations will still scan all Channels to see if there is an existing "Ad-hoc" group they can join. This device has been tested and meets the FCC RF exposure guidelines. The maximum SAR value reported is 0.61w/kg ii 202-10026-01 Technical Support Please refer to the support information card that shipped with your product. By registering your product at www.netgear.com/register , we can provide you with faster expert technical support and timely notices of product and software upgrades. NETGEAR, INC. Support Information Phone: 1-888-NETGEAR, for US & Canada only. For other countries, see your Support information card. E-mail: [email protected] Web site: www.netgear.com Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. ©2004 NETGEAR, Inc. NETGEAR, the NETGEAR logo, The Gear Guy and Everybody's Connecting are trademarks or registered trademarks of NETGEAR, Inc. in the United States and/or other countries. Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and/or other countries. Other brand and product names are trademarks or registered trademarks of their respective holders. Information is subject to change without notice. All rights reserved . May 2004 Certificate of the Manufacturer/Importer It is hereby certified that the Model WG111v2 Wireless USB 2.0 Adapter has been suppressed in accordance with the conditions set out in the BMPT- AmtsblVfg 243/1991 and Vfg 46/1992. The operation of some equipment (for example, test transmitters) in accordance with the regulations may, however, be subject to certain restrictions. Please refer to the notes in the operating instructions. Federal Office for Telecommunications Approvals has been notified of the placing of this equipment on the market and has been granted the right to test the series for compliance with the regulations. VCCI Statement This equipment is in the Class B category (information equipment to be used in a residential area or an adjacent area thereto) and conforms to the standards set by the Voluntary Control Council for Interference by Data Processing 202-10026-01 iii Equipment and Electronic Office Machines aimed at preventing radio interference in such residential areas. When used near a radio or TV receiver, it may become the cause of radio interference. Read instructions for correct handling. FCC Information to User This product does not contain any user serviceable components and is to be used with approved antennas only. Any product changes or modifications will invalidate all applicable regulatory certifications and approvals FCC Guidelines for Human Exposure This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Declaration Of Conformity We NETGEAR, Inc., 4500 Great America Parkway, Santa Clara, CA 95054, declare under our sole responsibility that the model WG111v2 Wireless USB 2.0 Adapter complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: •This device may not cause harmful interference, and •This device must accept any interference received, including interference that may cause undesired operation. Regul…

Text truncated - open the document above for the full version.

April 1, 2005 Statement Federal Communications Commission To Whom It May Concern, We, SerComm Corporation, hereby declare that the product FCC ID: PY305100001 only channels 1-11 will be available, and that the end user will be given no ability to change to an operating frequency outside of the USA channel set. Sincerely, Kevin Tseng Project Manager SerComm Corporation Ivy Chen

Exclusive Certification Corp. 4F-2, No. 28, Lane 78, Xing-Ai Rd. Nei-hu, Taipei City 114 Taiwan R.O.C 11478284-2F Tel: 886-2-2792-3366 Fax: 886-2-2792-1100 To whom it may concern The enclosed documents constitute a formal submittal and application for a Grant of Equipment Authorization pursuant to Subpart C of Part 15 of FCC rules (CFR47) regarding NETGEAR WG111v2 54Mbps Wireless USB2.0 Adapter for the Netgear model WG111v2. Data within this report demonstrates that the equipment tested complied with the FCC limits for intentional radiators. Exclusive Certificate Corp. (ECC), as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is enclosed. If there are any questions or if further information is needed, please contact ECC for assistance. Ivy Chen TEL: +886-2-2792-3366 # 204 FAX: +886-2-2792-1100 E-mail: [email protected]

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 February 22, 2005 RE: Netgear Inc. FCC ID: PY305100001 I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) Please provide a proper label for this device. No FCC ID appears on the label sample provided. Kindly confirm that the requested FCC ID is: PY305100001 2.) Kindly confirm that for products imported into the USA that only channels 1-11 will be available, and that the end user will be given no ability to change to an operating frequency outside of the USA channel set. 3.) This device appears to incorporate a standard USB connector thereby making it possible for the end user to plug this device directly into a notebook PC. Therefore, the 20cm statements in the Manual (two instances on pp.2) are incorrect. Please revise. 4.) Item #4 in the Operational Description seems to show that this device is capable of RF powers up to +23dBm. Kindly confirm that the maximum power used with this device is 16mW as indicated on Form 731. Please be advised that this USB device will need SAR testing if the RF power can exceed 24mW. 5.) FYI: Please note that in instances where SAR reporting is required, a spectrum analyzer is generally not accurate enough in RF power readings to maintain the required 5% tolerance between SAR report and EMC report. If SAR testing is required, then I will request an alternative RF Pout test. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

External Photos

WG111v2 Tested to Comply with FCC Standards FOR HOME OF OFFICE USE NETGEAR size: 8*50 mm FCC ID: PY305100001

Internal Photos

WG111 v3 Operation Principle 1. CPU, RTL8187L is a low-profile highly integrated cost-effective Wireless LAN USB 2.0 network interface controller that integrates a USB 2.0 PHY, SIE (Serial Interface Engine), 8051 MCU, a Wireless LAN MAC, and a Direct Sequence Spread Spectrum/OFDM baseband onto one chip. It provides USB high speed (480Mbps), and full speed (12Mbps), and supports 4 endpoints for transfer pipes. To reduce protocol overhead, the RTL8187L supports short InterFrame Space (SIFS) burst mode to send packets back-to –back. A protection mechanism prevents collisions among 802.11b nodes. The RTL8187L fully complies with IEEE 802.11a/b/g specification. 2. Transceiver RTL8225, 802.11g/b Zero-IF RF transceiver. Building synthesizer LC auto calibration. Building RX low pass filter RC auto calibration. Fast 80MHz Series interface controls transmit and receive PGA. Transceiver multi-mode control 3-wire interface or shut down transceiver by external power down pin. Whole chip ESD protection circuits. Self power on reset. On-chip Oscillator. Synthesizer clock source selectable. 3. EEPROM, The AT93C46 provides 1024bits of serial electrically erasable programmable read only memory (EEPROM) organized as 64 words of 16 bits. 4. 2.4GHz – 2.5GHz Power Amplifier, The SE2525L-EK1 Evaluation Kit is a tool that is intended to demonstrate the performance of the RangeCharger TM SE2525L 802.11g Power Amplifier in 802.11g application. 11dBm O/P Power, 802.11b, 11Mbps. 12dBm O/P Power, 802.11g, 54Mbps.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Feb. 05, 2005 1 of 61 FCC ID: PY305100001 FCC Test Report: FI05010502-A FCC TEST REPORT according to FCC Rules and Regulations Part 15 Subpart C Laboratory Accredition 1332 ILAC MRA † The test result refers exclusively to the test presented test model / sample., † Without written approval of Exclusive Certification Corp. the test report shall not be reproduced except in full. † The EUT is also considered as a kind of computer peripheral, because the connection to computer is necessary for typical use. It has been verified to comply with the requirements of FCC Part 15, Subpart B, Class B (DoC). The test report has been issued separately. Applicant Netgear Inc. Address 4500 Great America Parkway Santa Clara California 95054 USA Equipment NETGEAR WG111v2 54Mbps Wireless USB 2.0 Adapter Model No. WG111v2 FCC ID PY305100001 Trade Name Netgear Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Feb. 05, 2005 2 of 61 FCC ID: PY305100001 FCC Test Report: FI05010502-A Contents 1. Report of Measurements and Examinations..................................................................................4 1.1. List of Measurements and Examinations............................................................................4 1.2. Antenna Requirements......................................................................................................5 1.3. Test of Conducted Emission..............................................................................................6 1.4. Test of Radiated Emission.................................................................................................8 1.5. 6dB Bandwidth.................................................................................................................9 1.6. Maximum Peak Output Power...........................................................................................9 1.7. Band Edges Measurement..............................................................................................10 1.8. Power Spectral Density...................................................................................................10 1.9. Restricted Bands of Operation..........................................................................................11 1.10. Labeling Requirement......................................................................................................11 1.11. RF Exposure..................................................................................................................12 2. Test Configuration of Equipment under Test................................................................................14 2.1. Test Mode and Test Software...........................................................................................14 2.2. Description of Test System..............................................................................................14 2.3. Connection Diagram of Test System................................................................................15 2.4. Feature of Equipment under Test.....................................................................................16 2.5. History of this test report.................................................................................................16 3. General Information of Test.......................................................................................................17 4. Test Result and Data.................................................................................................................18 4.1. Antenna Requirement.....................................................................................................18 4.2. Test Result of Conducted Emission..................................................................................19 4.3. 6dB Bandwidth Measurement Data..................................................................................40 4.4. Peak Output Power Measurement Data...........................................................................44 4.5. Band Edges Measurement Data......................................................................................48 4.6. Restrict band emission Measurement Data.......................................................................53 4.7. Power Spectral Density Measurement Data......................................................................57 5. List of Measuring Equipment Used.............................................................................................61 Appendix A. Photographs of EUT........................................................................ ...............A1 ~ A4 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Feb. 05, 2005 3 of 61 FCC ID: PY305100001 FCC Test Report: FI05010502-A CERTIFICATE OF COMPLIANCE according to FCC Rules and Regulations Part 15 Subpart C Applicant Netgear Inc. Address 4500 Great America Parkway Santa Clara California 95054 USA Equipment NETGEAR WG111v2 54Mbps Wireless USB 2.0 Adapter Model No. WG111v2 FCC ID PY305100001 I HEREBY CERTIFY THAT : The measurements shown in this test report were made in accordance with the procedures given in ANSI C63.4 The equipment was passed the test performed according to FCC Rules and Regulations Part 15 Subpart C (2003). The test was carried out on Jan. 28, 2005 at Exclusive Certification Corp. Signature Anson Chou / Manager Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Feb. 05, 2005 4 of 61 FCC ID: PY305100001 FCC Test Report: FI05010502-A 1. Report of Measurements and Examinations 1.1. List of Measurements and Examinations FCC Rule . Description of Test Result 15.203 . Antenna Requirement Pass 15.207 . Conducted Emission Pass 15.209 . Radiated Emission Pass 15.247(a)(2) . 6dB Bandwidth Pass 15.247(b) . Maximum Peak Output Power Pass 15.247(c) …

Text truncated - open the document above for the full version.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Feb. 05, 2005 31 of 61 FCC ID: PY305100001 FCC Test Report: FI05010502-A 4.2.1. Photographs of Conducted Emission Test FRONT VIEW REAR VIEW

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Feb. 05, 2005 39 of 61 FCC ID: PY305100001 FCC Test Report: FI05010502-A Photographs of Radiated Emission Test FRONT VIEW REAR VIEW
