September 2006 NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA 54Mbps Wireless Router Model KWGR614 Reference Manual ii v1.2, September 2006 © 2006 by NETGEAR, Inc. All rights reserved. September 2006. Trademarks NETGEAR is a trademark of Netgear, Inc. Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders. Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. Maximum Wireless Signal Rate Derived from IEEE Standard 802.11 Specifications Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Placement and Range Guidelines Indoors, computers can connect over 802.11 wireless networks at a maximum range of 500 feet (152.4 m) for 802.11b devices. However, the operating distance or range of your wireless connection can vary significantly, based on the physical placement of the wireless access point. For best results, identify a location for your wireless access point according to these guidelines: •• Away from potential sources of interference, such as PCs, large metal surfaces, microwaves, and 2.4 GHz cordless phones. •• In an elevated location such as a high shelf that is near the center of the wireless coverage area for all mobile devices. Failure to follow these guidelines can result in significant performance degradation or inability to wirelessly connect to the wireless access point. To meet FCC and other national safety guidelines for RF exposure, the antennas for this device must be installed to ensure a minimum separation distance of 20cm (7.9 in.) from persons. Further, the antennas shall not be collocated with other transmitting structures. FCC Statement: DECLARATION OF CONFORMITY We Netgear, 4500 Great America Parkway, Santa Clara, CA 95054, USA, Tel: +1 408 907 8000, declare under our sole responsibility that the product(s) KWGR614 (Model Designation) Wireless Router (Product Name) complies with Part 15 of FCC Rules. v1.2, September 2006 iii Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Requirements for Operation in the United States Radio Frequency Interference Warnings & Instructions This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: •• Reorient or locate the receiving antenna. •• Increase the separation between the equipment and receiver. •• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •• Consult the dealer or an experienced radio/TV technician for help. RF Exposure Warning for North America, and Australia Warning! To meet FCC and other national safety guidelines for RF exposure, the antennas for this device (see below) must be installed to ensure a minimum separation distance of 20cm (7.9 in.) from persons. Further, the antennas shall not be collocated with other antennas or radio transmitters. CAUTION: Any changes of modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment v1.2, September 2006 iv European Union Statement of Compliance Hereby, NETGEAR, Inc. declares that this wireless router is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Èesky [Czech] NETGEAR, Inc. tímto prohlašuje, že tento 54Mbps Wireless Router Model KWGR614 je ve shodì se základními požadavky a dalšími pøíslušnými ustanoveními smìrnice 1999/ 5/ES. Dansk [Danish] Undertegnede NETGEAR, Inc. erklærer herved, at følgende udstyr 54Mbps Wireless Router Model KWGR614 overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Deutsch [German] Hiermit erklärt NETGEAR, Inc., dass sich das Gerät 54Mbps Wireless Router Model KWGR614 in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Eesti [Estonian] Käesolevaga kinnitab NETGEAR, Inc. seadme 54Mbps Wireless Router Model KWGR614 vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. English Hereby, NETGEAR, Inc., declares that this 54Mbps Wireless Router Model KWGR614 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Español [Spanish] Por …

Text truncated - open the document above for the full version.

4500 GREAT AMERICA PARKWAY SANTA CLARA CA95054 U.S.A. FCC ID: PY306300055 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________________________ Mark Gandler/Senior Compliance Engineer NETGEAR, INC. Tel: 408-907-8000 Fax: 408-907-8097 E-mail: [email protected]

From: Mark Gandler [mailto:[email protected]] Sent: Tuesday, September 26, 2006 11:17 AM To: [email protected] Subject: KWGR614NA (PY306300055 Steve, Please review proposed statement for FCC statements for user manual. Regarding channel selection. KWGR614NA product has capabilities to operate ONLY in channels 1-11 bands. “Select Region” option allows you to choose only “North America” region, there are no other option under select region. Best Regards, Mark Gandler Sr. Compliance Engineer Netgear 408-907-8000 408-367-7957: direct 408-907-8097: fax [email protected] From: steve.cheng [mailto:[email protected]] Sent: Monday, September 25, 2006 7:54 PM To: '[email protected]' Cc: '[email protected]'; '[email protected]' Subject: TCB Review Comments for (A06-0925a- PY306300055- Netgear 11g router) TCB Review Comments for (A06-0925a- PY306300055- Netgear 11g router) -EMC- Question #1: Manual is missing following regulatory statements: - 47 CFR 15.19 no interference & no protection warning - 47 CFR 15.21 -- information re modifying product - 47 CFR 2.1091 – Mobile RF exposure user information Question #2: Page 21, 22. 27, 50 & 51 Manual show region selection and it is not clear that if this feature is available on US model. Please clarify. Best regards, Steve Cheng Curtis-Straus LLC Email: [email protected]

4500 GREAT AMERICA PARKWAY SANTA CLARA CA95054 U.S.A. Date: 2006/9/11 AGENCY AUTHORIZATION LETTER We, the undersigned NETGEAR, INC. hereby authorize Advance Data Technology Corp. (ADT) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15C and any communication needed with the national authority. Any and all acts carried out by ADT on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, _________________________________ Mark Gandler/Senior Compliance Engineer NETGEAR, INC. Tel: 408-907-8000 Fax: 408-907-8097 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

Page 1 Label Location FCC ID: PY306300055

SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISIONENG APPDDATE NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 5. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). 5 01AW-10114-031 of 1 AW, KWGR614, V1H1, PLBL M YU 08/23/06M YUINITIAL DOCUMENT CREATION01 Pantone 430C

Page 3 Page 4 Page 5 Page 6

FCC ID: PY306300055 Report No. RF95017L10A Operational Description This device is an 802.11 b+g Wireless Router with 4ports 10/100 Mbps Switch, which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by AC Adapter. The antenna are Dipole antenna with R-SMA connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual.

FCC ID: PY306300055 Report No: SA950417L10A Reference No.: 950830L05 1 RF EXPOSURE REPORT REPORT NO.: SA950417L10A MODEL NO.: KWGR614 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: NETGEAR, Inc. ADDRESS: 4500 Great America Parkway, Santa Clara, CA 95054 USA ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: PY306300055 Report No: SA950417L10A Reference No.: 950830L05 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: PY306300055 Report No: SA950417L10A Reference No.: 950830L05 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: PY306300055 Report No: SA950417L10A Reference No.: 950830L05 4 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 2.0dBi or 1.5849 (numeric). 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: Dipole antenna gain: 5dBi 802.11b DSSS modulation Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241263.2410.0201.0 6243763.3870.0201.0 11246264.1210.0201.0 802.11g OFDM modulation Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241225.1770.0081.0 6243725.3510.0081.0 11246225.1190.0081.0

Report No.: RF950417L10A1Report Format Version 2.0.4 Reference No.: 950830L05 FCC TEST REPORT REPORT NO.: RF950417L10A MODEL NO.: KWGR614 RECEIVED: Aug. 30, 2006 TESTED: Sep. 01 ~ Sep. 05, 2006 ISSUED: Sep. 11, 2006 APPLICANT: NETGEAR, Inc. ADDRESS: 4500 Great America Parkway, Santa Clara, CA 95054 USA ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 61 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF950417L10A2Report Format Version 2.0.4 Reference No.: 950830L05 Table of Contents 1CERTIFICATION...........................................................................................................4 2SUMMARY OF TEST RESULTS..................................................................................5 2.1MEASUREMENT UNCERTAINTY...............................................................................5 3GENERAL INFORMATION...........................................................................................6 3.1GENERAL DESCRIPTION OF EUT.............................................................................6 3.2DESCRIPTION OF TEST MODES...............................................................................7 3.2.1CONFIGURATION OF SYSTEM UNDER TEST..........................................................7 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..............................8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS...........................................10 3.4DESCRIPTION OF SUPPORT UNITS.......................................................................10 4TEST TYPES AND RESULTS.....................................................................................11 4.1CONDUCTED EMISSION MEASUREMENT.............................................................11 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT...........................................11 4.1.2TEST INSTRUMENTS.................................................................................................11 4.1.3TEST PROCEDURES................................................................................................12 4.1.4DEVIATION FROM TEST STANDARD......................................................................12 4.1.5TEST SETUP..............................................................................................................13 4.1.6EUT OPERATING CONDITIONS...............................................................................13 4.1.7TEST RESULTS..........................................................................................................14 4.2RADIATED EMISSION MEASUREMENT..................................................................20 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT...............................................20 4.2.2TEST INSTRUMENTS................................................................................................21 4.2.3TEST PROCEDURES................................................................................................22 4.2.4DEVIATION FROM TEST STANDARD......................................................................22 4.2.5TEST SETUP..............................................................................................................23 4.2.6EUT OPERATING CONDITIONS...............................................................................23 4.2.7TEST RESULTS..........................................................................................................24 4.36dB BANDWIDTH MEASUREMENT..........................................................................31 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT.......................................................31 4.3.2TEST INSTRUMENTS................................................................................................31 4.3.3TEST PROCEDURE...................................................................................................32 4.3.4DEVIATION FROM TEST STANDARD......................................................................32 4.3.5TEST SETUP..............................................................................................................32 4.3.6EUT OPERATING CONDITIONS...............................................................................32 4.3.7TEST RESULTS..........................................................................................................33 4.4MAXIMUM PEAK OUTPUT POWER.........................................................................39 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.........................39 4.4.2TEST INSTRUMENTS................................................................................................39 4.4.3TEST PROCEDURES................................................................................................40 4.4.4DEVIATION FROM TEST STANDARD......................................................................40 4.4.5TEST SETUP..............................................................................................................40 4.4.6EUT OPERATING CONDITIONS...............................................................................40 4.4.7TEST RESULTS..........................................................................................................41 4.5POWER SPECTRAL DENSITY MEASUREMENT....................................................42 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT..................................42 4.5.2TEST INS…
