FCC ID: PY310200132 Report No.: RF990810E05A Operational Description This device is an Netgear Roku XD Player, which operates in the 2.4GHz frequency spectrum with throughput of up to 270Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 270Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the power adapter. The antennas are PCB printed antennas without any antenna connectors. The other instruction, please have a look at the users manual.

Report No.: SA990810E05A Report Format Version 3.0.1 Reference No.: 990816E06 1 RF EXPOSURE REPORT REPORT NO.: SA990810E05A MODEL NO.: NTV250 FCC ID: PY310200132 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Netgear Incorporated ADDRESS: 350 East Plumeria Drive San Jose, CA 95134 United States. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan Report No.: SA990810E05A Report Format Version 3.0.1 Reference No.: 990816E06 2 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in our lab, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Report No.: SA990810E05A Report Format Version 3.0.1 Reference No.: 990816E06 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device Report No.: SA990810E05A Report Format Version 3.0.1 Reference No.: 990816E06 4 6. TEST RESULTS 6.1 Antenna Gain There are two antennas provided to this EUT, please refer to the following table: Chain Antenna Type Antenna Connector Antenna Gain (dBi) Chain (0) PCB Printed NA 3 Chain (1) PCB Printed NA 3 Report No.: SA990810E05A Report Format Version 3.0.1 Reference No.: 990816E06 5 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: 802.11b: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 229.1 0.091 1.0 6 2437 363.1 0.144 1.0 11 2462 204.2 0.081 1.0 802.11g: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 260.8 0.104 1.0 6 2437 622.2 0.247 1.0 11 2462 279.3 0.111 1.0 802.11n (20MHz): Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 216.8 0.086 1.0 6 2437 628.6 0.250 1.0 11 2462 240.5 0.095 1.0 802.11n (40MHz): Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2422 202.3 0.080 1.0 4 2437 590.4 0.234 1.0 7 2452 221.9 0.088 1.0 --- END ---

Report No.: RF990810E05A 1 Report Format Version 3.0.1 Reference No.: 990816E06 FCC TEST REPORT REPORT NO.: RF990810E05A MODEL NO.: NTV250 FCC ID: PY310200132 RECEIVED: Aug. 11, 2010 TESTED: Aug. 16 to 27, 2010 ISSUED: Aug. 30, 2010 APPLICANT: Netgear Incorporated ADDRESS: 350 East Plumeria Drive San Jose, CA 95134 United States. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 82 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990810E05A 2 Report Format Version 3.0.1 Reference No.: 990816E06 Table of Contents 1. CERTIFICATION................................................................................................4 2. SUMMARY OF TEST RESULTS.........................................................................5 2.1 MEASUREMENT UNCERTAINTY.......................................................................6 3. GENERAL INFORMATION..................................................................................7 3.1 GENERAL DESCRIPTION OF EUT....................................................................7 3.2 DESCRIPTION OF TEST MODES......................................................................9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.......................10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.....................................13 3.4 DESCRIPTION OF SUPPORT UNITS...............................................................14 3.5 CONFIGURATION OF SYSTEM UNDER TEST.................................................16 4. TEST TYPES AND RESULTS...........................................................................18 4.1 CONDUCTED EMISSION MEASUREMENT......................................................18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................18 4.1.2 TEST INSTRUMENTS......................................................................................18 4.1.3 TEST PROCEDURES.......................................................................................19 4.1.4 DEVIATION FROM TEST STANDARD..............................................................19 4.1.5 TEST SETUP...................................................................................................20 4.1.6 EUT OPERATING CONDITIONS......................................................................20 4.1.7 TEST RESULTS...............................................................................................21 4.2 RADIATED EMISSION MEASUREMENT..........................................................25 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.........................................25 4.2.2 TEST INSTRUMENTS......................................................................................26 4.2.3 TEST PROCEDURES.......................................................................................28 4.2.4 DEVIATION FROM TEST STANDARD..............................................................28 4.2.5 TEST SETUP...................................................................................................29 4.2.6 EUT OPERATING CONDITIONS......................................................................29 4.2.7 TEST RESULTS...............................................................................................30 4.3 6dB BANDWIDTH MEASUREMENT.................................................................59 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT................................................59 4.3.2 TEST INSTRUMENTS......................................................................................59 4.3.3 TEST PROCEDURE.........................................................................................59 4.3.4 DEVIATION FROM TEST STANDARD..............................................................59 4.3.5 TEST SETUP...................................................................................................59 4.3.6 EUT OPERATING CONDITIONS......................................................................59 4.3.7 TEST RESULTS...............................................................................................60 4.4 MAXIMUM PEAK OUTPUT POWER.................................................................64 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT....................64 4.4.2 INSTRUMENTS................................................................................................64 4.4.3 TEST PROCEDURES.......................................................................................64 4.4.4 DEVIATION FROM TEST STANDARD..............................................................64 Report No.: RF990810E05A 3 Report Format Version 3.0.1 Reference No.: 990816E06 4.4.5 TEST SETUP...................................................................................................64 4.4.6 EUT OPERATING CONDITIONS......................................................................64 4.4.7 TEST RESULTS...............................................................................................65 4.5 POWER SPECTRAL DENSITY MEASUREMENT..............................................67 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT............................67 4.5.2 TEST INSTRUMENTS...............................…
