PY310400144N750 Wireless Dual Band Gigabit Router

Netgear Incorporated

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 02, 2011
Application Purpose: Original Equipment
Date of Application: Mar 02, 2011
Equipment Note: N750 Wireless Dual Band Gigabit Router
Frequency Range: 5755.00000000 - 5795.00000000
Company: Netgear Incorporated
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

November 2010 208-10752-01 v1.0 NETGEAR, Inc. 350 E. Plumeria Drive San Jose, CA 95134 USA N750 Wireless Dual Band Gigabit Router WNDR4000 Setup Manual 2 ©2010 by NETGEAR, Inc. All rights reserved. Trademarks NETGEAR and the NETGEAR logo are registered trademarks, and Smart Wizard is a trademark of NETGEAR. Inc. Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders. Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. Contentsiii Contents N750 Wireless Dual Band Gigabit Router WNDR4000 Setup Manual Getting to Know Your Wireless Router................................................................................ 1 Unpacking Your New Wireless Router .............................................................................. 1 Hardware Features ............................................................................................................ 2 Front Panel .................................................................................................................. 3 Back Panel .................................................................................................................. 5 Router Label ................................................................................................................ 6 Positioning Your Wireless Router ...................................................................................... 6 Installing Your Wireless Router ......................................................................................... 7 Updating Your Router Firmware ........................................................................................ 8 Installing Your Wireless Router Using Smart Wizard........................................................................................................................... 9 Installing Your Wireless Router Manually (Advanced and Linux Users)........................ 11 Connecting Your N750 Wireless Gigabit Router ............................................................. 11 Verifying Your Connection ............................................................................................... 14 Setting Up Your Router for Internet Access .................................................................... 15 Configuring Your Wireless Network................................................................................... 19 Accessing Your Router After Installation and Checking for New Firmware ..................... 19 Configuring Your Wireless Settings and Security Options .............................................. 20 Setting Your SSID and Wireless Security Manually .................................................. 20 Using Push 'N' Connect (WPS) to Configure Your Wireless Network ....................... 23 Testing Basic Wireless Connectivity ................................................................................ 24 Troubleshooting................................................................................................................... 26 Basic Setup Checklist ...................................................................................................... 26 Checking Basic Router Functions ................................................................................... 27 Troubleshooting Login Problems ..................................................................................... 29 Contentsiv Checking the Internet Service Connection ...................................................................... 30 Obtaining an Internet IP Address .............................................................................. 30 Troubleshooting PPPoE ............................................................................................ 31 Troubleshooting Internet Browsing ........................................................................... 32 Troubleshooting Connectivity Using the Ping Utility ........................................................ 32 Testing the Path from a PC to Your Router .............................................................. 32 Testing the Path from a PC to the Internet ................................................................ 33 Technical Specifications..................................................................................................... 35 Default Configuration Settings ......................................................................................... 35 Restoring the Default Password and Configuration Settings ........................................... 38 Related Documents............................................................................................................. 39 Registration and Certifications............................................................................................ 40 Getting to Know Your Wireless Router1 Getting to Know Your Wireless Router Congratulations on your purchase of the NETGEAR® N750 Wireless Dual Band Gigabit Router WNDR4000. Before you begin installing your router, check the package contents (see “Unpacking Your New Wireless Router” on page 1). Become familiar with the front and back panels of your router— especially the LEDs—and the important information on the router label (see “Hardware Features” on page 2). Then, read the section on “Positioning Your Wireless Router” on page 6 to ensure that you have selected the best location to install your router. Unpacking Your New Wireless Router The product package should contain the following items: •The N750 wireless gigabit router •A slide-on stand for your N750 wire…

Text truncated - open the document above for the full version.

Cover Letter(s)

Page No. : 9 NETGEAR, Inc. 350 East Plumeria Drive, San Jose, California 95134-1911, USA Tel: +1 408 907 8000 Fax: +1 408 907 8097 Date: 2011/1/11 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Confidentiality Request for FCC ID：PY310400144 Gentlemen: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site to be used in obtaining a grant of certification. Short-term Pursuant to DA 04-1705 of the Commission’s pubic notice, we request short-term confidential treatment for the following information until 90 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: 1. External Photos 2. Internal Photos 3. Test Setup photos 4. User’s Manual Permanent NETGEAR, Inc. requests that the material in the following files be withheld from public disclosure in accordance with Section 0.459 of the Commission’s Rules, 47 C.F.R. 0.459, following grant of the application. 1. Block Diagram 2. Circuit Diagram 3. Operational Description Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Applicant’s company name : NETGEAR, Inc. Applicant’s company address : 350 East Plumeria Drive, San Jose, California 95134-1911, USA Signature : _____________________________ Job Title and Dept. : Mark Gandler / Compliance Manager E-Mail : [email protected] Tel. : +1 408 907 8000 NETGEAR, Inc.

Cover Letter(s)

Page No. : 15 NETGEAR, Inc. 350 East Plumeria Drive, San Jose, California 95134-1911, USA Tel: +1 408 907 8000 Fax: +1 408 907 8097 DoC Attestation Letter Date: 2011/1/11 We NETGEAR, Inc., as the grantee of this project FCC ID: PY310400144, would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Regards, FCC Grantee contact person information. Applicant’s company name : NETGEAR, Inc. Applicant’s company address : 350 East Plumeria Drive, San Jose, California 95134-1911, USA Signature : _____________________________ Job Title and Dept. : Mark Gandler / Compliance Manager E-Mail : [email protected] Tel. : +1 408 907 8000

Cover Letter(s)

Page No. : 2 NETGEAR, Inc. 350 East Plumeria Drive, San Jose, California 95134-1911, USA Tel: +1 408 907 8000 Fax: +1 408 907 8097 Power of Attorney Date: 2011/1/11 Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Sporton International Inc. Address : No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. Name : Leo Huang Job Title : Manager e-mail : [email protected] I am therefore responsible for the contents of the application. Brand name and model type of the specified radio equipment: NETGEAR / WNDR4000 FCC ID: PY310400144 Product name: N750 Wireless Dual Band Gigabit Router FCC Grantee contact person information. Applicant’s company name : NETGEAR, Inc. Applicant’s company address : 350 East Plumeria Drive, San Jose, California 95134-1911, USA Signature : ____________________________ _ Job Title and Dept. : Mark Gandler / Compliance Manager E-Mail : [email protected] Tel. : +1 408 907 8000

External Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A3 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A4 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A5 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A6 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A7 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A8 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A9 OF A9 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 07, 2011 FAX : 886-2-2696-2255

ID Label/Location Info

Label size: 17.5mm*4.5mm The label locates bottom side of EUT.

Internal Photos

RF Exposure Info

Report No.: FR0D1643 FCC ID: PY310400144 Page No. : C1 of C4 Appendix C. Maximum Permissible Exposure Report No.: FR0D1643 FCC ID: PY310400144 Page No. : C2 of C4 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP××30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP × ×× From the peak EUT RF output power, the minimum mobile separation distance, d=0.2 m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR0D1643 FCC ID: PY310400144 Page No. : C3 of C4 1.3. Calculated Result and Limit 1.3.1. For 5GHz Band: For UNII Band: Antenna Type : PCB Antenna Max Conducted Power for IEEE 802.11an MCS0 20MHz Ant. 3 + Ant. 4 + Ant. 5: 16.98 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 4.42 2.7669 16.9807 49.8970 0.027480 1 Complies For ISM Band: Antenna Type : PCB Antenna Max Conducted Power for IEEE 802.11an MCS0 20MHz Ant. 3 + Ant. 4 + Ant. 5: 29.45 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 4.42 2.7669 29.4546 881.9751 0.485743 1 Complies 1.3.2. For 2.4GHz Band: Antenna Type : PCB Antenna Max Conducted Power for IEEE 802.11n MCS0 20MHz Ant. 1 + Ant. 2: 29.66 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.48 2.2284 29.6574 924.1443 0.409912 1 Complies Report No.: FR0D1643 FCC ID: PY310400144 Page No. : C4 of C4 1.3.3. For 5GHz & 2.4GHz Band (Co-Location): <For 5GHz Band>: Antenna Type : PCB Antenna Max Conducted Power for IEEE 802.11an MCS0 20MHz Ant. 3 + Ant. 4 + Ant. 5: 28.36 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 4.42 2.7669 28.3617 685.7558 0.377676 1 Complies <For 2.4GHz Band>: Antenna Type : PCB Antenna Max Conducted Power for IEEE 802.11n MCS0 20MHz Ant. 1 + Ant. 2: 29.66 dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.48 2.2284 29.6574 924.1443 0.409912 1 Complies CONCULSION: Both of the 5GHz and 2.4GHz can transmit simultaneously, the formula of calculatedthe MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.485743 / 1 + 0.409912 / 1 = 0.895655, which isless than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit.

Test Report

Report No.: FR0D1643 FCC ID: PY310400144 Page No. : D1 of D6 Appendix D. Co-location Test Report Report No.: FR0D1643 FCC ID: PY310400144 Page No. : D2 of D6 1.1. Co-Location Measurement 1.1.1. Limit The emission fall within the restricted band specified on 15.205(a), then the 15.209(a) limit in the table below has to be followed. Frequencies (MHz) Field Strength (micorvolts/meter) Measurement Distance (meters) 0.009~0.490 2400/F(KHz) 300 0.490~1.705 24000/F(KHz) 30 1.705~30.0 30 30 30~88 100 3 88~216 150 3 216~960 200 3 Above 960 500 3 1.1.2. Measuring Instruments and Setting Please refer to section 5 of equipments list in this report. The following table is the setting of spectrum analyzer and receiver. Spectrum Parameter Setting Attenuation Auto Start Frequency 1000 MHz Stop Frequency 40 GHz RB / VB (Emission in restricted band) 1MHz / 1MHz for Peak, 1 MHz / 10Hz for Average RB / VB (Emission in non-restricted band) 1MHz / 1MHz for peak Report No.: FR0D1643 FCC ID: PY310400144 Page No. : D3 of D6 1.1.3. Test Procedures 1. The EUT was placed on the top of the turntable 0.8 meter above ground. The phase center of the receiving antenna mounted on the top of a height-variable antenna tower was placed 3 meters far away from the turntable. 2. Power on the EUT and all the supporting units. The turntable was rotated by 360 degrees to determine the position of the highest radiation. 3. The horn antenna was varied between one meter and four meters above ground to find the maximum emissions field strength of both horizontal and vertical polarization. 4. For each suspected emissions, the antenna tower was scan (from 1 M to 4 M) and then the turntable was rotated (from 0 degree to 360 degrees) to find the maximum reading. 5. For emissions above 1GHz, use 1MHz VBW and RBW for peak reading. Then 1MHz RBW and 10Hz VBW for average reading in spectrum analyzer. 6. When the radiated emissions limits are expressed in terms of the average value of the emissions, and pulsed operation is employed, the measurement field strength shall be determined by averaging over one complete pulse train, including blanking intervals, as long as the pulse train does not exceed 0.1 seconds. As an alternative (provided the transmitter operates for longer than 0.1 seconds) or in cases where the pulse train exceeds 0.1 seconds, the measured field strength shall be determined from the average absolute voltage during a 0.1 second interval during which the field strength is at its maximum value. 7. For testing above 1GHz, the emissions level of the EUT in peak mode was lower than average limit (that means the emissions level in peak mode also complies with the limit in average mode), then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions will be measured in average mode again and reported. Report No.: FR0D1643 FCC ID: PY310400144 Page No. : D4 of D6 1.1.4. Test Setup Layout For radiated emissions above 1000MHz Above 10 GHz shall be extrapolated to the specified distance using an extrapolation factor of 20 dB/decade form 3m to 1.5m. Distance extrapolation factor = 20 log (specific distance [3m] / test distance [1.5m]) (dB); Limit line = specific limits (dBuV) + distance extrapolation factor [6 dB]. 1.1.5. Test Deviation There is no deviation with the original standard. 1.1.6. EUT Operation during Test The EUT was programmed to be in continuously transmitting mode. 3 or 1.5m Report No.: FR0D1643 FCC ID: PY310400144 Page No. : D5 of D6 2. Results of Radiated Emissions for Co-located Temperature 24°C Humidity 68% Test Engineer Satoshi Yang Configurations 2.4GHz + 5 GHz TX Normal Link Test Result Pass Horizontal Report No.: FR0D1643 FCC ID: PY310400144 Page No. : D6 of D6 Vertical

Test Report

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company NETGEAR, Inc. Applicant Address 350 East Plumeria Drive, San Jose, California 95134-1911, USA FCC ID PY310400144 Manufacturer’s company Ambit Microsystems (Shanghai) Ltd. Manufacturer Address No. 1925, Nanle Road, Songjiang Export Processing Zone, Shanghai, China Product Name N750 Wireless Dual Band Gigabit Router Brand Name NETGEAR Model Name WNDR4000 Test Rule Part(s) 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz / 5725 ~ 5850MHz Received Date Dec. 08, 2010 Final Test Date Feb. 16, 2011 Submission Type Original Equipment Statement Test result included is only for the 802.11n, 802.11b/g part and 802.11a (5725 ~ 5850MHz) of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR0D1643AB Report Format Version: 01 Page No. : i of ii FCC ID: PY310400144 Issued Date : Feb. 17, 2011 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details .................................................................................................................................................................................... 3 3.2. Accessories ......................................................................................................................................................................................... 6 3.3. Table for Filed Antenna....................................................................................................................................................................... 7 3.4. Table for Carrier Frequencies ............................................................................................................................................................. 9 3.5. Table for Test Modes ......................................................................................................................................................................... 10 3.6. Table for Testing Locations ................................................................................................................................................................ 12 3.7. Table for Supporting Units ................................................................................................................................................................. 12 3.8. Table for Parameters of Test Software Setting ................................................................................................................................... 13 3.9. Test Configurations ........................................................................................................................................................................... 15 4. TEST RESULT ................................................................................................................................................... 19 4.1. AC Power Line Conducted Emissions Measurement ......................................................................................................................... 19 4.2. Maximum Conducted Output Power Measurement ......................................................................................................................... 23 4.3. Power Spectral Density Measurement .............................................................................................................................................. 29 4.4. 6dB Spectrum Bandwidth Measurement .......................................................................................................................................... 37 4.5. Radiated Emissions Measurement .................................................................................................................................................... 46 4.6. Band Edge Emissions Measurement ................................................................................................................................................. 72 4.7. Antenna Requirements ..................................................................................................................................................................... 84 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................... 85 6. TEST LOCATION.............................................................................................................................................. 87 7. TAF CERTIFICATE OF ACCREDITATION ............................................................................................................. 88 APPENDIX A. PHOTOGRAPHS OF EUT ......................................................................................................... A1 ~ A19 APPENDIX B. TEST PHOTOS .......................................................................................................................... B1 ~ B5 APPENDIX C. MAXIMUM …

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: FR0D1643 FCC ID: PY310400144 Page No. : 1 of 6 Appendix B. Test Photos Report No.: FR0D1643 FCC ID: PY310400144 Page No. : 2 of 6 1. Photographs of Conducted Emissions Test Configuration Test Mode: Mode 3 FRONT VIEW REAR VIEW Report No.: FR0D1643 FCC ID: PY310400144 Page No. : 3 of 6 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 9kHz ~30MHz FRONT VIEW REAR VIEW Report No.: FR0D1643 FCC ID: PY310400144 Page No. : 4 of 6 Test Configuration: 30MHz~1GHz Test Mode: Mode 2 FRONT VIEW REAR VIEW Report No.: FR0D1643 FCC ID: PY310400144 Page No. : 5 of 6 Test Configuration: Above 1GHz Test Mode: Mode 1 FRONT VIEW REAR VIEW Report No.: FR0D1643 FCC ID: PY310400144 Page No. : 6 of 6 Test Configuration: Co-Location FRONT VIEW REAR VIEW

Contact Information

Applicant

David Kay

[email protected]4088903160Fax: 4089078097

Test Firm

Sporton International Inc.Alex Chen

[email protected]886-3-327-3456Fax: 886-3-327-0973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
4	15C	5.75 GHz - 5.79 GHz	838.00 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is the maximum combined conducted peak output power as indicated in the filing. This device must be installed and operated to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided transmitter operating conditions for satisfying RF exposure compliance. Device is operating in a 2T2R (2.4GHz) and 3T3R (5GHz) Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz and 5755 to 5795 MHz respectively.
