PY31040015011n wireless touch screen

Netgear Incorporated

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jun 01, 2011
Application Purpose: Original Equipment
Date of Application: Jun 01, 2011
Equipment Note: 11n wireless touch screen
Frequency Range: 2412.00000000 - 2462.00000000
Company: Netgear Incorporated
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

350 East Plumeria Drive San Jose, CA 95134 USA April 2011 202-10834-01 v1.0 Home Security Touchscreen HSS101 User Manual 2 Home Security Touchscreen HSS101 © 2011 NETGEAR, Inc. All rights reserved No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of NETGEAR, Inc. Technical Support Thank you for choosing NETGEAR. To register your product, get the latest product updates, get support online, or for more information about the topics covered in this manual, visit the Support website at http://support.netgear.com. Phone (US & Canada only): 1-888-NETGEAR Phone (Other Countries): Check the list of phone numbers at http://support.netgear.com/app/answers/detail/a_id/984 Trademarks NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. Other brand and product names are registered trademarks or trademarks of their respective holders. © 2011 NETGEAR, Inc. All rights reserved. Statement of Conditions To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use, or application of, the product(s) or circuit layout(s) described herein. 3 Contents Chapter 1 Introduction Box Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Product Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 System Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Access Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Entering Numbers and Letters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Numeric Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Alpha Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Chapter 2 Security Bar Security Bar Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Emergency Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 System Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Sensors Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Bypassing Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 ARM and DISARM Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Arm Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 DISARM Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Quick Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Trouble Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Subdisarm the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Chapter 3 Widgets System Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Thermostats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Night Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Internet Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 News. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Sports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Daily Word . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 4 Home Security Touchscreen HSS101 Chapter 4 Settings Settings Button Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Background Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Add Widgets to the Screen Saver List . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Change the Playing Time of a Widget . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Remove a Widget from the Screen Saver List . . . . . . . . …

Text truncated - open the document above for the full version.

Attestation Statements

NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134-1911 Date: General Declaration FCC ID: PY310400150 We, NETGEAR, Inc. declares that the device does not have “Ad Hoc on non-US frequencies” and/ or “on DFS frequencies”. If you have any questions regarding the declaration, please don’t hesitate to contact us. Thank you! Sincerely yours, Signed name below --------------------------------------------- Print Name Mark.Gandler / Sr. Regulatory Compliance Engineer Company: NETGEAR, Inc. TEL: (408)907-8000 FAX: E-mail: [email protected]

Cover Letter(s)

NETGEAR, Inc. Address: 350 East Plumeria Drive San Jose, CA 95134-1911 T：(408)907-8000 FAX：XXXXXXX To Whom It May Concern：：：： FCC ID:PY310400150 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to FCC DA 04-1705 dated 6/15/2004, we are requesting the commission to withhold the following attachments as SHORT-TERM confidential document from public disclosure indefinitely for 180 days. User manual Product outlook and internal photos, Test setting up photos pursuant to 47 CFR 0.459 of the Commission Rules, we are requesting the commission to withhold the following attachments as LONG-TERM confidential document from public disclosure indefinitely. Schematic Block diagram Part List Operational Description Yours faithfully ， 02/16/2011 Mark Gandler, Sr. Regulatory Compliance Engineer Email: [email protected]

Cover Letter(s)

NETGEAR, Inc. 350 E. Plumeria Dr. San Jose, CA 95134 www.netgear.com Date: 03/02/1011 Subject: Power of Attorney To Whom It May Concern We, the undersigned, NETGEAR, Inc., hereby authorize ADT (Shanghai) Corporation of Shanghai to act on our behalf in all matters relating to all processes required in the FCC part 15 approval and any communication needed with the national authority. Any and all acts carried out by ADT-SH on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please do not hesitate to contact us. Thank you! . Date: 03/02/1011 Mark Gandler Telephone no.: 408-907-8000 Fax no.: 408-907-8097 E-mail address: [email protected]

External Photos

EXT PHOTOS

ID Label/Location Info

Please the label to the area where label 1 is pointing SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REVDESCRIPTION OF REVISIONENG APPDDATE 01AW-11432-021 of 1 AW, HSS101, V1H1, PLBLR HU 04MAY11R HUINITIAL DOCUMENT CREATION01 Pantone Process Black C Pantone 7461 C NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. INK COLOR IS SHOWN TO THE RIGHT. 5. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), UNHIDE THE WHITE BOX LAYER AND INCLUDE WHITE BOX ON LABEL. 5

Internal Photos

INT PHOTOS

RF Exposure Info

Inventec Appliances (Pudong) Corporation Report No. 110412SAR01 Page : 1 of 41 Version:1.0 SAR Test Report Product Name: iScreen Applicant: NETGEAR. lnc. Address : 350 East Plumeria Drive San Jose, CA 95134-1911 Date of Receipt: Apr.11,2011 Date of Test : Apr.12,2011 Report No. : 110412SAR01 The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of IACP EMC Lab. Inventec Appliances (Pudong) Corporation Report No. 110412SAR01 Page : 2 of 41 Version:1.0 Test Report Certification Report No. : 110412SAR01 Product Name : iScreen Applicant : NETGEAR. lnc. Address : 350 East Plumeria Drive San Jose, CA 95134-1911 Model No. : HSS101 Trade Name : iScreen Measurement Standard : IEEE C95.1-1999 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C FCC KDB 248227 D01 FCC KDB 447498 D01 Test Result : Complied The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of IACP EMC Lab Documented By : Tested By : Approved By : Inventec Appliances (Pudong) Corporation Report No. 110412SAR01 Page : 3 of 41 Version:1.0 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ------------------------------------------------------------- 5 1.1. EUT DESCRIPTION------------------------------------------------------------------------ 5 1.2. T EST ENVIRONMENT---------------------------------------------------------------------- 5 2. SAR MEASUREMENT SYSTEM ------------------------------------------------------- 6 2.1. ALSAS-10U SYSTEM DESCRIPTION---------------------------------------------------- 6 2.1.1 Applications -------------------------------------------------------------------------- 6 2.1.2 Area Scans------------------------------------------------------------------------------- 7 2.1.3 Zoom Scan (Cube Scan Averaging) ----------------------------------------------- 7 2.1.4 ALSAS-10U Interpolation and Extrapolation Uncertainty --------------------- 7 2.2 I SOTROPIC E-FIELD PROBE--------------------------------------------------------------- 8 2.2.1 I SOTROPIC E-FIELD PROBE SPECIFICATION--------------------------------------------- 9 2.3 B OUNDARY DETECTION UNIT AND PROBE MOUNTING DEVICE---------------------- 9 2.4 D AQ-PAQ (ANALOG TO DIGITAL ELECTRONICS) --------------------------------------10 2.5 A XIS ARTICULATED ROBOT-------------------------------------------------------------10 2.6 ALSAS UNIVERSAL WORKSTATION---------------------------------------------------11 2.7 U NIVERSAL DEVICE POSITIONER-------------------------------------------------------11 2.8 P HONTOM TYPES-------------------------------------------------------------------------11 2.8.1 APREL SAM Phantoms -------------------------------------------------------------12 2.8.2 APREL Laboratories Universal Phantom------------------------------------------12 3. TISSUE SIMULATING LIQUID -------------------------------------------------------13 3.1. T HE COMPOSITION OF THE TISSUE SIMULATING LIQUID-------------------------------13 3.2. T ISSUE CALIBRATION RESULT----------------------------------------------------------13 3.3. T ISSUE DIELECTRIC PARAMETERS FOR HEAD AND BODY PHANTOMS--------------14 4. SAR MEASUREMENT PROCEDURE -----------------------------------------------15 4.1. SAR SYSTEM VALIDATION--------------------------------------------------------------15 4.1.1. V ALIDATION DIPOLES-----------------------------------------------------------------15 Inventec Appliances (Pudong) Corporation Report No. 110412SAR01 Page : 4 of 41 Version:1.0 4.1.2. Validation Result----------------------------------------------------------------------15 4.2. A RRANGEMENT ASSESSMENT SETUP---------------------------------------------------16 4.2.1. Test Positions of Device Relative to Head ----------------------------------------16 4.2.2.1. Definition of the “Cheek” Position --------------------------------------------17 4.2.1.2 Definition of the “Tilted” Position -------------------------------------------18 4.2.2 Test Positions for body-worn ------------------------------------------------------19 4.3. SAR MEASUREMENT PROCEDURE-----------------------------------------------------19 5. SAR EXPOSURE LIMITS ---------------------------------------------------------------20 6. TEST EQUIPMENT LIST ---------------------------------------------------------------21 7. MEASUREMENT UNCERTAINTY ---------------------------------------------------22 8. TEST RESULTS ----------------------------------------------------------------------------23 8.1. SAR TEST RESULTS SUMMARY---------------------------------------------------------23 8.2. CONDUCT POWER-------------------------------------------------------------------------25 8.3. SAR Measurement Data ----------------------------------------------------------------- 26 SAR TEST PHOTOGRAPHS ----------------------------------------------------------------38 Inventec Appliances (Pudong) Corporation Report No. 110412SAR01 Page : 5 of 41 Version:1.0 1. GENERAL INFORMATION 1.1. EUT Description Product Name : iScreen Trade Name : iScreen TX Frequency : 802.11b: 2412MHz~2462MHz 802.11g: 2412MHz~2462MHz : 802.11n: 2412MHz~2462MHz Main antenna: Pole antenna Antenna Type : Auxiliary antenna: PCB antenna Max. Output Power (Conducted) : 802.11b: 14.5~18.5dBm 802.11g: 12.5~16.5dBm 802.11n: 11.5~15.5dBm 1.2. Test Environment Ambient conditions in the laboratory: Items Required Actural Temperature(°C) 15~30 21.4 Humidity(%RH) 30~70 46 Inventec Appliances (Pudong) Corporation Report No. 110412SAR01 Page : 6 of 41 Version:1.0 2. SAR Measurement System 2.1. ALSAS-10U System Description ALSAS-10-U is fully compliant with the technical and scientific requirements of IEEE 1528, IEC 62209, CENELEC, ARIB, ACA, and the Federal Communications Commission. The system comprises of a six axes articulated robot which utilizes a dedicated controller. ALSAS-10U uses the latest methodologies and FDTD order to …

Text truncated - open the document above for the full version.

RF Exposure Info

Inventec Appliances(Pudong) Corporation Page : 1 of 20 Version:1.0 Dipole calibration report Inventec Appliances(Pudong) Corporation Page : 2 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 3 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 4 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 5 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 6 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 7 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 8 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 9 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 10 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 11 of 20 Version:1.0 Probe calibration report Inventec Appliances(Pudong) Corporation Page : 12 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 13 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 14 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 15 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 16 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 17 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 18 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 19 of 20 Version:1.0 Inventec Appliances(Pudong) Corporation Page : 20 of 20 Version:1.0

Test Report

Report No.: 110215FIA01 Page 1 of 156 Report Format Version 2.1.0 FCC TEST REPORT (15.247) REPORT NO.: 110215FIA01 MODEL NO.: HSS101 RECEIVED: Mar. 02, 2011 TESTED: Mar. 07 – Mar. 21, 2011 ISSUED: Mar. 31, 2011 APPLICANT: NETGEAR. Inc. ADDRESS: 350 East Plumeria Drive San Jose, CA 95134-1911 ISSUED BY: BUREAU VERITAS ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan rd., 201103, Shanghai, China This test report consists of 156 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: 110215FIA01 Page 2 of 156 Report Format Version 2.1.0 TABLE OF CONTENTS 1. CERTIFICATION ................................................................................................. 3 2. SUMMARY OF TEST RESULTS......................................................................... 4 2.1 MEASUREMENT UNCERTAINTY............................................................................................................. 4 3. GENERAL INFORMATION ................................................................................. 5 3.1 GENERAL DESCRIPTION OF EUT ....................................................................................................... 5 3.2 DESCRIPTION OF TEST MODES .......................................................................................................... 7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................... 12 3.4 DESCRIPTION OF SUPPORT UNITS...................................................................................................12 4. TEST TYPES AND RESULTS .......................................................................... 13 4.1 RADIATED EMISSION MEASUREMENT .......................................................................................... 13 4.2 CONDUCTED EMISSION MEASUREMENT...................................................................................... 83 4.3 6dB BANDWIDTH MEASUREMENT ................................................................................................... 94 4.4 MAXIMUM PEAK OUTPUT POWER .................................................................................................112 4.5 POWER SPECTRAL DENSITY MEASUREMENT............................................................................118 4.6 BAND EDGES MEASUREMENT ........................................................................................................ 136 4.7 ANTENNA REQUIREMENT ................................................................................................................ 155 5. APPENDIX - INFORMATION ON THE TESTING LABORATORIES.............. 156 Report No.: 110215FIA01 Page 3 of 156 Report Format Version 2.1.0 1. CERTIFICATION PRODUCT: iScreen MODEL: HSS101 BRAND: NETGEAR APPLICANT: NETGEAR. Inc. TEST SAMPLE: ENGINEERING SAMPLE TESTED: Mar. 07 – Mar. 21, 2011 STANDARDS: FCC Part 15, Subpart C (Section 15.247) ANSI C63.4-2003 The above equipment (Model: HSS101) has been tested by Bureau Veritas Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Mar. 31, 2011 Kevin Jiang Engineer TECHNICAL ACCEPTANCE : , DATE: Mar. 31, 2011 Joy Zhu Lab Manager APPROVED BY : , DATE: Mar. 31, 2011 Zhaoqian Yu Director of Operations Report No.: 110215FIA01 Page 4 of 156 Report Format Version 2.1.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC PART 15, SUBPART C (SECTION 15.247) STANDARD SECTION TEST TYPE AND LIMIT RESULTREMARK 15.207 AC Power Conducted Emission PASS Meet the requirement of limit. Minimum passing margin is -15.35dB at 0.21647MHz 15.247(a)(2) Spectrum Bandwidth of a Direct Sequence Spread Spectrum System Limit: min. 500kHz PASS Meet the requirement of limit. 15.247(b) Maximum Peak Output Power Limit: max. 30dBm PASS Meet the requirement of limit. 15.247(d) Radiated Emissions Limit: Table 15.209 PASS Meet the requirement of limit. Minimum passing margin is -2.13dB at 87.52MHz 15.247(e) Power Spectral Density Limit: max. 8dBm PASS Meet the requirement of limit. 15.247(d) Band Edge Measurement Limit: 20dB less than the peak value of fundamental frequency PASS Meet the requirement of limit. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2 Ed 1.0. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. This lab’s measurement uncertainty U Lab , is low than U Cispr , Table 1 – Values of U Cispr of CISPR 16-4-2 Ed. 1.0, therefore compliance is deemed to occur if no measured disturbance exceeds the disturbance limit. Measurement Value Conducted emissions 2.55 dB Conducted emissions at telecom port 2.6180 dB Radiated emissions 3.99 dB Report No.: 110215FIA01 Page 5 of 156 Report Format Version 2.1.0 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT EUT iScreen MODEL NO. HSS101 FCC ID PY310400150 POWER SUPPLY Power received from host unit DC 5V nominal,range 4.99-5.01V MODULATION TYPE CCK, DQPSK, DBPSK ,OFDM for DSSS MODULATION TECHNOLOGY DSSS and OFDM TRANSFER RATE 802.11b:11/ 5.5/ 2/1Mbps 802.11g: 54/ 48/ 36/ 24/ 18/ 12/ 9/ 6Mbps 802.11n: MCS0~MCS7,HT20&HT40 FREQUENCY RANGE 2.4GHz: 2400 ~ 2483.5MHz NUMBER OF CHANNEL 2.4GHz: 11 for 802.11b, 802.11g, 802.11n (20MHz) 7 for …

Text truncated - open the document above for the full version.

Test Setup Photos

CONDUCTED EMISSION MEASUREMENT RADIATED EMISSION MEASUREMENT

Test Setup Photos

Report No. 110412SAR01 Page : 1 of 41 Version:1.0 SAR Test Photographs Photo of Liquid Height for Body SAR Bottom flated Report No. 110412SAR01 Page : 2 of 41 Version:1.0 Left edge To p e d g e Report No. 110412SAR01 Page : 3 of 41 Version:1.0 EUT Report No. 110412SAR01 Page : 4 of 41 Version:1.0

Contact Information

Applicant

David Kay

[email protected]4088903160Fax: 4089078097

Technical Contact

ADT (Shanghai) CorporationWallace Pan

[email protected]86-21-64659091-201

2F, Building C, No. 1618, Yishan Rd., · Shanghai · China

Non-Technical Contact

ADT (Shanghai) CorporationJoy ZHU

[email protected]86-21-64659091-205

Test Firm

BUREAU VERITAS ADT (Shanghai) CorporationZhaoqian YU

[email protected]862164659091Fax: 862164659092

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	95.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. Device is an 802.11bgn wireless touch screen. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The highest reported body SAR value is: 0.728 W/kg.
