Installation Guide ADT Pulse Gateway PGZNG1 Package Contents Gateway Wall mount kit Stand Power adapter Connecting the Gateway 1. Verify the package contents. 2. Decide where to place the Gateway. Locate the broadband router on the premises. Then identify a relatively central location within the premise to place the Gateway for optimal Wi-Fi coverage, and where there is an AC outlet. 3. Place the Gateway either flat, or prepare the Gateway for vertical installation either on a flat surface or mounted to a wall. 4. Connect and verify all of the cables. a.Connect an Ethernet cable from one of the broadband open ports of the router to the Broadband Ethernet port of the Gateway. b.Connect a 4-wire cable from the security panel to the Gateway’s Security connector. c.Verify that all wiring and connections are done correctly. 5. Start up the Gateway. a.Plug the power cord into the Gateway, and then plug the power adapter into an AC outlet. b.Wait until the Connection LED on the Gateway becomes solid green (approximately 5 minutes, during which the Gateway establishes remote connectivity with ADT Pulse). 6. Begin the activation process. Go to https://www.adtpulse.com/activation Warning: Do not stack equipment, or place equipment in tight spaces, in drawers, or on carpets. Make sure that your equipment is surrounded by at least 2 inches (5 centimeters) of air space. (a) Flat mount (c) Wall mount (b) Vertical mount 5 1/2 inches 3/16 inches Broadband routerPGZNG1 gatewaySecurity panel June 2012 © 2012 by NETGEAR, Inc. All rights reserved. NETGEAR and the NETGEAR logo are registered trademarks of NETGEAR, Inc. in the United States and/or other countries. Other brand and product names are trademarks or registered trademarks of their respective holders. Information is subject to change without notice . Troubleshooting Use the LEDs on the front of the unit to determine its status and to troubleshoot its operation. For the complete DoC, go to the NETGEAR EU Declarations of Conformity website at http://support.netgear.com/app/answers/detail/a_id/11621/. For GNU General Public License (GPL) related information, go to http://support.netgear.com/app/answers/detail/a_id/2649 LEDDescription Devices •Solid green: Unit is able to communicate with all devices. •Blinking green: All devices are OK, and unit is communicating with a device. •Solid orange: Unit is unable to communicate with at least one device that has been previously installed and working. •Blinking orange: Unit is communicating with a device, but is having trouble communicating with other devices. •Blinking red: Unit is unable to communicate with the security panel. •Solid red: Unit is unable to communicate with the security panel, but device traffic is occurring. •Off: Unit is still starting up. Wi-Fi •Solid green: Unit is linked with Wi-Fi clients. •Blinking green: Data is being transmitted or received over Wi-Fi. •Off: Wi-Fi is disabled. Connection •Solid green: Unit is connected for remote access. •Pulsing green: Unit is establishing a connection for remote access. •Blinking green: Data is being exchanged with remote access. •Solid orange: Unit is ready for activation. •Pulsing orange: Unit is trying to reconnect for remote access. •Solid red: Unit is unable to communicate with remote access. •Off: Unit is still starting up. Power •Solid green: Unit is powered on. •Blinking green: Firmware upgrade is in progress. •Solid red: POST (Power On Self Test) failure or device malfunction. •Off: Unit is powered off. FCC Requirements for Operation in the United States FCC Information to User This product does not contain any user serviceable components and is to be used with approved antennas only. Any product changes or modifications will invalidate all applicable regulatory certifications and approvals. FCC Guidelines for Human Exposure This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Declaration of Conformity We, NETGEAR, Inc., 350 East Plumeria Drive, San Jose, CA 95134, declare under our sole responsibility that the ADT Pulse Gateway PGZNG1 complies with Part 15 Subpart B of FCC CFR47 Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. FCC Radio Frequency Interference Warnings & Instructions This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following methods: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an electrical outlet on a circuit different from that which the radio receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Caution • Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. • This device complies with Part 15 of the FCC Rules. Operation is subject to the following two…

Text truncated - open the document above for the full version.

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Declaration for no non‐US channel operation July 2, 2012 We, Netgear Incorporated declare that the device does not support any non-US channels in all the operational mode(s), like Ad-Hoc...etc, for the following product. FCC ID: PY312100192 If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Mark Gandler / project manager Netgear INC. TEL:+1 408‐907‐8000 Fax:+1 408‐907‐8097 E‐mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-06-28 FCC ID: PY312100192 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ___________________________________ Mark Gandler / project manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-06-28 FCC ID: PY312100192 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to DA 04-1705 of the commission’s public notice, we request short-term confidential treatment for the following information until 2012/9/14 in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ___________________________________ Mark Gandler / project manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-06-28 AUTHORIZATION LETTER To whom it may concern: We, the undersigned Netgear Incorporated hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15C and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------ Mark Gandler / project manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Report No.: 120511C23 1 of 12 Report Format Version 5.0.0 CONSTRUCTION PHOTOS OF EUT Report No.: 120511C23 2 of 12 Report Format Version 5.0.0 Report No.: 120511C23 3 of 12 Report Format Version 5.0.0 Model No.: AD817F10 Report No.: 120511C23 4 of 12 Report Format Version 5.0.0 Report No.: 120511C23 5 of 12 Report Format Version 5.0.0 Model No.: MT18-9120150-A1 Report No.: 120511C23 6 of 12 Report Format Version 5.0.0 Report No.: 120511C23 7 of 12 Report Format Version 5.0.0 Model No.: SAL018F1 NA Report No.: 120511C23 8 of 12 Report Format Version 5.0.0

Report No.: 120511C23 1 of 4 Report Format Version 5.0.0 CONSTRUCTION PHOTOS OF EUT Report No.: 120511C23 2 of 4 Report Format Version 5.0.0 Report No.: 120511C23 3 of 4 Report Format Version 5.0.0 Report No.: 120511C23 4 of 4 Report Format Version 5.0.0

FCC ID: PY312100192 Report No.: RF 120511C23 Operational Description This device is an Home Security, which operates in 2.4GHz band; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the 12Vdc from Power Adapter. The antennas are PIFA antennas without antenna connector. The other instruction, please have a look at the users manual.

FCC ID: PY312100192 Report No.: RF 120511C23 Operational Description The transmitter of the EUT (Home Security) is powered by 12Vdc from AC adapter. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference. For more detailed instruction, please take a look at the user’s manual.

Report No.: SA120511C23 1 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 RF EXPOSURE REPORT REPORT NO.: SA120511C23 MODEL NO.: PGZNG1, C24-HUB2, ASG1000 FCC ID: PY312100192 RECEIVED: May 11, 2012 TESTED: May 18, 2012 ISSUED: June 27, 2012 APPLICANT: Netgear Incorporated ADDRESS: 350 East Plumeria Drive San Jose California United States 95134 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA120511C23 2 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA120511C23 3 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120511C23 Original release June 27, 2012 Report No.: SA120511C23 4 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 1. CERTIFICATION PRODUCT: Home Security BRAND NAME: ADT, DSC, NTGR, G2i MODEL NO.: PGZNG1, C24-HUB2, ASG1000 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Netgear Incorporated TESTED DATE: May 18, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: PGZNG1) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: May 15, 2011 ( Phoenix Huang, Specialist ) APPROVED BY : , DATE: May 15, 2011 ( May Chen, Deputy Manager ) Report No.: SA120511C23 5 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA120511C23 6 of 6 Report Format Version 5.0.0 Cancels and replaces the report No.: SA110718E01 dated Aug. 19, 2011 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For WLAN: 15.247(2.4GHz) There are Zwave technology and WLAN technology used for the EUT. This report was only recorded at the WLAN technology. FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 734.613 6.94 20 0.72242 1.00 Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] Effective Legacy Gain (dBi) = 6.94 ---END---

Report No.: RF120511C23 1 of 59 Report Format Version 5.0.0 Reference No.: 110719E01, 120110E14 FCC TEST REPORT REPORT NO.: RF120511C23 MODEL NO.: PGZNG1, C24-HUB2, ASG1000 FCC ID: PY312100192 RECEIVED: May 11, 2012 TESTED: May 15 to 21, 2012 ISSUED: June 27, 2012 APPLICANT: Netgear Incorporated ADDRESS: 350 East Plumeria Drive San Jose California United States 95134 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120511C23 2 of 59 Report Format Version 5.0.0 Reference No.: 110719E01, 120110E14 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 6 3. GENERAL INFORMATION ..................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 7 3.2 DESCRIPTION OF TEST MODES ....................................................................... 10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 15 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 16 4. TEST TYPES AND RESULTS .............................................................................. 17 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 17 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 17 4.1.2 TEST INSTRUMENTS .......................................................................................... 17 4.1.3 TEST PROCEDURES .......................................................................................... 18 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 18 4.1.5 TEST SETUP ....................................................................................................... 19 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 19 4.1.7 TEST RESULTS (MODE 1) .................................................................................. 20 4.1.8 TEST RESULTS (MODE 2) .................................................................................. 22 4.1.9 TEST RESULTS (MODE 3) .................................................................................. 24 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 26 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 26 4.2.2 TEST INSTRUMENTS .......................................................................................... 27 4.2.3 TEST PROCEDURES .......................................................................................... 28 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 28 4.2.5 TEST SETUP ....................................................................................................... 29 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 29 4.2.7 TEST RESULTS ................................................................................................... 30 4.3 6dB BANDWIDTH MEASUREMENT .................................................................... 43 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................. 43 4.3.2 TEST INSTRUMENTS .......................................................................................... 43 4.3.3 TEST PROCEDURE ............................................................................................. 43 4.3.4 DEVIATION FROM TEST STANDARD…

Text truncated - open the document above for the full version.

Report No.: RF120511C23-1 1 of 32 Report Format Version 5.0.0 Reference no.:120424E05 FCC TEST REPORT REPORT NO.: RF120511C23-1 MODEL NO.: PGZNG1, C24-HUB2, ASG1000 FCC ID: PY312100192 RECEIVED: May 11, 2012 TESTED: May 23 to 24, 2012 ISSUED: June 27, 2012 APPLICANT: Netgear Incorporated ADDRESS: 350 East Plumeria Drive San Jose California United States 95134 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120511C23-1 2 of 32 Report Format Version 5.0.0 Reference no.:120424E05 Table of Contents RELEASE CONTROL RECORD ......................................................................................................... 3 1. CERTIFICATION .................................................................................................................... 4 2. SUMMARY OF TEST RESULTS ............................................................................................. 5 2.1 MEASUREMENT UNCERTAINTY .......................................................................................... 5 3. GENERAL INFORMATION ..................................................................................................... 6 3.1 GENERAL DESCRIPTION OF EUT ........................................................................................ 6 3.2 DESCRIPTION OF TEST MODES .......................................................................................... 8 3.3 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL............................................ 8 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................................. 10 3.4.1 CONFIGURATION OF SYSTEM UNDER TEST ..................................................................... 11 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................ 12 4. TEST TYPES AND RESULTS ............................................................................................... 13 4.1 CONDUCTED EMISSION MEASUREMENT ......................................................................... 13 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ....................................................... 13 4.1.2 TEST INSTRUMENTS .......................................................................................................... 13 4.1.3 TEST PROCEDURES .......................................................................................................... 14 4.1.4 DEVIATION FROM TEST STANDARD.................................................................................. 14 4.1.5 TEST SETUP ....................................................................................................................... 14 4.1.6 EUT OPERATING CONDITIONS .......................................................................................... 15 4.1.7 TEST RESULTS (MODE 1) ................................................................................................... 16 4.1.8 TEST RESULTS (MODE 2) ................................................................................................... 18 4.1.9 TEST RESULTS (MODE 3) ................................................................................................... 20 4.2 RADIATED EMISSION AND BAND EDGE MEASUREMENT ................................................ 22 4.2.1 LIMITS OF RADIATED EMISSION AND BAND EDGE MEASUREMENT .............................. 22 4.2.2 TEST INSTRUMENTS .......................................................................................................... 23 4.2.3 TEST PROCEDURES .......................................................................................................... 25 4.2.4 DEVIATION FROM TEST STANDARD.................................................................................. 25 4.2.5 TEST SETUP ....................................................................................................................... 26 4.2.6 EUT OPERATING CONDITIONS .......................................................................................... 26 4.2.7 TEST RESULTS ................................................................................................................... 27 5. PHO…

Text truncated - open the document above for the full version.

Report No.: 120511C23 1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST(Mode 1) Report No.: 120511C23 2 CONDUCTED EMISSION TEST(Mode 2) Report No.: 120511C23 3 CONDUCTED EMISSION TEST(Mode 3) Report No.: 120511C23 4 RADIATED EMISSION TEST
