350 East Plumeria Drive San Jose, CA 95134 USA July 2012 202-11003-01 v1.0 Powerline 500 WiFi Access Point (XWN5001) User Manual This manual is for certification purposes only. The art, screen captures, and descriptions might vary from the actual device. 2 Powerline 500 WiFi Access Point (XWN5001) ©2012 NETGEAR, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of NETGEAR, Inc. Technical Support Thank you for choosing NETGEAR. To register your product, get the latest product updates, or get support online, visit us at http://support.netgear.com. Phone (US & Canada only): 1-888-NETGEAR Phone (Other Countries): Check the list of phone numbers at http://support.netgear.com/app/answers/detail/a_id/984. Trademarks NETGEAR, the NETGEAR logo, ReadyNAS, ProSafe, Smart Wizard, Auto Uplink, X-RAID2, and NeoTV are trademarks or registered trademarks of NETGEAR, Inc. Microsoft, Windows, Windows NT, and Vista are registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders. Statement of Conditions To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use, or application of, the product(s) or circuit layout(s) described herein. 3 Contents Chapter 1 Getting Started Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 LED and Feature Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 How the Powerline AV 500 Access Point Fits in Your Network . . . . . . . . . . 7 Set Up the Powerline Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Set Up a New Powerline Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Add the Powerline Access Point to an Existing Powerline Network . . . . . 9 Set Up the Access Point Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . 10 Method A: Use the Powerline Utility for Wireless Setup . . . . . . . . . . . . . 10 Method B: Use the WPS Button for Wireless Setup . . . . . . . . . . . . . . . . 11 Join the Powerline Access Point Wireless Network . . . . . . . . . . . . . . . . . . 12 Powerline Network Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Use the Security Button to Set the Encryption Key . . . . . . . . . . . . . . . . . . 13 Set the Encryption Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Chapter 2 Powerline Utility Install the Powerline Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Powerline Utility Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Security Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Change the Name of a Powerline Device. . . . . . . . . . . . . . . . . . . . . . . . . . 18 Turn LEDs Off or On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Set the Powerline Encryption Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Reset a Device to Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Add a Device to the Powerline Network . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Set Up Quality of Service (QoS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Advanced Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Chapter 3 Troubleshooting Basic Functioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 If You Do Not See All Your Devices with the Powerline Utility . . . . . . . . . . 29 Appendix A Supplemental Information Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Appendix B Notification of Compliance Index 4 1 1. Getting Started This chapter describes your Powerline 500 WiFi Access Point (XWN5001), and how your adapters can fit into a home network. It also explains the security features and how to customize the encryption key for added security. For more information about the topics covered in this manual, visit the support website at http://support.netgear.com. This chapter includes the following sections: • Hardware Features • How the Powerline AV 500 Access Point Fits in Your Network • Set Up the Powerline Network • Powerline Network Security • Set Up the Access Point Wireless Network • Join the Access Point Wireless Network • Use the Security Button to Set the Encryption Key • Use the Security Button to Set the Encryption Key • Set the Encryption Key Getting Started 5 Powerline 500 WiFi Access Point (XWN5001) Hardware Features The package includes a Powerline 500 WiFi Access Point (XWN5001), a Resource CD, and an Ethernet cable. Powerline 500 WiFi Access Point Ethernet cable Figure 1. Package contents The following illustration shows the front and side panels of the XWN5001: LEDs Security button Reset button On/Off button Ethernet port Figure 2. Powerline 500 WiFi Access Point (XWN5001) Getting Started 6 Powerline 500 WiFi Access Point (XWN5001) LED and Feature Descriptions The following tab…

Text truncated - open the document above for the full version.

Date: June 29, 2012 Subject: Ad Hoc Mode Function Declaration FCC ID: PY312200195 To Whom it may concern, We, Netgear Incorporated, declare that the device (FCC ID: PY312200195) 1. is able to be operated on both master and client mode. 2. Ad Hoc function is available on client mode. 3. does not work in non-US/Canada frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Applicant : Netgear Incorporated Address : 350 East Plumeria Drive, San Jose, California 95134 United States Signature : _________________________________ Name and Job Title. : Mark Gandler / Compliance Engineer E-mail : [email protected] Te l . : +1 408-907-8000

Confidentiality Request Letter Date: 2012/6/29 Federal Communications Commission Authorization and Evaluation Division FCC ID：PY312200195 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : Netgear Incorporated Applicant’s company address : 350 East Plumeria Drive, San Jose, California 95134 United States Signature : _________________________________ Job Title and Dept. : Mark Gandler / Compliance Engineer E-mail : [email protected] Tel. : +1 408-907-8000

Date: 2012/6/29 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Product Certification Representative Authorization Letter FCC ID: PY312200195 Product name: Powerline 200 WiFi Range Extender , Powerline 500 WiFi Range Extender To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model XAVN2001v2; XWN5001 to the FCC Rules and Regulations. Sporton International Inc. Address : No. 52, Hwa Ya 1st Road., Kwei-Shan Hsiang, TaoYuan Hsien Taiwan R.O.C. Name : Wayne Hsu Job Title : Vice Manager e-mail : [email protected] We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Netgear Incorporated Address : 350 East Plumeria Drive, San Jose, California 95134 United States Signature : _________________________________ Name and Job Title. : Mark Gandler / Compliance Engineer E-mail : [email protected] Tel. : +1 408-907-8000

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B1 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B2 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B1 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B3 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B4 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B5 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B6 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B7 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B8 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B9 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B10 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B11 OF B11 TEL : 886-3-327-3456 ISSUED DATE : Jun. 28, 2012 FAX : 886-3-327-0973

SPORTON INTERNATIONAL INC. Page No. : 1 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 1 Human Exposure Assessment 1.1 Maximum Permissible Exposure 1.1.1 Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310 SPORTON INTERNATIONAL INC. Page No. : 2 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 600 4.9 - 6 1-10 600/ƒ 4.9/ƒ - 6 10-30 60 4.9/ƒ - 6 30-300 60 0.163 10* 6 300-1500 3.54 ƒ 0.5 0.0094 ƒ 0.5 ƒ/30 6 1500-15000 137 0.364 50 6 15000-150000 137 0.364 50 616000/ƒ 1.2 150000-300000 0.354 ƒ 0.5 9.4 x 10-4 ƒ 0.5 3.33 x 10-4 ƒ 616000/ƒ 1.2 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/ƒ 2.19/ƒ - 6 10-30 28 2.19/ƒ - 6 30-300 28 0.073 2* 6 300-1500 1.585 ƒ 0.5 0.0042 ƒ 0.5 ƒ/150 6 1500-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note 1: ƒ is frequency in MHz. Note 2: For the applicable limit, see IC RSS-102 1.1.2 MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric field (V/m) P = RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d377 GP30   SPORTON INTERNATIONAL INC. Page No. : 3 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 1.1.3 Result of Maximum Permissible Exposure Transmitter Chains & Receiver Chains Information IEEE Std. 802.11 Protocol Number of Transmit Chains (N TX ) Number of Receive Chains (N RX ) Correlation Signals with Multiple N TX RF Output Power (dBm) Co-location b 2 2 N/A 19.75 N/A g 2 2 Correlated 19.84 N/A n (HT20) 2 2 Uncorrelated 18.44 N/A n (HT40) 2 2 Uncorrelated 17.66 N/A Note 1: Co-location, Co-location is generally defined as simultaneously transmitting (co-transmitting) antennas within 20 cm of each other. (i.e., EUT has simultaneously co-transmitting that operating 2.4GHz and 5GHz.) Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Power Level 1 RF Output Power (dBm) Modulation Mode N TX Chain- Port 1 Chain- Port 2 - - Sum Chain Gain (dBi) EIRP Power PD (S) (mW/cm²) 11B-20M 2 16.89 16.58 - - 19.75 5.73 25.48 0.0702 11G-20M 2 17.01 16.65 - - 19.84 5.73 25.57 0.0718 11N2.4G-20M 2 15.47 15.38 - - 18.44 2.73 21.16 0.0260 11N2.4G-40M 2 14.74 14.55 - - 17.66 2.73 20.38 0.0217 Maximum Permissible Exposure Limit (mW/cm²) 1 Note 1: N TX = Number of Transmit Chains

SPORTON INTERNATIONAL INC. Page No. : 51 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 3.6.4 Test Setup Transmitter Radiated Unwanted Emissions Magnetic field tests shall be performed in the frequency range of 9 kHz to 30 MHz using a calibrated loop antenna. Electric field tests shall be performed in the frequency range of 30 MHz to 1000 MHz using a calibrated bi-log antenna and the frequency range of 1 GHz to 40 GHz using a calibrated horn antenna. SPORTON INTERNATIONAL INC. Page No. : 52 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 3.6.5 Test Result of Transmitter Radiated Unwanted Emissions (Below 1GHz) Transmitter Radiated Unwanted Emissions (Below 1GHz) Modulation Mode 11N2.4G-20M Power Level 1 Test Freq. (FX) F2 Operating Mode 1 Ant. No. 1 Polarization V Operating Function Normal Link Note 1: “>20dB” means spurious emission levels that exceed the level of 20 dB below the applicable limit. Note 2: “N/F” means Nothing Found spurious emissions (No spurious emissions were detected.) Note 3: Measurement receive antenna polarization: H (Horizontal), V (Vertical) SPORTON INTERNATIONAL INC. Page No. : 53 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Transmitter Radiated Unwanted Emissions (Below 1GHz) Modulation Mode 11N2.4G-20M Power Level 1 Test Freq. (FX) F2 Operating Mode 1 Ant. No. 1 Polarization H Operating Function Charger + POE + Normal Link... Note 1: “>20dB” means spurious emission levels that exceed the level of 20 dB below the applicable limit. Note 2: “N/F” means Nothing Found spurious emissions (No spurious emissions were detected.) Note 3: Measurement receive antenna polarization: H (Horizontal), V (Vertical) SPORTON INTERNATIONAL INC. Page No. : 54 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 3.6.6 Test Result of Transmitter Radiated Unwanted Emissions (Above 1GHz) Transmitter Radiated Unwanted Emissions (Above 1GHz) Modulation Mode 11B-20M Power Level 1 Test Freq. (FX) F1 Operating Function Transmit Ant. No. 1 Polarization V Note 1: “>20dB” means spurious emission levels that exceed the level of 20 dB below the applicable limit. Note 2: “N/F” means Nothing Found spurious emissions (No spurious emissions were detected.) Note 3: Measurement receive antenna polarization: H (Horizontal), V (Vertical) Note 4: For un-restricted bands, unwanted emissions (item 3 and 4) shall be attenuated by at least 20 dB relative to the maximum measured in-band level. SPORTON INTERNATIONAL INC. Page No. : 55 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Transmitter Radiated Unwanted Emissions (Above 1GHz) Modulation Mode 11B-20M Power Level 1 Test Freq. (FX) F1 Operating Function Transmit Ant. No. 1 Polarization H Note 1: “>20dB” means spurious emission levels that exceed the level of 20 dB below the applicable limit. Note 2: “N/F” means Nothing Found spurious emissions (No spurious emissions were detected.) Note 3: Measurement receive antenna polarization: H (Horizontal), V (Vertical) Note 4: For un-restricted bands, unwanted emissions (item 3 and 4) shall be attenuated by at least 20 dB relative to the maximum measured in-band level. SPORTON INTERNATIONAL INC. Page No. : 56 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Transmitter Radiated Unwanted Emissions (Above 1GHz) Modulation Mode 11B-20M Power Level 1 Test Freq. (FX) F2 Operating Function Transmit Ant. No. 1 Polarization V Note 1: “>20dB” means spurious emission levels that exceed the level of 20 dB below the applicable limit. Note 2: “N/F” means Nothing Found spurious emissions (No spurious emissions were detected.) Note 3: Measurement receive antenna polarization: H (Horizontal), V (Vertical) Note 4: For un-restricted bands, unwanted emissions (item 5) shall be attenuated by at least 20 dB relative to the maximum measured in-band level. SPORTON INTERNATIONAL INC. Page No. : 57 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Transmitter Radiated Unwanted Emissions (Above 1GHz) Modulation Mode 11B-20M Power Level 1 Test Freq. (FX) F2 Operating Function Transmit Ant. No. 1 Polarization H Note 1: “>20dB” means spurious emission levels that exceed the level of 20 dB below the applicable limit. Note 2: “N/F” means Nothing Found spurious emissions (No spurious emissions were detected.) Note 3: Measurement receive antenna polarization: H (Horizontal), V (Vertical) Note 4: For un-restricted bands, unwanted emissions (item 4) shall be attenuated by at least 20 dB relative to the maximum measured in-band level. SPORTON INTERNATIONAL INC. Page No. : 58 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Transmitter Radiated Unwanted Emissions (Above 1GHz) Modulation Mode 11B-20M Power Level 1 Test Freq. (FX) F3 Operating Function Transmit Ant. No. 1 Polarization V Note 1: “>20dB” means spurious emission levels that exceed the level of 20 dB below the applicable limit. Note 2: “N/F” means Nothing Found spurious emissions (No spurious emissions were detected.) Note 3: Measurement receive antenna polarization: H (Horizontal), V (Vertical) Note 4: For un-restricted bands, unwanted emissions (item 4) shall be attenuated by at least 20 dB relative to the maximum measured in-band level. SPORTON INTERNATIONAL INC. Page No. : 59 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Transmitter Radiated Unwanted Emissions (Above 1GHz) Modulation Mode 11B-20M Power Level 1 Test Freq. (FX) F3 Operating Function Transmit Ant. No. 1 Polarization H Note 1: “>20dB” means spurious emission levels that …

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page No. : 1 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 FCC Test Report Equipment Model No. : Powerline 200 WiFi Range Extender XAVN2001v2 Equipment Model No. : Powerline 500 WiFi Range Extender XWN5001 Brand Name : NETGEAR FCC ID : PY312200195 Standard : 47 CFR FCC Part 15.247 Applicant : NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, United States Manufacturer : DELTA NETWORKS, INC. 252, Shang Ying Road, Kuei San Taoyuan Shien 333, Taiwan, R.O.C. The product sample received on Jun. 06, 2012 and completely tested on Jun. 19, 2012. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Wayne Hsu / Assistant Manager SPORTON INTERNATIONAL INC. Page No. : 2 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Accessories and Support Equipment ..................................................................................................... 8 1.3 Testing Applied Standards ..................................................................................................................... 8 1.4 Testing Location Information .................................................................................................................. 8 1.5 Measurement Uncertainty ...................................................................................................................... 9 2 TEST CONFIGURATION OF EUT ...................................................................................................... 10 2.1 The Worst Case Modulation Configuration .......................................................................................... 10 2.2 Test Channel Frequencies Configuration ............................................................................................. 10 2.3 The Worst Case Power Setting Parameter .......................................................................................... 11 2.4 The Worst Case Measurement Configuration ...................................................................................... 12 2.5 Test Setup Diagram ............................................................................................................................. 14 3 TRANSMITTER TEST RESULT .......................................................................................................... 16 3.1 AC Power-line Conducted Emissions .................................................................................................. 16 3.2 6dB Bandwidth ..................................................................................................................................... 19 3.3 RF Output Power .................................................................................................................................. 25 3.4 Power Spectral Density ........................................................................................................................ 35 3.5 Transmitter Radiated Bandedge Emissions ......................................................................................... 40 3.6 Transmitter Radiated Unwanted Emissions ......................................................................................... 48 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 78 5 CERTIFICATION OF TAF ACCREDITATION ..................................................................................... 79 APPENDIX A. TEST PHOTOS ....................................................................................................................... A5 APPENDIX B. PHOTOGRAPHS OF EUT .................................................................................................... B11 SPORTON INTERNATIONAL INC. Page No. : 3 of 79 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna RequirementAntenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions 0.16241MHz: 41.83dBuV (13.51dB) - AV 53.07dBuV (12.27dB) - QP FCC 15.207 Complied 3.2 15.247(a) 6dB Bandwidth 6dB Bandwidth Unit [MHz] 2412-2462MHz: 10.34-DSSS 2412-2462MHz: 17.80-OFDM 2422-2452MHz: 36.36-OFDM ≥500kHz Complied 3.3 15.247(b) RF Output Power (Maximum Peak Conducted Output Power) Power [dBm] 2412-2462MHz: 25.76-DSSS 2412-2462MHz: 27.28-OFDM 2422-2452MHz: 25.71-OFDM Power [dBm] 2412-2462MHz: 30 2422-2452MHz: 30 Complied 3.4 15.247(d) Power Spectral Density PSD [dBm/3kHz] 2412-2462MHz: -8.06-DSSS 2412-2462MHz: -11.27-OFDM 2422-2452MHz: -14.89-OFDM PSD [dBm/3kHz] 2412-2462MHz: 8 2422-2452MHz: 8 Complied 3.5 15.247(c) Transmitter Radiated Bandedge Emissions Non-Restricted Bands: 2400.00MHz: 29.62dB Restricted Bands [dBuV/m at 3m]: 2484.56MHz: 67.52 (Margin 6.48dB) - PK 52.86 (Margin 1.14dB) - AV Non-Restricted Bands: > 20 dB Restricted Bands: FCC 15.209 Complied 3.6 15.247(c) Transmitter Radiated Unwanted Emissions Restricted Bands [dBuV/m at 3m]: 4824.00MHz: 59.55 (Margin 14.45dB) - PK 53.00 (Margin 1dB) - AV Non-Restricted Bands: > 20 dB Restricted B…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page No. : A1 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 Appendix A. Test Photos SPORTON INTERNATIONAL INC. Page No. : A2 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW SPORTON INTERNATIONAL INC. Page No. : A3 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW SPORTON INTERNATIONAL INC. Page No. : A4 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW SPORTON INTERNATIONAL INC. Page No. : A5 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC TEST REPORT Report No. : FR260110 For radiated emissions above 1GHz FRONT VIEW REAR VIEW
