Installation Guide Installation To install and set up the Push2TV adapter with Intel WiDi: 1. Connect the Push2TV adapter to your TV and plug in the power adapter. The Push2TV adapter LED is blinking when the adapter powers up. The LED turns solid to indicate that the adapter is ready, but is not yet connected to your computer. 2. Turn on your TV and select the correct TV input source for your TV. • If you are not sure which input source to use, check the documentation that came with your TV set. • The Ready for Connection screen displays on your TV within 30 seconds. If you do not see this screen, make sure that the TV input is set to the HDMI port where the Push2TV adapter is connected and all cable connections are firmly secured. 3. On your laptop, launch the Intel Wireless Display software. There are two ways to launch the software • If your laptop has a button or key, press it. • From Windows, select Start. In the search field, type Intel Wireless Display. Select and run the Intel Wireless Display software. 4. Use the Intel Wireless Display software to scan and find the Push2TV adapter. The screen on the right shows that the Intel Wireless Display software has found the wireless adapter. 5. Double-click the detected Push2TV adapter to connect to it. 6. If you are connecting the laptop to the Push2TV adapter for the first time, the Push2TV adapter displays a 4-digit security code on the TV. Enter this 4-digit security code into the Intel Wireless Display software. 7. Within a few seconds, the TV screen displays your laptop screen. The LED on the Push2TV adapter turns solid. You are now ready to use Push2TV for Intel Wireless Display. Adjusting Your TV Display You can adjust the image display on the TV screen: • To change how the image fits on the TV screen, on the Intel Wireless Display, click the Properties button. Then click the Resize TV picture button and adjust the picture using the plus or minus symbols. • To remove black bars displayed on the sides of your TV screen, open the graphics properties and change the resolution to 1280x720. Changing the resolution might result in black bars on the laptop. To remove the black bars, open the graphics properties and clear the preserve aspect ratio check box. Push2TV Adapter for Wireless Display (PTV3000) Package Contents Push2TV Front and Back Views USB power cable Push2TV adapter Power adapter HDMI LED USB Power Reset Wireless Display Mode / WPS PTV3000 IG.fm Page 1 Friday, August 10, 2012 12:35 PM August 2012 ©2012 by NETGEAR, Inc.. All rights reserved. NETGEAR and the NETGEAR logo are registered trademarks of NETGEAR, Inc. in the United States and/or other countries. Other brand and product names are trademarks or registered trademarks of their respective holders. Information is subject to change without notice. This symbol was placed in accordance with the European Union Directive 2002/96 on the Waste Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European Union, this product should be treated and recycled in accordance with the laws of your jurisdiction implementing the WEEE Directive. Miracast Wireless Display Push2TV now supports Miracast™ Wireless Display. To switch between Intel WiDi and Miracast modes, press the button on the side of the Push2TV for 2 seconds. You can then launch the wireless display application on a Miracast-compatible smartphone, tablet, or laptop, and connect. FAQs 1. Can I display different content on the TV while I’m using my laptop? Yes. To display different content, change the screen display setting on your computer to extend mode. 2. Can I close the laptop lid and still use Wireless Display? Closing the laptop lid might put the system to sleep or turn it off and, as a result, close the connection. To prevent this from happening, from Windows select Start > Search, type Closing lid in the search field, and change the settings to do nothing. 3. Why can’t I play some DVD and Blu-ray discs? Many discs have copy protection mechanisms that prevent playback on Intel Wireless Display before software version v2.1.0.0. However, personal content you have burned to a disc will play. 4. Can I mute my laptop and still watch videos with sound? Yes. Even if your laptop has sound muted, the sound for the media you are playing will play on your TV. 5. How can I fix the delay in the cursor? You cannot change the delay, but you can turn off the cursor on the TV and use the laptop to navigate. To do this, connect to the adapter using Intel WiDi software on your PC, and click Properties. 6. What should I do if I get a Windows Firewall security alert? From Windows, select Start > Search and in the search field type Allow a program through a Windows Firewall. Add WiDiApp and Wireless PAN DHCP Server to the list of allowed programs. Make sure both the private and public check boxes are selected. If you are not using Windows Firewall, consult your firewall user’s manual. 7. What should I do if the TV stops showing my laptop screen? Use Intel Wireless Display to check the wireless connection and reconnect to the Push2TV adapter if necessary. If the situation continues, try moving your laptop closer to the Push2TV adapter or place it in a location with a clear line of sight to the Push2TV adapter. Changing the channel of your WiFi router might also help. For more information, launch Intel Wireless Display and select Help. 8. How can I restore factory settings to the Push2TV? The Reset button is on the bottom of the unit. Use a paper clip to press and hold the Reset button for 10 seconds. 9. How can I update my Push2TV? a. Use your computer and navigate to http://www.netgear.com/stream to check for and download the latest firmware. b. Press the Wireless Display Mode / WPS button on the side of the Push2TV unit for more than 5 seconds. c. Using the wireless network manager utility on your computer, search for the Push2TV wireless network name (SSID) and connect. d. Open a browser on your compute…

Text truncated - open the document above for the full version.

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Industry Canada statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme a la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage prejudiciable, et (2) ce dispositif doit accepter tout brouillage recu, y compris un brouillage susceptible de provoquer un fonctionnement indesirable. Caution : the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; Avertissement:les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont reserves uniquement pour une utilisation a l’interieur afin de reduire les risques de brouillage prejudiciable aux systemes de satellites mobiles utilisant les memes canaux; Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Declaration d'exposition aux radiations:Cet equipement est conforme aux limites d'exposition aux rayonnements IC etablies pour un environnement non controle. Cet equipement doit etre installe et utilise avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Declaration for no non‐US channel operation September 6, 2012 We, Netgear Incorporated declare that the device does not support any non-US channels in all the operational mode(s) for the following product. FCC ID: PY312200199 If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Mark Gandler / project manager Netgear INC. TEL:+1 408‐907‐8000 Fax:+1 408‐907‐8097 E‐mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-09-02 FCC ID: PY312200199 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ___________________________________ Mark Gandler / project manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-09-02 FCC ID: PY312200199 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to DA 04-1705 of the commission’s public notice, we request short-term confidential treatment for the following information until 2012/9/28 in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ___________________________________ Mark Gandler / project manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-09-06 AUTHORIZATION LETTER To whom it may concern: We, the undersigned Netgear Incorporated hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15C/E and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. FCC ID: PY312200199 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------ Mark Gandler / project manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Report No.: 120802E02 1 of 9 CONSTRUCTION PHOTOS OF EUT Report No.: 120802E02 2 of 9 Report No.: 120802E02 7 of 9 Report No.: 120802E02 8 of 9 Report No.: 120802E02 9 of 9

(Fig.1) FCC ID: PY312200199 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Report No.: 120802E02 3 of 9 Report No.: 120802E02 4 of 9 Report No.: 120802E02 5 of 9 Report No.: 120802E02 6 of 9

FCC ID: PY312200199 Report No.: RF 120802E02 Operational Description This device is a PUSH2TV WIRELESS DISPLAY ADAPTER, which operates in both of 5GHz and 2.4GHz bands; the maximum data rate could be up to 150Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 150Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the 5Vdc form power adapter. The device is used PIFA antenna. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.
