350 East Plumeria Drive San Jose, CA 95134 USA July 2012 TBD v1.0 802.11ac USB WiFi Adapter A6200 User Manual Note: This document is for certification purposes only. Some of the procedures, illustrations, and screen captures might not exactly match the device. 2 802.11ac USB WiFi Adapter A6200 © 2012 NETGEAR, Inc. All rights reserved No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of NETGEAR, Inc. Technical Support Thank you for choosing NETGEAR. To register your product, get the latest product updates, get support online, or for more information about the topics covered in this manual, visit the Support website at http://support.netgear.com.  Phone (US & Canada only): 1-888-NETGEAR Phone (Other Countries): Check the list of phone numbers at http://support.netgear.com/app/answers/detail/a_id/984. Trademarks NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. Other brand and product names are registered trademarks or trademarks of their respective holders. © 2011 NETGEAR, Inc. All rights reserved. Statement of Conditions To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use, or application of, the product(s) or circuit layout(s) described herein. 3 Contents Chapter 1 Set up Your Wireless Adapter NETGEAR Genie Desktop Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 NETGEAR Genie Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Status Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Join a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Network Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Join a Network or Connect to a Different Network . . . . . . . . . . . . . . . . . . 8 Join a Hidden Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Chapter 2 Maintenance Other Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Remove the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Frequently Asked Questions (FAQs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Appendix A Supplemental Information Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Appendix B Notification of Compliance 4 1 1. Set up Your Wireless Adapter This chapter includes the following sections: • NETGEAR Genie Desktop Icon • NETGEAR Genie Home • Join a Wireless Network For help installing your wireless USB Adapter, see the installation guide that came in the package. For more information about the topics covered in this manual, visit the support website at http://support.netgear.com. Set up Your Wireless Adapter 5 802.11ac USB WiFi Adapter Gain Better Wireless Performance Rotate the black part that contains the antenna to gain better wireless performance. Rotate the black part that hasthe antenna. Figure 1. Rotate the antenna for better performance NETGEAR Genie Desktop Icon When you install your adapter, the NETGEAR Genie icon appears in the Windows system tray and on the desktop. You can click this icon to open NETGEAR Genie to make changes or connect to a different wireless network. The color of the icon indicates the strength of your wireless connection from 0 (zero) to 5 bars. White: 3 to 5 bars Yellow: 1 or 2 bars Red: 0 (zero) bars, indicating no connection If you remove your adapter, NETGEAR Genie is not available, so the icon is not displayed. if you insert the adapter again, the icon returns. Set up Your Wireless Adapter 6 802.11ac USB WiFi Adapter NETGEAR Genie Home When you launch NETGEAR Genie, the home screen displays. This screen shows you at a glance if you are connected to a network, and if you have Internet access. The following options are available: •Sele ct Language. If more than one language is available, you can select a language from this drop-down list. NETGEAR Genie screens will be displayed in the language that you selected. •Home button. The currently selected Home screen. You can click the Home button to return here from a different screen. •Jo in a Network button. View a list of wireless networks and join a network. •Other button. View more information or check for software updates. •Help. Display the help. Status Bar The status bar is located at the bottom of the screen: NetworkConnectionNetwork Wireless Physical Signal security channelstrengthnamestatus rate Figure 2. Status bar Set up Your Wireless Adapter 7 802.11ac USB WiFi Adapter Network name. The network name (SSID) of the wireless network that the adapter is currently connected to. Connection status. This shows the status that is also shown in the diagram in the middle of this screen. • Connected to the Internet • Connected to the Router • No Connectio n Network security. The lock symbol shows whether or not the network you are connected to uses wireless security. An open lock indicates an open network without wireless security, such as one that you might use in a coffee shop. Wireless channel. Th e wireless channel of the network that the adapter is connected to. Physical rate. The p hysical transmission rate for wireless communication. Signal strength. The strength of the wireless signal. Three-to-five bars indi…

Text truncated - open the document above for the full version.

Netgear Incorporated 350 East Plumeria Drive, San Jose, California 95134, United States Tel: 408-907-8000 ; Fax: 408-907-8097 Date: August 7, 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: PY312200200 To Whom It May Concern: We, Netgear Incorporated, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Sincerely yours, Mark Gandler

Rev. 1/1/03 Netgear Incorporated 350 East Plumeria Drive, San Jose, California 95134, United States Tel: 408-907-8000 ; Fax: 408-907-8097 Date: August 7, 2012 Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request regarding application for certification of FCC ID: PY312200200 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request Permanent Confidential treatment of information accompanying this application as outlined below: Schematics (file: A6200_Schem_Confidential.pdf) Block Diagram (file: A6200_BlkDia_Confidential.pdf) Parts List (file: A6200_PartsLst_Confidential.pdf) Operation Description (file: A6200_OpDes_Confidential.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, ________________________ Mark Gandler

Netgear Incorporated 350 East Plumeria Drive, San Jose, California 95134, United States Tel: 408-907-8000 ; Fax: 408-907-8097 Date: August 7, 2012 Power of Attorney To whom it may concern, Please be notified that I, Mark Gandler, have designated Jones Tsai in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Jones Tsai in Sporton International Inc. on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: PY312200200 If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Contact Person: Mark Gandler Company: Netgear Incorporated TEL: 408-907-8000 FAX: 408-907-8097 E-mail: [email protected]

1/1 Netgear Incorporated 350 East Plumeria Drive, San Jose, California 95134, United States Tel: 408-907-8000 ; Fax: 408-907-8097 Date: August 7, 2012 Federal Communications Commission Authorization and Evaluation Division RE : Certification Application FCC ID : PY312200200 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days:  External Photos (file: A6200_ExtPho.pdf)  Internal Photos (file: A6200_IntPho.pdf)  Test Setup Photos (file: A6200_Tsup.pdf)  User Manual (file: A6200_UserMan.pdf) The application contains technical information, which Netgear Incorporated deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Sincerely, Mark Gandler

SPORTON International Inc. PAGE NUMBER : 1 OF 4 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 Photographs of EUT SPORTON International Inc. PAGE NUMBER : 2 OF 4 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 3 OF 4 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 4 OF 4 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255

Label Location Bottom of EUT Rotating Upper part

METRIC D C B A TOLERANCES SIZEDRAWING NOREV C DO NOT SCALE DRAWING THIRD ANGLE PROJECTION COPYRIGHT NETGEAR, INC., 2006 DATEDRAWN OF 0 - 2 0.05 DESIGNDATE THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. SCALE PRO/E CAD MODEL 1234 1234 D C B A DESCRIPTION OF REVISIONENG APPDDATEREV SHEET (UNLESS OTHERWISE SPECIFIED) 2 - 10 0.08 10 - 50 0.10 50 - 100 0.15 100 - 200 0.20 >200 0.30 ANGLES 0.5 25.00 26.60 R1.00 R0.55 01INITIAL PLOTJ MATHESON20JUN2012 J MATHESON20JUN2012 J MATHESON18MAY2012 FD-10569-0201 FD-10569-02 FD,PLBL,A6200 4.000 1 1 NOTES: (UNLESS OTHERWISE SPECIFIED) 1 MATERIAL: 0.14 MM (TOTAL) THK WHITE PET, CLEAR COLOR TOP LAYER: MATTE TEXTURE PET, CLEAR, 0.025 THK ADHESIVE PLY: ACRYLIC ADHESIVE, TRANSPARENT, 0.022 THK BOTTOM LAYER: WHITE PET, CLEAR, 0.075THK. 2 ADHESIVE: 3M #467MP OR EQUIVALENT. APPLY ADHESIVE ON BACK. 3 DIE-CUT TOLERANCES: 0.25mm 4 LAYER TO LAYER GRAPHIC TOLERANCE: 0.12 5 GRAPHIC TO DIE-CUT TOLERANCE: 0.20 6 REFER TO ARTWORK FOR COLORS AND GRAPHICS 7 THE MATERIALS AND PROCESS USED TO FABRICATE THIS PART ARE TO BE CONSISTENT WITH EC DIRECTIVE 2002/95/EC, RESTRICTION OF HAZARDOUS SUBSTANCES IN ELECTRICAL AND ELECTRONIC EQUIPMENT (RoHS). THE FINISHED PART TO BE ACCOMPANIED BY A SIGNED CERTIFICATE OF COMPLIANCE TO DIRECTIVE 2002/95/EC.

SPORTON International Inc. PAGE NUMBER : 1 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 Photographs of EUT SPORTON International Inc. PAGE NUMBER : 2 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 3 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 4 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 5 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 6 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 7 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 8 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 9 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 10 OF 10 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 12, 2012 FAX : 886-2-2696-2255

SPORTON INTERNATIONAL INC. Page Number : C1 of C1 TEL : 886-3-327-3456 Report Issued Date : Aug. 23, 2012 FAX : 886-3-328-4978 Report Version : Rev. 02 FCC ID : PY312200200 FCC SAR Test Report Report No. : FA262930 Appendix C. DASY Calibration Certificate The DASY calibration certificates are shown as follows. SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. Calibration Certificate of DASY SPORTON INTERNATIONAL INC. TEL : 886-3-327-3456 FAX : 886-3-328-4978 FCC Test Report D2450V2, serial no. 736 Extended Dipole Calibrations Referring to KDB 450824, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. <Justification of the extended calibration> D2450V2 – serial no. 736 2450 Head 2450 Body Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 7.25.2011 -27.042 54.398 1.4805 -30.696 50.812 2.8262 7.25.2012 -27.950 -3.365 52.541 1.857 0.77343 0.707 -31.781 -3.535 50.572 0.24 1.5953 1.2309 The return loss is < -20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. SPORTON INTERNATIONAL INC. TEL : 886-3-327-3456 FAX : 886-3-328-4978 FCC Test Report <Dipole Verification Data> - D2450 V2, serial no. 736 (Date of Measurement : 7.25.2012) 2450 MHz - Head SPORTON INTERNATIONAL INC. TEL : 886-3-327-3456 FAX : 886-3-328-4978 FCC Test Report 2450 MHz – Body

SPORTON INTERNATIONAL INC. Page Number : 1 of 36 TEL : 886-3-327-3456 Report Issued Date : Aug. 29, 2012 FAX : 886-3-328-4978 Report Version : Rev. 03 FCC ID : PY312200200 FCC SAR Test Report Report No. : FA262930 FCC SAR Test Report APPLICANT : NETGEAR, Inc. EQUIPMENT : WiFi USB Adapter BRAND NAME : NETGEAR MODEL NAME : A6200 FCC ID : PY312200200 STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) The product was completely tested on Aug. 29, 2012. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 36 TEL : 886-3-327-3456 Report Issued Date : Aug. 29, 2012 FAX : 886-3-328-4978 Report Version : Rev. 03 FCC ID : PY312200200 FCC SAR Test Report Report No. : FA262930 Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Administration Data ...................................................................................................................................................... 5 2.1 Testing Laboratory .................................................................................................................................................. 5 2.2 Applicant ................................................................................................................................................................ 5 2.3 Manufacturer .......................................................................................................................................................... 5 2.4 Application Details .................................................................................................................................................. 5 3. General Information ...................................................................................................................................................... 6 3.1 Description of Device Under Test (DUT) ................................................................................................................ 6 3.2 Product Photos....................................................................................................................................................... 7 3.3 Applied Standards .................................................................................................................................................. 7 3.4 Device Category and SAR Limits ........................................................................................................................... 7 3.5 Test Conditions ....................................................................................................................................................... 7 4. Specific Absorption Rate (SAR) ................................................................................................................................... 8 4 .1 Introduction ............................................................................................................................................................ 8 4.2 SAR Definition ........................................................................................................................................................ 8 5. SAR Measurement System ........................................................................................................................................... 9 5.1 E-Field Probe ........................................................................................................................................................10 5.2 Data Acquisition Electronics (DAE) ....................................................................................................................... 11 5.3 Robot .................................................................................................................................................................... 11 5.4 Measurement Server .............................................................................................................................................12 5.5 Phantom ................................................................................................................................................................12 5.6 Device Holder........................................................................................................................................................13 5.7 Data Storage and Evaluation ................................................................................................................................15 5.8 Test Equipment List ...............................................................................................................................................17 6. Tissue Simulating Liquids ...........................................................................................................................................18 7. SAR Measurement Evaluation ....................................................................................................................................20 7.1 Purpose of System Performance check ................................................................................................................20 7.2 System Setup ......................................................................................…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page Number : A1 of A1 TEL : 886-3-327-3456 Report Issued Date : Aug. 29, 2012 FAX : 886-3-328-4978 Report Version : Rev. 03 FCC ID : PY312200200 FCC SAR Test Report Report No. : FA262930 Appendix A. Plots of System Performance Check The plots are shown as follows. Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/7/5 System Check_Body_2450MHz_120705 DUT: D2450V2-SN:736 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: MSL_2450_120705 Medium parameters used: f = 2450 MHz; σ = 1.965 mho/m; ε r = 52.764; ρ = 1000 kg/m 3 Ambient Temperature：22.6 °C; Liquid Temperature：21.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN3792; ConvF(7.1, 7.1, 7.1); Calibrated: 2012/6/21; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1338; Calibrated: 2012/6/12 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP1127 - Measurement SW: DASY52, Version 52.8 (1); SEMCAD X Version 14.6.5 (6469) Pin=250mW/Area Scan (91x91x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 14.1 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 82.218 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 27.407 mW/g SAR(1 g) = 12.5 mW/g; SAR(10 g) = 5.93 mW/g Maximum value of SAR (measured) = 13.8 mW/g 0 dB = 13.8 mW/g = 22.80 dB mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/7/28 System Check_Body_2450MHz_120728 DUT: D2450V2-SN:736 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: MSL_2450_120728 Medium parameters used: f = 2450 MHz; σ = 1.965 mho/m; ε r = 52.451; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3792; ConvF(7.1, 7.1, 7.1); Calibrated: 2012/6/21; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn495; Calibrated: 2012/4/23 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP1127 - Measurement SW: DASY52, Version 52.8 (1); SEMCAD X Version 14.6.5 (6469) Pin=250mW/Area Scan (91x91x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 14.5 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 83.211 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 28.016 mW/g SAR(1 g) = 12.8 mW/g; SAR(10 g) = 6.09 mW/g Maximum value of SAR (measured) = 14.2 mW/g 0 dB = 14.2 mW/g = 23.05 dB mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/8/4 System Check_Body_5200MHz_120804 DUT: D5GHzV2-SN:1006 Communication System: CW; Frequency: 5200 MHz;Duty Cycle: 1:1 Medium: MSL_5G_120804 Medium parameters used: f = 5200 MHz; σ = 5.162 mho/m; ε r = 48.492; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3792; ConvF(4.2, 4.2, 4.2); Calibrated: 2012/6/21; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Electronics: DAE3 Sn495; Calibrated: 2012/4/23 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1026 - Software: DASY5 Version; SEMCAD X Version 14.6.6 (6477) Pin=250mW/Area Scan (91x91x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 33.9 mW/g Pin=250mW/Zoom Scan (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 85.145 V/m; Power Drift = -0.13 dB Peak SAR (extrapolated) = 64.786 mW/g SAR(1 g) = 18.9 mW/g; SAR(10 g) = 5.24 mW/g Maximum value of SAR (measured) = 32.3 mW/g 0 dB = 32.3 mW/g = 30.18 dB mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/8/5 System Check_Body_5800MHz_120805 DUT: D5GHzV2-SN:1006 Communication System: CW; Frequency: 5800 MHz;Duty Cycle: 1:1 Medium: MSL_5G_120805 Medium parameters used: f = 5800 MHz; σ = 5.939 mho/m; ε r = 46.527; ρ = 1000 kg/m 3 Ambient Temperature：22.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3819; ConvF(4.02, 4.02, 4.02); Calibrated: 2011/11/16; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Electronics: DAE3 Sn495; Calibrated: 2012/4/23 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP1127 - Measurement SW: DASY52, Version 52.8 (1); SEMCAD X Version 14.6.5 (6469) Pin=250mW/Area Scan (91x91x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 32.1 mW/g Pin=250mW/Zoom Scan (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 79.061 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 54.344 mW/g SAR(1 g) = 17.8 mW/g; SAR(10 g) = 5.15 mW/g Maximum value of SAR (measured) = 29.6 mW/g 0 dB = 29.6 mW/g = 29.43 dB mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/8/23 System Check_Body_5800MHz_120823 DUT: D5GHzV2-SN:1006 Communication System: CW; Frequency: 5800 MHz;Duty Cycle: 1:1 Medium: MSL_5G_120823 Medium parameters used: f = 5800 MHz; σ = 6.127 mho/m; ε r = 47.784; ρ = 1000 kg/m 3 Ambient Temperature：22.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: EX3DV4 - SN3661; ConvF(4.02, 4.02, 4.02); Calibrated: 2012/1/27; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Electronics: DAE3 Sn495; Calibrated: 2012/4/23 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP1127 - Measurement SW: DASY52, Version 52.8 (2); SEMCAD X Version 14.6.6 (6824) Pin=250mW/Area Scan (91x91x1): Measurement grid: dx=10 mm, dy=10 mm Maximum value of SAR (interpolated) = 30.0 W/kg Pin=250mW/Zoom Scan (8x8x8)/Cube 0: Measurement grid: dx=4.3mm, dy=4.3mm, dz=3mm Reference Value = 79.284 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 65.960 mW/g SAR(1 g) = 17.2 mW/g; SAR(10 g) = 4.76 mW/g Maximum value of SAR (measured) = 29.7 W/kg 0 dB = 29.7 W/kg = 29.46 dB W/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/8/29 System Check_Body_5800MHz_120829 DUT: D5GHzV2-SN:1006 Communication System: CW; Frequency: 5800 MHz;Duty Cycle: 1:1 Medium: MSL_5G_120829 Medium parameters used: f = 5800 MHz; σ = 6.118 mho/m; …

Text truncated - open the document above for the full version.

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company NETGEAR, Inc. Applicant Address 350 East Plumeria Drive, San Jose, California 95134-1911 FCC ID PY312200200 Manufacturer’s company Ambit Microsystems (Shanghai) Ltd. Manufacturer Address No. 1925, Nanle Road, Songjiang Export Processing Zone, Shanghai, China Product Name WiFi USB Adapter Brand Name NETGEAR Model Name A6200 Test Rule Part(s) 47 CFR FCC Part 15 Subpart E § 15.407 Test Freq. Range 5150 ~ 5250MHz Received Date Jun. 22, 2012 Final Test Date Aug. 01, 2012 Submission Type Original Equipment Operating Mode Client (without radar detection function) Statement Test result included is for the IEEE 802.11n and IEEE 802.11a (5150 ~ 5250MHz) of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2009 and 47 CFR FCC Part 15 Subpart E and KDB 789033 – 20120305. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR262930AA Report Format Version: 01 Page No. : i of ii FCC ID: PY312200200 Issued Date : Aug. 01, 2012 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................6 3.3. Table for Filed Antenna.......................................................................................................................................................................7 3.4. Table for Carrier Frequencies .....................................................................................................................................................…
