PY312200203ProSafe 3x3 Dual Radio, Dual Band Wireless Access Point

Installation Guide ProSafe 3x3 Dual Radio, Dual Band Wireless-N Access Point WNDAP660 Package Contents Unpack the box and verify the contents: • ProSafe 3x3 Dual Radio, Dual Band Wireless-N Access Point WNDAP660 • Straight through Category 5 Ethernet cable • Power adapter and cord (12V, 1.5A) • Ceiling mount kit • Installation Guide • Resource CD, which includes link to the Reference Manual Set Up the Access Point Follow these instructions to set up your wireless access point. Before proceeding with the WNDAP660 installation, familiarize yourself with the contents of the Resource CD. See the Reference Manual for instructions on advanced configuration options. Tip: Before mounting the access point in a high location, first set up and test the unit to verify wireless network connectivity. 1. Connect the wireless access point to your computer. a.Prepare a PC with an Ethernet adapter. If this PC is already part of your network, record its TCP/IP configuration settings. Configure the PC with a static IP address of 192.168.0.210 and 255.255.255.0 as the subnet mask. b.Connect an Ethernet cable from the access point to the PC (point A in the illustration). c.Securely insert the other end of the cable into an access point Ethernet port (point B in the illustration). d. Connect the power adapter to the access point. Verify the following: The Power LED blinks when the access point is first turned on. After a few seconds it should stay on (steady green). If after 30 seconds the Power LED is off or is still blinking, check the connections and check to see if the power outlet is controlled by a wall switch that is turned off. The ACTIVE LED blinks when there is network traffic. The LAN1 and LAN2 LEDs indicate LAN speed for each LAN port; green for 1000 Mbps, amber for 100Mbps, and no light for 10Mbps. 2.4 GHz (WLAN). This LED indicates 2.4 GHz traffic. 5 GHz (WLAN). This LED indicates 5 GHz traffic. 2. Configure LAN and wireless access a. From your PC, configure the access point Ethernet port for LAN access. Connect to the access point by opening your browser and entering http://192.168.0.100 in the address field. b. A login window displays. When prompted, enter admin for the user name and password for the password, both in lower case letters. The access point user interface displays. c. Select Configuration > System > Basic > General from the menu. Fill in the Access Point Name field and select your Country/Region of operation from the drop-down list. NETGEAR Cable A B WNDAP660 Ethernet port d. Select Configuration > IP > IP Settings from the menu and configure the IP settings for your network. e. If you use DHCP, reserve an IP address (based on the access point’s MAC address) on the DHCP server. You can then use that address to log in to the access point. f. Select Configuration > Wireless > Basic > Wireless Settings and select the Turn Radio On setting. g. Select Configuration > Security > Profile Settings and configure security profiles for your network. See the online help or the Reference Manual for full instructions. 3. Test wireless connectivity. Using a PC with a wireless adapter, verify that you can establish a wireless connection to the access point. Now that you have finished the setup, you are ready to deploy the access point in your network. If needed, you can reconfigure the PC you used in step 1 back to its original TCP/IP settings. Deploy the Access Point 1. Disconnect the access point and position it where you will deploy it. The best location is elevated such as wall or ceiling mounted, at the center of your wireless coverage area, and within line of sight of all mobile devices. Note: DO NOT place the AP in a false ceiling space facing up. Ceiling MountWall Mount WNDAP660_IG_19June2012.fm Page 1 Tuesday, June 19, 2012 12:58 PM Note: To comply with FCC/IC RF Exposure Limits set forth for an uncontrolled environment, the product must be installed and operated with a minimum separation distance (between nearby person(s) and radiating antenna) which is 23cm minimum. June 2012 This symbol was placed in accordance with the European Union Directive 2002/96 on the Waste Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European Union, this product should be treated and recycled in accordance with the laws of your jurisdiction implementing the WEEE Directive. NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. Other brand and product names are registered trademarks or trademarks of their respective holders. © 2011 NETGEAR, Inc. All rights reserved. 2. Connect an Ethernet cable from your access point to a LAN port on your router, switch, or hub. 3. Connect the power adapter to the wireless access point and plug the power adapter into a power outlet. The Power and LAN LEDs should go on. Tip: The access point supports Power over Ethernet (PoE). If you have a switch that provides PoE, you do not need to use the power adapter to power the access point. This can be especially convenient when the access point is installed in a high location far from a power outlet. Verify Wireless Connectivity Using a computer with an 802.11b/g/n wireless adapter, verify connectivity by using a browser to connect to the Internet, or check for file and printer access on your network. Note: If you cannot connect, see Troubleshooting Tips in this guide or the Reference Manual. If You Use an External Antenna To use an external 2.4 GHz antenna: 1. Mount the accessory antenna(s). 2. Attach the antenna(s) to the connector(s) on the access point rear panel. 3. Log into the access point and configure it to use the external antenna. The access point cannot use the internal and external 2.4GHz antennas at the same time. Troubleshooting Tips No LEDs are lit on the access point. The wireless access point has no pow…

Text truncated - open the document above for the full version.

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 23cm between the radiator & your body. Industry Canada statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme a la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage prejudiciable, et (2) ce dispositif doit accepter tout brouillage recu, y compris un brouillage susceptible de provoquer un fonctionnement indesirable. Caution : the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; Avertissement:les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont reserves uniquement pour une utilisation a l’interieur afin de reduire les risques de brouillage prejudiciable aux systemes de satellites mobiles utilisant les memes canaux; Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 23cm between the radiator & your body. Declaration d'exposition aux radiations:Cet equipement est conforme aux limites d'exposition aux rayonnements IC etablies pour un environnement non controle. Cet equipement doit etre installe et utilise avec un minimum de 23 cm de distance entre la source de rayonnement et votre corps. DETACHABLE ANTENNA USAGE This device has been designed to operate with a Dipole antenna have a maximum gain of 5dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. This radio transmitter (IC: 4054A-12200203 / Model: WNDAP660) has been approved by Industry Canada to operate with the antenna type, maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this user’s manual, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Ce dispositif a ete concu pour fonctionner avec une antenne ayant un gain maximal de Dipole antenna avec 5dBi. Une antenne a gain plus eleve est strictement interdite par les reglements d'Industrie Canada. L'impedance d'antenne requise est de 50 ohms. Conformement a la reglementation d'Industrie Canada, le present emetteur radio peutfonctionner avec une antenne d'un type et d'un gain maximal (ou inferieur) approuve pourl'emetteur par Industrie Canada. Dans le but de reduire les risques de brouillage radioelectriquea l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que lapuissance isotrope rayonnee equivalente (p.i.r.e.) ne depasse pas l'intensite necessaire al'etablissement d'une communication satisfaisante. Le present emetteur radio (IC: 4054A-12200203/ Model: WNDAP660) a ete approuve par Industrie Canada pour fonctionner avec les types d'antenne enumeres ci-dessous et ayant un gain admissible maximal et l'impedance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est superieur au gain maximal indique, sont strictement interdits pour l'exploitation de l'emetteur.

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Declaration for DFS client devices August 15, 2012 We, Netgear Incorporated declare that the device does not support any non-US channels in all the operational mode(s), like Ad-Hoc...etc, for the following product. Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad‐hoc peer‐to‐peer modes. FCC ID: PY312200203 If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Mark Gandler / Regulatory Compliance manager Netgear INC. TEL:+1 408‐907‐8000 Fax:+1 408‐907‐8097 E‐mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-08-15 FCC ID: PY312200203 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ___________________________________ Mark Gandler / Regulatory Compliance manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-08-15 FCC ID: PY312200203 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to DA 04-1705 of the commission’s public notice, we request short-term confidential treatment for the following information until 2012/9/28 in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ___________________________________ Mark Gandler / project manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California United States 95134 Date: 2012-08-15 AUTHORIZATION LETTER To whom it may concern: We, the undersigned Netgear Incorporated hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15C and E any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. FCC ID:PY312200203 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------ Mark Gandler / Regulatory Compliance manager Netgear INC. TEL:+1 408-907-8000 Fax:+1 408-907-8097 E-mail: [email protected]

Report No.: 120725E01 1 of 9 CONSTRUCTION PHOTOS OF EUT Report No.: 120725E01 2 of 9 Report No.: 120725E01 3 of 9 Report No.: 120725E01 4 of 9 External Ant.: ANT-32405 Report No.: 120725E01 5 of 9 Report No.: 120725E01 6 of 9 Model No.: MT18-9120150-A1 Report No.: 120725E01 7 of 9 Report No.: 120725E01 8 of 9 Model No.: SAL018F1 NA Report No.: 120725E01 9 of 9

SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONEWITHOUTTHE PERMISSION OF NETGEAR, INC. REVDESCRIPTION OF REVISIONENG APPDDATE 01AW-11779-011 of 1 AW,WNDAP660, V1H1, PLBLR HU 29MAY12R HU INITIAL DOCUMENT CREATION01 7 Pantone 430C NOTE: 1. REFER TO NETGEAR SPEC. FD-10360-01 FOR MATERIAL SPECIFICATIONS AND TOLERANCES. 2. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. INK COLOR IS SHOWN TO THE RIGHT. 5. See NTGR DOC-00112 for SN standard. 6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), UNHIDE THE WHITE BOX LAYER AND INCLUDE WHITE BOX ON LABEL.

(Fig.1) FCC ID: PY312200203 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Report No.: 120725E01 1 of 7 CONSTRUCTION PHOTOS OF EUT Report No.: 120725E01 2 of 7 Report No.: 120725E01 3 of 7 Report No.: 120725E01 4 of 7 Report No.: 120725E01 5 of 7 Report No.: 120725E01 6 of 7 Report No.: 120725E01 7 of 7

FCC ID: PY312200203 Report No.: RF 120725E01 Operational Description This device is a ProSafe 3x3 Dual Radio, Dual Band Wireless Access Point, which operates in both of 5GHz and 2.4GHz bands; the maximum data rate could be up to 450Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 450Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the 12Vdc form power adapter or 55Vdc for POE. The device is used Dipole antenna. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA120725E01 1 of 9 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA120725E01 MODEL NO.: WNDAP660 FCC ID: PY312200203 RECEIVED: July 19, 2012 TESTED: July 31, 2012 ISSUED: Aug. 15, 2012 APPLICANT: Netgear Incorporated. ADDRESS: 350 East Plumeria Drive San Jose California United States 95134 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA120725E01 2 of 9 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN....................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 7 Report No.: SA120725E01 3 of 9 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120725E01 Original release Aug. 15, 2012 Report No.: SA120725E01 4 of 9 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: ProSafe 3x3 Dual Radio, Dual Band Wireless Access Point BRAND NAME: Netgear MODEL NO.: WNDAP660 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Netgear Incorporated. TESTED: July 31, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: WNDAP660) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Aug. 15, 2012 ( Elsie Hsu, Specialist ) APPROVED BY : , DATE: Aug. 15, 2012 ( May Chen, Deputy Manager ) Report No.: SA120725E01 5 of 9 Report Format Version 5.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 23cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA120725E01 6 of 9 Report Format Version 5.0.0 5. ANTENNA GAIN 1. The antennas provided to the EUT, please refer to the following table: Internal Antenna (For 2.4GHz / 5GHz) Transmitter Circuit Antenna Type Peak Gain (dBi) 2.4GHz 5GHz Band 1 5GHz Band 4 Chain (0) Dipole 2.44 4.36 5.95 Chain (1) Dipole 2.44 5.31 5.02 Chain (2) Dipole 2.44 3.87 3.96 External Antenna (For 2.4GHz) Model Antenna Type Gain (dBi) (Exclude cable loss ) Cable Loss (dB) Net Gain (dBi) (Include cable loss) Connecter Type ANT-32405 Dipole 5 3.68 1.32 SMA Plug Reverse Report No.: SA120725E01 7 of 9 Report Format Version 5.0.0 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): 802.11b: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 250.352 7.21 23 0.19810 1.00 Directional gain = gain of antenna element + 10 log (# of TX antenna elements) Effective Legacy Gain (dBi) = 7.21 802.11g: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 575.666 7.21 23 0.45552 1.00 Directional gain = gain of antenna element + 10 log (# of TX antenna elements) Effective Legacy Gain (dBi) = 7.21 802.11n(HT20): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/…

Text truncated - open the document above for the full version.

Report No.: RF120725E01 1 of 99 Report Format Version 5.0.0 Cancels and replaces the report No.: IC120322E03 dated Apr. 10, 2012 FCC TEST REPORT (15.247) REPORT NO.: RF120725E01 MODEL NO.: WNDAP660 FCC ID: PY312200203 RECEIVED: July 19, 2012 TESTED: July 19 to Aug. 04, 2012 ISSUED: Aug. 15, 2012 APPLICANT: Netgear Incorporated. ADDRESS: 350 East Plumeria Drive San Jose California United States 95134 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120725E01 2 of 99 Report Format Version 5.0.0 Cancels and replaces the report No.: IC120322E03 dated Apr. 10, 2012 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 5 1. CERTIFICATION .................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................ 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 9 3. GENERAL INFORMATION ................................................................................... 10 3.1 GENERAL DESCRIPTION OF EUT ..................................................................... 10 3.2 DESCRIPTION OF TEST MODES ....................................................................... 13 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 14 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 17 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 18 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 19 4. TEST TYPES AND RESULTS (fOR 2.4GHz, 2.400 ~ 2.4835GHz Band) .............. 21 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 21 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 21 4.1.2 TEST INSTRUMENTS .......................................................................................... 21 4.1.3 TEST PROCEDURES .......................................................................................... 22 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 22 4.1.5 TEST SETUP ....................................................................................................... 23 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 23 4.1.7 TEST RESULTS (MODE 1) .................................................................................. 24 4.1.8 TEST RESULTS (MODE 2) .................................................................................. 26 4.1.9 TEST RESULTS (MODE 3) .................................................................................. 28 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 30 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 30 4.2.2 TEST INSTRUMENTS .......................................................................................... 31 4.2.3 TEST PROCEDURES .......................................................................................... 32 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 32 4.2.5 TEST SETUP ............................................…

Text truncated - open the document above for the full version.
