Installation Guide ProSAFE® Single Band 802.11n Wireless Access Point WN203 Follow the instructions in this installation guide to set up your ProSAFE® Single Band 802.11n Wireless Access Point WN203. For information about advanced configuration options, see the reference manual. Note:In this installation guide, the Wireless Access Point WN203 is referred to as the access point. Package Contents Unpack the box and verify the contents: •Wireless Access Point WN203 •Straight-through Category 5 Ethernet cable •Power adapter and cord (12V, 1A) •Stand •Installation guide Set Up the Access Point Setting up the access point consists of three short procedures: •Connect the access point to your computer. •Configure the LAN and wireless access settings. •Test wireless connectivity. Estimated total time for these procedures: 10 minutes. Tip: Before you mount the access point in a high location, first set up and test the access point to verify wireless network connectivity. Connect the Access Point to Your Computer 1.Prepare a computer with an Ethernet adapter: a.If this computer is already part of your network, record its TCP/IP configuration settings. b.Configure the computer with a static IP address of 192.168.0.210 and a subnet mask of 255.255.255.0. 2.Insert an Ethernet cable in the Ethernet port of the computer (point A in the illustration). 3.Securely insert the other end of the cable into the Ethernet LAN port on the back panel of the access point (point B in the illustration). 4.Connect the power adapter to the access point and plug the power adapter into a power outlet. 5.Verify the following: • Power LED. The Power LED is green. If the Power LED is off, check the connections, and check if the power outlet is controlled by a wall switch that is turned off. • Test LED. The Test LED blinks amber at startup and turns off after about 1 minute. • LAN LED. The LAN LED indicates LAN speeds: green for 1000 Mbps, amber for 100 Mbps or 10 Mbps. If no link is detected, the LAN LED is off. • WLAN LED. The WLAN LED is blue, indicating that the wireless LAN (WLAN) is ready. A B B LAN port Console port Power connector Configure the LAN and Wireless Access Settings 1.On the computer that is connected to the access point, enter http://192.168.0.100 in the address field of a browser. A login window displays. 2.Enter admin for the user name and password for the password, both in lowercase letters. The web management interface of the access point displays. The menu lets you navigate to the various screens. 3.Select Configuration > System > Basic > General from the menu. a.In the Access Point Name field, enter a unique name or leave the default name. b.From the Country/Region drop-down list, select the country where the access point is installed. c.Click Apply. 4.Select Configuration > IP > IP Settings from the menu. By default, the access point has a static IP address of 192.168.0.100 with a subnet mask of 255.255.255.0, and the DHCP client is disabled. a.Configure the IP settings for your LAN. b.Click Apply. Tip: If you configure the access point as a DHCP client, reserve an IP address on the DHCP server in your network by binding the access point’s MAC address to the IP address that is issued by the DHCP server. The next time that you log in to the access point, you need to use the reserved IP address. 5.Select Configuration > Security > Profile Settings from the menu. a.Configure one or more security profiles for your wireless network. b.After configuring each security profile, click Apply. Note:By default, the wireless radio is on and the default wireless mode is ng (that is, 802.11ng). Note:The online help and the reference manual provide more information about the configuration options. April 2013 NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. © NETGEAR, Inc. All rights reserved. For indoor use only. Valid in all EU member states, EFTA states, and Switzerland. NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134 USA Test Wireless Connectivity Using a computer or another wireless device, verify that you can establish a wireless connection to the access point. Now that you have finished the setup, you are ready to deploy the access point in your network. You can reconfigure the computer that you used to configure the access point back to its original TCP/IP settings. Deploy the Access Point 1.Disconnect the access point and position it where you plan to deploy it. The best location is elevated such as wall or ceiling mounted, at the center of your wireless coverage area, and within line of sight of all wireless devices. 2.Connect an Ethernet cable from the Ethernet LAN port on your access point to a LAN port on your router, switch, or hub. 3.Connect the power adapter to the access point and plug the power adapter into a power outlet. The Power and LAN LEDs should light. Tip: The access point supports Power over Ethernet (PoE). If you have a switch that provides PoE, you do not need to use the power adapter to power the access point. This can be especially convenient when the access point is installed in a high location far from a power outlet. 4.Using a computer or another wireless device, verify the following: •You can establish a wireless connection to the access point. •You can connect to the Internet through a browser. •You can access files and printers on your network. Troubleshooting Tips This section provides some tips for correcting simple problems that you might encounter. For more troubleshooting information, see the troubleshooting chapter in the reference manual. ProblemCausePossible Solution No LEDs are lit on the access point. The access point has no power. • Make sure that the power cord is connected to the access point and plugged in to a working power outlet or power strip. • Make sure that you are usi…

Text truncated - open the document above for the full version.

Netgear Inc. 350 East Plumeria Drive San Jose, CA 95134 U.S.A. Date: 2013/5/10 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: PY312400222 To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization o the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Hsiang, Tao Yuan Hsein 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Signature : _________________________________ Name and Job Title. : John Ramones / Director of Product Design and Regulations E-mail : [email protected] Tel. : 408-890-3530

Netgear Inc. 350 East Plumeria Drive San Jose, CA 95134 U.S.A. Confidentiality Request Letter Date: 2013/5/10 Federal Communications Commission Authorization and Evaluation Division FCC ID：PY312400222 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Signature : _________________________________ Name and Job Title. : John Ramones / Director of Product Design and Regulations E-mail : [email protected] Tel. : 408-890-3530

Netgear Inc. 350 East Plumeria Drive San Jose, CA 95134 U.S.A. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Date: May 15, 2013 Subject: FCC Application for FCC ID: PY312400222 To Whom it may concern, We, the undersigned, would like to declare that the composite portion catagorized as computer peripheral has been authorized under the Declaration of Conformity procedures, which the report issued from International Certification Corp..(report number: FD341901) Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Signature : _________________________________ Name and Job Title. : John Ramones / Director of Product Design and Regulations E-mail : [email protected] Tel. : 408-890-3530

Netgear Inc. 350 East Plumeria Drive San Jose, CA 95134 U.S.A. Date: May 10, 2013 Subject: Ad Hoc Mode Function Declaration To whom it may concern, We, NETGEAR, Inc. declare that the device does not support any non-US channels and country code selection in all the operational mode(s) for the following product. FCC ID: PY312400222 Regards, Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Signature : _________________________________ Name and Job Title. : John Ramones / Director of Product Design and Regulations E-mail : [email protected] Tel. : 408-890-3530

International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 1 of 18 Photographs of EUT International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 2 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 3 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 4 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 5 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 6 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 7 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 8 of 18

SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISION ENG APPDDATE 01AW-12370-021 of 1 AW, WN203, V1, PLBLR HU 02JAN2013R HUINITIAL DOCUMENT CREATION01 Pantone Cool Gray 7C Netgear white 490-10001-01 Pantone 200C Black NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. WAN MAC, SERIAL NUMBERS, SSID, PASSPHRASE, and WPS PIN TO BE PRINTED BY THE ODM. SSID, PASSPHRASE,WNS PIN NEED TO BE LEFT-ALIGNED. THE FONT/SIZE OF THE PRINTS NEED TO BE “AJB.39.39” OR BETTER IN ODM’s PRINT-SETTINGS AT FACTORY . 5. See NTGR DOC-00112 for SN standard. 6. NTGR SN AND MAC ADDRESS BARCODE TO BE ENCODED CODE128 AND INCLUDE PRINTED CHARACTERS BELOW BARCODES. THE BARCODE SIZE MUST BE 28-30MM BY 5MM OR LARGER . 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). user name: admin password: password http://192.168.0.100 272-11850-02 Made in China Designed by NETGEAR in California Single Band 802.11n Wireless Access Point WN203 Reset to Factory Defaults 12V1.0A Power 2.4 Ghz2.4 GhzConsoleLAN MAC SERIAL This device complies with part 15 of the FCC Rules and Canada ICES-003. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: PY312400222 IC: 4054A-12400221 ProSAFE Label Location

International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 9 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 10 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 11 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 12 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 13 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 14 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 15 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 16 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 17 of 18 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Project No.: 341901 Page No. : 18 of 18

Operational Description FCC ID : PY312400222 IC : 4054A-12400221 This is a Wireless AP which operates at 2.4GHz and supports 11b / 11g / HT20 / HT40. The access point supports Power over Ethernet (PoE). This can be especially convenient when the access point is installed in a high location far from a power outlet. RF ma i n chip AR9432 Os ci llating fre quency 40 MHz Ante nna type PCB / Di pole Ope ra ting frequency ra nge 2412~2462 MHz Modul ation type DSSS-DBPSK, DQPSK, CCK. BPSK, QPSK, 16QAM, 64QAM Worki ng voltage 3.3Vdc Cha nnel frequency Mode Channel Frequency (MHz) Mode Channel Frequency (MHz) 11b/g/n 20 1 2412 11 n 40 3 2422 2 2417 4 2427 3 2422 5 2432 4 2427 6 2437 5 2432 7 2442 6 2437 8 2447 7 2442 9 2452 8 2447 9 2452 10 2457 11 2462

International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FA341901 Page : 1 of 4 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : PY312400222 Equipment : ProSAFE® Single Band 802.11n Wireless Access point Model No. : WN203 Brand Name : NETGEAR Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Standard : 47 CFR FCC Part 2.1091 Received Date : Apr. 25, 2013 Tested Date : Apr. 25 ~ May 07, 2013 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FA341901 Page : 2 of 4 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 MPE EVALUATION RESULTS .............................................................................................................. 4 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FA341901 Page : 3 of 4 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA341901 Rev. 01 Initial issue May 15, 2013 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FA341901 Page : 4 of 4 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in Mw Pi= 3.1416 R= Measurement distance 1.3 MPE EVALUATION RESULTS Frequency Range (MHz) Maximum Conducted Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412~2462 24.32 3 20 0.107 1 ══END══

International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FR341901 Page : 1 of 95 Report Version: Rev. 01 FCC Test Report FCC ID : PY312400222 Equipment : ProSAFE® Single Band 802.11n Wireless Access point Model No. : WN203 Brand Name : NETGEAR Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Standard : 47 CFR FCC Part 15.247 Received Date : Apr. 25, 2013 Tested Date : Apr. 25 ~ May 07, 2013 We, International Certification Corp., w ould like to declare that the tested sample has been ev aluated and in compliance w ith the requirement of the abov e standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approv al of the applicant. It shall not be reproduced except in full w ithout the w ritten approv al of our laboratory. Approv ed & Rev iew ed by: Gary Chang / Manager Ty: XXX International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FR341901 Page : 2 of 95 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .......................................................................................................... 5 1.1 Information.................................................................................................................................. 5 1.2 Local Support Equipment List....................................................................................................... 7 1.3 T est Setup Chart ......................................................................................................................... 8 1.4 T he Equipment List...................................................................................................................... 9 1.5 T est Standards.......................................................................................................................... 10 1.6 Measurement Uncertainty .......................................................................................................... 10 2 TES T CONFIGURATION........................................................................................................... 11 2.1 T esting Condition ...................................................................................................................... 11 2.2 T he Worst T est Modes and Channel Details................................................................................ 11 3 TRANSMITTER TEST RESUL TS............................................................................................... 13 3.1 Conducted Emissions ................................................................................................................ 13 3.2 6dB Bandwidth and Occupied Bandwidth .................................................................................... 22 3.3 RF Output Power....................................................................................................................... 25 3.4 Power Spectral Density.............................................................................................................. 27 3.5 Unwanted Emissions into Restricted Frequency Bands ................................................................ 29 3.6 Unwanted Emissions into Non-Restricted Frequency Bands......................................................... 87 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FR341901 Page : 3 of 95 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR341901 Rev. 01 Initial issue May 15, 2013 International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FR341901 Page : 4 of 95 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 0.360MHz 49.04 (Margin -9.70dB) - QP Pass 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 2483.50MHz 73.98 (Margin -0.02dB) - Peak Pass 15.247(b)(3) Fundamental Emission Output Power Power [dBm]: 11b: 24.32 11g: 23.72 HT 20: 22.90 HT 40: 15.74 Pass 15.247(a)(2) 6dB Bandwidth Meet the requirement of limit Pass 15.247(e) Power Spectral Density Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Report No.: FR341901 Page : 5 of 95 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) Data Rate / MCS 2400-2483.5 b 2412-2462 1-11 [11] 2 1-11 Mbps 2400-2483.5 g 2412-2462 1-11 [11] 2 6-54 Mbps 2400-2483.5 n (HT 20) 2412-2462 1-11 [11] 2 MCS 0-15 2400-2483.5 n (HT 40) 2422-2452 3-9 [7] 2 MCS 0-15 Note 1: RF output power specifies that Maximum Conducted (Average) Output Power. Note 2: 802.11b uses a combination of DSSS-DBPSK, DQPSK, CCK modulation. Note 3: 802.11g/n uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM modulation. 1.1.2 Antenna Details Ant. No. Type Gain (dBi) Connector Remark 1 PCB 2.4 --- --- 2 PCB 3 --- --- 3 Dipole 3 R-SMA Optional, this antenna will not be sold with this device. 1.1.3 EUT Operational Condition Supply Voltage AC mains DC Type of DC Source Internal DC supply External DC adapter Battery International Certification Corp. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. Tel: 886-3-271-8666 Fax: 886-3-3…
