WN2500RP WiFi Range Extender Installation Guide 2 Getting Started The WN2500RP WiFi Range Extender increases the distance of a WiFi network by boosting the existing WiFi signal and enhancing the overall signal quality over long distances. An extender repeats the signals from an existing WiFi router or access point. Existing WiFi Sometimes your router does not provide the WiFi coverage you need. WiFi Range Extender Boosts the range of your existing WiFi and creates a stronger signal in hard-to-reach areas. 3 Meet Your Extender Before you install your extender, familiarize yourself with its LEDs, buttons, and ports. Front Panel 5 GHz Link Rate LED Device to Extender LED WPS LED 2.4 GHz Link Rate LED Ethernet LEDs Power LED 4 Rear Panel Factory reset button Ethernet ports Power input Power On/Off button WPS button Note: The WPS button is located on the top of the extender. 5 LED Descriptions Use the LEDs during installation to find the best location for the extender or to monitor the extender performance. Power LEDSolid Green. The extender is powered on. Off. The extender is powered off. 2.4 GHz Link Rate LED This LED indicates a 2.4 GHz WiFi connection between the extender and the router or access point. •Solid Green. Best connection. •Solid Yellow. Good connection. •Solid Red. Poor connection. •Off. No connection. 5 GHz Link Rate LED This LED indicates a 5 GHz WiFi connection between the extender and the router or access point. •Solid Green. Best connection. •Solid Yellow. Good connection. •Solid Red. Poor connection. •Off. No connection. 6 Device to Extender LED •Solid Green. The extender is connected to a computer or mobile device. •Off. The extender is not connected to a computer or wireless device. Ethernet LEDs •Solid Green. The Ethernet port has detected an Ethernet connection. •Off. No device is detected to an Ethernet port. WPS LED•Solid Green. WiFi security is enabled (WPS or WPA2). •Blinking Green. A WPS connection is in progress. •Off. WiFi security is not enabled. 7 Install the WiFi Extender Place the extender, apply power, and connect it to your WiFi network. Place the Extender and Apply Power 1.Place your extender in the same room as your WiFi router. Note: Proximity to the WiFi router is required only during the initial setup process. 2.Connect the power adapter to the extender and plug it into an electrical outlet. The Power LEDlights solid green. Connect to an Existing WiFi Network To extend the range of your WiFi network, you must connect the extender to your existing WiFi network. You can do this in one of two ways: •Connect with WPS. For more information, see Connect with WPS on page 8. •Connect with the genie web browser setup. For more information, see Connect with NETGEAR genie Smart Setup on page 10. 8 Connect with WPS Wi-Fi Protected Setup (WPS) lets you easily join a secure WiFi network without typing the network name and password. The WPS button is a physical button on the router or access point. To connect with WPS: 1.Press the WPS button located on the bottom of the extender. 2.Within two minutes, press the WPS button on your router or access point. The extender connects to your existing WiFi network, and the WPS LED and the 2.4 GHz Link Rate LED on your extender lights solid green. If the 2.4 GHz Link Rate LED does not light, or the LED is blinking amber, try again. If it still does not light, follow the instructions in Connect with NETGEAR genie Smart Setup on page 10. 3.If your WiFi router supports the 5 GHz band, repeat steps 1 and 2 to connect the extender to the 5 GHz band. 9 4.Find the new extender network name. The extender’s wireless network name (SSID) changes to your existing WiFi network name, with _2GEXT or _5GEXT at the end of the name, depending on whether the extender is connecting to your WiFi network in 2.4 GHz or 5 GHz. For example: •Existing WiFi network name. MyNetworkName •New extended network name. MyNetworkName_2GEXT or MyNetworkName_5GEXT 5.Connect your WiFi devices to the new extended network. Use the same WiFi password that you use for your WiFi router. 10 Connect with NETGEAR genie Smart Setup 1.After the extender is powered-on and the Power LED lights green, use a WiFi network manager on a computer or mobile device to find and connect to the NETGEAR_EXT (SSID) WiFi network. You can use any WiFi network utility on a computer, tablet, or smartphone to find and connect to the extender WiFi network. After the connection with the computer or mobile device is established, the Device to Extender LED lights solid green. 2.Open a web browser window from the same computer or mobile device. The browser takes you directly to the NETGEAR genie® smart setup. Note: If you are not automatically directed to NETGEAR genie, launch an Internet browser and type www.mywifiext.net in the address field of the browser. Enter admin for the user name and password for the password. 11 3.Select your 2.4 GHz WiFi network to extend, and click the Continue button. 4.Type the network password (also called passphrase or security key) in the Password field, and click the Continue button. 5.Select your 5 GHz WiFi router network, and click the Continue button. Note: If your router does not support the 5 GHz band, select the My router does not support 5GHz band radio button, and click the Continue button. 12 6.Type the network password (also called passphrase or security key) in the Password field, and click the Continue button. 7.Create a name (SSID) for your new extender WiFi network in the 2.4GHz Network Name (SSID) and the 5GHz Network Name (SSID) field, and click the Continue button. Note: You can change the SSID and WiFi password or use the same security settings as you existing network by selecting the check box. 13 The settings are applied and the following screen appears: 8.Use a WiFi network manager on the computer or mobile device to connect to the extender’s newly created WiFi network. Use your password to connect. 14 9.After you connect your device to the…
