Installation N300 WiFi Range Extender Model WN3000RPv3 2 Getting Started The NETGEAR WiFi Range Extender increases the distance of a WiFi network by boosting the existing WiFi signal and enhancing the overall signal quality over long distances. An extender repeats the signals from an existing WiFi router or access point. You can also connect the extender to your router or gateway with an Ethernet cable and use the extender as an access point. See Install the Extender as an Access Point on page 12. Existing WiFi Sometimes your router does not provide the WiFi coverage you need. WiFi Range Extender Boosts the range of your existing WiFi and creates a stronger signal in hard-to-reach areas. 3 Meet Your Extender Before you install your extender, familiarize yourself with its LEDs, buttons, and port. Front Panel Router Arrow LED Device Arrow LED Power LED WPS LED Router Link LED Client Link LED 4 Side and Bottom Panels Factory Reset button Ethernet port WPS button Power On/Off button 5 LED Descriptions Router Link LEDThis LED indicates the connection between the extender and the router or access point. Solid green. Best connection. Solid amber. Good connection. Solid red. Poor connection. Off. No connection. Client Link LEDThis LED indicates the connection between the extender and a computer or mobile device. Solid green. Best connection. Solid amber. Good connection. Solid red. Poor connection. Off. No connection. Power LEDSolid amber. The extender is booting. Solid green. The extender is powered on. Off. The extender is powered off. WPS LEDSolid green. WiFi security is enabled (WPA or WPA2). Blinking green. A WPS connection is in progress. Off. WiFi security is not enabled. Note: If the Router Arrow LED or Client Arrow LED blinks, see Find the Best Location on page 10. If no arrow LEDs light, the extender is in a good location. 6 Install the WiFi Extender 1. Place your extender in the same room as your WiFi router. Proximity to the WiFi router is required only during the initial setup process. 2. Plug the extender into an electrical outlet. The Power LED lights green. If the Power LED does not light, press the Power button. 3. Use a WiFi network manager on a computer or mobile device to find and connect to the NETGEAR_EXT (SSID) WiFi network. After the connection with the computer or mobile device is established, the Client Link LED lights. 4. Open a web browser window from the same computer or mobile device. The browser takes you directly to the NETGEAR genie Smart Setup. If you are not automatically directed to NETGEAR genie, launch a web browser and type www.mywifiext.net in the address field. Enter admin for the user name and password for the password. The NETGEAR genie screen displays. 7 5. Select the WiFi Range Extender (Wireless) radio button and click the Continue button. The extender searches for WiFi networks in your area and displays a list. 6. Select a WiFi network to extend and click the Continue button. 8 7. When prompted, type the network password (also called passphrase or security key) in the Password field, and click the Continue button. 8. In the Name field, type the name (SSID) for your new extender WiFi network and click the Continue button. You can use the same security settings as your existing network by selecting the check box. The settings are applied and the following screen displays. On iPads, iPhones, and MacBook computers, this screen automatically closes. 9. Use a WiFi network manager on the computer or mobile device to connect to the extender’s newly created WiFi network. Repeat this step for all of your computers and mobile devices. 9 10. If the screen is still displayed on your computer or device, select the following check box and click the Continue button. A message displays confirming that the extender has connected to the WiFi network. 11. Click the Finish button. 12. Unplug the extender and move it to a new location closer to the area with a poor WiFi signal. The location that you choose must be within the range of your existing WiFi router network. 13. Plug the extender into an electrical outlet. The Power LED lights green. If the Power LED does not light, press the Power button. 14. Use the Router Link LED to help you choose a spot where the extender-to-router connection is optimal. 10 Find the Best Location If the WiFi signal is weak, the first time you join the extender network, an arrow LED blinks for two minutes. If this happens, adjust the position of the extender. • If the Router arrow blinks, move the extender closer to the router. • If the Client arrow blinks, move the computer or mobile device closer to the extender. If no arrow LEDs are lit, the extender is in a good location. 11 Connect an Ethernet-Enabled Device After the extender is connected to your existing WiFi network, you can connect a wired device to the extender using an Ethernet cable. That device can then access your existing network through the WiFi connection. 1. Set up the extender. For more information, see Place the Extender and Apply Power on page 6 . Blu-ray player WiFi router 12 2. Connect the extender to an existing WiFi network. For more information, see Connect to an Existing WiFi Network on page 6 . 3. Plug the Ethernet cable from an Ethernet-enabled device in to the Ethernet port on the extender. Install the Extender as an Access Point You can use the extender as a WiFi access point, which creates a new WiFi hotspot within your local network. 1. Place your extender in the same room as your WiFi router. Proximity to the WiFi router is required only during the initial setup process. 2. Plug the extender into an electrical outlet. The Power LED lights green. If the Power LED does not light, press the Power button. 3. Use a WiFi network manager on a computer or mobile device to find and connect to the NETGEAR_EXT (SSID) WiFi network. After the connection with the computer or mobile device is established, the Client Link LED lights. 13 4. Open a web browser window from t…
