PY314200269N150 Wireless Router

Installation Package Contents Front and Back Panels N150 and N300 Wireless Routers Router (product appearance varies by model) Ethernet cable (only available for some models) Power adapter (varies by region) Power LED Internet LEDWiFi LED Ethernet LEDs 1–4 Ethernet ports 1–4 Internet port Power connector WPS/Reset button 1. Prepare your modem. Unplug your modem’s power. If it has a battery backup, remove the battery. 2. Connect your modem. Plug in your modem. Put the battery back in. Then cable the modem to the router’s Internet port. 3. Power on the router. Connect the power adapter to the router and plug the power adapter into an electrical outlet. The Power LED lights green. Wait for the WiFi LED to light green. 4. Connect a computer. Use an Ethernet cable to connect your computer to the Ethernet port on the router. You can also use WiFi to connect. To connect with WiFi, use the WiFi network name and password on the product label. 5. Log in to the router. Launch a web browser. NETGEAR genie displays. If you do not see genie, enter www.routerlogin.net in the address field of the web browser . When prompted, enter admin for the user name and password for the password. DSL or cable Internet Ethernet cable (only available for some models) Note: Product appearance varies by model. Ethernet cable (not included) Power adapter Modem April 2014 NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134, USA NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. © NETGEAR, Inc. All rights reserved. WiFi Network Name and Password The preset WiFi network name (SSID) and password (network key) are unique to your router, like a serial number. Because the router automatically uses WiFi security, you don’t need to set it up. The WiFi settings are on the product label. NETGEAR recommends that you use the preset WiFi settings because you can check the product label if you forget them. NETGEAR genie lets you change these settings. If you do so, write down the new WiFi settings and store them in a safe place. Find the preset WiFi settings on your router and record them here: WiFi network name (SSID) Network key (password) If you change the WiFi settings, write the new settings here for easy reference and store this booklet in a safe place. WiFi network name (SSID) Network key (password) Join the Router’s WiFi Network To connect your computer or WiFi device (such as a smartphone or gaming device) to your router’s WiFi network, you can use either the manual method or Wi-Fi Protected Setup (WPS) method. Manual Method 1. Open the software utility that manages your WiFi connections on the computer or WiFi device that you want to connect to your router. This utility scans for all wireless networks in your area. 2. Find and select your router’s WiFi network name (SSID). The SSID is on the product label. 3. Enter the router’s password (or your custom password if you changed it) and click the Connect button. The password is on the product label. 4. Repeat Step 1 through Step 3 to add other computers or WiFi devices. WPS Method If your computer or WiFi device supports WPS, you can use WPS to join the router’s WiFi network. For help with the WPS button on your computer or WiFi device, check the instructions or online help that came with that computer or WiFi device. Some older equipment cannot use WPS. Note: WPS does not support WEP security. If you are using WEP security, use the manual method. 1. Press the WPS/Reset button on the router with the end of a paper clip or a similar object for one to three seconds. The WiFi LED blinks green. 2. Within two minutes, on your computer or WiFi device, press its WPS button or click its onscreen WPS button. The WPS LED on the router lights solid green when the computer or WiFi device connects to your router. 3. Repeat this process to add other computers or WiFi devices. Reset Router to Factory Settings You can return the router to its factory settings. Use the end of a paper clip or a similar object to press and hold the WPS/Reset button on the back of the router for at least four seconds. The Power LED blinks green. The router resets and returns to the factory settings. Support Thank you for purchasing this NETGEAR product. After installing your device, locate the serial number on the label of your product and use it to register your product at https://my.netgear.com. You must register your product before you can use NETGEAR telephone support. NETGEAR recommends registering your product through the NETGEAR website. For product updates and web support, visit http://support.netgear.com. NETGEAR recommends that you use only the official NETGEAR support resources. You can get this installation guide in multiple languages and the user manual online at http://downloadcenter.netgear.com or through a link in the product’s user interface. For the current EU Declaration of Conformity, visit http://support.netgear.com/app/answers/detail/a_id/11621/. For regulatory compliance information, visit http://www.netgear.com/about/regulatory/. See the regulatory compliance document before connecting the power supply. Notification of Compliance Regulatory Compliance Information This document includes user requirements for operating NETGEAR products in accordance with national laws including usage of radio spectrum and operation of radio devices. Failure of the end-user to comply with the applicable requirements may result in unlawful operation and adverse action against the end-user by the applicable national regulatory authority. The NETGEAR product firmware limits operation to only the channels allowed in a particular region or country. Therefore, all options described in this document may not be available in your version of the product. This document applies to both Class A and Class B devices:  Class A devices are i…

Text truncated - open the document above for the full version.

NETGEAR Inc. 350 East Plumeria Drive San Jose, California 95134 USA Date: 2014/6/12 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: PY314200269 To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization o the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Hsiang, Tao Yuan Hsein 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Signature : _________________________________ Name and Job Title. : David Kay / Regulatory Compliance Manager E-mail : [email protected] Tel. : 408-890-3657

NETGEAR Inc. 350 East Plumeria Drive San Jose, California 95134 USA Date: June 12, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for confidentiality FCC ID: PY314200269 To whom it may concern: Short-term confidentiality Pursuant to DA 04-1705 of the Commission’s public notice, in order to comply with the marketing regulations in 47CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments for 180 days. ☒ Internal Photographs ☒ External Photographs ☒ User's manual ☒ Test Set up photo Permanent confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: ☒ Block Diagram ☒ Schematics ☒ Operation description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Signature : _________________________________ Name and Job Title. : David Kay / Regulatory Compliance Manager E-mail : [email protected] Tel. : 408-890-3657

NETGEAR Inc. 350 East Plumeria Drive San Jose, California 95134 USA Date: June 12, 2014 Subject: Ad Hoc Mode Function Declaration To whom it may concern, We, NETGEAR, Inc. declare that the device does not support any non-US channels and country code selection in all the operational mode(s) for the following product. FCC ID: PY314200269 Regards, Applicant’s company name : NETGEAR, Inc. Applicant’s company address : 350 East Plumeria Drive, San Jose, California 95134, USA Signature : Name and Job Title : David Kay / Regulatory Compliance Manager E-Mail : [email protected] Tel. : 408-890-3657

Project No.: EP460603 Page No. : 1 of 22 Photographs of EUT Model: JNR1010v2 Project No.: EP460603 Page No. : 2 of 22 Project No.: EP460603 Page No. : 3 of 22 Project No.: EP460603 Page No. : 4 of 22 Project No.: EP460603 Page No. : 5 of 22 Project No.: EP460603 Page No. : 6 of 22 Unilink Antenna Project No.: EP460603 Page No. : 7 of 22 Masterwave Antenna WNC Antenna Project No.: EP460603 Page No. : 8 of 22 Model: WNR1000v4 Project No.: EP460603 Page No. : 9 of 22 Project No.: EP460603 Page No. : 10 of 22 Project No.: EP460603 Page No. : 11 of 22 Project No.: EP460603 Page No. : 12 of 22 Project No.: EP460603 Page No. : 13 of 22 Unilink Antenna Project No.: EP460603 Page No. : 14 of 22 Masterwave Antenna WNC Antenna

SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISION ENG APPDDATE 01AW-12937-021 of 1 AW,PLBL,WNR1000,V4R HU 10JUN14R HUINITIAL DOCUMENT CREATION01 7 NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 5. See NTGR DOC-00112 for SN standard. 6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). PANTONE COOL GREY 1C PANTONE BLACK C SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISION ENG APPDDATE 01AW-12702-021 of 1 AW,JNR1010, PLBL,V2M HUMPHREY 12JUN14M HUMPHREYINITIAL DOCUMENT CREATION01 NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 5. See NTGR DOC-00112 for SN standard. 6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). PANTONE 430C WHITE Back Label location

Project No.: EP460603 Page No. : 15 of 22 Model: JNR1010v2 Project No.: EP460603 Page No. : 16 of 22 Project No.: EP460603 Page No. : 17 of 22 Project No.: EP460603 Page No. : 18 of 22 Project No.: EP460603 Page No. : 19 of 22 Model: WNR1000v4 Project No.: EP460603 Page No. : 20 of 22 Project No.: EP460603 Page No. : 21 of 22 Project No.: EP460603 Page No. : 22 of 22

Report No.: FA460603 Page : 1 of 6 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : PY314200269 Equipment : N150 Wireless Router Model No. : WNR1000v4, JNR1010v2 (please refer to section 1.1.1 for more details.) Brand Name : NETGEAR Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Standard : 47 CFR FCC Part 2.1091 Received Date : May 23, 2014 Tested Date : May 23 ~ Jun. 04, 2014 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FA460603 Page : 2 of 6 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 4 1.1 Information .............................................................................................................................................. 4 2 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 5 2.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 5 2.2 MPE EVALUATION FORMULA ............................................................................................................. 5 2.3 MPE EVALUATION RESULTS .............................................................................................................. 5 3 TEST LABORATORY INFORMATION ................................................................................................. 6 Report No.: FA460603 Page : 3 of 6 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA460603 Rev. 01 Initial issue Jul. 15, 2014 Report No.: FA460603 Page : 4 of 6 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Product Details The following models are provided to this EUT. Brand Name Model Name Product Name Description Ant. Housing NETGEAR WNR1000v4 N150 Wireless Router 1x 2dBi black color JNR1010v2 1x 5dBi white color  Difference between each model is only antenna and housing. PCB board of each model is identical.  The above models, model JNR1010v2 were selected as a representatives for the final test and only its data was recorded in this report. 1.1.2 Antenna Details Ant. No. Ant. brand Ant. Model EUT Model Type Gain (dBi) Connector Remarks 1 Unilink MCS-017-02 WNR1000v4 Dipole 2 --- 1 st source Ant. 2 Unilink MCS-042-02 JNR1010v2 Dipole 5 --- 3 Masterwave 98242MYYF021 WNR1000v4 Dipole 2 --- 2 nd source Ant. 4 Masterwave 98158MYYF006 JNR1010v2 Dipole 5 --- 5 WNC 08.22400.003 WNR1000v4 Dipole 2 --- 3 rd source Ant. 6 WNC 08.22400.009 JNR1010v2 Dipole 5 --- NOTE: 1. 1st source (Unilink), 2 nd source (Masterwave) and 3 rd source (WNC) antenna had been covered during the pretest and found that the worst antenna is 2 nd source (Masterwave); and the antenna with highest gain (5dBi) was selected for final testing. Report No.: FA460603 Page : 5 of 6 Report Version: Rev. 01 2 MPE EVALUATION OF MOBILE DEVICES Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. 2.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 2.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 2.3 MPE EVALUATION RESULTS Frequency Range (MHz) Maximum Conducted Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412~2462 19.58 5 20 0.057 1 Report No.: FA460603 Page : 6 of 6 Report Version: Rev. 01 3 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp, it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan Hsiang. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Tel: 886-2-2601-1640 Tel: 886-3-271-8666 No. 30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan, R.O.C. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══

Report No.: FR460603 Page : 1 of 64 Report Version: Rev. 01 FCC Test Report FCC ID : PY314200269 Equipment : N150 Wireless Router Model No. : WNR1000v4, JNR1010v2 (please refer to section 1.1.1 for more details.) Brand Name : NETGEAR Applicant : NETGEAR, Inc. Address : 350 East Plumeria Drive, San Jose, California 95134, USA Standard : 47 CFR FCC Part 15.247 Received Date : May 23, 2014 Tested Date : May 23 ~ Jun. 04, 2014 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FR460603 Page : 2 of 64 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 9 1.3 Test Setup Chart .................................................................................................................................... 9 1.4 The Equipment List .............................................................................................................................. 10 1.5 Test Standards ..................................................................................................................................... 11 1.6 Measurement Uncertainty .................................................................................................................... 11 2 TEST CONFIGURATION ..................................................................................................................... 12 2.1 Testing Condition ................................................................................................................................. 12 2.2 The Worst Test Modes and Channel Details ....................................................................................... 12 3 TRANSMITTER TEST RESULTS ........................................................................................................ 13 3.1 Conducted Emissions ........................................................................................................................... 13 3.2 6dB and Occupied Bandwidth .............................................................................................................. 16 3.3 RF Output Power .................................................................................................................................. 19 3.4 Power Spectral Density ........................................................................................................................ 21 3.5 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 23 3.6 Emissions in Non-Restricted Frequency Bands ................................................................................... 51 4 TEST LABORATORY INFORMATION ............................................................................................... 64 Report No.: FR460603 Page : 3 of 64 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR460603 Rev. 01 Initial issue Jul. 15, 2014 Report No.: FR460603 Page : 4 of 64 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 0.386MHz 38.33 (Margin -9.82dB) - AV Pass 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 4824.00MHz, 2483.50MHz 53.89 (Margin -0.11dB) - AV Pass 15.247(b)(3) Fundamental Emission Output Power Power [dBm]: 11b: 21.75 11g: 25.64 HT20: 25.58 HT40: 24.75 Pass 15.247(a)(2) 6dB Bandwidth Meet the requirement of limit Pass 15.247(e) Power Spectral Density Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Report No.: FR460603 Page : 5 of 64 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Product Details The following models are provided to this EUT. Brand Name Model Name Product Name Description Ant. Housing NETGEAR WNR1000v4 N150 Wireless Router 1x 2dBi black color JNR1010v2 1x 5dBi white color  Difference between each model is only antenna and housing. PCB board of each model is identical.  The above models, model JNR1010v2 was selected as a representative for the final test and only its data was recorded in this report. 1.1.2 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) Data Rate / MCS 2400-2483.5 b 2412-2462 1-11 [11] 1 1-11 Mbps 2400-2483.5 g 2412-2462 1-11 [11] 1 6-54 Mbps 2400-2483.5 n (HT20) 2412-2462 1-11 [11] 1 MCS 0-7 2400-2483.5 n (HT40) 2422-2452 3-9 [7] 1 MCS 0-7 Note 1: RF output power specifies that Maximum Peak Conducted Output Power. Note 2: 802.11b uses a combination of DSSS-DBPSK, DQPSK, CCK modulation. Note 3: 802.11g/n uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM modulation. Report No.: FR460603 Page : 6 of 64 Report Version: Rev. 01 1.1.3 Antenna Details Ant. No. Ant. brand Ant. Model EUT Model Type Gain (dBi) Connector Remarks 1 Unilink MCS-017-02 WNR1000v4 Dipole 2 --- 1 st source Ant. 2 Unilink MCS-042-02 JNR1010v2 Dipole 5 --- 3 Masterwave 98242MYYF021 WNR1000v4 Dipole 2 --- 2 nd source Ant. 4 Masterwave 98158MYYF006 JNR1010v2 Dipole 5 --- 5 WNC 08.22400.003 WNR1000v4 Dipole 2 --- 3 rd source Ant. 6 WNC 08.22400.009 JNR1010v2 Dipole…

Text truncated - open the document above for the full version.

Report No.: FR460603 Page: : 1 of 2 Report Version: Rev. 01 Photographs of the Test Configuration Conducted Emission Test Report No.: FR460603 Page: : 2 of 2 Report Version: Rev. 01 Radiated Emission Test
