Quick Start AC1200 WiFi Range Extender Model EX6150 2 Getting Started The NETGEAR WiFi Range Extender increases the distance of a WiFi network by boosting the existing WiFi signal and enhancing the overall signal quality over long distances. An extender repeats the signals from an existing WiFi router or access point. 3 Meet Your Extender Before you install your extender, familiarize yourself with its LEDs, buttons, and port. Front Panel and Side Panel Router Arrow LED Client Arrow LED Router Link LED Client Link LED Power LED WPS LED Ethernet port Access Point/Extender switch Power On/Off button Factory Reset button WPS button 4 LED Descriptions Router Link LED This LED indicates the connection between the extender and the router or access point. Solid green. Best connection. Solid amber. Good connection. Solid red. Poor connection. Off. No connection. Client Link LEDThis LED indicates the connection between the extender and a computer or WiFi device. Solid green. Best connection. Solid amber. Good connection. Solid red. Poor connection. Off. No connection. Power LED Solid amber. The extender is booting. Solid green. The extender is powered on. Off. The extender is powered off. WPS LEDSolid green. WiFi security is enabled (WPA or WPA2). Blinking green. A WPS connection is in progress. Off. WiFi security is not enabled. Note: If the Router Arrow LED or Client Arrow LED blinks, see Find the Best Location on page 11. If no arrow LEDs light, the extender is in a good location. 5 Use the Extender in Extender Mode Set the Access Point/Extender switch, place the extender, apply power, and connect it to your WiFi network. Set the Access Point/Extender Switch To use the extender in extender mode, set the Access Point/Extender switch to Extender. Place the Extender and Apply Power 1. Place your extender in the same room as your WiFi router. Proximity to the WiFi router is required only during the initial setup process. 2. Plug the extender into an electrical outlet. The Power LED lights green. If the Power LED does not light, press the Power On/Off button on the side of the extender. 6 Connect to an Existing WiFi Network To extend the range of your WiFi network, you must connect the extender to your existing WiFi network. You can do this in one of two ways: • Connect with WPS. For more information, see Connect with WPS on page 6 . • Connect with web browser setup. For more information, see Connect with Web Browser Setup on page 8. Connect with WPS Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network without typing the network name and password. Note: WPS does not support WEP network security. If you are using WEP security, follow the instructions in Connect with Web Browser Setup on page 8 . 1. Press the WPS button on the side panel of the extender. The WPS LED blinks. 2. Within two minutes, press the WPS button on your router or access point. The WPS LED on the extender lights solid green, the Router Link LED lights, and the extender connects to your existing WiFi network. 7 If the Router LED does not light, try again. If it still does not light, see Connect with Web Browser Setup on page 8. 3. If your WiFi router supports the 5 GHz band, repeat steps 1 and 2 to connect the extender to the 5 GHz band. 4. Find the new extended WiFi network name on your computer or WiFi device. The extender’s wireless network name (SSID) changes to your existing network name, with _2GEXT or _5GEXT at the end of the name, depending on whether the extender is connecting to your WiFi network in 2.4 GHz or 5 GHz. For example: • Existing WiFi network name. MyNetworkName • New extended network name. MyNetworkName_2GEXT or MyNetworkName_5GEXT 5. Connect your computer or WiFi devices to the new extended WiFi network. Use the same WiFi password that you use for your WiFi router. 6. Unplug the extender and move it to a new location closer to the area with a poor WiFi signal. 8 The location that you choose must be within the range of your existing WiFi router network. 7. Plug the extender into an electrical outlet. The Power LED lights green. If the Power LED does not light, press the Power On/Off button. 8. Use the Router Link LED on the front panel to help you choose a spot where the extender-to-router connection is optimal. Connect with Web Browser Setup 1. Use a WiFi network manager on a computer or WiFi device to find and connect to the NETGEAR_EXT (SSID) WiFi network. After the connection with the computer or WiFi device is established, the Client Link LED lights. 2. Open a web browser window from the same computer or WiFi device. The browser takes you directly to the NETGEAR genie Smart Setup. If you are not automatically directed to NETGEAR genie, launch a web browser and enter www.mywifiext.net in the address field. The login screen displays. 3. Click the NEW EXTENDER SETUP button. The Extender Setup screen displays. 4. Complete the Extender Setup screen and click the NEXT button. 9 NETGEAR genie displays. 5. Verify that the Access Point/Extender switch is set to Extender and click the CONTINUE button. 6. Select a WiFi network to extend and click the NEXT button. If you do not want to extend both WiFi bands, clear the 2.4GHz WiFi Networks or the 5GHz WiFi Networks checkbox. 7. Type the existing WiFi network password (also called passphrase or security key) in the Password (network key) field and click the NEXT button. 8. Set the network name (SSID) and password for your new extender WiFi network and click the NEXT button. 9. Use a WiFi network manager on the computer or WiFi device to connect to the new extended WiFi network. Repeat this step for all of your computers and WiFi devices. 10. Select the check box at the bottom of the screen and click the NEXT button. A message displays confirming that the extender has connected to the WiFi network. 11. Click the Next button. The reregistration screen displays. 10 12. Complete the registration fields and click the Finish button to complete the setup. If you d…

Text truncated - open the document above for the full version.

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2014/11/17 G E N E R A L D E C L A R A T I O N We, NETGEAR, INC. declare that the device does not support channel 12 ~ 14 in 2.4GHz band and any non- US channels in all the operational mode(s) for the following product. FCC ID: PY314300283 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 P O W E R O F A T T O R N E Y Date: 2014/11/17 FCC ID: PY314300283 To whom it may concern: We, the undersigned, hereby authorize Amanda Wu of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to Contact us. Thank you! Sincerely yours, ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2014/11/17 FCC ID: PY314300283 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Federal Communications Commission Authorization and Evaluation Division Date: November 18, 2014 Confidentiality Request FCC ID: PY314300283 Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

Report No.: 141003E10 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 141003E10 Page 2

(Fig. 1) FCC ID: PY314300283 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. EUT Back Label

SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REVDESCRIPTION OF REVISIONENG APPDDATE Pantone Cool Gray 11C 01AW-12973-011 of 1 AW, EX6150, V1, PLBLM HUMPHREY 15JUL14M HUMPHREYINITIAL DOCUMENT CREATION01 7 NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 5. See NTGR DOC-00112 for SN standard. 6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS).

Report No.: 141003E10 Page 3 Report No.: 141003E10 Page 4 Report No.: 141003E10 Page 5 Report No.: 141003E10 Page 6 Report No.: 141003E10 Page 7 Report No.: 141003E10 Page 8

Report No.: SA141003E10 1 of 9 Report Format Version 5.2.1 RF EXPOSURE REPORT REPORT NO.: SA141003E10 MODEL NO.: EX6150 FCC ID: PY314300283 RECEIVED: Oct. 03, 2014 TESTED: Dec. 09, 2014 ISSUED: Jan. 12, 2015 APPLICANT: NETGEAR, Inc. ADDRESS: 350 East Plumeria Drive San Jose, CA 95134 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA141003E10 2 of 9 Report Format Version 5.2.1 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT ............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN ...................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .......................... 7 Report No.: SA141003E10 3 of 9 Report Format Version 5.2.1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA141003E10 Original release Jan. 12, 2015 Report No.: SA141003E10 5 of 9 Report Format Version 5.2.1 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA141003E10 6 of 9 Report Format Version 5.2.1 5. ANTENNA GAIN The antennas provided to the EUT, please refer to the following table: PCB Chain No. Brand Model Antenna Gain(dBi) < including cable loss> Frequency range (MHz ~ MHz) Antenna Type Connecter Type Cable Length (mm) Chain 0 NETGEAR NA 3.1 2400~2500 Dipole i-pex 50 2.7 5150~5250 2.9 5250~5350 2.2 5470~5725 2.6 5725~5850 Chain 1 NETGEAR NA 3.1 2400~2500 Dipole i-pex 50 2.7 5150~5250 2.9 5250~5350 2.2 5470~5725 2.6 5725~5850 Report No.: SA141003E10 7 of 9 Report Format Version 5.2.1 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): 802.11b: FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 ~ 2462 212.595 6.11 20 0.17270 1 Directional gain = 3.1dBi + 10log(2) = 6.11dBi 802.11g: FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 ~ 2462 616.801 6.11 20 0.50104 1 Directional gain = 3.1dBi + 10log(2) = 6.11dBi 802.11n (HT20): FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 ~ 2462 471.291 6.11 20 0.38284 1 Directional gain = 3.1dBi + 10log(2) = 6.11dBi 802.11n (HT40): FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2422 ~ 2452 122.807 6.11 20 0.09976 1 Directional gain = 3.1dBi + 10log(2) = 6.11dBi Report No.: SA141003E10 8 of 9 Report Format Version 5.2.1 For 15.247(5GHz): 802.11a: FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 333.071 5.61 20 0.24114 1 Directional gain = 2.6dBi + 10log(2) = 5.61dBi 802.11ac (VHT20) FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 329.636 5.61 20 0.23865 1 Directional gain = 2.6dBi + 10log(2) = 5.61dBi 802.11ac (VHT40) FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DI…
