PY315100319Nighthawk X4S AC2600 Smart WiFi Router

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operation in the 5.15-5.25GHz band are restricted to indoor usage only. Radiation Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 29cm between the radiator & your body.

Quick Start Package Contents The package contains the following items. In some regions, a resource CD is included in the package. Nighthawk X4S AC2600 Smart WiFi Router Model R7800 Support Thank you for purchasing this NETGEAR product. You can visit www.netgear.com/support to register your product, get help, access the latest downloads and user manuals, and join our community. We recommend that you use only official NETGEAR support resources. Trademarks © NETGEAR, Inc. NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non‑NETGEAR trademarks are used for reference purposes only. Compliance For the current EU Declaration of Conformity, visit: http://support.netgear.com/app/answers/detail/a_id/11621/. For regulatory compliance information, visit: http://www.netgear.com/about/regulatory/ . See the regulatory compliance document before connecting the power supply. NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134 USA August 2015 Router Ethernet cable Power adapter (varies by region) Antennas (4) BETA DOCUMENT 21 1. Attach and position the antennas. To determine where to attach the antennas, match the labels on the antennas with the labels on the router. Attach the antennas on the threaded antenna posts. Position the antennas vertically for the best WiFi performance. 2. Prepare your modem. Unplug your modem’s power. If it uses a battery backup, remove the battery. 3. Connect your modem. Plug in your modem. Put the battery back in. Then cable the modem to the yellow Internet port on the router. 4. Power on the router. The Power LED lights amber and then turns white when the router is ready. 5. Connect a device. You can use an Ethernet cable or use WiFi to connect a device to the router. To connect with WiFi, use the WiFi network name and password on the product label. 6. Log in to the router. Launch a web browser. NETGEAR genie displays. If you do not see genie, enter www.routerlogin.net in the address field of the web browser. When prompted, enter admin for the user name and password for the password. Follow the genie steps to connect to the Internet. 8. Get the user manual. You can get the user manual online at http://downloadcenter.netgear.com or through a link in the product’s user interface. Router Ethernet cable Cable or DSL Internet Modem Power adapter You can use this diagram to connect your router or follow the detailed instructions in this booklet. 7. Get free apps. During the installation process, genie prompts you to download two free apps: • genie app. A personal dashboard that lets you monitor, control, and repair your home network. • ReadySHARE Vault app. Enables automatic continuous backup of a Windows computer to a USB device that’s connected to your router. Ethernet cable Computer WiFi device Computer 1 Hardware Features Top and Side Panels The LEDs, buttons, and USB ports are shown in the following figure. For more information about the LEDs and buttons on the top panel, see Top Panel LEDs and Buttons on page 2. Rear Panel The rear panel connections and buttons are shown in the following figure. LEDsWPS button with LED Reset button Ethernet ports 1–4 Internet port Power On/Off button Power connector LED Indicator On/Off switch eSATA port USB 1 port USB 2 port WiFi button with LED 2 Top Panel LEDs and Buttons The LEDs on the top of the router light to indicate router activity: LEDDescription Power LED • Solid white. The router is ready. • Solid amber. The router is starting. • Blinking amber. The firmware is upgrading, or the Reset button was pressed. • Blinking white. The firmware is corrupted. • Off. Power is not supplied to the router. Internet LED • Solid white. The Internet connection is ready. • Solid amber. The router detected an Ethernet cable connection to the modem. • Blinking white. The port is sending or receiving traffic. • Off. No Ethernet cable is connected between the router and the modem. 2.4 GHz WiFi LED • Solid white. The 2.4 GHz WiFi radio is operating. • Blinking. The router is sending or receiving WiFi traffic. • Off. The 2.4 GHz WiFi radio is off. 5 GHz WiFi LED • Solid white. The 5 GHz WiFi radio is operating. • Blinking. The router is sending or receiving WiFi traffic. • Off. The 5 GHz WiFi radio is off. USB 1 LED USB 2 LED The USB 1 LED is for the blue USB 3.0 USB port. The USB 2 LED is for the USB 2.0 port. • Solid white. A USB storage device is connected and is ready. • Blinking. A USB storage device is plugged in and is trying to connect. • Off. No USB storage device is connected, or someone clicked the Safely Remove Hardware button in the router’s web interface and it is now safe to remove the attached USB storage device. 3 LEDDescription eSATA LED • Solid white. An eSATA device is connected and is ready. • Blinking white. An eSATA device is plugged in and is trying to connect. • Off. No eSATA device is connected. Ethernet ports 1–4 LEDs The LED color indicates the speed: white for Gigabit Ethernet connections and amber for 100 Mbps or 10 Mbps Ethernet connections. • Solid. A powered‑on device is connected to the Ethernet port. • Blinking. The port is sending or receiving traffic. • Off. No device is connected to this Ethernet port. WiFi On/Off button with LED Pressing this button for two seconds turns the 2.4 GHz and 5 GHz WiFi radios on and off. If this LED is lit, the WiFi radios are on. If this LED is off, the WiFi WPS button with LED This button lets you use WPS to join the WiFi network without typing the WiFi password. The WPS LED blinks white during this process and then lights solid white. 4 Install Your Router Make sure that your Internet service is active before you install your router. ¾To install your router: 1. Attach and position the antennas: a. To determine where to attach the antennas, match the labels on the antennas with the labels on the router. b. Align the antennas with the antenna posts on the router. c. Attach the antennas on the threaded antenna posts. d. Position the antennas for the best WiFi perfor…

Text truncated - open the document above for the full version.

Netgear Incorporated 350 East Plumeria Drive San Jose California, United Sates 95134 TEL: 408-890-3657 FAX: 408-907-8097 FCC ID: PY315100319 Date: October 29, 2015 We, Nergear Incorporated declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCC ID: PY315100319 If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------- David Kay / Regulatory Compliance Manager Tel: 4088903657 Fax: 4089078097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California, United Sates 95134 TEL: 408-890-3657 FAX: 408-907-8097 Date: 2015-10-29 FCC ID: PY315100319 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Software Operational Description Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ----------------------------------- David Kay / Regulatory Compliance Manager Tel: 4088903657 Fax: 4089078097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California, United Sates 95134 TEL: 408-890-3657 FAX: 408-907-8097 Date: 2015-10-29 FCC ID: PY315100319 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 2015/12/2 in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ----------------------------------- David Kay / Regulatory Compliance Manager Tel: 4088903657 Fax: 4089078097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive San Jose California, United Sates 95134 TEL: 408-890-3657 FAX: 408-907-8097 Date: 2015-10-29 FCC ID: PY315100319 A U T H O R I Z A T I O N L E T T E R To whom it may concern: We, the undersigned, hereby authorize Andrea Hsia / Senior Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Andrea Hsia / Senior Specialist of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ----------------------------------- David Kay / Regulatory Compliance Manager Tel: 4088903657 Fax: 4089078097 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6

SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISION ENG APPDDATE 01AW-13335-011 of 1 AW,R7800NA,PLBL,V2M HUMPHREY 01SEP15M HUMPHREYINITIAL DOCUMENT CREATION01 Pantone Cool Gray 5C Pantone Black C 7 NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 5. See NTGR DOC-00112 for SN standard. 6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). Made in Vietnam

Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14

Report No.: SA150826C05 Page No. 1 / 11 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA150826C05 FCC ID: PY315100319 Test Model: R7800 Received Date: Aug. 21, 2015 Test Date: Sep. 04 ~ Oct. 28, 2015 Issued Date: Oct. 30, 2015 Applicant: NETGEAR INC. Address: 350 East Plumeria Drive, San Jose, CA 95134, USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA150826C05 Page No. 2 / 11 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result Of Maximum Conducted Power .......................................................................... 6 Report No.: SA150826C05 Page No. 3 / 11 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA150826C05 Original release Oct. 30, 2015 Report No.: SA150826C05 Page No. 4 / 11 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Nighthawk X4S AC2600 Smart WiFi Router Brand: NETGEAR Test Model: R7800 Sample Status: Engineering sample Applicant: NETGEAR INC. Test Date: Sep. 04 ~ Oct. 28, 2015 Standards: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date:Oct. 30, 2015 Polly Chien / Specialist Approved by : , Date:Oct. 30, 2015 Ken Liu / Senior Manager Report No.: SA150826C05 Page No. 5 / 11 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 29cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA150826C05 Page No. 6 / 11 Report Format Version: 6.1.1 3 Calculation Result Of Maximum Conducted Power Band Modulation type Frequency Channel (MHz) Max Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) CDD Mode 2.4GHz 802.11b 2412 29.896.23 29 0.387 1 2422 29.846.43 29 0.401 1 2437 29.846.13 29 0.374 1 802.11g 2412 27.35 6.23 29 0.216 1 2422 29.84 6.43 29 0.401 1 2437 27.13 6.13 29 0.200 1 802.11n(20MHz) 2412 27.356.23 29 0.216 1 2437 29.846.43 29 0.401 1 2462 27.356.13 29 0.211 1 802.11n(40MHz) 2422 23.79 6.43 29 0.100 1 2437 26.76 6.43 29 0.197 1 2452 25.51 6.23 29 0.141 1 5GHz (U-NII-1) 802.11a 5180 29.026.63 29 0.348 1 5200 29.056.73 29 0.358 1 5240 29.046.93 29 0.374 1 802.11n(20MHz) 5180 29.04 6.63 29 0.349 1 5200 28.99 6.73 29 0.353 1 5240 28.94 6.93 29 0.366 1 802.11n(40MHz) 5190 26.13 6.73 29 0.183 1 5230 29.97 6.93 29 0.463 1 802.11ac(80MHz) 5210 25.036.83 29 0.145 1 5GHz (U-NII-3) 802.11a 5745 29.777.63 29 0.520 1 5785 29.777.53 29 0.508 1 5825 29.887.63 29 0.533 1…
