Quick Start Nighthawk X4 AC2350 Smart WiFi Router Model R7500 Support Thank you for purchasing this NETGEAR product. After installing your device, locate the serial number on the label of your product and use it to register your product at https://my.netgear.com. You must register your product before you can use NETGEAR telephone support. NETGEAR recommends registering your product through the NETGEAR website. For product updates and web support, visit http://support.netgear.com. NETGEAR recommends that you use only the official NETGEAR support resources. You can get the user manual online at http://downloadcenter.netgear.com or through a link in the product’s user interface. Trademarks NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. © NETGEAR, Inc. All rights reserved. Compliance For the current EU Declaration of Conformity, visit: http://support.netgear.com/app/answers/detail/a_id/11621/. For regulatory compliance information, visit: http://www.netgear.com/about/regulatory/. See the regulatory compliance document before connecting the power supply. Package Contents The box contains the following items. In some regions, a resource CD is included in the package. Installation Video To view the Nighthawk installation video, visit http://www.netgear.com/R7500_vid1 or use this QR code: NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134 USA AC2350 Smart WiFi Router Ethernet cable Power adapter Antennas (4) October 2014 1. Attach the antennas. To determine where to attach the antennas, match the labels on the antennas with the labels on the router. Attach the antennas on the threaded antenna posts. Position the antennas for the best WiFi performance. NETGEAR recommends that you position all of the antennas vertically, as shown. 2. Prepare your modem. Unplug your modem’s power. If it has a battery backup, remove the battery. 3. Connect your modem. Plug in your modem. Put the battery back in. Then cable the modem to the yellow Internet port on the router. 4. Power on the router. The Power LED lights amber and then turns white when the router is ready. 5. Connect a computer. You can use an Ethernet cable or connect with WiFi. To connect with WiFi, use the WiFi network name and password on the product label. 6. Log in to the router. Launch a web browser. NETGEAR genie displays. If you do not see genie, enter www.routerlogin.net in the address field of the web browser. When prompted, enter admin for the user name and password for the password. Follow the genie steps to connect to the Internet. 7. Get the genie app. Download the free genie app from www.NETGEAR.com/genie. Easily share media, files, and printers on the network from your smartphone, tablet, or laptop. 8. Get the user manual. You can get the user manual online at http://downloadcenter.netgear.com or through a link in the product’s user interface. Ethernet cable Router Ethernet cable DSL or cable Internet Modem Power adapter You can use this diagram to connect your router or follow the detailed instructions in this booklet. 1 LEDs The LEDs on the top of the router light to indicate router activity: Power Internet 2.4 GHz WiFi 5 GHz WiFi USB 3.0 port 1 USB 3.0 port 2 eSATA port Ethernet ports 1–4 WiFi On/Off button with LED WPS button with LED You can use the LED Off/On switch on the rear panel of the router to turn the LEDs on the top of the router on or off. Note: The Power LED stays lit even if the LED Off/On switch is in the off position. LED Off/On switch 2 Install Your Router Make sure that your Internet service is active before you install your router. ¾To install your router: 1. Attach the antennas. a. To determine where to attach the antennas, match the labels on the antennas with the labels on the router. b. Align the antennas with the antenna posts on the router. c. Attach the antennas on the threaded antenna posts. d. Position the antennas for the best WiFi performance. NETGEAR recommends that you position all of the antennas vertically, as shown. 3 2. Prepare your modem. a. Unplug your modem’s power. b. If the modem has a battery backup, remove its batteries. c. If your modem was already connected to another router, disconnect the cable between your modem and that router. Make sure that your modem is turned off and is cabled only to the wall jack for your Internet service. 3. Connect your modem. a. Plug in, then turn on your modem. b. If you removed the batteries, replace them. c. With the yellow Ethernet cable that came with the router, connect your modem to the yellow Internet port on your router. Modem DSL or cable Internet Router Ethernet cable Modem Internet DSL or cable 4 4. Add power to the router. a. Connect the power adapter to the router and plug the power adapter into an outlet. b. Wait for the Power LED on the front panel to light amber and turn white. If no LEDs are lit, press the Power On/Off button on the rear panel of the router. 5. Connect a computer. You can use an Ethernet cable or connect with WiFi: • For a wired connection, use an Ethernet cable (not included) to connect your computer to a black Ethernet port on your router. • To connect with WiFi, use the WiFi settings on the product label. Power adapter Internet Internet DSL or cable Modem Router DSL or cable Modem Router Ethernet cable Ethernet cable Power adapter Ethernet cable 5 6. Launch a web browser. The first time that you connect to the router, the genie screen displays. Follow the genie steps to connect to the Internet. If the genie screen does not display, try the following: • Close and reopen the browser. • Make sure that your computer is connected to one of the four black LAN Ethernet ports on the router, or that you are connected to your WiFi network. • Make sure that the router has full power, and that its Power LED is lit. • If your computer is set t…

Text truncated - open the document above for the full version.

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2015/5/20 G E N E R A L D E C L A R A T I O N We, NETGEAR, INC. declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non- US channels in all the operational mode(s) for the following product. FCC ID: PY315200310 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 P O W E R O F A T T O R N E Y Date: 2015/5/20 FCC ID: PY315200310 To whom it may concern: We, the undersigned, hereby authorize Amanda Wu of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to Contact us. Thank you! Sincerely yours, ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2015/5/20 FCC ID: PY315200310 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description Software Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Federal Communications Commission Authorization and Evaluation Division Date: May 20, 2015 Confidentiality Request FCC ID: PY315200310 Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

Report No.: 150430E10 Page No. 1 / 14 CONSTRUCTION PHOTOS OF EUT Report No.: 150430E10 Page No. 13 / 14 Report No.: 150430E10 Page No. 14 / 14

SHEET: AUTHOR: TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISION ENG APPD DATE 01 AW-13286-01 1 of 1 AW,PLBL,R8500NAS,V1 M HUMPHREY 19MAY15 M HUMPHREY INITIAL DOCUMENT CREATION 01 Pantone Cool Gray 5CBlack 7 NOTE:1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT.3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT.4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM.5. See NTGR DOC-00112 for SN standard.6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). Nighthawk X4S Smart WIFI Router Model: R7800 Nighthawk X4S SHEET: AUTHOR: TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISION ENG APPD DATE 01 AW-13285-01 1 of 1 AW,PLBL,R8500PAS,V1 M HUMPHREY 19MAY15 M HUMPHREY INITIAL DOCUMENT CREATION 01 Pantone Cool Gray 5CBlack NOTE:1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT.3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT.4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM.5. See NTGR DOC-00112 for SN standard.6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). Nighthawk X4S Nighthawk X4S Smart WIFI Router Model: R7800

Report No.: 150430E10 Page No. 2 / 14 Report No.: 150430E10 Page No. 3 / 14 Report No.: 150430E10 Page No. 4 / 14 Report No.: 150430E10 Page No. 5 / 14 Report No.: 150430E10 Page No. 6 / 14 Report No.: 150430E10 Page No. 7 / 14 Report No.: 150430E10 Page No. 8 / 14 Report No.: 150430E10 Page No. 9 / 14 Report No.: 150430E10 Page No. 10 / 14 Report No.: 150430E10 Page No. 11 / 14 Report No.: 150430E10 Page No. 12 / 14

Report No.: SA150430E10 Page No. 1 / 7 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA150430E10 FCC ID: PY315200310 Test Model: R7800 Received Date: Mar. 25, 2015 Test Date: May 14 to 15, 2015 Issued Date: May 21, 2015 Applicant: NETGEAR, Inc. Address: 350 East Plumeria Drive San Jose, CA 95134 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. Report No.: SA150430E10 Page No. 2 / 7 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits For Maximum Permissible Exposure (MPE) ............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Antenna Gain ......................................................................................................................................... 6 4 Calculation Result of Maximum Conducted Power ........................................................................... 7 Report No.: SA150430E10 Page No. 3 / 7 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA150430E10 Original release. May 21, 2015 Report No.: SA150430E10 Page No. 5 / 7 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 32cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA150430E10 Page No. 6 / 7 Report Format Version: 6.1.1 3 Antenna Gain The antennas provided to the EUT, please refer to the following table: Antenna No. Ant. Gain(dBi) Frequency range (GHz to GHz) Antenna Type Connecter Type External (1) 0.67 2.4~2.4835 Dipole i-pex(MHF) 1.16 5.15~5.25 Dipole i-pex(MHF) 0.62 5.25~5.35 Dipole i-pex(MHF) 0.4 5.47~5.725 Dipole i-pex(MHF) 0.21 5.725~5.85 Dipole i-pex(MHF) External (2) 0.67 2.4~2.4835 Dipole i-pex(MHF) 1.16 5.15~5.25 Dipole i-pex(MHF) 0.62 5.25~5.35 Dipole i-pex(MHF) 0.4 5.47~5.725 Dipole i-pex(MHF) 0.21 5.725~5.85 Dipole i-pex(MHF) External (3) 0.67 2.4~2.4835 Dipole i-pex(MHF) 1.16 5.15~5.25 Dipole i-pex(MHF) 0.62 5.25~5.35 Dipole i-pex(MHF) 0.4 5.47~5.725 Dipole i-pex(MHF) 0.21 5.725~5.85 Dipole i-pex(MHF) External (4) 0.67 2.4~2.4835 Dipole i-pex(MHF) 1.16 5.15~5.25 Dipole i-pex(MHF) 0.62 5.25~5.35 Dipole i-pex(MHF) 0.4 5.47~5.725 Dipole i-pex(MHF) 0.21 5.725~5.85 Dipole i-pex(MHF) Report No.: SA150430E10 Page No. 7 / 7 Report Format Version: 6.1.1 4 Calculation Result of Maximum Conducted Power For 15.247(2.4GHz) CDD Mode Frequency Band (MHz) Max Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412-2462 962.497 6.69 32 0.34905 1 NOTE: Directional gain = 0.67dBi + 10log(4) = 6.69dBi For 15.247(5GHz) CDD Mode Frequency Band (MHz) Max Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 5745-5825 944.69 6.23 32 0.30816 1 Beamforming Mode Frequency Band (MHz) Max Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 …
