PY315200315AC1600 WiFi VDSL/ADSL Modem Router

Quick Start AC1600 WiFi Modem Router Model D6400 Support Thank you for purchasing this NETGEAR product. After installing your device, locate the serial number on the label of your product and use it to register your product at https://my.netgear.com. You must register your product before you can use NETGEAR telephone support. NETGEAR recommends registering your product through the NETGEAR website. For product updates and web support, visit http://support.netgear.com. NETGEAR recommends that you use only the official NETGEAR support resources. You can get the user manual online at http://downloadcenter.netgear.com or through a link in the product’s user interface. Trademarks © NETGEAR, Inc. NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non‑NETGEAR trademarks are used for reference purposes only. Compliance For the current EU Declaration of Conformity, visit: http://support.netgear.com/app/answers/detail/a_id/11621/. For regulatory compliance information, visit: http://www.netgear.com/about/regulatory/. See the regulatory compliance document before connecting the power supply. Package Contents The box contains the following items. In some regions, a resource CD is included in the package. NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134 USA December 2014 Modem router Ethernet cable Power adapter (varies by region) Phone cable ADSL microfilter (varies by region) 1. Connect the modem router to a DSL service or a cable or fiber modem. To connect to a DSL service (ADSL or VDSL): Install an ADSL microfilter or a VDSL microfilter and connect it to the ADSL port on the modem router. To connect to a cable or fiber modem: Prepare the cable or fiber modem and connect it to the red Internet port on the modem router. 2. Power on the modem router. Wait for the Power LED to light green. If the Power LED does not light, press the Power On/Off button. Wait for the WiFi LED to light blue. 3. Check the DSL LED. If the modem router is connected to a DSL service, the DSL LED lights green. 4. Connect a computer. You can use an Ethernet cable or connect with WiFi. To connect with WiFi, use the WiFi network name and password on the product label. 5. Log in to the modem router. Launch a web browser. NETGEAR genie displays. If you do not see genie, enter www.routerlogin.net in the address field of the web browser. When prompted, enter admin for the user name and password for the password. NETGEAR genie determines your Internet connection. If the modem router successfully connects to the Internet, the Internet LED lights green. 6. Get the genie app. Download the free genie app from www.NETGEAR.com/genie. Easily share media, files, and printers on the network from your smartphone, tablet, or laptop. 7. Get the user manual. You can get the user manual online at http://downloadcenter.netgear.com or through a link in the product’s user interface. Ethernet cable ADSL or VDSL Internet Cable or fiber modem Power adapter You can use this diagram to connect your modem router or follow the detailed instructions in this booklet. ADSL or VDSL microfilter Ethernet cable (not included) Phone cable Modem router Cable or fiber Internet 1 Front and Side Panels The status LEDs and buttons on the router are shown in the following figure. Back Panel The connections and buttons on the rear panel of the router are shown in the following figure. WPS button WiFi button USB 2.0 port Power LED Internet LED WiFi LED USB port LED DSL LED Internet port Reset button Power On/Off button Power connector USB 2.0 port ADSL port Ethernet ports 1–4 2 Additional Information for DSL Service Make sure that your DSL service (ADSL or VDSL) is active before you install the modem router. You need the following information to install your modem router and connect to the Internet: • DSL user name and password. This information is included in the welcome letter your DSL Internet service provider (ISP) sent you when you signed up for your service. • Your telephone number or DSL account number. If you do not use voice service, you can use your DSL account number instead. If you do not know or cannot locate your DSL user name and password, call your DSL ISP. Note: If your provider says that they do not support NETGEAR services, tell them that you need only your DSL user name and password; you do not need support. 3 Install Your Modem Router Make sure that your Internet service is active before you install your modem router. ¾To install your modem router: 1. Connect the modem router to a DSL service (ADSL or VDSL) or a cable or fiber modem. To connect the modem router to a DSL service (ADSL or VDSL): a. Install an ADSL or VDSL microfilter between your phone line and a phone. Note: A VDSL microfilter is not included in the box. b. Use the phone cable to connect the microfilter to the ADSL port on the modem router. ADSL or VDSL Internet ADSL or VDSL microfilter Phone cable Modem router Phone cable (not included) 4 To connect the modem router to a cable or fiber modem: a. Unplug your modem’s power, leaving the modem connected to the wall jack for your Internet service. If your modem uses a battery backup, remove the battery. b. Plug in and turn on your modem. If your modem uses a battery backup, put the battery back in. c. With an Ethernet cable, connect your modem to the red Internet port on your modem router. 2. Add power to the modem router: a. Connect the power adapter to the modem router and plug the power adapter into an outlet. b. Wait for the Power LED to light green. If the Power LED does not light, press the Power On/Off button. Ethernet cable (not included) Modem router Cable or fiber Internet Cable or fiber modem Power adapter Modem router 5 c. Wait for the WiFi LED to light blue. If the WiFi LED does not light, press the WiFi On/Off button . 3. Check the DSL LED. If the modem router is connected to a DSL service, the DSL LED lights green. 4. Connect a computer. You can use an Ethernet cable or connect with WiFi: • For a wired c…

Text truncated - open the document above for the full version.

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Federal Communications Commission Authorization and Evaluation Division Date: November 9, 2015 Confidentiality Request FCC ID: PY315200315 Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2015-11-09 FCC ID: PY315200315 G E N E R A L D E C L A R A T I O N We, NETGEAR, INC hereby declare that the device meets all the other requirements specified in Part 15E Section 15.407. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ------------------------------------------------------ David Kay/ Regulatory Compliance Manager NETGEAR, INC. TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

Report No.: 141016E01B Page 1 Reference No.: 150602E04 CONSTRUCTION PHOTOS OF EUT Report No.: 141016E01B Page 2 Reference No.: 150602E04 Report No.: 141016E01B Page 3 Reference No.: 150602E04 Report No.: 141016E01B Page 4 Reference No.: 150602E04 Report No.: 141016E01B Page 18 Reference No.: 150602E04 Model No.: 2ABL030F Report No.: 141016E01B Page 19 Reference No.: 150602E04 Report No.: 141016E01B Page 20 Reference No.: 150602E04 Model No.: ADS-40FPA-12 12030GPCU/GPC Report No.: 141016E01B Page 21 Reference No.: 150602E04 Report No.: 141016E01B Page 22 Reference No.: 150602E04 Report No.: 141016E01B Page 23 Reference No.: 150602E04 Splitter Model No.: DSL499

SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISION ENG APPDDATE 02AW-12747-031 of 1 AW,PLBL, D6400,V1M HUMPHREY 29OCT15M HUMPHREYINITIAL DOCUMENT CREATION01 02NOV15M HUMPHREYFCC US ID ADDED02 NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 5. See NTGR DOC-00112 for SN standard. 6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). Pantone 877C Black White Made in Vietnam (Fig. 1) FCC ID: PY315200315 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. EUT Back Label

Report No.: 141016E01B Page 5 Reference No.: 150602E04 Report No.: 141016E01B Page 6 Reference No.: 150602E04 Report No.: 141016E01B Page 7 Reference No.: 150602E04 Report No.: 141016E01B Page 8 Reference No.: 150602E04 Report No.: 141016E01B Page 9 Reference No.: 150602E04 Report No.: 141016E01B Page 10 Reference No.: 150602E04 Report No.: 141016E01B Page 11 Reference No.: 150602E04 Report No.: 141016E01B Page 12 Reference No.: 150602E04 Report No.: 141016E01B Page 13 Reference No.: 150602E04 Report No.: 141016E01B Page 14 Reference No.: 150602E04 Report No.: 141016E01B Page 15 Reference No.: 150602E04 Report No.: 141016E01B Page 16 Reference No.: 150602E04 Report No.: 141016E01B Page 17 Reference No.: 150602E04

Report No.: SA141016E01B Page No. 1 / 7 Report Format Version: 6.1.1 Reference No.: 150602E04 RF Exposure Report Report No.: SA141016E01B FCC ID: PY315200315 Test Model: D6400 Received Date: June 02, 2015 Test Date: Nov. 06 to 09, 2015 Issued Date: Nov. 17, 2015 Applicant: NETGEAR, Inc. Address: 350 East Plumeria Drive San Jose, CA 95134 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (3): E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. Report No.: SA141016E01B Page No. 2 / 7 Report Format Version: 6.1.1 Reference No.: 150602E04 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 6 2.5 Calculation Result of Maximum Conducted Power ............................................................................. 7 Report No.: SA141016E01B Page No. 3 / 7 Report Format Version: 6.1.1 Reference No.: 150602E04 Release Control Record Issue No. Description Date Issued SA141016E01B Original release. Nov. 17, 2015 Report No.: SA141016E01B Page No. 5 / 7 Report Format Version: 6.1.1 Reference No.: 150602E04 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA141016E01B Page No. 6 / 7 Report Format Version: 6.1.1 Reference No.: 150602E04 2.4 Antenna Gain The antennas provided to the EUT, please refer to the following table: For 2.4GHz Band PCB Chain No. Brand Model Antenna Gain(dBi) < including cable loss> Frequency range (GHz ~ GHz) Antenna Type Connecter Type Cable Length (mm) Chain 0 NETGEAR 98P91MIPF044 2 2.4~2.4835 PCB I-Pex 85 Chain 1 NETGEAR 98P91MIPF045 2 2.4~2.4835 PCB I-Pex 150 For 5GHz Band PCB Chain No. Brand Model Antenna Gain(dBi) < including cable loss> Frequency range (GHz ~ GHz) Antenna Type Connecter Type Cable Length (mm) Chain 0 NETGEAR 98P92UIPF061 3 5.15~5.85 PCB I-Pex 60 Chain 1 NETGEAR 98P92UIPF062 3 5.15~5.85 PCB I-Pex 70 Chain 2 NETGEAR 98P92UIPF063 3 5.15~5.85 PCB I-Pex 80 Report No.: SA141016E01B Page No. 7 / 7 Report Format Version: 6.1.1 Reference No.: 150602E04 2.5 Calculation Result of Maximum Conducted Power Frequency Band (MHz) Max Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412-2462 183.097 5.01 20 0.11545 1 5180-5240 327.522 7.77 20 0.38991 1 5745-5825 168.809 7.77 20 0.20097 1 NOTE: 2.4GHz: Directional gain = 2dBi + 10log(2) = 5.01dBi 5GHz: Directional gain = 3dBi + 10log(3) = 7.77dBi Conclusion: The formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of powe…

Text truncated - open the document above for the full version.

Report No.: RF141016E01B Page No. 1 / 58 Report Format Version: 6.1.1 Reference No.: 150602E04 FCC Test Report Report No.: RF141016E01B FCC ID: PY315200315 Test Model: D6400 Received Date: June 02, 2015 Test Date: June 08 to Nov. 09, 2015 Issued Date: Nov. 17, 2015 Applicant: NETGEAR, Inc. Address: 350 East Plumeria Drive San Jose, CA 95134 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Lab A: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (3): E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan R.O.C. Test Lab B: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 33383, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report contains Radiated Emissions & Band Edge Measurement (above 1GHz) test data that were produced under subcontract by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories. Report No.: RF141016E01B Page No. 2 / 58 Report Format Version: 6.1.1 Reference No.: 150602E04 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................. 10 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................ 11 3.3 Duty Cycle of Test Signal .................................................................................................................. 13 3.4 Description of Support Units ............................................................................................................. 14 3.4.1 Configuration of System under Test .................................................................................................. 15 3.5 General Description of Applied Standards ........................................................................................ 16 4 Test Types and Results ...................................................................................................................... 17 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 17 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 17 4.1.2 Test Instruments ................................................................................................................................ 18 4.1.3 Test Procedures ................................................................................................................................. 20 4.1.4 Deviation from Test Standard ............................................................................................................ 20 4.1.5 Test Setup .......................................................................................................................................... 21 4.1.6 EUT Operating Conditions ............................................................................................................…

Text truncated - open the document above for the full version.

Report No.: RF141016E01B-1 Page No. 1 / 63 Report Format Version:6.1.1 Reference No.: 150602E04 FCC Test Report Report No.: RF141016E01B-1 FCC ID: PY315200315 Test Model: D6400 Received Date: June 02, 2015 Test Date: June 08 to Nov. 09, 2015 Issued Date: Nov. 17, 2015 Applicant: NETGEAR, Inc. Address: 350 East Plumeria Drive San Jose, CA 95134 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Lab A: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (3): E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan R.O.C. Test Lab B: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories. Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 33383, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report contains Radiated Emissions & Band Edge Measurement (above 1GHz) test data that were produced under subcontract by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories. Report No.: RF141016E01B-1 Page No. 2 / 63 Report Format Version:6.1.1 Reference No.: 150602E04 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................. 10 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................ 11 3.3 Duty Cycle of Test Signal .................................................................................................................. 13 3.4 Description of Support Units ............................................................................................................. 14 3.4.1 Configuration of System under Test .................................................................................................. 15 3.5 General Description of Applied Standard .......................................................................................... 16 4 Test Types and Results ...................................................................................................................... 17 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 17 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 17 4.1.2 Test Instruments ................................................................................................................................ 18 4.1.3 Test Procedure .................................................................................................................................. 20 4.1.4 Deviation from Test Standard ............................................................................................................ 20 4.1.5 Test Setup .......................................................................................................................................... 21 4.1.6 EUT Operating Condition .......................................................................................................…

Text truncated - open the document above for the full version.

Report No.: 140717E01A-1 1 of 4 Reference No.: 140805E09 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Mode 1) Report No.: 140717E01A-1 2 of 4 Reference No.: 140805E09 CONDUCTED EMISSION TEST (Mode 2) Report No.: 140717E01A-1 3 of 4 Reference No.: 140805E09 RADIATED EMISSION TEST (Below 1GHz) Report No.: 140717E01A-1 4 of 4 Reference No.: 140805E09 RADIATED EMISSION TEST (Above 1GHz)
