PY320300508Nighthawk AXE11000 Tri-Band WiFi 6E Router

Netgear Incorporated

Click to zoom

Application Details

Equipment Class: 6ID - 15E 6 GHz Low Power Indoor Access Point
Date of Grant: Jan 07, 2021
Application Purpose: Original Equipment
Date of Application: Dec 23, 2020
Equipment Note: Nighthawk AXE11000 Tri-Band WiFi 6E Router
Frequency Range: 6115.00000000 - 7115.00000000
Company: Netgear Incorporated
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Quick Start 1 On your mobile phone, download the Nighthawk app and follow the setup instructions. Tap the Security icon in your Nighthawk app to verify that NETGEAR Armor™ is activated. Your Nighthawk comes with NETGEAR Armor cybersecurity. Armor blocks online threats like hackers and phishing attempts on your devices. Check out everything you can do on the Nighthawk app! Run a speed test, pause the Internet, see all the connected devices, and more. 2 Download the Nighthawk app to install your router Secure your devices with NETGEAR Armor 3 Do more with the app Contents Overview RouterEthernet Cable 1 Power LED 6 Ethernet Ports 1–5 LEDs A WPS Button with LED F Internet Port 2 Internet LED 7 USB 2 LED B WiFi On/Off Button with LED G Ethernet Ports 1–4 3 6 GHz WiFi LED 8 USB 1 LED C LED On/Off Switch H Multi-Gig Ethernet Port 5 4 5 GHz WiFi LED D Reset Button I Power On/Off Button 5 2.4 GHz WiFi LED E USB Ports 1 and 2 J Power Connector CEHFDIJG Support and Community Visit netgear.com/support to get your questions answered and access the latest downloads. You can also check out our NETGEAR Community for helpful advice at community.netgear.com. NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134, USA © NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non‑NETGEAR trademarks are used for reference purposes only. NETGEAR INTERNATIONAL LTD Floor 1, Building 3, University Technology Centre Curraheen Road, Cork, T12EF21, Ireland December 2020 Si ce produit est vendu au Canada, vous pouvez accéder à ce document en français canadien à https://www.netgear.com/support/download/. (If this product is sold in Canada, you can access this document in Canadian French at https://www.netgear.com/support/download/.) For regulatory compliance information including the EU Declaration of Conformity, visit https://www.netgear.com/about/regulatory/. See the regulatory compliance document before connecting the power supply. For NETGEAR’s Privacy Policy, visit https://www.netgear.com/about/privacy-policy. By using this device, you are agreeing to NETGEAR’s Terms and Conditions at https://www.netgear.com/about/terms-and-conditions. If you do not agree, return the device to your place of purchase within your return period. For 6 GHz devices, only use this device indoors: The operation of this device is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet. Operation of transmitters in the 5.925 ‑7.125 GHz band is prohibited for control of or Communications with unmanned aircraft systems. Regulatory and Legal Troubleshooting If you’re having problems with the installation, try one of the following: • Turn off your modem and router and disconnect them. Reboot your modem. Reconnect your router to your modem, and try installing with the Nighthawk app again. • If you’re still unable to install your router using the Nighthawk app, manually install it using the router web interface. Visit http://www.routerlogin.net to access the router web interface. For more information, visit netgear.om/routerhelp. Power Adapter (varies by region) B A 1 2 357 486 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC regulations restrict the operation of this device to indoor use only. The operation of this device is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet. Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or communications with unmanned aircraft systems. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 32cm between the radiator & your body.

Attestation Statements

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2020/12/16 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: PY320300508 To Whom It May Concern: We, NETGEAR, Inc., attest that this device under FCC ID PY320300508 complies with device protocol requirements and operational restrictions: for Indoor Access Point 6ID. 1. Protocol attestation statement: The device designs meet the IEEE requirements of sending regulatory info in TPE. • An 11ax IEEE AP's TPE element has information fields for EIRP/PSD limits for connecting client devices. The TPE information is contained in the AP signals (e.g.. beacon, probe response , FILS Discovery frames and the Reduced Neighbour Report element) and used by connecting clients to ensure that it knows the regulatory TX powers it is allowed to transmit at. • In addition there is a "regulatory field" in the AP beacon and probe response frames which details the AP type when the client associates to the AP. • Both the "regulatory field" and the TPE element are included in the same message and both are mandatory for IEEE devices. • At association an 11ax client device will always know what type of AP it is connecting to. 2. Statement acknowledging device restrictions: a. Low-power indoor Access Point. Access Point operating in the 5.925-7.125 GHz band shall be supplied power from a wired connection, has an integrated antenna, is not battery powered, and does not have a weatherized enclosure. b. This device's operation will not be allowed on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet. c. Indoor access points are prohibited for control of or communications with unmanned aircraft systems, including drones. If you have any question or concerns, pls. contact us. Sincerely, ------------------------------------------------------ David Kay / Regulatory Compliance Director Tel: 4088903657 Fax: 4089078097 E-mail: [email protected]

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2020/08/27 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____NETGEAR, Inc. _____ hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: PY320300508 Product Description: Nighthawk AXE11000 Tri-Band WiFi 6E Router Model: RAXE500 Sincerely, ------------------------------------------------------ David Kay / Regulatory Compliance Director Tel: 4088903657 Fax: 4089078097 E-mail: [email protected]

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 6.0 NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2020/12/08 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: PY320300508 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description - Software Operational Description - Operating Description-Antenna Spec. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ------------------------------------------------------ David Kay / Regulatory Compliance Director Tel: 4088903657 Fax: 4089078097 E-mail: [email protected] -- ---------------------------------------------------------------------------------------------------------------- ---------- David Kay / Regulatory C C C C C C Comomomomomplianc e Director SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 6.0 NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2020/12/08 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: PY320300508 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47, and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of / / not to exceed 180 days from the Grant Date. See KDB 726920. - User Manual - Internal Photos - Test Setup photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, - ----------------------------------------------------- David Kay / Regulatory Compliance Director Tel: 4088903657 Fax: 4089078097 E-mail: [email protected] --------------------------------------------------------------------------------------------------------------------- ------------ David Kay / Regulatoryryryryryryry C C C C C Complia nce Director - User Manual - Internal Photos - Test Setup photos - Exernal Photos

Cover Letter(s)

NETGEAR, INC. 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 P O W E R O F A T T O R N E Y Date: 2020/12/08 FCC ID: PY320300508 To whom it may concern: We, the undersigned, hereby authorize Debby Lin of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Debby Lin of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to Contact us. Thank you! Sincerely yours, ------------------------------------------------------ David Kay / Regulatory Compliance Director Tel: 4088903657 Fax: 4089078097 E-mail: [email protected]

External Photos

Reference No.: BBQZ-WTW-P20110526-1 Page 1/7 CONSTRUCTION PHOTOS OF EUT Reference No.: BBQZ-WTW-P20110526-1 Page 2/7 Reference No.: BBQZ-WTW-P20110526-1 Page 3/7 Reference No.: BBQZ-WTW-P20110526-1 Page 4/7 Adapter (Brand: NETGEAR, Model: 2ABS060K) Reference No.: BBQZ-WTW-P20110526-1 Page 5/7 Reference No.: BBQZ-WTW-P20110526-1 Page 6/7 Adapter (Brand: NETGEAR, Model: AD2073F20) Reference No.: BBQZ-WTW-P20110526-1 Page 7/7 RJ45 Cable

ID Label/Location Info

SHEET: AUTHOR:TITLE: P/N: REV: THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR WHEREWITH IS NOT TO BE REPRODUCED, USED OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF NETGEAR, INC. REV DESCRIPTION OF REVISION ENG APPDDATE 01AW-14751-011 of 1 AW,PLBL,RAXE500NA,V1R HU Pantone Cool Gray 1C Black 7 NOTE: 1. REFER TO NETGEAR SPEC. DOC-00093 FOR COLOR TOLERANCES. 2. INK COLOR IS SHOWN TO THE RIGHT. 3. DIE LINES ARE MAGENTA COLOR AND DO NOT PRINT. 4. MAC & SERIAL NUMBERS TO BE PRINTED BY THE ODM. 5. See NTGR DOC-00112 for SN standard. 6. NTGR SN and MAC address barcode to be encoded AIM USS Code39 and include printed characters below barcodes. 7. INSURE COUNTRY OF ORIGIN IS CORRECT. A. IF COUNTRY OF ORIGIN IS PRE-PRINTED, UNHIDE THE APPROPRIATE COUNTRY OF ORIGIN LAYER AND INCLUDE COUNTRY OF ORIGIN ON LABEL. B. IF COUNTRY OF ORIGIN IS POST-PRINTED USING A THERMAL PRINTER (OR EQUIVALENT), OMIT TEXT FROM ARTWORK (USE LAYERS). 14AUG2020R HUDOCUMENT RELEASE01 Made in China

ID Label/Location Info

(Fig. 1) FCC ID: PY320300508 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. EUT Bottom Label

Internal Photos

Reference No.: BBQZ-WTW-P20110526-2 Page 1/38 CONSTRUCTION PHOTOS OF EUT Reference No.: BBQZ-WTW-P20110526-2 Page 2/38 Reference No.: BBQZ-WTW-P20110526-2 Page 3/38 Reference No.: BBQZ-WTW-P20110526-2 Page 4/38 Reference No.: BBQZ-WTW-P20110526-2 Page 5/38 Reference No.: BBQZ-WTW-P20110526-2 Page 6/38 Reference No.: BBQZ-WTW-P20110526-2 Page 7/38 Reference No.: BBQZ-WTW-P20110526-2 Page 8/38 Reference No.: BBQZ-WTW-P20110526-2 Page 9/38 Reference No.: BBQZ-WTW-P20110526-2 Page 10/38 1st FEM Reference No.: BBQZ-WTW-P20110526-2 Page 11/38 2 nd FEM Reference No.: BBQZ-WTW-P20110526-2 Page 12/38 Reference No.: BBQZ-WTW-P20110526-2 Page 13/38 Reference No.: BBQZ-WTW-P20110526-2 Page 14/38 Reference No.: BBQZ-WTW-P20110526-2 Page 15/38 Reference No.: BBQZ-WTW-P20110526-2 Page 16/38 Reference No.: BBQZ-WTW-P20110526-2 Page 17/38 Reference No.: BBQZ-WTW-P20110526-2 Page 18/38 Reference No.: BBQZ-WTW-P20110526-2 Page 19/38 Reference No.: BBQZ-WTW-P20110526-2 Page 20/38 Reference No.: BBQZ-WTW-P20110526-2 Page 21/38 Reference No.: BBQZ-WTW-P20110526-2 Page 22/38 Reference No.: BBQZ-WTW-P20110526-2 Page 23/38 Reference No.: BBQZ-WTW-P20110526-2 Page 24/38

Internal Photos

Reference No.: BBQZ-WTW-P20110526-2 Page 25/38 Reference No.: BBQZ-WTW-P20110526-2 Page 26/38 Reference No.: BBQZ-WTW-P20110526-2 Page 27/38 Reference No.: BBQZ-WTW-P20110526-2 Page 28/38 Reference No.: BBQZ-WTW-P20110526-2 Page 29/38 Right Side 2.4G Ant 3 / 6G Ant 3 2.4G Ant 2 / 6G Ant 0 6G Ant 1 6G Ant 2 Reference No.: BBQZ-WTW-P20110526-2 Page 30/38 Left Side 2.4G Ant 1 / 5G Ant 3 2.4G Ant 0 / 5G Ant 0 5G Ant 2 5G Ant 1 Reference No.: BBQZ-WTW-P20110526-2 Page 31/38 Ant_5G chain 0 & 2.4G chain 0 Reference No.: BBQZ-WTW-P20110526-2 Page 32/38 Ant_5G chain 1 Reference No.: BBQZ-WTW-P20110526-2 Page 33/38 Ant_5G chain 2 Reference No.: BBQZ-WTW-P20110526-2 Page 34/38 Ant_ 5G chain 3 & 2.4G chain 1 Reference No.: BBQZ-WTW-P20110526-2 Page 35/38 Ant_6G chain 0 & 2.4G chain 2 Reference No.: BBQZ-WTW-P20110526-2 Page 36/38 Ant_6G chain 1 Reference No.: BBQZ-WTW-P20110526-2 Page 37/38 Ant_6G chain 2 Reference No.: BBQZ-WTW-P20110526-2 Page 38/38 Ant_6G chain 3 & 2.4G chain 3

RF Exposure Info

Report No.: SABBQZ-WTW-P20110526 Page No. 1 / 7 Report Format Version: 6.1.1 RF Exposure Report Report No.: SABBQZ-WTW-P20110526 FCC ID: PY320300508 Test Model: RAXE500 Received Date: Nov. 17, 2020 Test Date: Dec. 18, 2020 Issued Date: Dec. 22, 2020 Applicant: NETGEAR, Inc. Address: 350 East Plumeria Drive San Jose, CA 95134 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SABBQZ-WTW-P20110526 Page No. 2 / 7 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 6 2.5 Calculation Result ............................................................................................................................... 7 Report No.: SABBQZ-WTW-P20110526 Page No. 3 / 7 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SABBQZ-WTW-P20110526 Original release. Dec. 22, 2020 Report No.: SABBQZ-WTW-P20110526 Page No. 4 / 7 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Nighthawk AXE11000 Tri-Band WiFi 6E Router Brand: NETGEAR Test Model: RAXE500 Sample Status: Engineering sample Applicant: NETGEAR, Inc. Test Date: Dec. 18, 2020 Standards: FCC Part 2 (Section 2.1091) IEEE C95.3 -2002 References Test Guidance KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date: Dec. 22, 2020 Claire Kuan / Specialist Approved by : , Date: Dec. 22, 2020 Clark Lin / Technical Manager Report No.: SABBQZ-WTW-P20110526 Page No. 5 / 7 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 32cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SABBQZ-WTW-P20110526 Page No. 6 / 7 Report Format Version: 6.1.1 2.4 Antenna Gain Frequency Range (GHz) Directional Antenna Gain (dBi) Antenna Type Antenna Connector 2.4~2.4835 7.02 Dipole i-pex(MHF) 5.15~5.25 7.07 5.25~5.35 6.98 5.47~5.725 7.09 5.725~5.85 7.32 Frequency Range (GHz) Mode Nss Directional Antenna Gain (dBi) Antenna Type Antenna Connector For Power For PSD 5.925~6.425 CDD Nss1 2.94 4.92 Dipole i-pex(MHF) SDM Nss4 2.99 2.90 Beamforming Nss1 6.87 6.77 Nss4 2.96 2.94 6.425~6.525 CDD Nss1 2.91 4.99 SDM Nss4 2.96 2.98 Beamforming Nss1 6.87 6.95 Nss4 2.99 2.97 6.525~6.875 CDD Nss1 2.99 4.97 SDM Nss4 2.94 2.95 Beamforming Nss1 6.98 6.77 Nss4 2.96 2.91 6.875~7.125 CDD Nss…

Text truncated - open the document above for the full version.

RF Exposure Info

Text truncated - open the document above for the full version.

Test Report

Report No.: RFBBQZ-WTW-P20110526-4 Page No. 1 / 460 Report Format Version:6.1.2 FCC Test Report Report No.: RFBBQZ-WTW-P20110526-4 FCC ID: PY320300508 Test Model: RAXE500 Received Date: Nov. 17, 2020 Test Date: Nov. 24 to Dec. 29, 2020 Issued Date: Dec. 30, 2020 Applicant: NETGEAR, Inc. Address: 350 East Plumeria Drive San Jose, CA 95134 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li H…

Text truncated - open the document above for the full version.

Contact Information

Applicant

David Kay

[email protected]4088903160Fax: 4089078097

Test Firm

Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch HsinKen Liu

[email protected]+886-3-2600609Fax: +886-3-2115834

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15E	6.12 GHz - 7.12 GHz	445.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is EIRP. Device is restricted to indoor use only. Device support 4x4 MIMO and has 20 MHz, 40 MHz 80MHz and 160MHz bandwidth modes. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 32 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines.
