PY3204005155G MHS Travel Router

Quick Start 5G Mobile Router M5 Install the SIM card and battery The SIM card must be activated with a data plan from your operator. Do not use a tool, pen, or paperclip to insert or remove the SIM card. Doing so might cause damage to your mobile router that is not covered by the warranty. 1. Gently insert the SIM card into the slot. 2. Insert the battery. 3. Install the back cover. The battery is partially charged. To fully charge it, connect the USB cable to the mobile router and then plug it into either a laptop or the provided Quick Charge AC power adapter. Reset button SIM card Get to know your Mobile Router Touch screen USB C port TS-9 external antenna connector TS-9 external antenna connector Power button Home Back What’s in the box • Nighhawk M5 5G Mobile Router • Battery cover • Battery • USB Type-C cable • Quick Charge AC power adapter • Quick Start Guide Set up Your Mobile Router 1. Press and hold the Power button for two seconds. To better safeguard your network, the first time you turn on your mobile router, you are asked to set up your login credentials. 2. Follow the onscreen instructions to customize your mobile router settings. CustomizeDon’t customize We recommend you change the default credentials to your own custom credentials. Customize your WiFi Signal strength Battery Network indicator Home screen The Home screen displays the mobile router’s WiFi network name and password. The network indicator lets you know which wireless network you are connected to. WiFi network name and password NETGEAR, Inc. 350 East Plumeria Drive San Jose, CA 95134, USA October 2020 NETGEAR INTERNATIONAL LTD Floor 1, Building 3, University Technology Centre Curraheen Road, Cork, T12EF21, Ireland © NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non-NETGEAR trademarks are used for reference purposes only. Note: The appearance of your home screen depends on the model. Ethernet port Visit netgear.com/support to get your questions answered and access the latest downloads. You can also check out our NETGEAR Community for helpful advice at community. netgear.com. For the best experience, we recommend using only the NETGEAR battery, USB type-C cable, and AC power adapter that came with your mobile router. Regulatory and Legal For regulatory compliance information including the EU Declaration of Conformity, visit https://www.netgear.com/ about/regulatory/ to access the full user manual and to download firmware updates. See the regulatory compliance document before connecting the power supply. For NETGEAR’s Privacy Policy, visit https://www.netgear.com/ about/privacy-policy. By using this device, you are agreeing to NETGEAR’s Terms and Conditions at https://www.netgear.com/about/terms-and- conditions. If you do not agree, return the device to your place of purchase within your return period. Support and Community LCD WiFi Manager You can manage the WiFi network and change the WiFi settings from the LCD screen. Change the WiFi network name and password 1. On the home screen, tap the WiFi icon. 2. Tap WiFi and then select from the available WiFi networks. 3. Tap WiFi Name and enter your changes. 4. Tap WiFi Password and enter your changes. WiFi Manager You can use a browser to view and change the mobile router settings. Log In 1. On your mobile router, go to the LCD Settings screen, tap the More icon. Then tap Device Information and look for the WiFi Manager URL. 2. On the WiFi device that is connected to your mobile router, type the WiFi Manager URL in the browser bar. 3. Log in as administrator. The default login is printed on the product label. LCD Settings View or change the settings On the home screen, tap the Settings icon. Change the WiFi band 1. On the home screen, tap the WiFi icon. 2. Tap Band. 3. Select the 2.4 GHz, 5 GHz, or dual WiFi band. Connect to the Internet Note: The mobile router’s Home screen displays the WiFi network name and password. The screen goes dark to save power. Press and release the Power button to wake the screen. On your laptop or other WiFi device 1. Open your WiFi network connection manager. 2. Find your mobile router’s WiFi network name (NTGR-XXXX) and connect. 3. Enter your mobile router’s WiFi password. 4. Launch your Internet browser. Note: The battery and the mobile router might become warm during operation. This is normal. If you use your device as a fixed wireless router, remove the battery and power the router using the provided Quick Charge AC power adapter. This prolongs battery life and reduces heating. ONLY use the provided Quick Charge AC power adapter for using the mobile router without a battery. Download the NETGEAR Mobile app Use the NETGEAR Mobile app to change your WiFi network name and password. You can also use it to play and share media, and enable the travel router feature. 1. Connect your mobile device to the Internet. 2. Download the NETGEAR Mobile app from netgear.com/mobileapps.

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure must be 10mm separation restricted can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.Déclaration d'exposition aux radiations: For external antenna This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with greater than 20cm between the radiator & your body. Note: The country code selection is for non-US model only and is not available to all US model. Per FCC regulation, all WiFi product marketed in US must fixed to US operation channels only.

B D C A E F G H B D C A E F G H 21 3 4 5 6 78 9 10 2 13 4 5 6 7 8 9 10 H E A R T O F T H E W I R E L E S S M A C H I N E TM SIERRAWIRELESS H E A R T O F T H E W I R E L E S S M A C H I N E TM SIERRAWIRELESS (1.00[.039])152.4[6.00] 241.3[9.50] 4x R6.35.250[] UNLESS OTHERWISE NOTED, THIS DOCUMENT CONTAINS SIERRA WIRELESS CONFIDENTIAL INFORMATION. REPRODUCTION, USE, DISCLOSURE OR TRANSMITTAL OF ALL OR ANY PORTION OF THIS DOCUMENT IS PROHIBITED, EXCEPT TO THE EXTENT APPROVED BY SIERRA WIRELESS. SIERRA WIRELESS EXPRESSLY RESERVES ALL RIGHTS UNDER PATENTS, TRADEMARKS, COPYRIGHTS AND TRADE SECRETS. COPYRIGHT (C) 2011, SIERRA WIRELESS. REVDESCRIPTIONDATEDRAWNAPPD 1 RELEASED FOR PRODUCTION23-FEB-11BWBG UNLESS OTHERWISE SPECIFIED, DIMENSIONS ARE PER THE FOLLOWING TOLERANCES: INCHES .X
# .1 .XX
# .06 .XXX
# .040 MM X
# 2.5 X.X
# 1.5 X.XX
# 1.00 ANGLES X
# 2
$ X.X
# 1.0
$ MATERIAL SEE NOTES FINISH SEE NOTES DO NOT SCALE PRINT PROJECT NAMEPART DESCRIPTION MIMO ANTENNABACKCARD, MIMO ANTENNA DRWNDATE B. WU20-JAN-11 DES ENGRDATE B. WU20-JAN-11 CHKDATE B. GILBERT23-FEB-11 PRT FILENAME 2400117 DRW FILENAME 2400117 RELEASE LEVEL PRODUCTION0 13811 Wireless Way Richmond, British Columbia Canada, V6V 3A4 Tel: 604.231.1100 Fax: 604.231.1109 SIZEUNITSDRAWING NO.REV C MM 2400117 1_0 SCALE: 1.000SHEET 1 OF 1 I NOTES APPLICABLE TO PART MANUFACTURER: 1. DESCRIPTION AND APPLICATION: RETAIL BOX FOR WIRELESS COMMUNICATIONS DEVICE PACKAGING 2. APPLICABLE DOCUMENTS: 2400117 REFERENCE ARTWORK 2140122 SIERRA WIRELESS GENERIC COSMETIC SPECIFICATION ASME Y14.5M-1994 GEOMETRIC DIMENSIONING AND TOLERANCING 3. MATERIAL: 3.1 600G CLAY COATED CHIPBOARD (1mm
# 0.01mm THICK) 3.2 THE PART/ASSEMBLY SHALL CONTAIN NO HAZARDOUS SUBSTANCES PER THE WASTE ELECTRICAL AND ELECTRONIC EQUIPTMENT (WEEE) 2002/96/EC RoHS DIRECTIVE. 3.3 THE PART/ ASSEMBLY SHALL CONFROM TO THE EU DIRECTIVE ON PACKAGING AND PACKAGING WASTE 94/62/EC 4. FINISH: 4.1 GLOSSY PP LAMINATE, BOTH SIDES 4.2 REFER TO ARTWORK FILE 2400117 FOR GRAPHIC SPECIFICATIONS 5. GENERAL REQUIREMENTS: 5.1 PARTS SHALL BE CLEAN AND FREE OF ALL FOREIGN MATTER. 5.2 REFERENCE ARTWORK P/N 2400117. 5.3 CONTROLLING GEOMETRY IS DEFINED BY DXF FILE DATABASE. ALL SURFACE TO BE WITHIN 0.10 OF DATABASE UNLESS OTHERWISE SPECIFIED. 6. QUALITY ASSURANCE REQUIREMENTS: 6.1 ALL DIMENSIONS INDICATED ON DRAWING ARE CRITICAL TO FORM, FIT, OR FUNCTION. 6.2 DIMENSIONS INDICATED WITH A X SYMBOL DENOTE QUALITY PROCESS CONTROL, (QPC), DIMENSIONS. 6.3 PRODUCTION LOT SAMPLES MUST DEMONSTRATE A Cpk VALUE OF 1.33 OR HIGHER. IF THE Cpk DROPS BELOW 1.33 AT ANY TIME DURING THE MANUFACTURE OF THIS PART, THEN THE SUPPLIER MUST 100% SCREEN ALL THOSE PARTS TO THOSE SPECIFIED CRITICAL PARAMETERS. 7.1 NO CHANGE SHALL BE ALLOWED ON PRODUCTION MATERIAL, REGARDLESS OF WHETHER SUCH CHANGE AFFECTS REQUIREMENTS SPECIFIED, WITHOUT PRIOR EXPLICIT WRITTEN APPROVAL BY SIERRA WIRELESS. II NOTES APPLICABLE TO CONTRACT MANUFACTURER: 1. INCOMING INSPECTION DIMENSION MARKED BY XX.XX 2. SAMPLE INSPECTION PER QEI-II-0000-18. 3. CONTRACT MANUFACTURER SHALL REQUIRE PART MANUFACTURER TO PROVIDE SPC DATA AND REVIEW WITH SIERRA WIRELESS. X X 4.1

Netgear Incorporated 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2/26/2021 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: PY320400515 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Software Operational Description - e.g. Parts List - e.g. Tune-up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ------------------------------------------------------ David Kay / Regulatory Compliance Director Netgear Incorporated TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2/26/2021 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: PY320400515 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47, and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days from the Grant Date. See KDB 726920. - e.g. External Photos - e.g. Internal Photos - e.g. Test Setup photos - e.g. User Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, ------------------------------------------------------ David Kay / Regulatory Compliance Director Netgear Incorporated TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2021-02-26 FCC ID: PY320400515 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Declaration letter for label requirement Label Location Declaration letter The label is permanent affixed in the battery compartment, and the EUT will be selling to market without the battery installed. The users can see the label during the battery installation process. The battery cover can be opened without any special tools. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------------------------- David Kay/ Regulatory Compliance Director Netgear Incorporated TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

Netgear Incorporated 350 East Plumeria Drive, San Jose, CA 95134, USA Tel:408-890-3657/Fax:408-907-8097 Date: 2/26/2021 FCC ID: PY320400515 AUTHORIZATION LETTER To Whom It May Concern: We, Netgear Incorporated hereby authorizes Amanda Wu / Senior Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu / Senior Specialist of BV CPS Taoyuan on Netgear Incorporated’s behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------------------------- David Kay/ Regulatory Compliance Director Netgear Incorporated TEL: 4088903657 FAX: 4089078097 E-mail: [email protected]

Reference No.: BBQZ-WTW-P20120750_EXT 1 of 8 CONSTRUCTION PHOTOS OF EUT Brand: Netgear / Model: MR5100C Antenna for WWAN Reference No.: BBQZ-WTW-P20120750_EXT 2 of 8 Reference No.: BBQZ-WTW-P20120750_EXT 3 of 8 Reference No.: BBQZ-WTW-P20120750_EXT 4 of 8 Reference No.: BBQZ-WTW-P20120750_EXT 5 of 8 Reference No.: BBQZ-WTW-P20120750_EXT 6 of 8 Reference No.: BBQZ-WTW-P20120750_EXT 7 of 8 Reference No.: BBQZ-WTW-P20120750_EXT 8 of 8

NETGEAR Confidential Brice Wu 12/08/2020 Page 1 of 3 Part #AW-14826-01 LBL,PRODUCT, 66.71mm x 55.11mm Note that barcode representations are for reference only; relati ve lengths, widths and shapes of bars are to be printed in compliance with the barcode format called out in Table 1 on page 2 Refer to FD-11231-01 for blank s tock specifications Figure 1 66.7mm ± 0.2mm 55.1mm ± 0.2mm REV-1

Reference No.: BBQZ-WTW-P20120750_INT 1 of 13 CONSTRUCTION PHOTOS OF EUT Brand: Netgear / Model: MR5100C Reference No.: BBQZ-WTW-P20120750_INT 2 of 13 Reference No.: BBQZ-WTW-P20120750_INT 3 of 13 Reference No.: BBQZ-WTW-P20120750_INT 4 of 13 Reference No.: BBQZ-WTW-P20120750_INT 5 of 13 Reference No.: BBQZ-WTW-P20120750_INT 6 of 13 Reference No.: BBQZ-WTW-P20120750_INT 7 of 13 Reference No.: BBQZ-WTW-P20120750_INT 8 of 13 Reference No.: BBQZ-WTW-P20120750_INT 9 of 13 Reference No.: BBQZ-WTW-P20120750_INT 10 of 13 Reference No.: BBQZ-WTW-P20120750_INT 11 of 13 Reference No.: BBQZ-WTW-P20120750_INT 12 of 13 Reference No.: BBQZ-WTW-P20120750_INT 13 of 13

Report No.: SABBQZ-WTW-P20120749 Page No. 1 / 8 Report Format Version: 6.1.1 RF Exposure Report Report No.: SABBQZ-WTW-P20120749 FCC ID: PY320400515 Test Model: MR5100C Received Date: Dec. 23, 2020 Test Date: Jan. 05 ~ Feb. 17, 2021 Issued Date: Mar. 03, 2021 Applicant and Manufacturer: NETGEAR INC. Address: 350 East Plumeria Drive, San Jose, CA 95134, USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth ourfindings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SABBQZ-WTW-P20120749 Page No. 2 / 8 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result of Maximum Conducted Power ........................................................................... 6 Report No.: SABBQZ-WTW-P20120749 Page No. 3 / 8 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SABBQZ-WTW-P20120749 Original release Mar. 03, 2021 Report No.: SABBQZ-WTW-P20120749 Page No. 4 / 8 Report Format Version: 6.1.1 1 Certificate of Conformity Product: 5G MHS Travel Router Brand: Netgear Test Model: MR5100C Sample Status: Engineering sample Applicant: NETGEAR INC. Test Date: Jan. 05 ~ Feb. 17, 2021 Standards: FCC Part 2 (Section 2.1091) IEEE C95.3 -2002 References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Prepared by : , Date:Mar. 03, 2021 Celine Chou / Senior Specialist Approved by : , Date:Mar. 03, 2021 Bruce Chen / Senior Project Engineer Report No.: SABBQZ-WTW-P20120749 Page No. 5 / 8 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SABBQZ-WTW-P20120749 Page No. 6 / 8 Report Format Version: 6.1.1 3 Calculation Result of Maximum Conducted Power WLAN Frequency Band (MHz) Max AV Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412-2462 12.97 6.08 20 0.016 1.00 5180-5240 12.74 4.64 20 0.011 1.00 5745-5825 12.92 5.69 20 0.014 1.00 Note: 1. Determining compliance based on the results of the compliance measurement, not taking into account measurement instrumentation uncertainty. 2. The above Antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. 2412-2462MHz: Directional gain = 10 log[(10 G1 /20 + 10 G2 /20 + ... + 10 GN /20 ) 2 /2] = 6.08dBi 5180-5240MHz: Directional gain = 10 log[(10 G1 /20 + 10 G2 /20 + ... + 10 GN /20 ) 2 /2] = 4.64dBi 5745-5825MHz: Directional gain = 10 log[(10 G1 /20 + 10 G2 /20 + ... + 10…

Text truncated - open the document above for the full version.

SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 60 Report No. : SFBBQZ-WTW-P20120749 Issued Date : Feb. 23, 2021 SAR Test Report Report No. : SFBBQZ-WTW-P20120749 Applicant : NETGEAR INC. Address : 350 East Plumeria Drive, San Jose, CA 95134, USA Product : 5G MHS Travel Router FCC ID : PY320400515 Brand : Netgear Model No. : MR5100C Standards : FCC 47 CFR Part 2 (2.1093), IEEE C95.1:1992, IEEE Std 1528:2013 KDB 865664 D01 v01r04, KDB 865664 D02 v01r02, KDB 248227 D01 v02r02, KDB 447498 D01 v06, KDB 941225 D01 v03r01, KDB 941225 D05 v02r05, KDB 941225 D05A v01r02 , KDB 941225 D06 v02r01 Sample Received Date : Dec. 23, 2020 Date of Testing : Jan. 04, 2021 ~ Jan. 21, 2021 Lab Address : No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location : No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City, Taiwan CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch–Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Vera Huang / Specialist Approved By : Gordon Lin / Manager FCC Accredited No.: TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 60 Report No. : SFBBQZ-WTW-P20120749 Issued Date : Feb. 23, 2021 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY6 System ............................................................................................................................................... 6 3.2.1 Robot ............................................................................................................................................................... 7 3.2.2 Probes ............................................................................................................................................................. 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................. 8 3.2.4 Phantoms ......................................................................................................................................................... 8 3.2.5 Device Holder .................................................................................................................................................. 9 3.2.6 System Validation Dipoles ............................................................................................................................. 10 3.2.7 Power Source ................................................................................................................................................ 10 3.2.8 Tissue Simulating Liquids .............................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 13 3.4 SAR Measurement Procedure ................................................................................................................................... 14 3 .4.1 Area Scan and Zoom Scan Procedure .......................................................................................................... 14 3.4.2 Volume Scan Procedure ..............................................................................…

Text truncated - open the document above for the full version.

SAR Test Report Report Format Version 5.0.0 Issued Date : Feb. 23, 2021 Report No. : SFBBQZ-WTW-P20120749 Appendix D. Photographs of EUT and Setup The setup photographs for SAR testing are shown as follows. SAR Test Report Report Format Version 5.0.0 Issued Date : Feb. 23, 2021 Report No. : SFBBQZ-WTW-P20120749 Appendix E. Maximum Target Conducted Power The maximum conducted average power (Unit: dBm) including tune-up tolerance is shown as below. Maximum Target Power Maximum Target Power WCDMA Band II Ant 124.023.0 WCDMA Band V Ant 124.023.0 WCDMA Max. Tune-up Power (Full) Mode RMC 12.2K HSDPA DC-HSDPA HSUPA Maximum Target Power Maximum Target Power Maximum Target Power Maximum Target Power LTE 2 Ant 1/223.022.021.018.0 LTE 4 Ant 124.023.022.019.0 LTE 5 Ant 124.023.022.019.0 LTE 7 Ant 1/224.023.022.019.0 LTE 12 Ant 124.023.022.019.0 LTE 13 Ant 124.023.022.019.0 LTE 17Ant 124.023.022.019.0 LTE 25 Ant 124.023.022.019.0 LTE 30 Ant 123.022.021.018.0 LTE 38 Ant 124.023.022.019.0 LTE 41 Ant 124.023.022.019.0 LTE 66 Ant 1/224.023.022.019.0 LTE 71 Ant 124.023.022.019.0 256QAM LTE Max. Tune-up Power (Full) Mode QPSK16QAM64QAM Maximum Target Power Maximum Target Power Maximum Target Power Maximum Target Power Maximum Target Power NR 5 Ant 1/224.024.023.021.519.5 NR 25 Ant 2 24.024.023.021.519.5 NR 6…
