PY3CG814WGV2WIRELESS CABLE MODEM GATEWAY

NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA Phone 1-888-NETGEAR 202-10074-01 February 2005 Reference Manual for the Wireless Cable Modem Gateway CG814WG ii © 2005 by NETGEAR, Inc. All rights reserved. Trademarks NETGEAR is a trademark of Netgear, Inc. Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders. Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. FCC Warning Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Prohibition of Co-location This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. Safety Information To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. Use the supplied antenna. iii Declaration of Conformity for R&TTE directive 1999/5/EC Essential requirements – Article 3. Protection requirements for health and safety – Article 3.1a. Testing for electric safety according to EN 60950-1 has been conducted. These are considered relevant and sufficient. Protection requirements for electromagnetic compatibility – Article 3.1b. Testing for electromagnetic compatibility according to EN 301 489-1 and EN 301 489-17 has been conducted. These are considered relevant and sufficient. Effective use of the radio spectrum – Article 3.2. Testing for radio test suites according to EN 300 328- 2 has been conducted. These are considered relevant and sufficient. Bestätigung des Herstellers/Importeurs Es wird hiermit bestätigt, daß das CG814WG Wireless Cable Modem Gateway gemäß der im BMPT-AmtsblVfg 243/ 1991 und Vfg 46/1992 aufgeführten Bestimmungen entstört ist. Das vorschriftsmäßige Betreiben einiger Geräte (z.B. Testsender) kann jedoch gewissen Beschränkungen unterliegen. Lesen Sie dazu bitte die Anmerkungen in der Betriebsanleitung. Das Bundesamt für Zulassungen in der Telekommunikation wurde davon unterrichtet, daß dieses Gerät auf den Markt gebracht wurde und es ist berechtigt, die Serie auf die Erfüllung der Vorschriften hin zu überprüfen. Certificate of the Manufacturer/Importer It is hereby certified that the CG814WG Wireless Cable Modem Gateway has been suppressed in accordance with the conditions set out in the BMPT-AmtsblVfg 243/1991 and Vfg 46/1992. The operation of some equipment (for example, test transmitters) in accordance with the regulations may, however, be subject to certain restrictions. Please refer to the notes in the operating instructions. Federal Office for Telecommunications Approvals has been notified of the placing of this equipment on the market and has been granted the right to test the series for compliance with the regulations. Technical Support Thank you for choosing Netgear product(s). Please register online and take advantage of the technical support resources such as Netgear online knowledge base. Technical support is available 24 hours a day, seven days a week; please call your Cable Internet Service Provider. Product and Publication Details Model Number:CG814WG Publication Date:February 2005 Product Family:gateway Product Name:CG814WG Wireless Cable Modem Gateway Home or Business Product:Home Language:English Publication Part Number:202-10074-01 iv Contentsi Contents Chapter 1 .................................................................................................................................. About This Manual ...............................................................................................................1-1 Audience, Conventions, Publication Date ......................................................................1-1 Chapter 2 .................................................................................................................................. Introduction ..........................................................................................................................2-1 About the CG814WG ......................................................................................................2-1 Key Features ................................…

Text truncated - open the document above for the full version.

External Photos of Wireless Cable Modem Gateway --------------------------------------- 1/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of Wireless Cable Modem Gateway --------------------------------------- 2/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of Wireless Cable Modem Gateway --------------------------------------- 3/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440

Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 LABEL Position:

LABEL Sample and Location information -------------------------------------------------- 1/2 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 LABEL Format: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. LABEL Sample and Location information -------------------------------------------------- 2/2 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 LABEL Position:

Internal Photos of Wireless Cable Modem Gateway----------------------------------------4/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of Wireless Cable Modem Gateway----------------------------------------5/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of Wireless Cable Modem Gateway----------------------------------------6/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of Wireless Cable Modem Gateway----------------------------------------7/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of Wireless Cable Modem Gateway----------------------------------------8/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of Wireless Cable Modem Gateway----------------------------------------9/9 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440

Measurement of Maximum Permissible Exposure ------------------------------------------------- 1/3 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Measurement of Maximum Permissible Exposure 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an Anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT FCC ID : PY3CG814WGV2 Product name : Wireless Cable Modem Gateway Model name : CG814WG v2 Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Frequency Range : 2.412 GHz ~ 2.462GHz Supported Channel : 11 Channels Modulation Skill : DBPSK, DQPSK, CCK, OFDM Power Type : Powered by the AC to DC adapter, Model: PWR-10030-01 I/P: 120VAC, 60Hz, 18W O/P: 12VDC, 1A Measurement of Maximum Permissible Exposure ------------------------------------------------- 2/3 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 [The EUT is tested in transmit and receive modes and in the first, middle and the last channel separately. The following shows only our observation have the greatest emissions.] According to OET BULLETIN 56 Fourth Edition/August 1999, Equation for Predicting RF Fields: Friis Transmission Formula: 2 22 /0868.0 )20(4 51356.140.288 4 cmmW R PG S= × == ππ Estimated safe separation: cm xPG R8938.5 4 51356.140.288 4 === ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 5.89 cm." Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 ( dB antenna gain / 10 ) G = Log -1 (1.80 / 10) = 1.51356 Measurement of Maximum Permissible Exposure ------------------------------------------------- 3/3 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Appendix Antenna Specification

Test Report -------------------------------------------------------------------------------------1/54 Report No.: N1015509, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 MEASUREMENT REPORT of Wireless Cable Modem Gateway Applicant:NETGEAR, Inc. EUT:Wireless Cable Modem Gateway Model:CG814WG v2 FCC ID:PY3CG814WGV2 Tested by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 No. 255, Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report -------------------------------------------------------------------------------------2/54 Report No.: N1015509, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 CERTIFICATION We here by verify that: The test data, data evaluation, test procedures and equipment configurations shown in this report were made mainly in accordance with the procedures given in ANSI C63.4 (2003) as a reference. All test were conducted by Training Research Co., Ltd., 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with the technical requirements set forth in the FCC Rules Part 15 Subpart B (Declaration of Conformity) and SubpartC Section 15.247. Applicant:NETGEAR, Inc. Applicant address:4500 Great America Parkway, Santa Clara, CA 9054 USA Product Name:Wireless Cable Modem Gateway Model Name:CG814WG v2 Report No.:N1015509 Test Date:February 23, 2005 Prepared by:Approved by: Jack TsaiFrank Tsai Conditions of issue : (1) This test report shall not be reproduced except in full, without written approval of TRC. And the test result contained within this report only relate to the sample submitted for testing. (2) This report must not be used by the client to claim product endorsement by NVLAP or any agency of U.S. Government. (3) This test report, measurements made by TRC are traceable to the NIST only Conducted and Radiated Method. NVLAP LAB CODE: 200174-0 Test Report -------------------------------------------------------------------------------------3/54 Report No.: N1015509, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Federal Communications Commission Declaration of Conformity (DoC) for the following equipment: Product name:Wireless Cable Modem Gateway Model name:CG814WG v2 Trade name:NETGEAR Is herewith confirmed and found to comply with the requirements of CFR 47 part15 Subpart B - Unintentional Radiators regulation. The results of electromagnetic mission evaluation are shown in the report number : N1015509 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation Manufacturer USA local representative Company name:Company name: ASUSTeK Computer Inc.NETGEAR INC. Computer address:Computer address: 4/F, 150, Li-Te Rd., Peitou, Taipei, Taiwan4500 Great America Parkway, Santa Clara, CA 95054, USA ZIP / Postal codeZIP / Postal code 11295054 Contact person:Contact person: Lawrence Yu Title:Title: Manager Internet e-mail address:Internet e-mail address: [email protected] Tel / Fax:Tel / Fax: 886-2-28943447 / 886-2-289501131-408-907-8000 / 1-408-907-8097 Test Report -------------------------------------------------------------------------------------4/54 Report No.: N1015509, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Tables of Contents I.GENERAL................................................................................................................... 6 1.1Introduction.......................................................................................................... 6 1.2Description of EUT .............................................................................................. 6 1.3Test method .......................................................................................................... 6 1.4Description of Support Equipment ....................................................................... 7 1.5Configuration of System Under Test .................................................................... 10 1.6Verify the Frequency and Channel ....................................................................... 12 1.7Test Procedure .................................................................................................... 13 1.8Location of the Test Site ...................................................................................... 13 1.9General Test Condition ....................................................................................... 13 II.Section 15.101(a) : Equipment Authorization of Unintentional Radiators............... 14 III.Section 15.203 : Antenna Requirement....................................................................... 15 IV.Section 15.207 : Power Line Conducted Emissions for AC Powered Units............ 16 4.1Test Condition & Setup....................................................................................... 16 4.2List of Test Instruments ....................................................................................... 17 4.3Test Result of Conducted Emissions ................................................................... 18 Standby mode ........................................................................................................ 18 IEEE 802.11b CH01................................................................................................ 19 IEEE 802.11b CH06................................................................................................ 19 IEEE 802.11b CH11................................................................................................ 20 IEEE 802.11g CH01................…

Text truncated - open the document above for the full version.

Test Setup Photos ------------------------------------------------------------------------ 1/2 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Conducted Test Setup Placement: Front View of the Test Configuration Side View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------ 2/2 Applicant: NETGEAR INCORPORATED FCC ID: PY3CG814WGV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement: Front View of the Test Configuration Rear View of the Test Configuration
