Hardware Block MAC_ATMEL76C510 USB 36MO.S.C 12MCrystal BASEBANDRF3000 RF2948B RF2494 374MSAW_Filter 44MO.S.C. SI4136 IF_LO RF5117_MLFRF_PA TX_RF_LORX_RF_LO 2.442GFilter 2.442GFilter RESET 2.442GFilter RX_PATH TX_PATH IEEE 802.11b 2.4G Access Point Atmel 29LV0404Mbits Flash ATF1504CPLD EthernetPHYRTL8201BL SRAM512K*8 SRAM128K*8 RJ45

External Photo of Netgear ME102 External Photo of Netgear ME102 External Photo of Netgear ME102 External Photo of Netgear ME102

Label Location of the Netgear ME102

Internal Photo of the Netgear ME102 rev B Internal Photo of the Netgear ME102 rev B Internal Photo of the Netgear ME102 rev B Internal Photo of the Netgear ME102 rev B Internal Photo of the Netgear ME102 rev B Internal Photo of the Netgear ME102 rev B Internal Photo of the Netgear ME102 rev B

Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Measurement of MPE 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT EUT : 802.11b Access Point Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Model No. : ME102 REV.B FCC ID : PY3ME102RB Frequency Range : 2.412 GHz ~ 2.462GHz Antenna Kit : 2 external dipole antenna Supported Channel: 11 Channel Modulation Skill : DBPSK, DQPSK, CCK Power Type : Powered by the AC-DC switching adapter Input: 100~120VAC, 50/60Hz, 0.3A Output: +5VDC, 1.0A Applicant : Netgear, Inc. 4500 America Parkway, Santa Clara, CA 95054. Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 [The EUT is tested in transmit and receive modes and in the first, middle and the last channel separately. The following shows only our observation have the greatest emissions.] According to OET BULLETIN 56 Fourth Edition/August 1999, equation for predicting RF fields, by the Friis Transmission Formula: Power density at the specific separation (portable): 22 22 /10918.1 )20(4 259.156.76 4 cmmW R PG S − ×= × == ππ Estimated safe separation: cm PG R77.2 4 259.156.76 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 2.77 cm." Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (1 / 10) = 1.259

Test Report -------------------------------------------------------------------------------- 1/43 Report No.: D0615635 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 MEASUREMENT REPORT of WIRELESS LAN ACCESS POINT Applicant : Netgear, Inc. Model No. : ME102 REV. B EUT : 802.11b Access Point FCC ID : PY3ME102RB Report No. : D0615635 Tested by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 255 Nanyang St., Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report -------------------------------------------------------------------------------- 3/43 Report No.: D0615635 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Tables of Contents I. GENERAL ......................................................................................................................... 5 1.1 Introduction .................................................................................................................. 5 1.2 Description of EUT ....................................................................................................... 5 1.3 Description of Support Equipment ................................................................................. 6 1.4 Configuration of System Under Test .............................................................................. 8 1.5 Verify the Frequency and Channel ................................................................................. 9 1.6 Test Procedure ............................................................................................................ 10 1.7 Location of the Test Site ............................................................................................... 10 1.8 General Test Condition ................................................................................................. 10 II. Section 15.203 : Antenna Requirement............................................................................. 11 III. Section 15.207: Power Line Conducted Emissions for AC Powered Units .................... 12 3.1 Test Condition & Setup ................................................................................................ 12 3.2 List of Test Instruments ................................................................................................ 12 3.3 Test Configuration ........................................................................................................ 13 3.4 Test Result of Conducted Emissions ............................................................................. 14 IV. Section 15.247(a) : Technical Description of the EUT..................................................... 17 V. Section 15.247(a)(2): Bandwidth for Direct Sequence System ...................................... 18 5.1 Test Condition & Setup ................................................................................................ 18 5.2 Test Instruments Configuration ...................................................................................... 18 5.3 List of Test Instruments ................................................................................................ 18 5.4 Test Result of Bandwidth .............................................................................................. 19 VI. Section 15.247(b) : Power Output .................................................................................... 23 6.1 Test Condition & Setup ................................................................................................ 23 6.2 List of Test Instruments ................................................................................................ 24 6.3 Test Result ................................................................................................................... 24 VII. Section 15.247(c) : Spurious Emissions (Radiated) ........................................................ 25 7.1 Test Condition & Setup ................................................................................................ 25 7.2 List of Test Instruments ................................................................................................ 26 7.3 Test Instruments Configuration ...................................................................................... 27 7.4 Test Result of Spurious Radiated Emissions .................................................................. 28 7.5 Test Result of Bandedge................................................................................................. 35 VIII.Section 15.247(d) : Power Spectral Density ................................................................... 38 8.1 Test Condition & Setup ................................................................................................ 38 8.2 Test Instruments Configuration ...................................................................................... 38 8.3 List of Test Instruments.................................................................................................. 38 8.4 Test Result of Power Spectral Density .......................................................................... 39 Test Report -------------------------------------------------------------------------------- 4/43 Report No.: D0615635 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Appendix A: Set Up Procedure ............................................................................................... 43 Test Report -------------------------------------------------------------------------------- 5/43 Report No.: D0615635 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Applicant in support of a wireless LAN Access Point certification in accordance with Part 2 Subpart J and Part 15 Subpart A and C of the Commission's Rules and Regulations. 1.2 Description of EUT EUT : 802.11b Access Point Model N…

Text truncated - open the document above for the full version.

Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Test setup photos: Netgear 802.11b Access Point (Test report no.:D0615635) FCC ID: PY3ME102RB Test Instruments Configuration of Conducted Emissions Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Test Instruments Configuration of Bandwidth Test Configuration of Bandwidth for Direct Sequence System P.S.: Notebook computer to control the EUT at maximal power output and channel Number and set antenna kit Test Condition & Setup of Power Output EUT Spectrum Analyzer (RBW:100kHz; VBW: 100kHz) EUT BOONTON 4532 RF Power Meter Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Test Instruments Configuration of the Spurious Radiated Emissions Front View of the Test Configuration Rear View of the Test Configuration The test configuration for frequency between 1GHz to 18GHz is same as above. Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Test Instruments Configuration of Power Spectral Density Test Configuration of Power Spectral Density P.S.: Notebook computer to control the EUT at maximal power output and channel number and set antenna kit EUT Spectrum Analyzer (RBW:3kHz; VBW: 10kHz)
