Page 1 CONSTRUCTION PHOTOS OF EUT

(Fig. 1) FCC ID: FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7

FCC ID: PY3FWG311 ADT No.920505H02 Operational Description This device is an 802.11g Wireless PCI Adapter which operates in the 2.4GHz band, the maximum data rate could be up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. This project is seeking the authorization of limited module approval specific to the mobile device such as access point and router. The transmitter of the EUT (802.11g Wireless PCI Adapter) is powered by from host equipment. The antenna types used in this product is Swivel dipole antenna with reverse SMA plug connector. The other instruction, please have a look at the users manual.

FCC ID: PY3FWG311 ADT No.: 920505H02 RF EXPOSURE REPORT REPORT NO.: RF920505H02 MODEL NO.: WG311 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: NETGEAR, Inc. ADDRESS: 4500 Great America Parkway, Santa Clara, CA 95054 USA ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. Lab Code: 200376-0 FCC ID: PY3FWG311 ADT No.: 920505H02 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: PY3FWG311 ADT No.: 920505H02 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: PY3FWG311 ADT No.: 920505H02 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 4.2Bi or 2.63 (numeric). 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: For DSSS: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 21.086 0.0110 1.0 6 2437 41.305 0.0216 1.0 11 2462 20.653 0.0108 1.0 For OFDM: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 21.928 0.0115 1.0 6 2437 43.152 0.0226 1.0 11 2462 21.330 0.0112 1.0

FCC ID: PY3FWG311 Report No.: RF920505H02 1 Issue Jun. 02, 2003 ADT No.: 920505H02 FCC TEST REPORT REPORT NO.: RF920505H02 MODEL NO.: WG311 RECEIVED: May 05, 2003 TESTED: May 09 to 30, 2003 APPLICANT: NETGEAR, Inc. ADDRESS: 4500 Great America Parkway, Santa Clara, CA 95054 USA ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 63 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any government agencies. The test results in the report only apply to the tested sample. Lab Code: 200376-0 FCC ID: PY3FWG311 Report No.: RF920505H02 2 Issue Jun. 02, 2003 ADT No.: 920505H02 Table of Contents 1 CERTIFICATION.......................................................................................................4 2 SUMMARY OF TEST RESULTS...........................................................................5 3 GENERAL INFORMATION.....................................................................................6 3.1 GENERAL DESCRIPTION OF EUT......................................................................6 3.2 DESCRIPTION OF TEST MODES........................................................................7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...................................7 3.4 DESCRIPTION OF SUPPORT UNITS.................................................................8 4 TEST TYPES AND RESULTS..............................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT....................................................10 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT................................10 4.1.2 TEST INSTRUMENTS...........................................................................................10 4.1.3 TEST SETUP..........................................................................................................11 4.1.4 EUT OPERATING CONDITIONS........................................................................12 4.1.5 TEST RESULTS.....................................................................................................13 4.2 RADIATED EMISSION MEASUREMENT..........................................................19 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.....................................19 4.2.2 TEST INSTRUMENTS...........................................................................................20 4.2.3 TEST PROCEDURES...........................................................................................21 4.2.4 TEST SETUP..........................................................................................................22 4.2.5 EUT OPERATING CONDITIONS........................................................................22 4.2.6 TEST RESULTS.....................................................................................................23 4.2.7 TEST RESULTS - DSSS.......................................................................................24 4.2.8 TEST RESULTS -OFDM.......................................................................................27 4.3 6dB BANDWIDTH MEASUREMENT..................................................................30 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT.............................................30 4.3.2 TEST INSTRUMENTS...........................................................................................30 4.3.3 TEST PROCEDURE..............................................................................................31 4.3.4 TEST SETUP..........................................................................................................31 4.3.5 EUT OPERATING CONDITIONS........................................................................31 4.3.6 TEST RESULTS-DSSS.........................................................................................32 4.3.7 TEST RESULTS-OFDM........................................................................................36 4.4 MAXIMUM PEAK OUTPUT POWER..................................................................40 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.............40 4.4.2 TEST INSTRUMENTS...........................................................................................40 4.4.3 TEST PROCEDURES...........................................................................................41 FCC ID: PY3FWG311 Report No.: RF920505H02 3 Issue Jun. 02, 2003 ADT No.: 920505H02 4.4.4 TEST SETUP..........................................................................................................41 4.4.5 EUT OPERATING CONDITIONS........................................................................41 4.4.6 TEST RESULTS-DSSS.........................................................................................42 4.4.7 TEST RESULTS-OFDM........................................................................................42 4.5 POWER SPECTRAL DENSITY MEASUREMENT...........................................43 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT......................43 4.5.2 TEST INSTRUMENTS...........................................................................................43 4.5.3 TEST PROCEDURE..............................................................................................44 4.5.4 TEST SETUP..........................................................................................................44 4.5.5 EUT OPERATING CONDITIONS........................................................................44 4.5.6 TEST RESULTS-DSSS.........................................................................................45 4.5.7 TEST RESULTS-OFDM...................................…

Text truncated - open the document above for the full version.

Report No.920505H02 1 The Measurement of Conducted Spurious Emissions CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 1. LIMITS OF CONDUCTED SPURIOUS EMISSIONS EASUREMENT Below 20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth, see Section 15.247(c)). Emissions which fall in the restricted bands, as defined in Section 15.205(a), must also comply with the limits specified in Section 15.209(a) (see Section 15.205(c)). 2. TEST INSTRUMENTS Description & Manufacturer Model No. Serial No. Calibrated Until R&S SPECTRUM ANALYZER FSP 1093.4495.30 Dec. 19, 2003 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 3. TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. Report No.920505H02 2 4. TEST SETUP 5. EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER Report No.920505H02 3 TEST RESULTS – For 802.11b The spectrum plots are attached on the following 4 pages. It shows compliance with the requirement in part 15.247(C),.15.205 and 15.209. Report No.920505H02 4 Ch1 Report No.920505H02 5 Report No.920505H02 6 Ch11 Report No.920505H02 7 Report No.920505H02 8 TEST RESULTS – For 802.11g The spectrum plots are attached on the following 4 pages. It shows compliance with the requirement in part 15.247(C),.15.205 and 15.209. Report No.920505H02 9 Ch1 Report No.920505H02 10 Report No.920505H02 11 Ch11 Report No.920505H02 12

FCC ID: PY3FWG311 Report No.: RF920505H02 61 Issue Jun. 02, 2003 ADT No.: 920505H02 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PY3FWG311 Report No.: RF920505H02 62 Issue Jun. 02, 2003 ADT No.: 920505H02 RADIATED EMISSION TEST
