PY3WG311V2IEEE 802.11g Wireless PCI Adapter

Netgear Incorporated

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 28, 2003
Application Purpose: Original Equipment
Date of Application: Dec 28, 2003
Equipment Note: IEEE 802.11g Wireless PCI Adapter
Frequency Range: 2412.00000000 - 2462.00000000
Company: Netgear Incorporated
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

IEEE 802.11g PCI Adapter User’s Guide ii Regulatory notes and statements Wireless LAN, Health and Authorization for use Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions however are far much less than the electromagnetic energy emissions from wireless devices like for example mobile phones. Wireless LAN devices are safe for use frequency safety standards and recommendations. The use of Wireless LAN devices may be restricted in some situations or environments for example: ·On board of airplanes, or ·In an explosive environment, or ·In case the interference risk to other devices or services is perceived or identified as harmful In case the policy regarding the use of Wireless LAN devices in specific organizations or environments (e.g. airports, hospitals, chemical/oil/gas industrial plants, private buildings etc.) is not clear, please ask for authorization to use these devices prior to operating the equipment. Regulatory Information/disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The Manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, of the substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. iii USA-FCC (Federal Communications Commission) statement This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of this device. FCC Radio Frequency Exposure statement This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner that the potential for human contact during normal operation is minimized. When nearby persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits established in the ANSI C95.1 standards, the distance between the antennas and the user should not be less than 20 cm. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: iv 1. Reorient or relocate the receiving antenna. 2. Increase the distance between the equipment and the receiver. 3. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. Export restrictions This product or software contains encryption code that may not be exported or transferred from the US of Canada without an approved US Department of Commerce export license. Safety Information Your device contains a low power transmitter. When device is transmitted it sends out radio frequency (RF) signal. CAUTION: To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Use on the supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations. The antenna(s) used for this transmitter must be installed to provide a a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. v CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. vi TABLE OF CONTENT Introduction.......................................................................................... 1 Overview of this User’s Guide......................................................... 1 Unpacking and Setup........................................................................... 3 Unpacking ........................................................................................ 3 Setup................................................................................................ 3 Hardware Installation........................................................................... 5 LED Indicator.................................................................................. 5 Check the installation....................................................................... 5 Software Installation ............................................................................ 7 Windows 98/ME/2000/XP Utility and Driver Installation............... 7 Wireless Utility Setting.................................................................... …

Text truncated - open the document above for the full version.

Cover Letter(s)

4500 Great America Parkway Santa Clara, CA 95054 Phone: 408-907-8000 Fax: 408-907-9897 www.netgear.com Letter Of Agency December 11, 2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that NETGEAR INC. authorizes TRAINING RESEARCH CO., LTD. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Signatory Chuck Olson, Vice President of Engineering NETGEAR INC. 4500 Great America Parkway Santa Clara, CA 95054 Phone: 408-907-8000 Fax: 408-907-9897 www.netgear.com Request for Confidentiality December 11, 2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: PY3WG311V2 Please be advised that the following information is to be held confidential and behalf of NETGEAR INC.: • Schematics • Part list • Block diagram • Operational description The application contains technical information which Netgear Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Signatory Chuck Olson, Vice President of Engineering NETGEAR INC. 4500 Great America Parkway Santa Clara, CA 95054 Phone: 408-907-8000 Fax: 408-907-9897 www.netgear.com Manufacturer’s Letter December 11, 2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: PY3WG311V2 To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Signatory Chuck Olson, Vice President of Engineering NETGEAR INC.

External Photos

Wireless PCI Adapter 1/4 FCC ID: PY3WG311V2 , CANADA ID: 4054A-WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Wireless PCI Adapter 2/4 FCC ID: PY3WG311V2 , CANADA ID: 4054A-WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Wireless PCI Adapter 3/4 FCC ID: PY3WG311V2 , CANADA ID: 4054A-WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Wireless PCI Adapter 4/4 FCC ID: PY3WG311V2 , CANADA ID: 4054A-WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440

ID Label/Location Info

4500 Great America Parkway Santa Clara, CA 95054 Phone: 408-907-8000 Fax: 408-907-9897 www.netgear.com FCC Labeling Requirements and Information December 11, 2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: FCC Labeling Requirements FCC ID: PY3WG311V2 The following label information is required by the FCC Rules and Regulations for certified devices. Also attached, please find marketing information required by the FCC Rules and Regulations. Thank you for your attention to these matters. Signatory Chuck Olson, Vice President of Engineering NETGEAR INC. LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation LABEL Position: Tested to Comply With FCC Standards FOR HOME OR OFFICE USE FCC ID: PY3WG311V2 CANADA ID: 4054A-WG311V2

Internal Photos

RF Exposure Info

Measurement of Maximum Permissible Exposure 1/4 FCC ID: PY3WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Measurement of Maximum Permissible Exposure 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT Granted FCC ID : PY3WG311V2 Product name : IEEE 802.11g Wireless PCI Adapter Model name : WG311 v2 Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Frequency Range : 2.412GHz ~ 2.462GHz Supported Channel : 11 Channels Modulation Skill : DBPSK, DQPSK, CCK, OFDM Power Type : Powered by PCI interface of the client’s device Measurement of Maximum Permissible Exposure 2/4 FCC ID: PY3WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 According to OET BULLETIN 56 Fourth Edition / August 1999, Equation for Predicting RF Fields: 3.1 IEEE 802.11b, Lowest CH Friis Transmission Formula: 2 22 /0189.0 )20(4 514.1661.62 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R747.2 4 514.1661.62 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 2.747cm." 3.2 IEEE 802.11b, Middle CH Friis Transmission Formula: 2 22 /0385.0 )20(4 514.1183.69 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R887.2 4 514.1183.69 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 2.887cm." Measurement of Maximum Permissible Exposure 3/4 FCC ID: PY3WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 3.3 IEEE 802.11b, Highest CH Friis Transmission Formula: 2 22 /0203.0 )20(4 514.1453.67 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R8507.2 4 514.1453.67 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 2.851cm." 3.4 IEEE 802.11g, Lowest CH Friis Transmission Formula: 2 22 /03555.0 )20(4 514.1032.118 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R771.3 4 514.10328.118 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 3.771cm." 3.5 IEEE 802.11g, Middle CH Friis Transmission Formula: 2 22 /0385.0 )20(4 514.1938.127 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R926.3 4 514.1938.127 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 3.926cm." 3.6 IEEE 802.11g, Highest CH Friis Transmission Formula: 2 22 /03774.0 )20(4 514.1314.125 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R8856.3 4 514.1314.125 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 3.886cm." Measurement of Maximum Permissible Exposure 4/4 FCC ID: PY3WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 ( dB antenna gain / 10 ) G = Log -1 (1.8 / 10) = 1.514

Test Report

Test Report -------------------------------------------------------------------------------1/47 Report No.: N1015420, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 MEASUREMENT REPORT of Wireless PCI Adapter Applicant:Netgear Inc. Product Name:IEEE 802.11g WirelessPCI Adapter Model Name:WG311 v2 FCC ID:PY3WG311V2 Report No.:N1015420 Tested by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 No. 255, Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report -------------------------------------------------------------------------------2/47 Report No.: N1015420, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 CERTIFICATION We here by verify that: The test data, data evaluation, test procedures and equipment configurations shown in this report were made mainly in accordance with the procedures given in ANSI C63.4 (1992) as a reference. All test were conducted by Training Research Co., Ltd., 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with the technical requirements set forth in the FCC Rules Part 15 Subpart B (Declaration of Conformity) and C Section 15.247. Applicant:Netgear Inc. Applicant address:4500 Great America Parkway, Santa Clara, CA 9054 USA Product Name:IEEE 802.11g Wireless PCI Adapter Model Name:WG311 v2 FCC ID : PY3WG311V2 Report No.:N1015420 Test Date:November26, 2003 Prepared by:Approved by: Jack TsaiFrank Tsai Conditions of issue : (1) This test report shall not be reproduced except in full, without written approval of TRC. And the test result contained within this report only relate to the sample submitted for testing. (2) This report must not be used by the client to claim product endorsement by NVLAP or any agency of U.S. Government. NVLAP LAB CODE: 200174-0 Test Report -------------------------------------------------------------------------------3/47 Report No.: N1015420, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Federal Communications Commission Declaration of Conformity (DoC) For the Following Equipment: Product name :IEEE 802.11g WirelessPCI Adapter Model name:WG311 v2 Trade name:NETGEAR Is herewith confirmed and found to comply with the requirements of CFR 47 part15 Subpart B - Unintentional Radiators regulation. The results of electromagnetic mission evaluation are shown in thereport number: N1015420 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation ManufacturerUSA local representative Company name:Company name: CAMEO COMMUNICATIONS, INC.NETGEAR INC. Computer address:Computer address: 6F, No.22, Chung Shin Rd., Hsi-Chih, Taipei 221, Taiwan 4500 Great America Parkway, Santa Clara, CA 95054, USA ZIP / Postal codeZIP / Postal code 22195054 Contact person:Contact person: Jason ChangChuck Olson Title:Title: Wireless Comm RD Dept ManagerVice President of Engineering Internet e -mail address:Internet e -mail address: [email protected] Tel / Fax:Tel / Fax: 886-2-26499800 / 886-2-264999841-408-907-8000 / 1-408-907-8097 Test Report -------------------------------------------------------------------------------4/47 Report No.: N1015420, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Tables of Contents I.GENERAL...................................................................................................................... 6 1.1 Introduction............................................................................................................... 6 1.2 Description of EUT .................................................................................................... 6 1.3 Description of Support Equipment .............................................................................. 6 1.4 Test method ............................................................................................................... 9 1.5 Configuration of System Under Test .......................................................................... 10 1.6 Verify the Frequency and Channel............................................................................. 12 1.7 Test Procedure ......................................................................................................... 12 1.8 Location of the Test Site ............................................................................................ 13 1.9 General Test Condition .............................................................................................. 13 II. Section 15.101(a) : Equipment Authorization of Unintentional Radiators.................... 14 III. Section 15.203 : Antenna Requirement.......................................................................... 15 IV. Section 15.207 : Power Line Conducted Emissions for AC Powered Units................ 16 4.1 Test Condition & Setup ............................................................................................. 16 4.2 List of Test Instruments ............................................................................................. 16 4.3 Test Result of Conducted Emissions .......................................................................... 17 RX mode...................................................................................................................... 17 IEEE 802.11b............................................................................................................. 18 IEEE 802.11g............................................................................................................. 19 V.Section 15.247(a) : Technical Description of…

Text truncated - open the document above for the full version.

Test Report

Test Report ------------------------------------------------------------------------------ 26/47 Report No.: N1015420, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 VII. Section 15.247(b): Power Output 7.1 Test Condition & Setup 1. The output of the transmitter is connected to the BOONTON RF Power Meter. 2. The calibration is performed before every tests. The values of the output power of the EUT will shown in the dBm directly are the transmitter output peak power. Recording as follows. 7.2 List of Test Instruments Instrument Name Model No. Brand Serial No. Last time Next time RF Power Meter 4532 BOONTON 117501 04/12/03 04/12/04 Peak Power Sensor 57340 BOONTON 2698 04/12/03 04/12/04 7.3 Test Result Formula: RF Output of EUT + |Cable Loss| = Output Peak Power IEEE 802.11b Channel RF Output Cable Loss Output Peak Power dBm dBm dBm mW CH 1 17.27 0.70 17.97 62.661 CH 6 17.70 0.70 18.40 69.183 CH 11 17.59 0.70 18.29 67.453 IEEE 802.11g Channel RF Output Cable Loss Output Peak Power dBm dBm dBm mW CH 1 20.02 0.70 20.72 118.032 CH 6 20.37 0.70 21.07 127.938 CH 11 20.28 0.70 20.98 125.314 EUT BOONTON 4532 RF Power Meter

Test Report

:products: Peak Power Sensors Sensor Response Model Impedance RF Connector Frequency Range (Low Bandwidth) Dynamic Range Peak Pwr Rng CW Pwr Rng(1) Int Trigger Range Overload Rating Pulse / Continuous Fast Risetime (Bandwidth) Slow Risetime (Bandwidth) DUAL DIODE PEAK POWER SENSORS For use with models 4400, 4500, 4400A, and 4500A RF Peak Power Meters and 4530 Series RF Power Meter when combined with Model 2530 1 GHz calibrator accessory. 56218 50 ohm N (M) 0.03 to 18 GHz -24 to +20 dBm -34 to +20 dBm -10 to +20 dBm 1 W for 1μs 200 mW <150 ns (2 MHz) <500 ns (700 kHz) 56318 50 ohm N (M) 0.5 to 18 GHz -24 to +20 dBm -34 to +20 dBm -10 to +20 dBm 1 W for 1μs 200 mW <15 ns (2) (35 MHz) <200 ns (1.75 MHz) 56326 50 ohm K (M) 0.5 to 26.5 GHz -24 to +20 dBm -34 to +20 dBm -10 to +20 dBm 1 W for 1μs 200 mW <15 ns(2) (35 MHz) <200 ns (1.75 MHz) 56418 50 ohm N (M) 0.5 to 18 GHz -34 to +5 dBm -40 to +5 dBm -18 to +5 dBm 1 W for 1μs 200 mW <30 ns (15 MHz) <100 ns (6 MHz) 56518 50 ohm N (M) 0.5 to 18 GHz -40 to +20 dBm -50 to +20 dBm -27 to +20 dBm 1 W for 1μs 200 mW <100 ns (6 MHz) <300 ns (1.16 MHz) For use with models 4400, 4500, 4400A, 4500A, and 4530. Compatible with 4530 Series internal 50 MHz calibrator. 57318 50 ohm N (M) 0.5 to 18 GHz (0.05 to 18 GHz) -24 to +20 dBm -34 to +20 dBm -10 to +20 dBm 1 W for 1μs 200 mW <15 ns(2) (35 MHz) <10 μs (35 kHz) 57340 50 ohm K (M) 0.5 to 40 GHz (0.05 to 40 GHz) -24 to +20 dBm -34 to +20 dBm -10 to +20 dBm 1 W for 1μs 200 mW <15 ns(2) (35 MHz) <10 μs (35 kHz) 57540 50 ohm K (M) 0.1 to 40 GHz (0.05 to 40 GHz) -40 to +20 dBm -50 to +20 dBm -27 to +20 dBm 1 W for 1μs 200 mW <100 ns (6 MHz) <10 μs (35 kHz)

Test Setup Photos

Test Setup Photos ------------------------------------------------------------------------ 1/3 FCC ID: PY3WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Conducted Test Setup Placement: Front View of the Test Configuration Side View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------ 2/3 FCC ID: PY3WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement: Front View of Unintentional Rear View of Unintentional Test Setup Photos ------------------------------------------------------------------------ 3/3 FCC ID: PY3WG311V2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement: Front View of Intentional Rear View of Intentional

Contact Information

Applicant

David Kay

[email protected]4088903160Fax: 4089078097

Technical Contact

Training Research Co., Ltd.Jack Tsai

[email protected]+886-2-26935155, 22

No. 255 Nanyang Street Shijr · Taipei Hsien · Taiwan

Test Firm

Training Research Co., Ltd.Jack Tsai

[email protected]886-2-26935155Fax: 886-2-26934440

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	128.00 mW

Confidentiality

Long Term

Grant Notes

Power Output listed is Conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
