FCC ID: PY3WGE101 ADT No.920528H11 Operational Description This device is an 802.11g Wireless Ethernet Bridge which operates in the 2.4GHz band, the maximum data rate could be up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. This project is seeking the authorization of limited module approval specific to the mobile device such as access point and router. The transmitter of the EUT (802.11g Wireless Ethernet Bridge) is powered by AC adapter. The antenna type used in this product is Dipole antenna with MMCX connector. The other instruction, please have a look at the users manual.

FCC ID: PY3WGE101 ADT No.: 920528H11 RF EXPOSURE REPORT REPORT NO.: RF920528H11 MODEL NO.: WGE101 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: NETGEAR, Inc. ADDRESS: 4500 Great America Parkway, Santa Clara, CA 95054 USA ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. Lab Code: 200376-0 FCC ID: PY3WGE101 ADT No.: 920528H11 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: PY3WGE101 ADT No.: 920528H11 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: PY3WGE101 ADT No.: 920528H11 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 2Bi or 1.585 (numeric). 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: For DSSS: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 30.690 0.0097 1.0 6 2437 31.189 0.0098 1.0 11 2462 31.915 0.0100 1.0 For OFDM: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 31.405 0.0099 1.0 6 2437 30.761 0.0097 1.0 11 2462 30.339 0.0096 1.0

FCC ID: PY3WGE101 Report No.: RF920528H11 1 Issued: Jun. 13, 2003 ADT No.: 920528H11 FCC TEST REPORT REPORT NO.: RF920528H11 MODEL NO.: WGE101 RECEIVED: May 28, 2003 TESTED: May 28 to Jun. 10, 2003 APPLICANT: NETGEAR, Inc. ADDRESS: 4500 Great America Parkway, Santa Clara, CA 95054 USA ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 62 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any government agencies. The test results in the report only apply to the tested sample. Lab Code: 200376-0 FCC ID: PY3WGE101 Report No.: RF920528H11 2 Issued: Jun. 13, 2003 ADT No.: 920528H11 Table of Contents 1 CERTIFICATION.......................................................................................................4 2 SUMMARY OF TEST RESULTS...........................................................................5 3 GENERAL INFORMATION.....................................................................................6 3.1 GENERAL DESCRIPTION OF EUT......................................................................6 3.2 DESCRIPTION OF TEST MODES........................................................................7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...................................7 3.4 DESCRIPTION OF SUPPORT UNITS.................................................................8 4 TEST TYPES AND RESULTS................................................................................9 4.1 CONDUCTED EMISSION MEASUREMENT......................................................9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..................................9 4.1.2 TEST INSTRUMENTS.............................................................................................9 4.1.3 TEST SETUP..........................................................................................................10 4.1.4 EUT OPERATING CONDITIONS........................................................................11 4.1.5 TEST RESULTS.....................................................................................................12 4.2 RADIATED EMISSION MEASUREMENT..........................................................18 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.....................................18 4.2.2 TEST INSTRUMENTS...........................................................................................19 4.2.3 TEST PROCEDURES...........................................................................................20 4.2.4 TEST SETUP..........................................................................................................21 4.2.5 EUT OPERATING CONDITIONS........................................................................21 4.2.6 TEST RESULTS.....................................................................................................22 4.2.7 TEST RESULTS - DSSS.......................................................................................23 4.2.8 TEST RESULTS -OFDM.......................................................................................26 4.3 6dB BANDWIDTH MEASUREMENT..................................................................29 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT.............................................29 4.3.2 TEST INSTRUMENTS...........................................................................................29 4.3.3 TEST PROCEDURE..............................................................................................30 4.3.4 TEST SETUP..........................................................................................................30 4.3.5 EUT OPERATING CONDITIONS........................................................................30 4.3.6 TEST RESULTS-DSSS.........................................................................................31 4.3.7 TEST RESULTS-OFDM........................................................................................35 4.4 MAXIMUM PEAK OUTPUT POWER..................................................................39 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.............39 4.4.2 TEST INSTRUMENTS...........................................................................................39 4.4.3 TEST PROCEDURES...........................................................................................40 FCC ID: PY3WGE101 Report No.: RF920528H11 3 Issued: Jun. 13, 2003 ADT No.: 920528H11 4.4.4 TEST SETUP..........................................................................................................40 4.4.5 EUT OPERATING CONDITIONS........................................................................40 4.4.6 TEST RESULTS-DSSS.........................................................................................41 4.4.7 TEST RESULTS-OFDM........................................................................................41 4.5 POWER SPECTRAL DENSITY MEASUREMENT...........................................42 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT......................42 4.5.2 TEST INSTRUMENTS...........................................................................................42 4.5.3 TEST PROCEDURE..............................................................................................43 4.5.4 TEST SETUP..........................................................................................................43 4.5.5 EUT OPERATING CONDITIONS........................................................................43 4.5.6 TEST RESULTS-DSSS.........................................................................................44 4.5.7 TEST RESULTS-OFDM...................…

Text truncated - open the document above for the full version.

FCC ID: PY3WGE101 Report No.: RF920528H11 60 Issued: Jun. 13, 2003 ADT No.: 920528H11 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PY3WGE101 Report No.: RF920528H11 61 Issued: Jun. 13, 2003 ADT No.: 920528H11 RADIATED EMISSION TEST
