Part Number Date Subject pages3 WGE111 Operation Principle 1. CPU, U6, 88W8510 have a 32-bit RISC processor integrated, operation frequency is 160MHz. It needs an external 44MHz crystal for reference frequency; this crystal is also used for RF module. This chip is responsible to control RF-Baseband Transceiver (88W8000G), Flash IC and LED. This chip also has MII interface integrated to communicate with 10/100 Ethernet Switch. 2. FLASH, U13, MX29LV800TTC-70, 8Mbits Flash, bottom sector, 70ns. It is used to store the normal and test firmware. 3. Integrated 2.4GHz ISM Band RF-Baseband Transceiver, U9, 88W8000G which is integrated all RF-Baseband receive and Transmit function. On-Chip Power Amplifier (PA) with up to +20 dBm output power at the antenna port. It is also integrated programmable frequency synthesizers with integrated VCOs, I/Q generation and CMOS up/down conversion mixers. 4. Components: Ethernet port (10/100BaseT) CONNECT THE 10/100BASET CABLING (RJ45 CONNECTOR) FOR THE EXTERNAL LAN, WAN, Reset Button Used to reboot, reset to factory default, Power Jack Connect the power adapter here. 2 stop manual switch Use to set different operation mode, Adhoc and Infrastucture mode 5. Power part: there are several regulators are used on the board. U17, AZ1084S-3 is used to transfer DC5V to DC3V3; U1, U8 AME8805 are used to transfer DC3V3 to DC2V5; U20, 1117-ADJ is used to transfer DC3V3 to DC1V62. The core of CPU is operate at 1.5V. 6. LED part: LED Color Controlled by Description Power Green FW on: green; (symbol) Ethernet Link Green FW Solid Green, whether 10 or 100 Mbps (symbol) Internet Link/Act Green FW Alternate Blinking: Looking for network association Solid Green LED – wireless connection available ADHOC Link/Act Blue FW Alternate Blinking: Looking for network association Solid Blue LED – wireless connection available 7. Switch button, SW1, it is used to reset the 88W8510. 8.

1.1. Test Result of RF Exposure Evaluation . Product: 54 Mbps Wireless Game Adapter . Test Item: RF Exposure Evaluation Data . Test site: OATSI-SD . Test Mode: Normal Operation 1.1.1. Antenna Gain The maximum Gain is 1.8 dBi. 1.1.2. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.1.3. Output Power into Antenna & RF Exposure Evaluation Distance Modulation Standard: IEEE 802.11b Test Date: Jun. 26, 2004 Temperature: 24 Humidity: 62 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 14.17 0.009 06 2437 15.63 0.013 11 2462 15.65 0.013 Modulation Standard: IEEE 802.11g Test Date: Jun. 26, 2004 Temperature: 24 Humidity: 62 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 14.11 0.009 06 2437 12.34 0.006 11 2462 14.47 0.010 The MPE is calculated as 0.013 mW / cm2 < limit 1 mW / cm2. So, RF exposure limit warning or SAR test are not required.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: July. 01, 2004 1 of 75 FCC ID: PY3WGE111 FCC Test Report: FI04062402-A FCC TEST REPORT according to FCC Rules and Regulations Part 15 Subpart C † The test result refers exclusively to the test presented test model / sample., † Without written approval of Exclusive Certification Corp. the test report shall not be reproduced except in full. Applicant Netgear Inc. Address 4500 Great America Parkway Santa Clara California 95054 USA Equipment 54 Mbps Wireless Game Adapter Model No. WGE111 FCC ID PY3WGE111 Trade Name Netgear Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: July. 01, 2004 2 of 75 FCC ID: PY3WGE111 FCC Test Report: FI04062402-A Contents 1. Report of Measurements and Examinations..................................................................................4 1.1. List of Measurements and Examinations.............................................................................4 1.2. Antenna Requirements......................................................................................................5 1.3. Test of Conducted Emission...............................................................................................6 1.4. Test of Radiated Emission.................................................................................................8 1.5. 6dB Bandwidth.................................................................................................................9 1.6. Maximum Peak Output Power............................................................................................9 1.7. Band Edges Measurement..............................................................................................10 1.8. Power Spectral Density...................................................................................................10 1.9. Restricted Bands of Operation.........................................................................................11 1.10. Labeling Requirement.....................................................................................................11 1.11. RF Exposure..................................................................................................................12 2. Test Configuration of Equipment under Test................................................................................14 2.1. Test Mode and Test Software...........................................................................................14 2.2. Description of Test System..............................................................................................14 2.3. Connection Diagram of Test System.................................................................................14 2.4. Feature of Equipment under Test.....................................................................................15 2.5. History of this test report..................................................................................................15 3. General Information of Test........................................................................................................16 4. Test Result and Data.................................................................................................................17 4.1. Antenna Requirement.....................................................................................................17 4.2. Test Result of Conducted Emission..................................................................................18 4.3. RF Portion......................................................................................................................33 4.4. 6dB Bandwidth Measurement Data..................................................................................49 4.5. Peak Output Power Measurement Data............................................................................53 4.6. Band Edges Measurement Data......................................................................................57 4.7. Power Spectral Density Measurement Data......................................................................70 4.8. Test Result of RF Exposure Evaluation.............................................................................74 5. List of Measuring Equipment Used.............................................................................................75 Appendix A. Photographs of EUT......................................................................................A1 ~ A5 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: July. 01, 2004 3 of 75 FCC ID: PY3WGE111 FCC Test Report: FI04062402-A CERTIFICATE OF COMPLIANCE according to FCC Rules and Regulations Part 15 Subpart C Applicant Netgear Inc. Address 4500 Great America Parkway Santa Clara California 95054 USA Equipment 54 Mbps Wireless Game Adapter Model No. WGE111 FCC ID PY3WGE111 I HEREBY CERTIFY THAT : The measurements shown in this test report were made in accordance with the procedures given in ANSI C63.4. The equipment was passed the test performed according to FCC Rules and Regulations Part 15 Subpart C (2002). The test was carried out on Jun. 26, 2004 at Exclusive Certification Corp. Signature Anson Chou / Manager Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: July. 01, 2004 4 of 75 FCC ID: PY3WGE111 FCC Test Report: FI04062402-A 1. Report of Measurements and Examinations 1.1. List of Measurements and Examinations FCC Rule . Description of Test Result 15.203 . Antenna Requirement Pass 15.207 . Conducted Emission Pass 15.209 . Radiated Emission Pass 15.247(a)(2) . 6dB Bandwidth Pass 15.247(b) . Maximum Peak Output Power Pass 15.247(c) . 100kHz Bandwidth of Frequency Band Edges Pass 15.247(d) . Power Spectral Density Pass 1.1307 1.1310 2.1091 2.1093 . RF Exposure Compliance Pass Test by: Exclusive Certification Corp. Tel:886-2-2792-3366 F…
