PY3WGR615VWIRELESS VOIP

September 2004 1.0 Version 1.0 September 2004 NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA NETGEAR Wireless VOIP Setup Manual September 2004 © 2004 by NETGEAR, Inc. All rights reserved. September 2004. Trademarks NETGEAR is a trademark of Netgear, Inc. Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or trademarks of their respective holders. Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Channel The Wireless Channel sets the radio frequency used for communication. Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best performance. In the USA and Canada, 11 channel are available. If using multiple Access Points, it is better if adjacent Access Points use different Channels to reduce interference. In "Infrastructure" mode, Wireless Stations normally scan all Channels, looking for an Access Point. If more than one Access Point can be used, the one with the strongest signal is used. (This can only happen within an ESS.) If using "Ad-hoc" mode (no Access Point), all Wireless stations should be set to use the same Channel. However, most Wireless stations will still scan all Channels to see if there is an existing "Ad-hoc" group they can join. Contentsi September 2004 Contents Chapter 1 About This Guide Audience, Conventions, and Formats ............................................................................1-1 Chapter 2 Getting to Know Your NETGEAR Wireless Router Package Contents ..........................................................................................................2-1 The Front Panel .......................................................................................................2-2 The Rear Panel ........................................................................................................2-3 Chapter 3 Connecting the Router to the Internet Prepare to Install Your Wireless Router ..........................................................................3-1 First, Connect the Wireless Router to Your Network ......................................................3-1 Use the Smart Wizard to Configure Your Wireless Router .............................................3-6 Now, Set Up a Computer for Wireless Connectivity .......................................................3-7 Troubleshooting Tips ......................................................................................................3-7 How to Manually Configure Your Internet Connection ....................................................3-9 Chapter 4 Optimizing Wireless Connectivity and Security Observe Performance, Placement, and Range Guidelines ............................................4-1 Implement Appropriate Wireless Security ......................................................................4-2 Understanding Wireless Settings ...................................................................................4-3 Information to Gather Before Changing Basic Wireless Settings .............................4-5 Default Factory Settings ...........................................................................................4-6 Chapter 5 Doing Basic Router Housekeeping Changing the Administrator Password ...........................................................................5-1 Upgrading the Wireless Router Software .......................................................................5-2 Chapter 6 Troubleshooting Common Problems Basic Functioning ..............................…

Text truncated - open the document above for the full version.

Statement Federal Communications Commission To whom it may concern, We, NetGear Inc., have done some modifications during testing the product of FCC ID: PY3WGR615V, and we hereby declare that this modification will be implemented in the final product. By: Larry Kerila Title: Product Design Manager Applicant: Netgear, Inc. Address: 4500 Great America Parkway, Santa Clara, California 95054 USA Tel: +1-408-907-8000 Fax: +1-408-907-8097 E-mail: [email protected] Date: Jan. 07, 2004

Netgear Inc. November 19, 2004 Federal Communications Commission Authorization and Evaluation Division FCC ID : PY3WGR615V Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompaniment this Application As outlined below: 1. Block Diagram, 2. Schematic Diagram, The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Larry Kerila, Product Design Manager Applicant: Netgear, Inc. Address: 4500 Great America Parkway, Santa Clara, California 95054 USA TEL: +1-408-907-8000 FAX: +1-408-907-8097

Netgear Inc. 4500 Great America Parkway, Santa Clara, California 95054 USA Federal Communications Commission Dear Sir, We, the undersigned, hereby authorize Exclusive Certification Corp. to act on our behalf in all matters relating to application for WIRELESS VOIP (Model: WGR615V, FCC ID No.: PY3WGR615V)” authorization, including the signing of all documents relating to these matters. Any and all carried out by Exclusive Certification Corp. on our behalf shall have the same effect as acts of our own. The applicant certifies that in the case of an individual applicant (e.g., corporation), no party to the applicant is subject to a denial of federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-drug abuse Act of 1988.21 U.S.A. 862. For a definition of a “party” for these purposes See 47 C.F.R. 1.2002(b). By: Larry Kerila Title: Product Design Manager Applicant: Netgear, Inc. Address: 4500 Great America Parkway, Santa Clara, California 95054 USA Tel: +1-408-907-8000 Fax: +1-408-907-8097 E-mail: [email protected] Date: October 29, 2004

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 30, 2004 RE: FCC ID: PY3WGR615V_ATCB002043 Attention: Lily Chang I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that in the first internal photo there is what appears to be copper tape connecting two sections. This appears to be a modification. However, nothing in the report or other documentation mentions modifying the EUT during testing. Please verify if this is an existing condition or if this was done during compliance testing. If this was done during compliance testing, please provide an attestation from the manufacturer that this modification will be implemented in the final product. 2. FYI - Please note that while your report states that you used ANSI C63.4 2003, the plots for peak readings are not in accordance to the standard specified. Please note that ANSI C63.4 states that above 1GHz for peak measurements the video bandwidth is to be at least 3 times the resolution BW. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

External Photos Test mode 1: Adaptor Model: DV-151A-1 Test mode 2: Adaptor Model: MU18-2120150-A1 Test mode 3: Adaptor Model: ADS6818-1812-W 1215

WIRELESS VOIP FCC ID: PY3WGR615V CANADA ID: 4054A-WGR615V RF Module Inside "Complies with RSS-210"

Internal Photos Test mode 1: Adaptor Model: DV-151A-1 Test mode 2: Adaptor Model: MU18-2120150-A1 Test mode 3: Adaptor Model: ADS6818-1812-W 1215

WGR615V Operation Principle 1. CPU, U12, TNETV1060 have a 32-bit RISC processor integrated, operation frequency is 125MHz. It needs an external 25MHz crystal for system reference frequency, and an 8.192MHz crystal for telephony interface reference frequency. This chip is responsible to control Flash/SDRAM IC, CODEC IC and LED. This chip also has two integrated 10/100 Ethernet MAC/PHY. 2. FLASH: U15, TE28F640J3C-120, 8Mbytes Flash, and 120ns. It is used to store the normal and test firmware. 3. Wireless q RC2326(U2): IEEE 802.11 b/g RFFE ISM Band, highly integrated 802.11 b/g radio Radio, fully integrated up/down converters, LNA, PA, TX detector and T/R switches q RC2422(U8): IEEE 802.11 b/g IQ/IF Transceiver With Dual VCO Synthesizers, Highly integrated 802.11 b/g radio IQ/IF Transceiver PLL ASIC, Fully integrated IF and RF VCOs and synthesizer q (U1)TNETW1130GVF Wireless MAC and Baseband processor 4. Switching Controller: U4, RTL8309SB. It is used to provide 4 ports of ethernet interface. 5. CODEC, U9/U10, Si3210-KT, Programmable CMOS SLIC/CODEC. They provide 2 channel VOIP function. 6. Power part: several regulators are used on the board. U8, FP5452 is used to generate 3.3V and 1.8V DC voltage from 12V DC power input. Q16/Q19/Q25 is used to generate 1.6V DC voltage from 3.3V DC power, and 1.6V is CPU core voltage. 7. Switch button, S1, it is used to factory restore or system reboot.

1.1. Test Result of RF Exposure Evaluation . Product: WIRELESS VOIP . Test Item: RF Exposure Evaluation Data . Test site: OATSI-SD . Test Mode: Normal Operation 1.1.1. Antenna Gain The maximum Gain is 2.0 dBi. 1.1.2. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.1.3. Output Power into Antenna & RF Exposure Evaluation Distance Modulation Standard: IEEE 802.11b Test Date: Nov. 24, 2004 Temperature: 24 Humidity: 63 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 16.01 0.0126 06 2437 15.98 0.0125 11 2462 15.91 0.0123 Modulation Standard: IEEE 802.11g Test Date: Nov. 24, 2004 Temperature: 24 Humidity: 63 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 15.85 0.0121 06 2437 15.75 0.0118 11 2462 15.71 0.0117 The MPE is calculated as 0.0126 mW / cm 2 < limit 1 mW / cm 2 . So, RF exposure limit warning or SAR test are not required.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 1 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A FCC TEST REPORT according to FCC Rules and Regulations Part 15 Subpart C † The test result refers exclusively to the test presented test model / sample., † Without written approval of Exclusive Certification Corp. the test report shall not be reproduced except in full. † The EUT is also considered as a kind of computer peripheral, because the connection to computer is necessary for typical use. It has been verified to comply with the requirements of FCC Part 15, Subpart B, Class B (DoC). The test report has been issued separately. Applicant NETGEAR Inc. Address 4500 Great America Parkway Santa Clara California 95054 USA Equipment WIRELESS VOIP Model No. WGR615V FCC ID PY3WGR615V Trade Name NETGEAR Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 2 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Contents 1. Report of Measurements and Examinations.................................................................................4 1.1. List of Measurements and Examinations............................................................................4 1.2. Antenna Requirements.....................................................................................................5 1.3. Test of Conducted Emission..............................................................................................6 1.4. Test of Radiated Emission................................................................................................8 1.5. 6dB Bandwidth.................................................................................................................9 1.6. Maximum Peak Output Power...........................................................................................9 1.7. Band Edges Measurement...............................................................................................10 1.8. Power Spectral Density....................................................................................................10 1.9. Restricted Bands of Operation..........................................................................................11 1.10. Labeling Requirement......................................................................................................11 1.11. RF Exposure...................................................................................................................12 2. Test Configuration of Equipment under Test................................................................................14 2.1. Test Mode and Test Software...........................................................................................14 2.2. Description of Test System...............................................................................................14 2.3. RF Module Specifications.................................................................................................14 2.4. History of this test report..................................................................................................14 2.5. Connection Diagram of Test System.................................................................................15 2.6. Feature of Equipment under Test......................................................................................15 3. General Information of Test........................................................................................................16 4. Test Result and Data.................................................................................................................17 4.1. Antenna Requirement......................................................................................................17 4.2. Test Result of Conducted Emission...................................................................................18 4.3. RF Portion......................................................................................................................70 4.4. 6dB Bandwidth Measurement Data.................................................................................101 4.5. Peak Output Power Measurement Data..........................................................................105 4.6. Band Edges Measurement Data.....................................................................................109 4.7. Restrict band emission Measurement Data.....................................................................114 4.8. Power Spectral Density Measurement Data.....................................................................130 5. List of Measuring Equipment Used...........................................................................................134 Appendix A. Photographs of EUT......................................................................................A1 ~ A13 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 3 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A CERTIFICATE OF COMPLIANCE according to FCC Rules and Regulations Part 15 Subpart C Applicant NETGEAR Inc. Address 4500 Great America Parkway Santa Clara California 95054 USA Equipment WIRELESS VOIP Model No. WGR615V FCC ID PY3WGR615V I HEREBY CERTIFY THAT : The measurements shown in this test report were made in accordance with the procedures given in ANSI C63.4 The equipment was passed the test performed according to FCC Rules and Regulations Part 15 Subpart C (2003). The test was carried out on Dec. 15, 2004 at Exclusive Certification Corp. Signature Anson Chou / Manager Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 4 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A 1. Report of Measurements and Examinations 1.1. List of Measurements and Examinations FCC Rule . Description of Test Result 15.203 . Antenna Require…

Text truncated - open the document above for the full version.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 24 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 25 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 26 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 27 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 28 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 29 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 30 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Test mode 2: Adaptor Model: MU18-2120150-A1 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 31 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 32 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 33 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 34 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 35 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 36 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 37 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 38 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 39 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 40 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 41 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 42 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Test mode 3: Adaptor Model: ADS6818-1812-W 1215 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 43 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 44 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 45 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 46 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 47 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 60 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 61 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 62 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 63 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 64 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 65 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Test by: Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 66 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A 4.2.1. Photographs of Conducted Emission Test Test mode 1: Adaptor Model: DV-151A-1 FRONT VIEW REAR VIEW Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 67 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Test mode 2: Adaptor Model: MU18-2120150-A1 FRONT VIEW REAR VIEW Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 68 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Test mode 3: Adaptor Model: ADS6818-1812-W 1215 FRONT VIEW REAR VIEW Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 69 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Test mode 4: Adaptor Model: DSA-0151F-12 A FRONT VIEW REAR VIEW

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 70 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A 4.3. RF Portion 4.3.1. Test Result of Conducted Emission A Att 20 dB * Ref 10 dBm 2.497 GHz/Start30 MHzStop25 GHz * * RBW 100 kHz VBW 100 kHz SWT 6.4 s * 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -43.19 dBm 2.027600000 GHz Date: 5.NOV.2004 09:02:32 A Att 20 dB * Ref 10 dBm * * RBW 100 kHz VBW 100 kHz SWT 6.4 s Start30 MHzStop25 GHz2.497 GHz/ * 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -42.78 dBm 2.027600000 GHz Date: 5.NOV.2004 09:04:10 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 71 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A A Att 20 dB * Ref 10 dBm * * RBW 100 kHz VBW 100 kHz SWT 6.4 s Start30 MHzStop25 GHz2.497 GHz/ * 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -43.26 dBm 2.077540000 GHz Date: 5.NOV.2004 09:05:52 A Att 20 dB * Ref 10 dBm * * RBW 100 kHz VBW 100 kHz SWT 6.4 s Start30 MHzStop25 GHz2.497 GHz/ * 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -41.10 dBm 2.427120000 GHz Date: 5.NOV.2004 09:06:59 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 72 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A A Att 20 dB * Ref 10 dBm * * RBW 100 kHz VBW 100 kHz SWT 6.4 s Start30 MHzStop25 GHz2.497 GHz/ * 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -42.94 dBm 2.027600000 GHz Date: 5.NOV.2004 09:08:49 A Att 20 dB * Ref 10 dBm * * RBW 100 kHz VBW 100 kHz SWT 6.4 s Start30 MHzStop25 GHz2.497 GHz/ * 1 PK VIEW -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -38.48 dBm 2.477060000 GHz Date: 5.NOV.2004 09:10:11 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 73 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A 4.3.2. Test Result of Radiated Emission The test result including four kind of power adaptor: Test mode 1: Adaptor Model: DV-151A-1 Modulation Standard: IEEE 802.11b a) Emission frequencies below 1 GHz Channel LO Test Date: Nov. 09, 2004 Temperature: 25 Humidity: 58% Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 189.08 H 56.23 -18.06 38.17 43.5 -5.33 Peak 192 1.0 565.44 H 46.84 -3.45 43.39 46.0 -2.61 Q.P 175 1.0 875.84 H 40.64 1.86 42.50 46.0 -3.15 Peak 200 1.0 938.89 H 40.02 3.99 44.01 46.0 -1.99 Q.P 255 1.0 94.99 V 58.23 -18.08 40.16 43.5 -3.34 Peak 165 1.0 565.44 V 46.28 -3.45 42.82 46.0 -3.18 Peak 172 1.0 688.63 V 43.67 -1.74 41.93 46.0 -4.07 Peak 220 1.0 875.84 V 41.22 1.86 43.08 46.0 -2.92 Q.P 190 1.0 938.89 V 40.59 3.99 44.58 46.0 -1.42 Q.P 265 1.0 b) Emission frequencies above 1 GHz Channel LO Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 1061.5 H 63.49 -6.19 57.30 74 -16.70 Peak 200 1.0 1061.5 H 52.11 -6.08 46.03 54 -7.97 Ave 200 1.0 1187.0 H 64.47 -5.28 59.20 74 -14.80 Peak 190 1.0 1187.0 H 53.32 -5.20 48.12 54 -5.88 Ave 190 1.0 2037.9 H 55.86 0.02 55.88 74 -18.12 Peak 210 1.0 2037.9 H 50.28 0.03 50.31 54 -3.69 Ave 210 1.0 1061.5 V 61.42 -6.69 54.73 74 -19.27 Peak 195 1.0 1061.5 V 53.51 -6.58 46.93 54 -7.07 Ave 195 1.0 1187.0 V 63.28 -5.78 57.50 74 -16.50 Peak 185 1.0 1187.0 V 54.12 -5.70 49.42 54 -5.58 Ave 185 1.0 2037.9 V 60.92 -0.68 60.23 74 -13.77 Peak 190 1.5 2037.9 V 50.60 -0.67 49.93 54 -4.07 Ave 190 1.5 2615.6 V 53.97 1.29 55.25 74 -18.75 Peak 195 1.0 2615.6 V 43.27 1.32 44.60 54 -9.40 Ave 195 1.0 4824.1 V 52.88 7.33 60.21 74 -13.79 Peak 220 1.5 4824.1 V 43.35 7.36 50.71 54 -3.29 Ave 220 1.5 7240.6 V 49.96 11.06 61.02 74 -12.98 Peak 215 1.5 7240.6 V 38.19 11.06 49.25 54 -4.75 Ave 215 1.5 Notes: 1. Result = Meter Reading + Corrected Factor 2. Corrected Factor = Antenna Factor + Cable Loss – Amplifier 3. The resolution bandwidth and video bandwidth of test receiver/spectrum analyzer is 120KHz for Peak detection at frequency below 1GHz. 4. The resolution bandwidth of test receiver/spectrum analyzer is 1MHz and video bandwidth is 3MHz for Peak detection and frequency above 1GHz. Peak detection and Quasi-peak detection at frequency above 1GHz. 5. The resolution bandwidth of test receiver/spectrum analyzer is 1MHz and video bandwidth is 10Hz for Average detection at frequency above 1GHz. Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Dec. 21, 2004 74 of 134 FCC ID: PY3WGR615V FCC Test Report: FI04100401-A Modulation Standard: IEEE 802.11b a) Emission frequencies below 1 GHz Channel MID Test Date: Nov. 09, 2004 Temperature: 25 Humidity: 58% Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 189.08 H 55.98 -18.06 37.92 43.5 -5.58 Peak 195…
