PZLMC9620SG2UMPortable phone used in a networked system

F E E N G L I S H R A N Ç A I S S P A Ñ O L D E U T S C H PMR Customer Documentation 10/1999 IH – PS7912EAC01 G2 Handportable Installation Handbook Notice d’Installation du Portatif G2 Instrucción de Instalación del Portátil G2 Installationsanleitung Handfunkgerät G2 MC9/TR/APP/00047 01.03/QL F E E N G L I S H R A N Ç A I S S P A Ñ O L D E U T S C H 10/1999 IH – PS7912EAC01 EQUIPMENT COMPLIANCE TO EUROPEAN STANDARDS The equipment used for the configurations described in this document complies with the following European standards: •“ElectroMagnetic Compatibility” (EMC) Standard n° 89/336/CEE amended by 92/31/CEE and 93/68/CEE directives. •“Low Voltage” (LVD) standard (electric safety for hardware and personnel) n° 73/23/CEE amended by 93/68/CEE directive. The tests carried out have proven that the equipment complies with one or several of the following standards related to these directives: ETS300279, EN50081–1, EN50082–1, EN60950 or EN60335–1 and EN60335–29. During installation, the state–of–the–hart procedures must be followed in order to maintain compliance with European requirements. CONFORMITÉ DES ÉQUIPEMENTS AUX DIRECTIVES EUROPÉENNES Les équipements constituant les différentes configurations décrites dans ce document sont conformes aux directives européennes suivantes : •Directive “Compatibilité ElectroMagnétique” (CEM) n° 89/336/CEE modifiée par les directives 92/31/CEE et 93/68/CEE. •Directive “Basse Tension” (DBT) (sécurité électrique des matériels et des personnes) n° 73/23/CEE modifiée par la directive 93/68/CEE. Les tests effectués ont prouvé que les équipements sont conformes à une ou plusieurs des normes suivantes relatives à ces directives : ETS300279, EN50081–1, EN50082–1, EN60950 ou EN60335–1 et EN60335–29. Lors des installations, il est impératif de respecter les règles de l’art en matière d’installation afin de conserver la conformité aux exigences européennes. CONFORMIDAD DE LOS EQUIPOS CON LAS DIRECTIVAS EUROPEAS Los equipos incluidos en las diferentes configuraciones descritas en el presente documento están en conformidad con las directivas europeas siguientes: •Directiva “ Compatibilidad ElectroMagnética ” (CEM) n°89/336/CEE modificada por las directivas 92/31/CEE y 93/68/CEE. •Directiva “ Baja Tensión ” (DBT) (seguridad eléctrica de los materiales y de las personas) n°73/23/CEE modificada por la directiva 93/68/CEE. Las pruebas efectuadas han demostrado que los equipos son conformes a una o a varias de las normas siguientes, relativas a dichas directivas: ETS300279, EN50081–1, EN50082–1, EN60950 o EN60335–1 y EN60335–29. Para efectuar la instalación se debe imperativamente respetar las reglas correspondientes para conservar la conformidad con las exigencias europeas. ÜBEREINSTIMMUNG DER AUSRÜSTUNGEN MIT DEN EG–RICHTLINIEN Die Ausrüstungen, aus welchen die verschiedenen in diesem Dokument beschriebenen Konfigurationen aufgebaut werden, entsprechen folgenden EG–Richtlinien: •Richtlinie “Elektromagnetische Verträglichkeit” (EM) Nr. 89/336/EG geändert durch die Richtlinie 92/31/EG und 93/68/EG. •“Niederspannungsrichtlinie” (elektrischer Material– und Personenschutz) Nr. 73/23/EG geändert durch die Richtlinie 93/68/EG. Die an diesem Material erfolgten Tests weisen nach, daß die Ausrüstungen einer oder mehreren der folgenden Normen in Zusammenhang mit den o. g. Richtlinien entsprechen: ETS300279, EN50081–1, EN60950 oder EN60335–1 und EN60335–29. Bei der Installation des Materials muß der Stand der Technik im Bereich der Installationsarbeiten zwingend eingehalten werden, um die Übereinstimmung des Materials mit den EG–Richtlinien zu wahren. G2 HANDPORTABLE INSTALLATION HANDBOOK E N G L I S H This document is the property of MATRA NORTEL COMMUNICATIONS and should not be copied or circulated without permission 1/6 IH – PS7912EAC0110/1999 INTRODUCTION The present G2 handportable installation handbook provides: •the description of the various kits, •the safety precautions, •the installation procedure, •the starting up and shutting down procedures. G2 HANDPORTABLE INSTALLATION HANDBOOK E N G L I S H 2/610/1999 IH – PS7912EAC01 This document is the property of MATRA NORTEL COMMUNICATIONS and should not be copied or circulated without permission DESCRIPTION Composition of the kits TR1020 to TR1031 (see Plate A–I) REFERENCEDESIGNATIONITEM RA1700 to RA1703, RA1710 to RA1713, RA1720 or RA1721 (1) G2 handportable set4 PK1024, PK1391 or PK1392 (2)Antenna6 HR5932 (3)4.8V NiMH battery pack1 PS7912G2 handportable installation handbook7 (1) The reference depends on the handportable type (Smart, Easy+ or Easy) and on the frequency range that is used (ULB, UMB or UHB). (2) The reference depends on the antenna type (long or short) and on the frequency range that is used (ULB, UMB or UHB). (3) The NiMH 4.8 V battery pack is supplied with certain kits. Note:The HR5980 belt clip (item 2) is available as an option. G2 HANDPORTABLE INSTALLATION HANDBOOK E N G L I S H This document is the property of MATRA NORTEL COMMUNICATIONS and should not be copied or circulated without permission 3/6 IH – PS7912EAC0110/1999 Characteristics •Dimensions: see Plate A–I. •Weight: see Plate A–I. •Power supply from: the supplied battery pack, an external power supply unit (voltage: 5 V ±5%, max. current: 2 A) a charger or a car or desktop adapter. •Operating temperature range for operation (extreme conditions): from –30°C to 60°C. •Temperature range for storing the battery pack: the battery pack life depends on the storage temperature: between –20 o C and +35 o C: one year, between –35 o C and +40 o C: 6 months, between –40 o C and +50 o C: 30 days. CAUTION:The battery pack is irreversibly damaged, if the storage temperature is above 50 o C. G2 HANDPORTABLE INSTALLATION HANDBOOK E N G L I S H 4/610/1999 IH – PS7912EAC01 This document is the property of MATRA NORTEL COMMUNICATIONS and should not be copied or circulated without permission SAFETY PRECAUTIONS Antenna •The antenna must not be bended with an angle gre…

Text truncated - open the document above for the full version.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TRP/Cetecom bvba November 13, 2001 Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21036 RE: FCC ID:PZLMC9620SG2UM application for certification Gentlemen: EADS-Defense and Security Networks herewith submits an application for a portable push to talk handset to be operated as part of a networked system under Part 90 of the FCC Rules. The system consist of multiple handsets together with single or multiple networked base stations to provide secure networked digital communication service to multiple users in the 440 MHz to 490 MHz band. Detailed descriptions of the respective systems are contained in the individual filing for the base and portable units. There are two portable unit models to be included under the reference FCC ID. The two model numbers are MC9620SG2UM (does not have the encryption integrated chip) and MC2620SG2UM which contains the encryption chip. As part of this filing, EADS through their American liaison, has provided an analysis showing the equipment meets the spectral efficiency requirements of Section 90.203(j)(8). This analysis has been accepted by the FCC as sufficient to show the spectral efficiency requirement is met. Copies of the pertinent documents and FCC confirmation of acceptance are included in this filing. This project is a joint venture of Matra, Nortel, and EADS-DSN with much of the supporting documentation showing the Matra Nortel logo. Sincerely, Phillip Inglis Consultant 14085 Howard Rd Dayton, MD 21036

Subject: Fwd: EDSN Nortel interpretation Date: Thu, 25 Oct 2001 13:42:47 -0400 From: "Frank Coperich" <[email protected]> To: <[email protected]> CC: "Rich Fabina" <[email protected]> The proposal attached to your incoming inquiry is acceptable for satisfying Section 90.208(j)(8). --------------------------------------------------------------------- Subject: EDSN Nortel interpretation Date: Mon, 22 Oct 2001 09:46:10 -0400 From: <[email protected]> To: [email protected] Frank, Can you confirm the acceptablility of the attached analysis for purposes of showing that the system in question meets the spectral efficiency comparison requirement of Section 90.203(j)(8). It is my understanding that the analysis has been accepted by the FCC. Regards, Phil --------------------------------------------------------------------- Name: 1_spectrum efficiency final_0107201_.doc 1_spectrum efficiency final_0107201_.doc Type: Microsoft Word Document (application/msword) Encoding: base64

November 1, 2001 CONFIDENTIALITY REQUEST Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re:EADS-Defense & Security Networks application for a Part 90 portable transmitter FCC ID: PZLMC9620SG2UM Gentlemen: EADS-Defense & Security Networks herein submits an application for Equipment Authorization to be followed by submission of the necessary fees for certification of portable handset transmitter under FCC Rules Part 90 as required by the FCC Rules. EADS-Defense & Security Networks requests, pursuant to 47CFR 0.459, post grant confidentiality for portions of the material contained in this application such that the identified material will be withheld from public inspection following the grant of this authorization. This material, as indicated by request for confidentiality of the items during the electronic submission process and further identified below, includes: 1. Circuit diagrams submitted as Equipment Authorization electronic filing attachment: "Schematics". 2. Parts list submitted as Equipment Authorization electronic filing attachment: "Parts List". 3. Block diagram submitted as Equipment Authorization electronic filing attachment: "Block Diagram". 4. Technical description submitted as Equipment Authorization electronic filing attachment: "Technical Description". 5. Technical description of spectral efficiency submitted as Equipment Authorization electronic filing attachment: "Spectrum Efficiency". Specifically, these exhibits contain information relating to circuit function and complexity that could be of benefit to competitors. The material contains trade secrets and confidential information that EADS-Defense & Security Networks does not customarily release to the public and which is otherwise not generally available to the public. Please contact the undersigned by telephone at 410-531-3439, by fax at 410-531-0807, by email at [email protected], or by correspondence at the address below if there are any further questions or additional information needed concerning this filing. Regards, (signed) Phillip Inglis, TRP/Cetecom b.v.b.a. 14085 Howard Rd. Dayton, MD. 21036

CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 58 (66) Photographs of the equipment CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 59 (66) Photographs of the equipment CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 60 (66) Photographs of the equipment

Draft proposal for FCC ID label requirement. 10/24/2001 Phil Inglis The proposed FCC ID label is as follows: FCC ID:PZLMC9620SG2UM Device restricted to occupational use to satisfy FCC RF exposure compliance. See owners manual for specific operating requirements. Battery compartment Label Location

CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 60 (66) Photographs of the equipment. FCC ID Label will replace the CE Mark Label.

CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 66 (66) Photographs of the equipment

CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 61 (66) Photographs of the equipment CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 62 (66) Photographs of the equipment CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 63 (66) Photographs of the equipment CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 64 (66) Photographs of the equipment CETECOM ICT Services GmbH Test report nr..: 5_3682-B/0001Issue Date:05.03.01Page 65 (66) Photographs of the equipment

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TRP/Cetecom bvba October 31, 2001 Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21036 RE: FCC ID:PZLMC9620SG2UM application for certification Gentlemen: This letter is to address the filing of RF exposure information with this application. Pursuant to Section 2.1093(c) equipment to be certified under the referenced FCC ID is excluded from routine environmental evaluation for RF exposure prior to certification and use except as provided in Section 1.1307(c) and (d) of the Rules. Sincerely, Phillip Inglis Consultant 14085 Howard Rd Dayton, MD 21036 [Click here and type slogan]

10/242001 LANGUAGE ACCEPTABLE TO EDSN. DISTANCES BELOW ARE NOMINAL AND MAY BE ADJUSTED IF NECESSARY FOR FCC APPROVAL. FCC RF Exposure Compliance Requirements for Occupational Use Only: This Radio has been tested and complies with the Federal Communications Commission (FCC) RF exposure limits for Occupational Use/Controlled exposure environment. In addition, it complies with the following Standards and Guidelines: ◊ FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio Frequency Radiation. ◊ FCC OET Bulletin 65 Edition 97-01 (1997) Supplement C, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. ◊ ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. ◊ ANSI/IEEE C95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave. 1. This radio is NOT approved for use by the general population in an uncontrolled environment. This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control its RF exposure conditions. 2. When transmitting with the unit in front of the mouth, hold the radio in a vertical position with its microphone away from your mouth and keep the antenna at least 1 inch (2.5 cm) away from your head and body. 3. The radio must be used with a maximum operating duty cycle not exceeding 50%, in typical Push-to- Talk (PTT) configurations. DO NOT transmit for more than 50% of total radio use time (50% duty cycle). Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded. The radio is transmitting when the red LED on the top of the radio is illuminated. You can cause the radio to transmit by pressing the PTT button. 4. Always use EDSN Standard authorized accessories.

835MHz Brain Dipole Validation Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: σ = 0.90 mho/m ε r = 41.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.10 mW/g, SAR (10g): 1.42 mW/g 835MHz Brain Dipole Validation (D835V2 S/N: 406) Frequency: 835 MHz; Antenna Input Power: 250 [mW] PCTEST Brain Tissue Simulating Liquid [12/19/2001] SAR Tot [mW/g] 2.18E-1 6.32E-1 1.07E+0 1.43E+0 1.95E+0 PCTEST Engineering Laboratory, Inc. 835MHz Muscle Dipole Validation Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Muscle: σ = 0.97 mho/m ε r = 55.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.07 mW/g, SAR (10g): 1.37 mW/g 835MHz Muscle Dipole Validation (D835V2 S/N: 406) Frequency: 835 MHz; Antenna Input Power: 250 [mW] PCTEST Muscle Tissue Simulating Liquid [12/21/2001] SAR Tot [mW/g] 2.41E-1 7.12E-1 1.17E+0 1.69E+0 2.12E+0 PCTEST Engineering Laboratory, Inc.

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) EDSN, INC. Dates of Tests: December 19-21, 2001 Rue J.P. Timbaud — MS01 Test Report S/N: SAR.211212711.PZL P.O. Box BP26 Test Site: PCTEST Lab, Columbia, MD USA Bois d’ Arch Cedex, France F-78392 Attn: Yann Lebail FCC ID PZLMC9620SG2UM APPLICANT EDSN, INC. EUT Type: Portable Push-to-talk Radio Tx/Rx Frequency Range: 440 ~ 490 MHz Max. RF Output Power: 2.0 W Max. SAR Measurement: 2.54 mW/g AMPS Head SAR; 1.44mW/g AMPS Body SAR; 1.28mW/g AMPS Mouth SAR Trade Name / Model(s): EADS TELECOM / MC9620SG2UM & MC2620SG2UM FCC Classification: Licensed Non-Broadcast Transmitter Held to Face (TBF) FCC Rule Part(s): §2.1093; FCC/OET Bulletin Supplement C [July 2001] Application Type: Certification This wireless portable device has been shown to be capable of continued compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992 and IEEE Std. 1528 (Draft Aug.2000). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 211212711.EAD SAR Measurement Report FCC Part 90 Certification © 2001 PCTEST Lab i Table of Contents 1.1 SCOPE 1 2.1 INTRODUCTION / SAR DEFINITION 2 3.1 SAR MEASUREMENT SET-UP 3 4.1 E-FIELD PROBE SYSTEM 4 5.1 E-FIELD PROBE CALIBRATION PROCESS 5-6 6.1 PHANTOM, HOLDER, & EQUIVALENT TISSUE 7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS 9 9.1 HEAD SAR TEST POSITIONS OF THE PHONE 10 10.1 BODY SAR TEST SETUP 11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS 12 12.1 MEASUREMENT UNCERTAINTIES 13 13.1 TEST DATA SUMMARY 14-20 14.1 SAR TEST EQUIPMENT LIST 21 15.1 CONCLUSION 22 16.1 REFERENCES 23 ATTACHMENT A - SAR TEST DATA ATTACHMENT B - SAR TEST SETUP PHOTOGRAPHS ATTACHMENT C - DIPOLE VALIDATION ATTACHMENT D - PROBE CALIBRATION Test Report S/N: SAR.211212711.EAD SAR Measurement Report Test Date(s): December 19-21, 2001 FCC Part 90 Certification © 2001 PCTEST Lab Portable Push-to-talk Radio 1 EDSN, INC. FCC ID: PZLMC9620SG2UM SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name: EDSN, INC. Address: Rue J.P. Timbaud — MS01 P.O. Box BP26 Bois d’ Arch Cedex, France F-78392 Attention: Yann Lebail • EUT Type: Portable Push-to-talk Radio • Trade Name: EADS TELECOM • Model(s): MC9620SG2UM & MC2620SG2UM • FCC IDENTIFIER: PZLMC9620SG2UM • Tx/Rx Frequency Range: 440 ~ 490 MHz • FCC Classification: Licensed Non-Broadcast Transmitter Held to Face (TBF) • Modulation(s): AMPS • FCC Rule Part(s): §2.1093, OET Bulletin 65, Supplement C (July 2001) • Max. RF Output Power: 2.0W • Max SAR Measurement: 2.54mW/g AMPS Head SAR 1.44mW/g AMPS Body SAR 1.28mW/g AMPS Mouth SAR • Application Type: Certification • Dates of Tests: December 19-21, 2001 Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.211212711.EAD 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.211212711.EAD SAR Measurement Report Test Date(s): December 19-21, 2001 FCC Part 90 Certification © 2001 PCTEST Lab Portable Push-to-talk Radio 2 EDSN, INC. FCC ID: PZLMC9620SG2UM 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[5] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source. SAR values have been related to threshold levels for potential biological hazards. 2.2 SAR Definition Specific Absorption Rate (SAR) is defined as the time derivative (rate) of the incremental energy (dU) absorbed by (dissipa…

Text truncated - open the document above for the full version.

Probe ET3DV6 SN:1560 Manufactured:December 1, 2000 Calibrated:February 20, 2001 Calibrated for System DASY3 Page 1 of 8 ET3DV6 SN:1560 DASY3 - Parameters of Probe: ET3DV6 SN:1560 Sensitivity in Free SpaceDiode Compression NormX1.48 μV/(V/m) 2 DCP X98mV NormY1.51 μV/(V/m) 2 DCP Y98mV NormZ1.43 μV/(V/m) 2 DCP Z98mV Sensitivity in Tissue Simulating Liquid Head450MHz ε r =43.5 ± 5% σ = 0.87 ± 10% mho/m ConvF X7.17 extrapolatedBoundary effect: ConvF Y7.17 extrapolatedAlpha0.25 ConvF Z7.17 extrapolatedDepth3.21 Head900MHz ε r =42 ± 5% σ = 0.97 ± 10% mho/m ConvF X6.59 ± 7% (k=2)Boundary effect: ConvF Y6.59 ± 7% (k=2)Alpha0.32 ConvF Z6.59 ± 7% (k=2)Depth2.93 Head1500MHz ε r =40.4 ± 5% σ = 1.23 ± 10% mho/m ConvF X5.82 interpolatedBoundary effect: ConvF Y5.82 interpolatedAlpha0.41 ConvF Z5.82 interpolatedDepth2.55 Head1800MHz ε r =40 ± 5% σ = 1.40 ± 10% mho/m ConvF X5.43 ± 7% (k=2)Boundary effect: ConvF Y5.43 ± 7% (k=2)Alpha0.46 ConvF Z5.43 ± 7% (k=2)Depth2.36 Sensor Offset Probe Tip to Sensor Center2.7mm Optical Surface Detection2.0 ± 0.2mm Page 2 of 8 ET3DV6 SN:1560 Receiving Pattern (φ), θ = 0° f = 30 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 100 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 300 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 900 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot Page 3 of 8 ET3DV6 SN:1560 Isotropy Error (φ), θ = 0° -1.00 -0.80 -0.60 -0.40 -0.20 0.00 0.20 0.40 0.60 0.80 1.00 060120180240300360 error[dB] 30 MHz 100 MHz 300 MHz 900 MHz 1800 MHz 2500 MHz f = 1800 MHz, WG R22 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 2500 MHz, WG R26 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot Page 4 of 8 ET3DV6 SN:1560 Frequency Response of E-Field ( TEM-Cell:ifi110, Waveguide R22) 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 050010001500200025003000 f [MHz] frequency response TEMR22 Page 5 of 8 ET3DV6 SN:1560 Dynamic Range f(SAR brain ) ( TEM-Cell:ifi110 ) ET3DV6 SN:1560 1.E+0 1.E+1 1.E+2 1.E+3 1.E+4 1.E+5 1.E+6 1.E+7 0.00010.0010.010.11.10.100. mW/cm 3 μ V not compensatedcompensated -2.0 -1.0 0.0 1.0 0.0010.010.1110100 mW/cm 3 errror[dB] Page 6 of 8 Conversion Factor Assessment Head900MHz ε r =42 ± 5% σ = 0.97 ± 10% mho/m ConvF X6.59 ± 7% (k=2)Boundary effect: ConvF Y6.59 ± 7% (k=2)Alpha0.32 ConvF Z6.59 ± 7% (k=2)Depth2.93 Head1800MHz ε r =40 ± 5% σ = 1.40 ± 10% mho/m ConvF X5.43 ± 7% (k=2)Boundary effect: ConvF Y5.43 ± 7% (k=2)Alpha0.46 ConvF Z5.43 ± 7% (k=2)Depth2.36 ET3DV6 SN:1560 f = 900 MHz, WG R9 (head) 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 0204060 z[mm] SAR[mW/cm 3 ] / W AnalyticalMeasuremets f = 1800 MHz, WG R22 (head) 0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 0204060 z[mm] SAR[mW/cm 3 ] / W AnalyticalMeasuremets Page 7 of 8 Deviation from Isotropy in HSL Error (θ,φ), f = 900 MHz 0 40 80 120 160 200 240 280 320 0 10 20 30 40 50 60 -1.00 -0.80 -0.60 -0.40 -0.20 0.00 0.20 0.40 0.60 0.80 1.00 Error [dB] θ φ -1.00--0.80-0.80--0.60-0.60--0.40-0.40--0.20-0.20-0.00 0.00-0.200.20-0.400.40-0.600.60-0.800.80-1.00 Page 8 of 8

EADS TELECOM FCC ID: PZLMC9620SG2UM -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Brain: σ = 0.87 mho/m ε r = 43.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.28 mW/g, SAR (10g): 1.74 mW/g EADS TELECOM 450MHz Portable Push-to-talk Radio Model:EADS MC9620 FM Low Channel 21 [450.00MHz]; Extended Battery Conducted Power = 2Watts; Left Head Phantom, Cheek/Touch Position Test Date -- 12-19-2001 SAR Tot [mW/g] 2.21E-1 6.63E-1 1.11E+0 1.55E+0 1.99E+0 PCTEST Engineering Laboratory, Inc. EADS TELECOM FCC ID: PZLMC9620SG2UM -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Brain: σ = 0.87 mho/m ε r = 43.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.29 mW/g, SAR (10g): 1.78 mW/g EADS TELECOM 450MHz Portable Push-to-talk Radio Model:EADS MC9620 FM Mid Channel 71 [475.00MHz]; Extended Battery Conducted Power = 2Watts; Left Head Phantom, Cheek/Touch Position Test Date -- 12-19-2001 SAR Tot [mW/g] 2.31E-1 6.92E-1 1.15E+0 1.61E+0 2.08E+0 PCTEST Engineering Laboratory, Inc. EADS TELECOM FCC ID: PZLMC9620SG2UM -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Brain: σ = 0.87 mho/m ε r = 43.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.49 mW/g, SAR (10g): 1.15 mW/g EADS TELECOM 450MHz Portable Push-to-talk Radio Model:EADS MC9620 FM High Channel 101 [490.00MHz]; Extended Battery Conducted Power = 2Watts; Left Head Phantom, Cheek/Touch Position Test Date -- 12-19-2001 SAR Tot [mW/g] 1.42E-1 4.27E-1 7.12E-1 9.97E-1 1.28E+0 PCTEST Engineering Laboratory, Inc. EADS TELECOM FCC ID: PZLMC9620SG2UM -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Brain: σ = 0.87 mho/m ε r = 43.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.95 mW/g, SAR (10g): 1.51 mW/g EADS TELECOM 450MHz Portable Push-to-talk Radio Model:EADS MC9620 FM Mid. Channel 71 [475.00MHz]; Standard Battery Conducted Power = 2Watts; Left Head Phantom, Cheek/Touch Position Test Date -- 12-19-2001 SAR Tot [mW/g] 2.07E-1 6.20E-1 1.03E+0 1.45E+0 1.86E+0 PCTEST Engineering Laboratory, Inc. EADS TELECOM FCC ID: PZLMC9620SG2UM -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Brain: σ = 0.87 mho/m ε r = 43.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.54 mW/g, SAR (10g): 1.86 mW/g EADS TELECOM 450MHz Portable Push-to-talk Radio Model:EADS MC9620 FM Low Channel 21 [450.00MHz]; Extended Battery Conducted Power = 2Watts; Left Head Phantom, Ear/15degree Tilt Position Test Date -- 12-19-2001 SAR Tot [mW/g] 2.49E-1 7.48E-1 1.25E+0 1.74E+0 2.24E+0 PCTEST Engineering Laboratory, Inc. EADS TELECOM FCC ID: PZLMC9620SG2UM -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Brain: σ = 0.87 mho/m ε r = 43.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.49 mW/g, SAR (10g): 1.84 mW/g EADS TELECOM 450MHz Portable Push-to-talk Radio Model:EADS MC9620 FM Mid Channel 71 [475.00MHz]; Extended Battery Conducted Power = 2Watts; Left Head Phantom, Ear/15degree Tilt Position Test Date -- 12-19-2001 SAR Tot [mW/g] 2.55E-1 7.64E-1 1.27E+0 1.78E+0 2.29E+0 PCTEST Engineering Laboratory, Inc. EADS TELECOM FCC ID: PZLMC9620SG2UM -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Brain: σ = 0.87 mho/m ε r = 43.5 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.66 mW/g, SAR (10g): 1.23 mW/g EADS TELECOM 450MHz Portable Push-to-talk Radio Model:EADS MC9620 FM High Channel 101 [490.00MHz]; Extended Battery Conducted Power = 2Watts; Left Head Phantom, Ear/15degree Tilt Position Test Date -- 12-19-2001 SAR Tot [mW/g] 1.76E-1 5.27E-1 8.78E-1 1.23E+0 1.58E+0 PCTEST Engineering Laboratory, Inc. EADS TELECOM FCC ID: PZLMC9620SG2UM -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Brain: σ = 0.87 mho/m ε r = 43.5 ρ = 1.00 g/cm 3 ; Anten…
