PZWAN22R01High Frequency 13.56MHz Transceiver

M18 / M30 Cylindrical type transceiver for 1732 series User’s Manual NOTICE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Properly shielded and grounded cables must be used for connection to host computers and / or peripherals in order to meet FCC emission limits. FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC CAUTION: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Federal Communication Commission Interference Statement For European Union [EN] English Hereby, DENSO WAVE INCORPORATED declares that this equipment (M18/M30 Type Transceiver) is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. [BG] Bulgarian С настоящето, DENSO WAVE INCORPORATED, декларира, че M18/M30 Type Transceiver е в съответствие със съществените изисквания и другитеприложими разпоредби на Директива 1999/5/EC. [HR] Croatian Ovim DENSO WAVE INCORPORATED, izjavljuje da je M18/M30 Type Transceiver u sklau s bitnim zahtjevima i drugim relevantnim odredbama Direktive 1999/5/EC i Pravilnika o RiTT opremi (NN25/2012). [CS] Czech DENSO WAVE INCORPORATED tímto prohlašuje, že M18/M30 Type Transceiver splňuje základní požadavky a všechna příslušná ustanoveni Směrnice 1999/5/ES. [DA] Danish Undertegnede DENSO WAVE INCORPORATED erklærer herved, at følgende udstyr M18/M30 Type Transceiver overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. [DE] German Hiermit erklärt DENSO WAVE INCORPORATED, dass sich das Gerät M18/M30 Type Transceiver in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. [ET] Estonian Käesolevaga kinnitab DENSO WAVE INCORPORATED seadme M18/M30 Type Transceiver vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. [EL] Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Ο ΚΑΤΑΣΚΕΥΑΣΤΗΣ DENSO WAVE INCORPORATED ΔΗΛΩΝΕΙ ΟΤΙ M18/M30 Type Transceiver ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ [ES] Spanish Por la presente, DENSO WAVE INCORPORATED, declara que este M18/M30 Type Transceiver cumple con los requisitos esenciales y otras exigencias relevantes de la Directiva 1999/5/EC. [FR] French Par la présente, DENSO WAVE INCORPORATED déclare que l’appareil M18/M30 Type Transceiver est conforme aux exigencies essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. [IT] Italian Con la presente DENSO WAVE INCORPORATED dichiara che questo M18/M30 Type Transceiver è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. [LV] Latvian Ar šo DENSO WAVE INCORPORATED deklarē, ka M18/M30 Type Transceiver atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. [LT] Lithuanian Šiuo DENSO WAVE INCORPORATED deklaruoja, kad šis M18/M30 Type Transceiver atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas [HU] Hungarian A DENSO WAVE INCORPORATED ezzennel kijelenti, hogy a HIGH FREQUENCY 13.56MHz TRANSCEIVER típusú beren-dezés teljesíti az alapvető követelményeket és más 1999/5/EK irányelvben meghatározott vonatkozó rendelkezéseket. [NL] Dutch Hierbij verklaart DENSO WAVE INCORPORATED dat het toestel l HIGH FREQUENCY 13.56MHz TRANSCEIVER in overeenstemming is met de essentiële eisen en de andere relevante bepalin-gen van richtlijn 1999/5/EG. [PL] Polish Niniejszym DENSO WAVE INCORPORATED deklaruje że HIGH FREQUENCY 13.56MHz TRANSCEIVER jest zgodny z zasadniczymi wymaganiami iinnymi właściwymi postanowieniami Dyrektywy 1999/5/EC. [PT] Portuguese Eu, DENSO WAVE INCORPORATED, declaro que o HIGH FREQUENCY 13.56MHz TRANSCEIVER cumpre os requisitos essenciais e outras provisões relevantes da Directiva 1999/5/EC. [RO] Romanian Prin prezenta, DENSO WAVE INCORPORATED, declară că aparatul HIGH FREQUENCY 13.56MHz TRANSCEIVER este în conformitate cu cerinţele esenţiale şi cu alte prevederi pertinente ale Directivei 1999/5/CE. [SK] Slovak DENSO WAVE INCORPORATED týmto vyhlasuje, že HIGH FREQUENCY 13.56MHz TRANSCEIVER spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. [SL] Slovenian DENSO WAVE INCORPORATED izjavlja, da je ta HIGH FREQUENCY 13.56MHz TRANSCEIVER v skladu z bistvenimi zahtevami in drugimi relevantnimi določili direktive 1999/5/ES. [FI] Finish DENSO WAVE INCORPORATED vakuuttaa täten että HIGH FREQUENCY 13.56MHz TRANSCEIVER tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. [SV] Swedish Denna utrustning är i överensstämmelse med de väsentliga kraven och andra relevanta bestämmelser i direktiv 1999/5/EC. Declaration of Conformity (For European Union) NOTICE: This M18/M30 Type Transceiver may be operated in below country: AT CZ FR HR LT PL SI IS HR BE DK DE IE LU PT ES LI MK BG EE GR IT MT RO SE NO TR CY FI HU LV NL SK GB CH LI Properly shielded cables must be used for connection to host computers and / or peripherals in order to meet CE emissio…

Text truncated - open the document above for the full version.

                                      56RF-TR-M18 and 56RF-TR-M30Detail Main_PCB CPU Transmitter and Receiver Filter RS-485 I/F Power Supply Adjusting Circuit TRF7962 (IC for RF Circuit) Xtal 13.56MHz To M12 Connector To Antenna Tr for LED Please refer to "Theory of Operation_Structure" for antenna position.                                       56RF-TR-M18 and 56RF-TR-M30Detail Antenna_PCB M18 Antenna M30 Antenna Please refer to "Theory of Operation_Structure" for antenna position.

Test report No. : 32JE0052-HO-01-B Page : 2 of 23 Issued date : July 18, 2012 FCC ID : PZWAN22R01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ................................................................................................... 3 SECTION 2: Equipment under test (E.U.T.) ..................................................................................... 3 SECTION 3: Test specification, procedures & results ...................................................................... 4 SECTION 4: Operation of E.U.T. during testing .............................................................................. 7 SECTION 5: Conducted emission ....................................................................................................... 9 SECTION 6: Radiated emission (Fundamental , Spurious Emission and Spectrum Mask ) ...... 10 SECTION 7: Other test ...................................................................................................................... 11 APPENDIX 1: Data of EMI test ........................................................................................................ 12 Conducted emission ..............................................................................................................................................................12 Fundamental emission and Spectrum Mask .......................................................................................................................14 Spurious emission .................................................................................................................................................................16 20dB Bandwidth and 99% Occupied Bandwidth ...............................................................................................................18 Frequency Tolerance ............................................................................................................................................................19 APPENDIX 2: Test instruments ........................................................................................................ 20 APPENDIX 3: Photographs of test setup ......................................................................................... 21 Conducted emission ..............................................................................................................................................................21 Radiated emission .................................................................................................................................................................22 Worst Case Position ..............................................................................................................................................................23 Test report No. : 32JE0052-HO-01-B Page : 3 of 23 Issued date : July 18, 2012 FCC ID : PZWAN22R01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 SECTION 1: Customer information Company Name : DENSO WAVE INCORPORATED Address : 1 Yoshiike Kusagi Agui-cho, Chita-gun, 470-2297 Aichi Telephone Number : +81-569-49-5302 Facsimile Number : +81-569-49-5488 Contact Person : AKIHIRO SUGIURA SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : High Frequency 13.56MHz Transceiver Model No. : 56RF-TR-M18 Serial No. : Refer to Section 4, Clause 4.2 Receipt Date of Sample : June 26, 2012 Country of Mass-production : Japan Condition of EUT : Engineering prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No Modification by the test lab 2.2 Product Description General Specification Clock frequency(ies) in the system : 13.56MHz Radio Specification Radio Type : Transceiver Frequency of Operation : 13.56MHz Modulation : ASK (10% to 30%) Operating voltage : DC 24V Power Supply (inner) : DC 5V Antenna type : Loop Coil Antenna Gain : -61dBi Operating Temperature : -25 deg. C. - +70 deg. C Test report No. : 32JE0052-HO-01-B Page : 4 of 23 Issued date : July 18, 2012 FCC ID : PZWAN22R01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 SECTION 3: Test specification, procedures & results 3.1 Test Specification Test Specification : FCC Part 15 Subpart C: 2012, final revised on May 17, 2012 and effective June 18, 2012 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.207 Conducted limits Section 15.225 : Operation within the band 13.110-14.010MHz 3.2 Procedures and results Item Test Procedure Specification Worst margin Results Remarks Conducted emission ANSI C63.4:2003 7. AC powerline conducted emission measurements Section 15.207 [QP] 16.3dB 7.62496MHz, N/L [AV] 9.0dB 7.62496MHz, N Complied - <IC>RSS-Gen 7.2.2 <IC>RSS-Gen 7.2.2 Electric Field Strength of Fundamental Emission ANSI C63.4:2003 13. Measurement of intentional radiators Section 15.225(a) 69.8dB 13.56000MHz, QP, 45deg. Complied Radiated <IC> RSS-Gen 4.8, 4.11 <IC>RSS-210 A2.6 Spectrum Mask ANSI C63.4:2003 13. Measurement of intentional radiators Section 15.225(b)(c) 46.4dB 13.11000MHz, QP, 45deg. Complied Radiated <IC>RSS-Gen 4.9, 4.11 <IC> RSS-210 A2.6 20dB Bandwidth ANSI C63.4:2003 13. Measurement of intentional radiators Section15.215(c) See data Complied Radiated <IC> - <IC> - Electric Field Strength of Spurious Emission ANSI C63.4:2003 13. Measurement of intentional radiators Section15.209, Section 15.225 (d) 1.6dB 88.000MHz, QP, Vert. Complied Radiated <IC>RSS-Gen 4.9, 4.11 <IC>RSS-210 A2.6 Frequency Tolerance ANSI C63.4:2003 13. Measurement of intentional radiators Section15.225(e) See data Complied Radiated <IC>RSS-Gen 4.7 <IC> RSS-210 A2.6 Note: …

Text truncated - open the document above for the full version.

Test report No. : 32JE0052-HO-01-B Page : 21 of 23 Issued date : July 18, 2012 FCC ID : PZWAN22R01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 APPENDIX 3: Photographs of test setup Conducted emission Photo 1 Photo 2 Test report No. : 32JE0052-HO-01-B Page : 22 of 23 Issued date : July 18, 2012 FCC ID : PZWAN22R01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Radiated emission Photo 1 Photo 2 Test report No. : 32JE0052-HO-01-B Page : 23 of 23 Issued date : July 18, 2012 FCC ID : PZWAN22R01 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Worst Case Position Below 30MHz X-axis Above 30MHz Horizontal:X-axis / Vertical:Y-axis X-axis Y-axis Z-axis End of Report
