PZWS1635-01Hand Held Terminal

496487-6490 Hand Held Terminal Operator's Guide Model S1635-01/01A/01B Thank you for using the Hand Held Terminal. Please read this manual thoroughly prior to operation to ensure full use of the product’s functionality, and store safely in a convenient location for quick reference even after reading. This manual contains only the basic details required for operation. Please refer to the User’s Manual for further details on general operation. Bundled Item - Hand Held Terminal - Battery - Hand Strap - Stylus - Operator’s Guide - Safety Precautions Some of the pixels on the LCD touch screen may not illuminate or stay permanently illuminated. Furthermore, there may also be inconsistencies in color and brightness. None of these aspects represent an LCD defect. A thin Newton's ring (rainbow-like patterns) may appear on the touch panel. This does not necessarily indicate a problem with the touch panel. About This Manual • Due to changes and improvements, the content of this manual may be subject to change without prior notice. • The reproduction or duplication of the whole or part of this manual is strictly prohibited without prior consent. • Please contact NEC Infrontia Corporation ("NEC Infrontia") if this manual is lost. • Every attempt has been made to ensure that the content of this manual is thorough and up to date, however, we kindly ask you to report any questionable descriptions, mistakes or omissions, if any, to NEC Infrontia. Liability Limitations • NEC Infrontia does not assume any product liability (including damages for lost profits, interruption of operations, or the loss of business-related information) arising out of, or in connection with, the use of, or inability to use the HHT system software or related manuals. • NEC Infrontia takes reasonable precautions to ensure its products do not infringe upon any patents or other intellectual property rights of other(s), however, NEC Infrontia cannot be responsible for any patent or other intellectual property right infringement(s) or violation(s) arising from any of the following. (1) The use of NEC Infrontia’s products in connection or in combination with other components, products, devices, data processing systems or software not supplied by NEC Infrontia. (2) The use of NEC Infrontia’s products in a manner for which they were not intended nor designed. (3) The modification of NEC Infrontia’s products by parties other than NEC Infrontia. • If it is judged by NEC Infrontia that malfunction of the product is due to the product having been dropped or subjected to impact, repairs will be made at a reasonable charge even within the warranty period. • This product is intended for use in the country/region where you purchased the product, and prohibited to export to restricted or prohibited countries. Usage Precautions Usage environment restrictions • Do not use the HHT where it may be exposed to fire, high temperatures, or direct sunlight. (Failure to observe this may result in damage, overheating, explosion, or fire.) * When the HHT is stored in a high-temperature, high-humidity environment of 50 to 60°C, leave to sit in a location at room temperature and normal humidity for at least 1 day prior to use. Failure to observe this may cause a reading failure or damage the HHT. • Do not use the HHT in places with extreme temperature variations. (Failure to observe this may lead to HHT malfunction due to condensation.) * Leave the HHT for a short while prior to use when moved from a cold to a warm environment. • Do not use the HHT in places where it may be exposed to strong impact or significant static electricity. Keep the HHT away from electromagnetic waves and metallic objects. Wireless communication may not be possible in the following locations. • In the vicinity of the following devices operating on a 2.4/5GHz waveband (Communication may not be possible due to electromagnetic interference.) • Industrial, scientific, or medical equipment such as microwave ovens • Wireless LAN devices • Logistics systems in places such as plants or warehouses • Wireless devices such as personal or amateur radio stations • In the vicinity of household appliances emitting electromagnetic waves such as computers or televisions (Communication may not be possible due to electromagnetic noise.) • In the vicinity of metallic objects, in places with high levels of metallic dust, or in places surrounded my metal walls (Communication may not be possible due to the presence of metallic objects.) SAFETY PRECAUTIONS Be sure to observe all these safety precautions. Meaning of Symbols Alerts you to those conditions which could cause serious bodily injury or death if the instructions are not followed correctly. Alerts you to those conditions which could cause minor bodily injury or substantial property damage if the instructions are not followed correctly. Handling the battery Incorrect handling of the battery could cause the batteries to generate heat or smoke, or to rupture or burn. This is DANGEROUS. Be sure to observe the following. • Never disassemble or modify the battery. • Never connect the positive and negative terminals of the battery with a wire or other metallic materials. • Do not carry or store the battery together with ballpoint pens, necklaces, coins, hairpins, or anything else metallic. • Never burn or heat the battery. • Do not use or leave the battery anywhere there is excessively high temperature (60°C or higher), such as near fire or stoves. • Do not put the battery into water of any kind or moisten it. • Never charge the battery near a fire or anywhere exposed to direct sunlight. Failure to do so could activate the protector due to high temperature and thus prevent the battery from being full charged. Or it may break the protector, resulting in the battery to overhead, blowout, or combustion. • Never charge the battery where any inflammable gases may be emitted. Doing so could cause fire. • Do not stick a needle into the battery, hammer at it, or tr…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT

41 23.5 C2 Ø 12.5 1R*3

主機背面

Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11

FCC ID: PZWS1635-01 Report No.: RF110801C10 Operational Description This device is a Hand Held Terminal, which operates in both of the 5GHz and 2.4GHz bands for WLAN and 2.4GHz for Bluetooth; the maximum data rate could be up to 72.2Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 72.2Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by DC 3.7V from batteries. The antenna is Printed PCB without antenna connectors. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA110801C10 1 Report Format Version 4.0.0 FCC SAR TEST REPORT REPORT NO.: SA110801C10 MODEL NO.: S1635-01 (Refer to item 2.1 for the more details) FCC ID: PZWS1635-01 RECEIVED: Aug. 01, 2011 TESTED: Nov. 10 ~ Nov. 11, 2011 ISSUED: Nov. 17, 2011 APPLICANT: DENSO WAVE INCORPORATED ADDRESS: 1 Yoshiike Kusagi Agui-cho,Chita-gun Aichi 470-2297, Japan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 24 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: SA110801C10 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................................................. 3 1. CERTIFICATION ............................................................................................................................. 4 2. GENERAL INFORMATION .............................................................................................................. 5 2.1 GENERAL DESCRIPTION OF EUT ................................................................................................ 5 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................. 7 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ....................................................................... 7 2.4 TEST EQUIPMENT ....................................................................................................................... 11 2.5 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION .................................... 12 3. RECIPES FOR TISSUE SIMULATING LIQUIDS .......................................................................... 16 4. SYSTEM VALIDATION .................................................................................................................. 18 4.1 TEST PROCEDURE...................................................................................................................... 18 4.2 VALIDATION RESULTS ................................................................................................................ 19 4.3 SYSTEM VALIDATION UNCERTAINTIES .................................................................................... 20 5. TEST RESULTS ............................................................................................................................ 21 5.1 TEST PROCEDURES ................................................................................................................... 21 5.2 MEASURED SAR RESULTS ........................................................................................................ 23 5.3 SIMULTANEOUS TRANSMISSION EVALUATION ....................................................................... 23 6. SAR LIMITS ................................................................................................................................... 23 7. INFORMATION ON THE TESTING LABORATORIES .................................................................. 24 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report No.: SA110801C10 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Nov. 17, 2011 Report No.: SA110801C10 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Hand Held Terminal MODEL NO.: S1635-01 (Refer to item 2.1 for the more details) FCC ID: PZWS1635-01 BRAND: NEC APPLICANT: DENSO WAVE INCORPORATED TESTED: Nov. 10 ~ Nov. 11, 2011 STANDARDS: FCC Part 2 (Section 2.1093) FCC OET Bulletin 65, Supplement C (01-01) IEEE 1528-2003 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. PREPARED BY : , DATE : Nov. 17, 2011 Pettie Chen / Specialist APPROVED BY : , DATE : Nov. 17, 2011 Roy Wu / Manager Report No.: SA110801C10 5 Report Format Version 4.0.0 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT EUT Hand Held Terminal MODEL NO. S1635-01 (Refer to NOTE for the more details) FCC ID PZWS1635-01 MODULATION TYPE CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM MODULATION TECHNOLOGY DSSS, OFDM TRANSFER RATE 802.11b:11.0/ 5.5/ 2.0/ 1.0Mbps 802.11g: 54.0/ 48.0/ 36.0/ 24.0/ 18.0/ 12.0/ 9.0/ 6.0Mbps 802.11a: 54.0/ 48.0/ 36.0/ 24.0/ 18.0/ 12.0/ 9.0/ 6.0Mbps 802.11 (20MHz): up to 150.0Mbps OPERATING FREQUENCY 2.4GHz: 2412.0 ~ 2462.0MHz 5.0GHz: 5180.0 ~ 5240.0MHz, 5745.0 ~ 5825.0MHz MAX. SAR (1g) 2.4GHz: 0.034 W/kg 5.0GHz: 0.077 W/kg ANTENNA TYPE Printed PCB antenna (Gain: 1.86 dBi for 2.4GHz, 1.2 dBi for 5GHz) ACCESSORY DEVICES Battery NOTE: 1. The following models are provided to this EUT. BRAND MODEL DESCRIPTION NEC S1635-01 All models are electrically identical. The different model no. is for marketing purpose. S1635-01A S1635-01B 2. The frequency bands used in this EUT are listed as follows: FREQUENCY BAND (MHz) 2412~2462 5180~5240 5745~5825 802.11b √ 802.11g √ 802.11a √ √ 802.11n (20MHz) √ √ √ 3. The EUT provides one completed transmitter and one receiver. MODULATION MODE T…
