Q3ZF10DANotebook With 802.11 b/g WLAN

Averatec Inc.,
Notebook With 802.11 b/g WLAN - FCC ID Q3ZF10DA - Averatec Inc.,
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Apr 26, 2005
Application Purpose
Original Equipment
Date of Application
Apr 26, 2005
Equipment Note
Notebook With 802.11 b/g WLAN
Frequency Range
2412.00000000 - 2462.00000000
Company
Averatec Inc.,
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Parts List/Tune Up Info

↗

RF Exposure Info

↗
↗
↗
↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

v1.2 U U s s e e r r ’ ’ s s M M a a n n u u a a l l Table of Contents CHAPTER 1 GETTING STARTED Getting Started Inventory Safety and Maintenance Checklists Features Where to Look For Information Quick Start Loading Windows Adjusting the Volume Adjusting the Brightness Turning off Your Computer Making a Startup Disk Tips for New Owners CHAPTER 2 GETTING STARTED Hardware and Software Front View Left View Right View Bottom View LED Status Indicators Power Indicators Function Keys Numeric Keypad Touchpad The Optical Drive Connecting the Printer The PC Card Slot The Graphics System Communication Components Built-in Wireless Local Area Network CHAPTER 3 MAKING CONNECTIONS Making Connections Left Side Connectors Right Side Connectors Front Side Connectors CHAPTER 4 POWER MANAGEMENT Power Management Power Saving Modes Power Saving Tips When to Replace the Battery Heat Considerations CHAPTER 5 USING THE BIOS SETUP UTILITY Using the BIOS Setup Utility Navigating and Entering Information in BIOS The Main Menu Advanced Menu Boot menu Security menu Exit menu Change User Password Change Supervisor Password CMOS Optimal Defaults Exiting and Saving APPENDIX A FREQUENTLY ASKED QUESTIONS Frequently Asked Questions APPENDIX B STATEMENTS Statements European Notice UL CAUTION Canadian Department of Communications Battery Disposal CAUTION FOR ADAPTER BATTERY CAUTION CLASS 1 LASER PRODUCT C C h h a a p p t t e e r r 1 1 I I n n t t r r o o d d u u c c t t i i o o n n Chapter 1 — Introduction Getting Started Congratulations on your purchase of a Notebook computer! Your new notebook features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with sophisticated architecture to provide you with a personal computer that is compact, powerful, and easy to use. Designed for a wide range of general, business, and personal productivity applications, this notebook is an ideal choice for use in the office, at home, and on the road. For maximum expandability without compromising portability, the notebook accommodates a number of modules, including a combo DVD+CD-RW optical drive, two USB ports, one PCMCIA and one 4-in-1 card slot. The high capacity hard disk drive provides you with plenty of storage space for multimedia files and applications. This Manual contains all the information you need to set up and use your new notebook. It describes all the features of the notebook in an easy-to-read yet thorough manner. Introduction — Chapter 1 Inventory This computer system is designed for years of productive and pleasurable computing. Use this section to keep details of your purchase. This information will be required should you need to make repairs to your notebook during the warranty period. Update this section when you add new options. DATE OF PURCHASE: PLACE OF PURCHASE: STORE NAME: STORE ADDRESS: TELEPHONE: E-MAIL ADDRESS/WWW: CONTACT PERSON: MODEL NUMBER: SERIAL NUMBER: The serial number is on the label (with a bar code) on the bottom side of the computer. Chapter 1 — Introduction Safety and Maintenance You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer: xFollow all warnings and instructions noted in this documentation and in the Windows Help program. xThe first time you use your computer, we recommend that you carefully read the Making Connections section of this manual and initialize the battery to ensure optimum battery performance. xUnplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use aerosols, solvents, or strong detergents. xDo not use the computer near open water or other liquids. Never spill liquid onto the computer. xDo not place the computer in an unstable location where it might slip or be knocked over. Serious damage could result from a fall. xSlots and openings in the system cabinet are for ventilation purposes. Do not block or cover these openings or the system could overheat. Do not use or store the computer near a source of heat or dust. xOn the base or rear panel of this notebook, there is a label with information on the power requirements of this system. These requirements must be followed. If you are unsure of your local power supply, consult your dealer or local Power Company. xDo not step on or place anything on the power cord. xIf you use the computer with an extension cord, ensure that the total ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet. xNever push foreign objects into the computer through any of the slots or openings. Dangerous voltages are present, which could cause electric shock or fire, or damage sensitive components. Introduction — Chapter 1 xFor best results, use a power strip with a built-in surge protector. Do not use inferior extension cords as this may result in damage to your computer. xSet the computer on a flat, stable surface. To prevent damage to the computer’s hard disk drive, avoid using the computer where it will be exposed to strong vibration. Checklists After opening the package, carefully inspect the contents. If any of the items are missing or appear damaged, contact your dealer. The shipping carton should contain the following: STANDARD xNotebook computer xInternal battery xAC adapter with power cord Caution:When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electro-magnetic radiation in excess of local regulations. For non- proprietary accessories such as PC cards or printers, ensure that the accessory functions prop…

Text truncated - open the document above for the full version.

Cover Letter(s)

April 12, 2005 Federal Communications Commission Authorization and Evaluation Division FCC ID: Q3ZF10DA Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (SAEED SHAHBA / Manager) (Averatec Inc.)

Cover Letter(s)

POWER OF ATTORNEY Date: April 12, 2005 We, the undersigned, hereby authorize Compliance Certification Services Inc. to act on our behalf in all matters relating to all processes related to FCC & IC applications and communications issue. Any and all acts carried out by Compliance Certification Services Inc. on our behalf shall have the same effects as acts of our own. If you have any questions regarding this authorization, please don’t hesitate to contact us. Thank you. Sincerely, (SAEED SHAHBA / Manager) (Averatec Inc.)

Cover Letter(s)

Mike Kuo From: [email protected] on behalf of [email protected] Sent: Monday, April 25, 2005 7:44 PM To: Mike Kuo Cc: [email protected]; Robert F. Martin; Bob Martin Subject: ?^?H?G RE: Re: ??? Averatec Inc.,, FCC ID: Q3ZF10DA, Assessment NO.: AN05T4713, Notice#2 Attachments: 1000 SAR Test Plot 0422 Revised.pdf; 1000 SAR Test Rpt 0424Revised.pdf 4/26/2005 Hi Lucy: 1)In the revised SAR test report, there is no SAR plots and system validation plots, please provide these two files. 2) Page 20 of revised SAR report, please provide a clear picture to show the separation distance between transmitting antennas to the bottom of base. The picture included in the page 20 is too small to be clearly identified. Best Regards Mike Kuo Compliance Certification Services 561F Monterey Road Morgan Hill CA 95037 Tel: (408)463-0885 x: 105 Fax: (408)463-0888 http://www.ccsemc.com From: [email protected] [mailto:[email protected]] Sent: Friday, April 22, 2005 9:34 AM To: Bob Martin Cc: [email protected]; Mike Kuo; Robert F. Martin Subject: Re: ??? Averatec Inc.,, FCC ID: Q3ZF10DA, Assessment NO.: AN05T4713, Notice#2 "Mike Kuo" <[email protected]> 2005/04/26 06:01 AM <[email protected]>, "Bob Martin" <[email protected]> <[email protected]>, "Robert F. Martin" <[email protected]> Lucy; I am afraid that I still have to ask you to amend your reports with regard to antennas. The antenna spec refers to: Antenna 1 Type PIFA, model F10D-L, part number TWF10WIPI01A Antenna 2 Type PIFA, model F10D-R, part number TWF10WIPI02A They have different gain patterns. You list a single gain (0.06dBi). If both antennas used in the test sample are the same, list the part number in the EUT table. If you use two different antennas, put both part numbers in the table. Again - please amend both reports to say specifically which part numbers were used. Thank you. Bob -----Original Message----- From: [email protected] Sent: Apr 21, 2005 11:53 PM To: Compliance Certification Services Cc: "[email protected]" , [email protected] Subject: ??? Averatec Inc.,, FCC ID: Q3ZF10DA, Assessment NO.: AN05T4713, Notice#2 Hi Bob, We have made some correction and please refer to below for our reply. Best Regards, Lucy RobM <[email protected]> 2005/04/22 11:20 PM RobM [email protected], Compliance Certification Services <[email protected]> "[email protected]" <[email protected]>, [email protected] Compliance Certification Services <[email protected]> 2005/04/21 06:13 AM ???? "[email protected]" <[email protected]> ????? "[email protected]" <[email protected]> ??? Averatec Inc.,, FCC ID: Q3ZF10DA, Assessment NO.: AN05T4713, Notice#2 4/26/2005 Lucy; Thank you for your response. Many of the issues result from poor description of the EUT. "Laptop" implies something that is larger than 20cm tall. Your response clarified that the device is very small. While the photograph with it near the AC/DC converter may indicate a small size, it is not clear. - Amend the report needs to be revised to better describe the EUT, especially because it is not typical of a laptop. The description should indicate the size of the device. A ruler next to the device in the external photos would also be useful. Ans. Additional an external photo with ruler was took and please refer to revised external photo for details. - amend the SAR report to include the enhanced description and an explanation of why the orientations were selected. Ans. It's because it was the worst case since the antenna was on the top of panel. However, SAR test is to measure it normal operation, so we have re-did test and please refer to the revised SAR test report for details. - amend both reports to explain the selection of the prototype. A justification of why it was selected and how it is representative of the final product is required. Ans. It's because this prototype sample approximates to production product and was provided by manufacturer. - the antenna specification describes "antenna 1" and "antenna 2". I see no place where it is specified for the EUT. I can't just ignore the third antenna. Amend both reports to say specifically which part numbers were used. Ans. Antenna spec. indicated EUT model: F10D which is Averatec's internal control model for model 1000. As for antenna 3, it has been removed from the antenna spec. because in this application BT module is not applied. Please refer to attached file for the revised antenna spec. - the comment about a handheld device is with regard to p5 Radiated Emissions; Amend the report to agree with the EUT and the test method actually used Ans. Test report is revised and please refer to attached for the revised test report. Bob Martin The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e- mail address listed below the name of the sender. 4/26/2005

External Photos

Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 1 Total Page: 1 Rev.00 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 2 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 3 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 4 Rev.00

Internal Photos

Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 5 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 6 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 7 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 8 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 9 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 10 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 11 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 12 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 13 Rev.00 Compliance Certification Services Inc. Report No: 50323005 Date of Issue: April 13, 2005 Page 14 Rev.00

Parts List/Tune Up Info

Well Green Technology Co., Ltd Data 3/22/05 RD Manager Supervisor RD engineer Sales engineer David Johnson Tim Jerry wgt No. 20, Alley51 ,Lane 118,Sh uangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 TWINHEAD Antenna Test Report 1. Information Overview 1.1 Platform Information Description Comments Project Code of System Project Stage ▓ Prototype □ EPR □ PPR □ MP Platform Type ▓ Notebook PC □ Tablet PC 1.2 Antenna Information Manufacturer Well Green Technology Co., Ltd. Design Stage □ Handmade ▓ Machine □ Tooling Antenna 1 Type PIFA Model Name F10D-L Part Number TWF10WIPI01A Antenna Location Left-up of the panel Antenna Purpose Wireless LAN 802.11abg Main Antenna Connector Manufacturer IPEX Connector Part No. 2078-101R-13 20278-111R-13 Frequency GHz 2.4 – 2.5, 5.15 – 5.85 Impedance 50Ω Cable Manufacturer & PN Wonderful A3132TS001 Cable Diameter ψmm 1.13 Cable Length Antenna 2 Type PIFA Model Name F10D-R Part Number TWF10WIPI02A Antenna Location Right-up of the panel Antenna Purpose Wireless LAN 802.11abg Aux Antenna Connector Manufacturer IPEX Connector Part No. 2078-101R-13 20278-111R-13 Frequency GHz 2.4 – 2.5, 5.15 – 5.85 Impedance 50Ω Cable Manufacturer & PN Wonderful A3132TS001 Cable Diameter ψmm 1.13 Cable Length Antenna 3 Type PIFA Model Name F10D-Side Part Number TWF10BLPI01A Antenna Location Left-Side of the panel Antenna Purpose Bluetooth Antenna Connector Manufacturer IPEX Connector Part No. 2078-101R-13 20278-111R-13 Frequency GHz 2.4 – 2.5 Impedance 50Ω Cable Manufacturer & PN Wonderful A3132TS001 Cable Diameter ψmm 1.13 Cable Length 7. Antenna Radiation Pattern Testing Set Up The radiation pattern and antenna gain shall be tested in an anechoic chamber. The an echoic chamber must be lined with absorpti ve materials. The measurements shall be made at the connecto r end of the cable for antenna assembly. The antennas must be installed in a fully po pulated platform to include a complete disp lay and display plastics. -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8. Radiation Pattern of XY Plane Testing Result 8.1 2.4 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak -0.17 Peak -0.92 V Average -5.66 V Average -7.18 Peak 0.06 Peak 0.05 H Average -6.34 H Average -6.71 Peak 2.01 Peak 2.57 H + V Average -2.98 H + V Average -3.93 V Gain >= -4 Area 18.57% V Gain >= -4 Area 8.99% V Gain >= -5 Area 20.57% V Gain >= -5 Area 15.99% 0 90 270 180 0 90 270 180 2.4 GHz Antenna 3 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak -3.97 V Average -14.59 Peak -7.66 H Average -12.28 Peak -6.74 H + V Average -10.27 V Gain >= -4 Area 0% V Gain >= -5 Area 0% 0 90 270 180 -40-30-20-10 0 H+V-PolarizationV-PolarizationH-Polarization 8.2 2.45 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizationV-PolarizationH-Polarization Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak 0.00 Peak -1.25 V Average -5.12 V Average -6.94 Peak -0.10 Peak -0.40 H Average -5.89 H Average -6.33 Peak 1.82 Peak 2.15 H + V Average -2.48 H + V Average -3.62 V Gain >= -4 Area 27.56% V Gain >= -4 Area 13.99% V Gain >= -5 Area 31.72% V Gain >= -5 Area 20.15% 0 90 270 180 0 90 270 180 2.45 GHz Antenna 3 -40-30-20-10 0 H+V-PolarizationV-PolarizationH-Polarization Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak -7.85 V Average -15.78 Peak -7.21 H Average -11.79 Peak -6.92 H + V Average -10.33 V Gain >= -4 Area 0% V Gain >= -5 Area 0% 0 90 270 180 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.3 2.5 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak -0.47 Peak -1.06 V Average -5.62 V Average -6.98 Peak 0.11 Peak -0.61 H Average -6.41 H Average -6.48 Peak 1.38 Peak 2.02 H + V Average -2.99 H + V Average -3.71 Gain >= -4 Area 16.40% Gain >= -4 Area 15.82% Gain >= -5 Area 24.56% Gain >= -5 Area 21.90% 0 270 90 180 0 270 90 180 2.5 GHz Antenna 3 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak -10.23 V Average -16.60 Peak -7.20 H Average -12.10 Peak -7.05 H + V Average -10.79 V Gain >= -4 Area 0% V Gain >= -5 Area 0% 0 90 270 180 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.4 5.15 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak 0.76 Peak -0.63 V Average -4.66 V Average -6.05 Peak -1.59 Peak -2.28 H Average -8.25 H Average -7.60 Peak 1.06 Peak 0.93 H + V Average -3.09 H + V Average -3.75 Gain >= -4 Area 30.89% Gain >= -4 Area 17.49% Gain >= -5 Area 40.13% Gain >= -5 Area 19.40% 0 270 180 90 0 270 180 90 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.5 5.25 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak 0.73 Peak 0.39 V Average -5.02 V Average -5.09 Peak -1.58 Peak -2.43 H Average -8.69 H Average -9.29 Peak 0.91 Peak 1.13 H + V Average -3.47 H + V Average -3.69 Gain >= -4 Area 19.57% Gain >= -4 Area 26.14% Gain >= -5 Area 24.98% Gain >= -5 Area 35.72% 0 270 180 90 0 270 180 90 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.6 5.35 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak 1.21 Peak -0.36 V Average -5.78 V Average -5.90 Peak -0.14 Peak -0.34 H Average -6.36 H Average -6.54 Peak 1.58 Peak 0.49 H + V Average -3.05 H + V Average -3.19 Gain >= -4 Area 20.82% Gain >= -4 Area 19.73% Gain >= -5 Are…

Text truncated - open the document above for the full version.

RF Exposure Info

Compliance Certification Services Inc. Report No: 50323005-SF FCC ID: Q3ZF10DA Date of Issue: April 22, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 23 Rev. 00 ANSI/IEEE Std. C95.1-1992 in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC TEST REPORT For Notebook built-in (Intel 802.11b/g) Trade Name: Averatec Model: 1000 Issued to Averatec Inc. 80 Icon, Foothill Ranch, CA92610 U.S.A. Issued by Compliance Certification Services Inc. No. 11, Wu-Kung 6 Rd, Wu-Ku Hsiang, Wu-Ku Industrial District, Taipei Hsien, (248) Taiwan. TEL: 886-2-2299-9720 FAX: 886-2-2299-9721 Compliance Certification Services Inc. Report No: 50323005-SF Date of Issue: April 22, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. EUT DESCRIPTION..................................................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC .................5 3. DOSIMETRIC ASSESSMENT SYSTEM ................................................................................5 3.1 MEASUREMENT SYSTEM DIAGRAM .........................................................................6 3.2 SYSTEM COMPONENTS.................................................................................................7 4. EVALUATION PROCEDURES ...............................................................................................9 5. MEASUREMENT UNCERTAINTY ......................................................................................13 6. EXPOSURE LIMIT..................................................................................................................14 7. TYPICAL COMPOSITION OF INGREDIENTS FOR LIQUID TISSUE PHANTOMS .14 8. MEASUREMENT RESULTS..................................................................................................15 8.1 SYSTEM PERFORMANCE CHECK..............................................................................15 8.2 TEST LIQUID CONFIRMATION...................................................................................16 8.3 EUT TUNE-UP PROCEDURES......................................................................................17 8.4 SAR MEASUREMENTS RESULTS...............................................................................18 9. EUT PHOTOS ...........................................................................................................................20 10. EQUIPMENT LIST & CALIBRATION STATUS................................................................21 11. FACILITIES..............................................................................................................................22 12. REFERENCES ..........................................................................................................................22 13. ATTACHMENTS......................................................................................................................23 Compliance Certification Services Inc. Report No: 50323005-SF Date of Issue: April 22, 2005 Page 3 Rev. 00 CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Applicant: Averatec Inc. 80 Icon, Foothill Ranch, CA92610 U.S.A. Equipment Under Test: Notebook built-in (Intel 802.11b/g) Trade Name: Averatec Model Number: 1000 Date of Test: April 21, 2005 Device Category: PORTABLE DEVICES Exposure Category: GENERAL POPULATION/UNCONTROLLED EXPOSURE APPLICABLE STANDARDS STANDARD TEST RESULT FCC OET 65 Supplement C No non-compliance noted Deviation from Applicable Standard None The device was tested by Compliance Certification Services Inc. in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C (Edition 01-01). The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Harris W. Lai Chris Hsieh Executive Vice President Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No: 50323005-SF Date of Issue: April 22, 2005 Page 4 Rev. 00 1. EUT DESCRIPTION Product Notebook built-in (Intel 802.11b/g) Trade Name / Model Number Averatec / 1000 Model Discrepancy N/A Frequency Range 802.11b: 2412 ~ 2462 MHz 802.11g: 2412 ~ 2462 MHz Max. O/P Power: (Conducted/Average) 802.11b: 17.21 dBm 802.11g: 17.60 dBm Max. SAR (10g): 802.11b: 0.000169 W/kg 802.11g: 0.000675 W/kg Modulation Technique 802.11b: Direct Sequence Spread Spectrum(DSSS) 802.11g: Orthogonal Frequency Division Multiplexing (OFDM) Antenna Specification Antenna 2 Type PIFA, model F10D-R, part no TWF10WIPI02A, gain 0.05dBi Battery option: Only one type/model with EUT Remark: The sample selected for test was prototype that approximated to production product and was provided by manufacturer. Antenna 1 Type PIFA, model F10D-L, part no TWF10WIPI01A, gain 0.06dBi Compliance Certification Services Inc. Report No: 50323005-SF Date of Issue: April 22, 2005 Page 5 Rev. 00 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC The US Federal Communications Commission has released the report and order “Guidelines for Evaluating the Environmental Effects of RF Radiation", ET Docket No. 93-62 in August 1996 [1]. The order requires routine SAR evaluation prior to equipment authorization of portable transmitter devices, including portable telephones. For consumer products, the applicable limit is 1.6 mW/g for an uncontrolled environment and 8.0 mW/g for an occupational/controlled environment as recommended by the ANSI/IEEE standard C95.1-1992 [6]. According to …

Text truncated - open the document above for the full version.

RF Exposure Info

Date/Time: 04/21/2005 5:41:14PM Test Laboratory: Compliance Certification Services Inc. D2450V2-SN 728-Body DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:728 Communication System: CW2450; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.94 mho/m; ε r = 50.8; ρ = 1000 kg/m 3 Air Temperature:25.5 deg C;Liquid Temperature:24.4 deg C Phantom section: Flat Section DASY4 Configuration: z Probe: EX3DV4 - SN3554; ConvF(6.14, 6.14, 6.14); Calibrated: 11/19/2004 z Sensor-Surface: 4mm (Mechanical Surface Detection)Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn558; Calibrated: 8/24/2004 z Phantom: SAM 34; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Pin=250mW,d=10mm/Area Scan (6x6x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 9.49 mW/g Pin=250mW,d=10mm/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 22.0 mW/g Pin=250mW,d=10mm/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 88.9 V/m; Power Drift = 0.123 dB Peak SAR (extrapolated) = 30.6 W/kg SAR(1 g) = 13.5 mW/g; SAR(10 g) = 5.86 mW/g Maximum value of SAR (measured) = 15.1 mW/g Page1 Page2 Date/Time: 04/21/2005 11:15:22PM Test Laboratory: Compliance Certification Services Inc. Test Configuration-1 Page1 Date/Time: 04/21/2005 8:28:04PM Test Laboratory: Compliance Certification Services Inc. 802.11b Touch mode-Main Ant DUT: FD10; Type: Notebook built-in (Intel 802.11g); Serial: N/A Communication System: IEEE 802.11b WLAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 1.94 mho/m; ε r = 50.8; ρ = 1000 kg/m 3 Air Temperature:25.5 deg C;Liquid Temperature:24.4 deg C Phantom section: Flat Section DASY4 Configuration: z Probe: EX3DV4 - SN3554; ConvF(6.14, 6.14, 6.14); Calibrated: 11/19/2004 z Sensor-Surface: 4mm (Mechanical Surface Detection)Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn558; Calibrated: 8/24/2004 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Middle CH Rate=1M bit/Area Scan (12x17x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.01 mW/g Middle CH Rate=1M bit/Z Scan (1x1x101): Measurement grid: dx=20mm, dy=20mm, dz=1mm Maximum value of SAR (measured) = 0.017 mW/g Middle CH Rate=1M bit 2/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 0.993 V/m; Power Drift = -0.2 dB Peak SAR (extrapolated) = 0.01 W/kg SAR(1 g) = 0.000169 mW/g; SAR(10 g) = 1.87e-005 mW/g Maximum value of SAR (measured) = 0.014 mW/g Page1 Page2 Date/Time: 04/21/2005 9:11:22PM Test Laboratory: Compliance Certification Services Inc. 802.11g Touch mode-Main Ant DUT: FD10; Type: Notebook built-in (Intel 802.11g); Serial: N/A Communication System: IEEE 802.11g WLAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 1.94 mho/m; ε r = 50.8; ρ = 1000 kg/m 3 Air Temperature:25.5 deg C;Liquid Temperature:24.4 deg C Phantom section: Flat Section DASY4 Configuration: z Probe: EX3DV4 - SN3554; ConvF(6.14, 6.14, 6.14); Calibrated: 11/19/2004 z Sensor-Surface: 4mm (Mechanical Surface Detection)Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn558; Calibrated: 8/24/2004 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Middle CH Rate=6M bit/Area Scan (12x17x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.01 mW/g Middle CH Rate=6M bit/Z Scan (1x1x101): Measurement grid: dx=20mm, dy=20mm, dz=1mm Maximum value of SAR (measured) = 0.010 mW/g Middle CH Rate=6M bit/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Refe…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jessie Labayen(Manager)
[email protected]1-949-460-5979Fax: 1-949-56-1081

Test Firm

Compliance Certification Services Inc.Kurt Chen
[email protected]886-2-86422071Fax: 886-2-86422256

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz57.10 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with specific operating instructions for satisfying RF exposure compliance requirements. Highest measured SAR value: 0.000675 W/kg ( body ).
