v1.2 U U s s e e r r ’ ’ s s M M a a n n u u a a l l Table of Contents CHAPTER 1 GETTING STARTED Getting Started Inventory Safety and Maintenance Checklists Features Where to Look For Information Quick Start Loading Windows Adjusting the Volume Adjusting the Brightness Turning off Your Computer Making a Startup Disk Tips for New Owners CHAPTER 2 GETTING STARTED Hardware and Software Front View Left View Right View Bottom View LED Status Indicators Power Indicators Function Keys Numeric Keypad Touchpad The Optical Drive Connecting the Printer The PC Card Slot The Graphics System Communication Components Built-in Wireless Local Area Network CHAPTER 3 MAKING CONNECTIONS Making Connections Left Side Connectors Right Side Connectors Front Side Connectors CHAPTER 4 POWER MANAGEMENT Power Management Power Saving Modes Power Saving Tips When to Replace the Battery Heat Considerations CHAPTER 5 USING THE BIOS SETUP UTILITY Using the BIOS Setup Utility Navigating and Entering Information in BIOS The Main Menu Advanced Menu Boot menu Security menu Exit menu Change User Password Change Supervisor Password CMOS Optimal Defaults Exiting and Saving APPENDIX A FREQUENTLY ASKED QUESTIONS Frequently Asked Questions APPENDIX B STATEMENTS Statements European Notice UL CAUTION Canadian Department of Communications Battery Disposal CAUTION FOR ADAPTER BATTERY CAUTION CLASS 1 LASER PRODUCT C C h h a a p p t t e e r r 1 1 I I n n t t r r o o d d u u c c t t i i o o n n Chapter 1 — Introduction Getting Started Congratulations on your purchase of a Notebook computer! Your new notebook features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with sophisticated architecture to provide you with a personal computer that is compact, powerful, and easy to use. Designed for a wide range of general, business, and personal productivity applications, this notebook is an ideal choice for use in the office, at home, and on the road. For maximum expandability without compromising portability, the notebook accommodates a number of modules, including a combo DVD+CD-RW optical drive, two USB ports, one PCMCIA and one 4-in-1 card slot. The high capacity hard disk drive provides you with plenty of storage space for multimedia files and applications. This Manual contains all the information you need to set up and use your new notebook. It describes all the features of the notebook in an easy-to-read yet thorough manner. Introduction — Chapter 1 Inventory This computer system is designed for years of productive and pleasurable computing. Use this section to keep details of your purchase. This information will be required should you need to make repairs to your notebook during the warranty period. Update this section when you add new options. DATE OF PURCHASE: PLACE OF PURCHASE: STORE NAME: STORE ADDRESS: TELEPHONE: E-MAIL ADDRESS/WWW: CONTACT PERSON: MODEL NUMBER: SERIAL NUMBER: The serial number is on the label (with a bar code) on the bottom side of the computer. Chapter 1 — Introduction Safety and Maintenance You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer: xFollow all warnings and instructions noted in this documentation and in the Windows Help program. xThe first time you use your computer, we recommend that you carefully read the Making Connections section of this manual and initialize the battery to ensure optimum battery performance. xUnplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use aerosols, solvents, or strong detergents. xDo not use the computer near open water or other liquids. Never spill liquid onto the computer. xDo not place the computer in an unstable location where it might slip or be knocked over. Serious damage could result from a fall. xSlots and openings in the system cabinet are for ventilation purposes. Do not block or cover these openings or the system could overheat. Do not use or store the computer near a source of heat or dust. xOn the base or rear panel of this notebook, there is a label with information on the power requirements of this system. These requirements must be followed. If you are unsure of your local power supply, consult your dealer or local Power Company. xDo not step on or place anything on the power cord. xIf you use the computer with an extension cord, ensure that the total ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet. xNever push foreign objects into the computer through any of the slots or openings. Dangerous voltages are present, which could cause electric shock or fire, or damage sensitive components. Introduction — Chapter 1 xFor best results, use a power strip with a built-in surge protector. Do not use inferior extension cords as this may result in damage to your computer. xSet the computer on a flat, stable surface. To prevent damage to the computer’s hard disk drive, avoid using the computer where it will be exposed to strong vibration. Checklists After opening the package, carefully inspect the contents. If any of the items are missing or appear damaged, contact your dealer. The shipping carton should contain the following: STANDARD xNotebook computer xInternal battery xAC adapter with power cord Caution:When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electro-magnetic radiation in excess of local regulations. For non- proprietary accessories such as PC cards or printers, ensure that the accessory functions prop…
Text truncated - open the document above for the full version.
POWER OF ATTORNEY Date: April 12, 2005 We, the undersigned, hereby authorize Compliance Certification Services Inc. to act on our behalf in all matters relating to all processes related to FCC & IC applications and communications issue. Any and all acts carried out by Compliance Certification Services Inc. on our behalf shall have the same effects as acts of our own. If you have any questions regarding this authorization, please don’t hesitate to contact us. Thank you. Sincerely, (SAEED SHAHBA / Manager) (Averatec Inc.)
April 12, 2005 Federal Communications Commission Authorization and Evaluation Division FCC ID: Q3ZF10DAM Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (SAEED SHAHBA / Manager) (Averatec Inc.)
Mike Kuo From: [email protected] on behalf of [email protected] Sent: Monday, May 02, 2005 10:25 PM To: Mike Kuo Subject: FW: Averatec Inc.,, FCC ID: Q3ZF10DAM, Assessment NO.: AN05T4749, Notice#1 Attachments: 1000 Schem for Module.pdf; 1000 BlkDia for Module.pdf 5/3/2005 Dear Mike: Please refer to below for our reply. Best Regards, Amanda Best Regards Mike Kuo Compliance Certification Services 561F Monterey Road Morgan Hill CA 95037 Tel: (408)463-0885 x: 105 Fax: (408)463-0888 http://www.ccsemc.com -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Thursday, April 28, 2005 7:30 PM To: Mike Kuo Subject: Averatec Inc.,, FCC ID: Q3ZF10DAM, Assessment NO.: AN05T4749, Notice#1 SAR portion: 1) Dipole antenna used for system validation is out of calibration. Please address this issue and submit the valid calibration report. Ans: It's because the dipole antenna's calibration cycle is two year. "Mike Kuo" <[email protected]> 2005/04/29 10:34 AM <[email protected]> Administrative portion: 2) Please provide radio portion of Block Diagram and Schematic Diagram. Ans: Please refer as belowing. Best Regards Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. 5/3/2005
Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 1 Total Page: 13 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 2 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 3 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 4 Rev.00
Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 5 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 6 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 7 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 8 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 9 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 10 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 11 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 12 Rev.00 Compliance Certification Services Inc. Report No: 50323004 Date of Issue: April 28, 2005 Page 13 Rev.00
Well Green Technology Co., Ltd Data 3/22/05 RD Manager Supervisor RD engineer Sales engineer David Johnson Tim Jerry wgt No. 20, Alley51 ,Lane 118,Sh uangLian Sec.2,Mintzu Rd., PingJen City, TaoYuan Hsien, Taiwan, R.O.C TEL: (03)420-6428 FAX: (03) 420-6418 TWINHEAD F10D A Antenna Test Report 4. Voltage Standing Wave Ratio (VSWR) 4.1 VSWR 2.4 GHz ~ 2.5 GHz Antenna 1 Antenna 2 VSWR VSWR Center freq. @MHz Bandwidth @MHz 2.4GHz 2.45GHz 2.5GHz Center freq. @MHz Bandwidth @MHz 2.4GHz 2.45GHz 2.5GHz 2450 1.50 1.39 1.32 2450 1.68 1.21 1.51 4.2 VSWR 5.15 GHz ~ 5.35 GHz Antenna 1 Antenna 2 VSWR VSWR Center freq. @MHz Bandwidth @MHz 5.15GHz 5.25GHz 5.35GHz Center freq. @MHz Bandwidth @MHz 5.15GHz 5.25GHz 5.35GHz 5250 1.34 1.90 1.15 5250 1.82 1.17 1.22 4.3 VSWR 5.47 GHz ~ 5.725 GHz Antenna 1 Antenna 2 VSWR VSWR Center freq. @MHz Bandwidth @MHz 5.47GHz 5.5975GHz 5.725GHz Center freq. @MHz Bandwidth @MHz 5.47GHz 5.5975GHz 5.725GHz 5597 1.31 1.65 1.90 5597 1.27 1.64 1.19 4.4 VSWR 5.725 GHz ~ 5.85 GHz Antenna 1 Antenna 2 VSWR VSWR Center freq. @MHz Bandwidth @MHz 5.725GHz 5.785GHz 5.85GHz Center freq. @MHz Bandwidth @MHz 5.725GHz 5.785GHz 5.85GHz 5785 1.88 1.78 1.36 5785 1.19 1.36 1.44 5. Return Loss 5.1 Return Loss 2.4GHz ~ 2.5GHz Antenna 1 Antenna 2 Return Loss Return Loss Center freq. @MHz Bandwidth @MHz 2.4GHz 2.45GHz 2.5GHz Center freq. @MHz Bandwidth @MHz 2.4GHz 2.45GHz 2.5GHz 2450 -13.90 -15.64 -17.25 2450 -11.96 -20.39 -13.84 5.2 Return Loss 5.15GHz ~ 5.35GHz Antenna 1 Antenna 2 Return Loss Return Loss Center freq. @MHz Bandwidth @MHz 5.15GHz 5.25GHz 5.35GHz Center freq. @MHz Bandwidth @MHz 5.15GHz 5.25GHz 5.35GHz 5250 -16.68 -10.10 -23.28 5250 -10.68 -21.76 -19.85 5.3 Return Loss 5.47GHz ~ 5.725GHz Antenna 1 Antenna 2 Return Loss Return Loss Center freq. @MHz Bandwidth @MHz 5.47GHz 5.5975GHz 5.725GHz Center freq. @MHz Bandwidth @MHz 5.47GHz 5.5975GHz 5.725GHz 5597 -17.18 -12.16 -10.22 5597 -18.60 -12.20 -21.00 5.4 Return Loss 5.725GHz ~ 5.85GHz Antenna 1 Antenna 2 Return Loss Return Loss Center freq. @MHz Bandwidth @MHz 5.725GHz 5.785GHz 5.85GHz Center freq. @MHz Bandwidth @MHz 5.725GHz 5.785GHz 5.85GHz 5785 -10.17 -11.08 -16.29 5785 -20.99 -16.11 -14.70 6. Smith Chart Antenna 1 Antenna 2 7. Antenna Radiation Pattern Testing Set Up The radiation pattern and antenna gain shall be tested in an anechoic chamber. The an echoic chamber must be lined with absorpti ve materials. The measurements shall be made at the connecto r end of the cable for antenna assembly. The antennas must be installed in a fully po pulated platform to include a complete disp lay and display plastics. -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8. Radiation Pattern of XY Plane Testing Result 8.1 2.4 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak -0.17 Peak -0.92 V Average -5.66 V Average -7.18 Peak 0.06 Peak 0.05 H Average -6.34 H Average -6.71 Peak 2.01 Peak 2.57 H + V Average -2.98 H + V Average -3.93 V Gain >= -4 Area 18.57% V Gain >= -4 Area 8.99% V Gain >= -5 Area 20.57% V Gain >= -5 Area 15.99% 0 90 270 180 0 90 270 180 -40-30-20-10 0 H+V-PolarizationV-PolarizationH-Polarization 8.2 2.45 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizationV-PolarizationH-Polarization Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak 0.00 Peak -1.25 V Average -5.12 V Average -6.94 Peak -0.10 Peak -0.40 H Average -5.89 H Average -6.33 Peak 1.82 Peak 2.15 H + V Average -2.48 H + V Average -3.62 V Gain >= -4 Area 27.56% V Gain >= -4 Area 13.99% V Gain >= -5 Area 31.72% V Gain >= -5 Area 20.15% 0 90 270 180 0 90 270 180 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.3 2.5 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak -0.47 Peak -1.06 V Average -5.62 V Average -6.98 Peak 0.11 Peak -0.61 H Average -6.41 H Average -6.48 Peak 1.38 Peak 2.02 H + V Average -2.99 H + V Average -3.71 Gain >= -4 Area 16.40% Gain >= -4 Area 15.82% Gain >= -5 Area 24.56% Gain >= -5 Area 21.90% 0 270 90 180 0 270 90 180 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.4 5.15 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak 0.76 Peak -0.63 V Average -4.66 V Average -6.05 Peak -1.59 Peak -2.28 H Average -8.25 H Average -7.60 Peak 1.06 Peak 0.93 H + V Average -3.09 H + V Average -3.75 Gain >= -4 Area 30.89% Gain >= -4 Area 17.49% Gain >= -5 Area 40.13% Gain >= -5 Area 19.40% 0 270 180 90 0 270 180 90 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.5 5.25 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak 0.73 Peak 0.39 V Average -5.02 V Average -5.09 Peak -1.58 Peak -2.43 H Average -8.69 H Average -9.29 Peak 0.91 Peak 1.13 H + V Average -3.47 H + V Average -3.69 Gain >= -4 Area 19.57% Gain >= -4 Area 26.14% Gain >= -5 Area 24.98% Gain >= -5 Area 35.72% 0 270 180 90 0 270 180 90 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.6 5.35 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polarization Gain of XY Plane (Azimuth) Horn Antenna Polarization Gain of XY Plane (Azimuth) Peak 1.21 Peak -0.36 V Average -5.78 V Average -5.90 Peak -0.14 Peak -0.34 H Average -6.36 H Average -6.54 Peak 1.58 Peak 0.49 H + V Average -3.05 H + V Average -3.19 Gain >= -4 Area 20.82% Gain >= -4 Area 19.73% Gain >= -5 Area 28.06% Gain >= -5 Area 24.90% 0 270 180 90 0 270 180 90 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized 8.7 5.47 GHz Antenna 1 Antenna 2 -40-30-20-10 0 H+V-PolarizedV-PolarizedH-Polarized Horn Antenna Polariza…
Text truncated - open the document above for the full version.
Compliance Certification Services Inc. Report No: 50323004-SF FCC ID: Q3ZF10DAM Date of Issue: April 27, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 23 Rev. 00 ANSI/IEEE Std. C95.1-1992 in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC TEST REPORT For Notebook built-in 802.11g Module Trade Name: Averatec Model: 1000 Series Issued to Averatec Inc. 80 Icon, Foothhill Ranch, CA92610 Issued by Compliance Certification Services Inc. No. 11, Wu-Kung 6 Rd, Wu-Ku Hsiang, Wu-Ku Industrial District, Taipei Hsien, (248) Taiwan. TEL: 886-2-2299-9720 FAX: 886-2-2299-9721 Compliance Certification Services Inc. Report No: 50323004-SF Date of Issue: April 27, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. EUT DESCRIPTION ....................................................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC .........................5 3. DOSIMETRIC ASSESSMENT SYSTEM ...................................................................................5 3.1 MEASUREMENT SYSTEM DIAGRAM....................................................................................6 3.2 SYSTEM COMPONENTS ...........................................................................................................7 4. EVALUATION PROCEDURES ..................................................................................................9 5. MEASUREMENT UNCERTAINTY .........................................................................................13 6. EXPOSURE LIMIT ....................................................................................................................14 7. TYPICAL COMPOSITION OF INGREDIENTS FOR LIQUID TISSUE PHANTOMS .........14 8. MEASUREMENT RESULTS ....................................................................................................15 8.1 SYSTEM PERFORMANCE CHECK................................................................................................ 15 8.2 TEST LIQUID CONFIRMATION...................................................................................................... 16 8.3 EUT TUNE-UP PROCEDURES......................................................................................................... 17 8.4 SAR MEASUREMENTS RESULTS.................................................................................................. 18 9. EUT PHOTOS............................................................................................................................20 10. EQUIPMENT LIST & CALIBRATION STATUS....................................................................21 11. FACILITIES ...............................................................................................................................22 12. REFERENCES............................................................................................................................22 13. ATTACHMENTS .......................................................................................................................23 Compliance Certification Services Inc. Report No: 50323004-SF Date of Issue: April 27, 2005 Page 3 Rev. 00 CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Applicant: Averatec Inc. 80 Icon, Foothhill Ranch, CA92610 Equipment Under Test: Notebook built-in 802.11g Module Trade Name: Averatec Model Number: 1000 Series Date of Test: April 27, 2005 Device Category: PORTABLE DEVICES Exposure Category: GENERAL POPULATION/UNCONTROLLED EXPOSURE APPLICABLE STANDARDS STANDARD TEST RESULT FCC OET 65 Supplement C No non-compliance noted Deviation from Applicable Standard None The device was tested by Compliance Certification Services Inc. in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C (Edition 01-01). The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Harris W. Lai Chris Hsieh Executive Vice President Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No: 50323004-SF Date of Issue: April 27, 2005 Page 4 Rev. 00 1. EUT DESCRIPTION Product Notebook built-in 802.11g Module Trade Name Averatec Model Number 1000 Series Model Discrepancy N/A Frequency Range 802.11b: 2412 ~ 2462 MHz 802.11g: 2412 ~ 2462 MHz Max. O/P Power: (Conducted/Average) 802.11b: 19.44 dBm 802.11g: 18.96 dBm Max. SAR (10g): 802.11b: 0.001910 W/kg 802.11g: 0.000574 W/kg Modulation Technique 802.11b: Direct Sequence Spread Spectrum(DSSS) 802.11g: Orthogonal Frequency Division Multiplexing (OFDM) Antenna Specification Antenna type: Main antenna: PIFA antenna Aux antenna: PIFA antenna Battery option: Only one type / model with EUT Remark: The sample selected for test was prototype that approximated to production product and was provided by manufacturer. Compliance Certification Services Inc. Report No: 50323004-SF Date of Issue: April 27, 2005 Page 5 Rev. 00 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC The US Federal Communications Commission has released the report and order “Guidelines for Evaluating the Environmental Effects of RF Radiation", ET Docket No. 93-62 in August 1996 [1]. The order requires routine SAR evaluation prior to equipment authorization of portable transmitter devices, including portable telephones. For consumer products, the applicable limit is 1.6 mW/g for an uncontrolled environment and 8.0 mW/g for an occupational/controlled environment a…
Text truncated - open the document above for the full version.
Date/Time: 4/27/2005 09:35:31 AM Test Laboratory: Compliance Certification Services Inc. D2450V2-SN 728-Body DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:728 Communication System: CW2450; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.92 mho/m; ε r = 51.1; ρ = 1000 kg/m 3 Air Temperature:24.0 deg C;Liquid Temperature:23.0 deg C Area scan setting: Find secondary maxima within 2 dB, and with a peak SAR value greater than 0.0012 mW/g Zoom scan setting: Maximum number of cubes to measure is 2 Phantom section: Flat Section DASY4 Configuration: z Probe: EX3DV4 - SN3554; ConvF(6.14, 6.14, 6.14); Calibrated: 11/19/2004 z Sensor-Surface: 4mm (Mechanical Surface Detection)Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn558; Calibrated: 8/24/2004 z Phantom: SAM 34; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Pin=250mW,d=10mm/Area Scan (6x6x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 9.43 mW/g Pin=250mW,d=10mm/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 21.3 mW/g Pin=250mW,d=10mm/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 87.1 V/m; Power Drift = 0.079 dB Peak SAR (extrapolated) = 30.0 W/kg SAR(1 g) = 13.3 mW/g; SAR(10 g) = 5.78 mW/g Maximum value of SAR (measured) = 14.9 mW/g Page1 Page2 Date/Time: 04/27/2005 4:26:00PM Test Laboratory: Compliance Certification Services Inc. Teat Configuration-1 Page1 Date/Time: 4/27/2005 09:44:44 AM Test Laboratory: Compliance Certification Services Inc. 802.11b Touch mode-Main Ant DUT: 1000 Series; Type: Notebook built-in 802.11g module; Serial: N/A Communication System: IEEE 802.11b WLAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 1.92 mho/m; ε r = 51.1; ρ = 1000 kg/m 3 Air Temperature:24.0 deg C;Liquid Temperature:23.0 deg C Area scan setting: Find secondary maxima within 2 dB, and with a peak SAR value greater than 0.0012 mW/g Zoom scan setting: Maximum number of cubes to measure is 2 Phantom section: Flat Section DASY4 Configuration: z Probe: EX3DV4 - SN3554; ConvF(6.14, 6.14, 6.14); Calibrated: 11/19/2004 z Sensor-Surface: 4mm (Mechanical Surface Detection)Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn558; Calibrated: 8/24/2004 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Middle CH Rate=1M bit/Area Scan (14x19x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.01 mW/g Middle CH Rate=1M bit/Z Scan (1x1x101): Measurement grid: dx=20mm, dy=20mm, dz=1mm Maximum value of SAR (measured) = 0.015 mW/g Middle CH Rate=1M bit/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 0.624 V/m; Power Drift = -0.2 dB Peak SAR (extrapolated) = 0.011 W/kg SAR(1 g) = 0.00191 mW/g; SAR(10 g) = 0.000384 mW/g Maximum value of SAR (measured) = 0.014 mW/g Middle CH Rate=1M bit/Zoom Scan (5x5x7)/Cube 1: Measurement grid: dx=7.5mm, d y=7.5mm, dz=5mm Page1 Reference Value = 0.624 V/m; Power Drift = -0.2 dB Peak SAR (extrapolated) = 0.01 W/kg SAR(1 g) = 0.00034 mW/g; SAR(10 g) = 4.84e-005 mW/g Maximum value of SAR (measured) = 0.005 mW/g Page2 Date/Time: 4/27/2005 12:28:40 PM Test Laboratory: Compliance Certification Services Inc. 802.11g Touch mode-Main Ant DUT: 1000 Series; Type: Notebook built-in 802.11g module; Serial: N/A Communication System: IEEE 802.11g WLAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 1.92 mho/m; ε r = 51.1; ρ = 1000 kg/m 3 Air Temperature:24.0 deg C;Liquid Temperature:23.0 deg C Air Temperature:24.0 deg Area scan setting: Find secondary maxima within 2 dB, and with a peak SAR value greater than 0.0012 mW/g Zoom scan setting: Maximum number of cubes to measure is 2 Phantom section: Flat Section DASY4 Configuration: z Probe: EX3DV4 - SN3554; ConvF(6.14, 6.14, 6.14); Calibrated: 11/19/2004 z Sensor-Surface: 4mm (Mechanical Surface Detection)Sensor-Surface: 0mm (Fix Surface) z Electronics: DAE3 Sn558; Calibrated: 8/24/2004 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Middle CH Rate=6M bit/Area Scan (14x19x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.033 mW/g Middle CH Rate=6M bit/Z Scan (1x1x101): Measurement grid: dx=20mm, dy=20mm, dz=1mm Maximum value of SAR (measured) = 0.01 mW/g Middle CH Rate=6M bit/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 0.22 V/m; Power Drift = 0.00 dB Peak SAR (extrapolated) = 0.019 W/kg SAR(1 g) = 0.000574 mW/g; SAR(10 g) = 0.000112 mW/g Maximum value of SAR (measured) = 0.019 mW/g Page1 Page2 Date/Time: 04/27/2005 4:30:39PM Test Laboratory: Compliance Certification Services Inc. Test Configuration-2 Page1 Date/Time: 4/27/2005 3:34:33 PM Test Laboratory: Compliance Certification Services Inc. 802.11b Touch mode-Aux Ant DUT: 1000 Series; Type: Notebook built-in 802.11g module; Serial: N/A Communication System: IEEE 802.11b WLAN; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 1.92 mho/m; ε r = 51.1; ρ = 1000 kg/m 3 Air Temperature:24.0 deg C;Liquid Temperature:23.0 deg C Area scan setting: Find secondary maxima within 2 dB, and with a peak SAR value greater than 0.0012 mW/g Zoom scan setting: Maximum number of cubes to measure is 2 Phantom section: Flat Section DASY4 Configuration: z Probe: EX3DV4 - SN3554; ConvF(6.14, 6.14, 6.14); Calibrated: 11/19/2004 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn558; Calibrated: 8/24/2004 z Phantom: SAM 12; Type: SAM V4.0; Serial: TP-1150 z Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Middle CH Rate=1M bit/Area Scan (14x19x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (…
