Q47-CID1BCard Reader

ERG Transit Systems

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 25, 2003
Application Purpose: Original Equipment
Date of Application: Nov 25, 2003
Equipment Note: Card Reader
Frequency Range: 13.56000000 - 13.56000000
Company: ERG Transit Systems
Country: Australia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC ID: Q47 - CID1 B Report No. T31109_F Appendix H APPENDIX H OF TEST REPORT T31109_F TEST SAMPLE TECHNICAL(USER) MANUAL FCC ID:Q47-CID1D Manufacturer:ERG Ltd Test Sample:Card Interface Device (CID1B) Model: 18186 Serial No:03222860 Date:13 th November 2003 EMC Technologies Pty Ltd A.C.N. 057 105 549 16/6 Gladstone Rd Castle Hill, NSW 2154 Ph: + 612 9899 4599 Fax: + 612 9899 4019 email: [email protected] HTTP: www.emctech.com.au This material is confidential to ERG and may not be disclosed in whole or in part to any third party nor used in any manner whatsoever other than for the purposes expressly consented to by ERG in writing. This material is also copyright and may not be reproduced, stored in a retrieval system or transmitted in any form or by any means in whole or in part without the express written consent of ERG. Device Product Group CID1B Field Maintenance Manual Document No:DPG-00253Category:434Revision:1 ERG Approvals AuthorProcess ManagerManager Name:William RiveraGino Bertino Signature: Date: Device Product GroupSecurity Level 3CID1B Field Maintenance Manual DPG-00253ERG Confidential © ERG 2003Page 2 of 21 Revision 1 / 13 Nov 03 Document History Revision Revision Date DescriptionAuthor 0.111 Nov 03Initial DraftWilliam Rivera 1.013 Nov 03Initial ReleaseWilliam Rivera Device Product GroupSecurity Level 3CID1B Field Maintenance Manual DPG-00253ERG Confidential © ERG 2003Page 3 of 21 Revision 1 / 13 Nov 03 FCC Compliance Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encourage to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. The CID1B was submitted and a grant of authorisation received from the FCC under the intentional radiator requirements of part 15, Subpart C. Warning: Any changes or modifications not expressively approved by ERG Transit Systems could void the user’s authority to operate this equipment Device Product GroupSecurity Level 3CID1B Field Maintenance Manual DPG-00253ERG Confidential © ERG 2003Page 4 of 21 Revision 1 / 13 Nov 03 Table of Contents 1INTRODUCTION .................................................................................................................................. 5 1.1PURPOSE............................................................................................................................................ 5 1.2SCOPE................................................................................................................................................ 5 1.3TERMINOLOGY.................................................................................................................................... 5 2OVERVIEW........................................................................................................................................... 6 2.1MAINTENANCE STRUCTURE OVERVIEW................................................................................................ 6 2.2FIRST LINE MAINTENANCE................................................................................................................... 6 2.3SECOND LINE MAINTENANCE............................................................................................................... 7 2.4THIRD LINE MAINTENANCE................................................................................................................... 7 3CID1B DEVICE DESCRIPTION ........................................................................................................... 8 3.1OPERATIONAL MODES......................................................................................................................... 9 4TROUBLESHOOTING AND DIAGNOSTIC TESTING ...................................................................... 10 4.1TROUBLESHOOTING GUIDE................................................................................................................ 10 4.2DIAGNOSTIC TESTING........................................................................................................................ 10 4.2.1Start-up ................................................................................................................................... 11 4.2.1.1Power on Self-Test........................................................................................................................11 4.2.2Maintenance Mode Testing..................................................................................................... 12 5PREVENTATIVE MAINTENANCE..................................................................................................... 13 5.1SAFETY............................................................................................................................................ 13 5.2RETRIEVING DATA FROM DEVICES......…

Text truncated - open the document above for the full version.

External Photos

FCC ID: Q47-CID1B Report No. T30218_F Appendix B2 Page 1 of 10 APPENDIX B2 OF TEST REPORT T31109_F Test Sample Identification Photographs FCC ID:Q47-CID1B Manufacturer:ERG Ltd Test Sample:Card Interface Device (CID1B) Model:181816 Serial No:03222860 Date: 13th November 2003 EMC Technologies Pty Ltd A.C.N. 057 105 549 16/6 Gladstone Rd Castle Hill, NSW 2154 Ph: + 612 9899 4599 Fax: + 612 9899 4019 email: [email protected] HTTP: www.emctech.com.au FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 2 of 10 TEST SAMPLE – IDENTIFICATION PHOTOS FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 3 of 10 Antenna PCB – Front FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 4 of 10 Antenna PCB – Rear FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 5 of 10 Transmitter Main PCB – Front FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 6 of 10 Transmitter Main PCB – Rear FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 7 of 10 Main PCB – Front FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 8 of 10 Main PCB – Rear FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 9 of 10 LCD DISPLAY FCC ID: Q47-CID1B Report No. T31109_F Appendix B2 Page 10 of 10 LCD DISPLAY - Rear

ID Label/Location Info

FCC ID: Q47-CID1BReport No. T31109_F Appendix F Page 1 of 3 APPENDIX F OF TEST REPORT T31109_F TEST SAMPLE FCC ID LABELLING FCC ID:Q47-CID1B Manufacturer:ERG Ltd Test Sample:Card Interface Device (CID1B) Model: 18186 Serial No:03222860 Date:13 th November 2003 EMC Technologies Pty Ltd A.C.N. 057 105 549 16/6 Gladstone Rd Castle Hill, NSW 2154 Ph: + 612 9899 4599 Fax: + 612 9899 4019 email: [email protected] HTTP: www.emctech.com.au D C B A REV A4 D C B A TOLERANCES UNLESS OTHERWISE NOTEDUNLESSOTHERWISENOTED WHOLE NUMBERSWHOLENUMBERS 1 DECIMAL PLACE1DECIMAL PLACE 2 DECIMAL PLACES2DECIMAL PLACES ANGLES ±0.5 ±0.2 ±0.1 ±0.5° 4 3 DIMENSIONS IN MILLIMETRESDIMENSIONSINMILLIMETRES 1 CHANGE NOTE REF:CHANGENOTEREF: DO NOT SCALEDONOT SCALE DATE SCALE APP'D CHK'D DRN 2 AS 1100-1992AS1100-1992 1 2 SHEET DRG No.DRGNo. 3 4 REV 0 1 2 DATE 23.04.03 06.05.03 10.11.03 DRN BY PH PH PH DESCRIPTION NEW DRAWING ISSUED UPDATED NEW FCC ID No REPLACE FCC ID: Q47-MCR200 WITH Q47-CID1B AND UPDATED LAYOUT PCO B00476 B00505 ZONE ERG Confidential, ERG 2003 87004.2 ARTWORK SERIAL-COMPLIANCE LABEL C/W CID1B FCC ID 76-0425 2 1OF1 1:1 PH NOTE: The displayed colours are for reference only and are not to be used for colour matching. REG MARKS ARE NOT TO BE PRINTED B00505 SIZE 66 x 30mm BLACK (AS APPLICABLE TO ANODISED ALUMINIUM PRINTING PROCESS)

Internal Photos

Test Report

Page 1 of 21 EMC Technologies Pty Ltd A.C.N. 057 105 549 ABN 82 057 105 549 Unit 16, 6 Gladstone Road, Castle Hill, N.S.W. 2154 Australia Telephone +612 9899 4599 Facsimile +612 9899 4019 Email [email protected] Victoria 57 Assembly Drive Tullarmarine, Victoria Australia 3043 Telephone +61 3 9335 3333 Facsimile +61 3 9338 9260 Accredited Testing and Competent Body Service EMI TEST REPORT for CERTIFICATION of FCC PART 15.225 & FCC PART 15.207 TRANSMITTER FCC ID:Q47-CID1B Manufacturer:ERG Ltd Test Sample:Card Interface Device (CID1B) Model:18186 Serial No:03222860 Date:13 th November 2003 EMC Technologies Pty Ltd reports apply only to the specific samples tested under stated test conditions. All samples tested were in good operating condition throughout the entire test program. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. EMC Technologies Pty Ltd shall have no liability for any deductions, interferences or generalisations drawn by the client or others from EMC Technologies Pty Ltd issued reports. This report shall not be used to claim, constitute or imply product endorsement by EMC Technologies Pty Ltd. The tests, calibrations or measurements covered by this document have been performed in accordance with NATA requirements which include the requirements of ISO/IEC 17025 and are traceable to national standards of measurement. This document shall not be reproduced, except in full. NATA Accredited Laboratory Number: 5292 FCC ID: Q47-CID1BReport No. T31109 _F Page 2 of 21 EMC Technologies Pty Ltd 16/6 Gladstone Rd Castle Hill NSW 2154 Australia Tel: +61 2 98994599 Fax: +61 2 98994019 EMI TEST REPORT FOR CERTIFICATION FOR CERTIFICATION OF FCC Part 15.225 & FCC PART 15.207 TRANSMITTER FCC ID: Q47-CID1B EMC Technologies Report No. T31109_F Date: 13 th November 2003 CONTENTS 1. SUMMARY of TEST RESULTS 2. GENERAL INFORMATION 3. CONDUCTED EMI RESULTS 4. RADIATED EMI RESULTS 5. FREQUENCY TOLERANCE 6. CONCLUSION APPENDIX A. MEASUREMENT INSTRUMENTATION DETAILS APPENDIX B. TEST SETUP AND IDENTIFICATION PHOTOGRAPHS APPENDIX C. TEST SAMPLE SCHEMATICS APPENDIX D. TEST SAMPLE PCB LAYOUTS APPENDIX E. TEST SAMPLE BLOCK DIAGRAM/OPERATIONAL DESCRIPTION APPENDIX F. LABELLING – LOCATION APPENDIX G. GRAPHS of EMI MEASUREMENT APPENDIX H. USER MANUAL APPENDIX I. PARTS LIST/BILL OF MATERIALS FCC ID: Q47-CID1BReport No. T31109 _F Page 3 of 21 EMC Technologies Pty Ltd 16/6 Gladstone Rd Castle Hill NSW 2154 Australia Tel: +61 2 98994599 Fax: +61 2 98994019 EMI TEST REPORT FOR CERTIFICATION OF FCC PART 15.225 & FCC PART 15.207 TRANSMITTER Report Number: T31109_F Test Sample Name: Card Interface Device (CID1B) Model Number: 18186 Serial Number: 03222860 FCC ID:Q47-CID1B Manufacturer: ERG Ltd Tested For: ERG Ltd Address: 247 Balcatta Road Balcatta WA 6021 Phone: (08) 9273 1100 Fax: (08) 9273 1570 Responsible Party: Mr Gino Bertino Test Standards:FCC Part 15.225 Intentional Radiators FCC Part 15.207 Conducted Limits ANSI C63.4:1992 OET Bulletin No. 63 Test Dates: 07/11/03, 10/11/03 and 12/11/03 Testing Officers: Bruce HoldsworthKumar Thambiaiah Attestation:I hereby certify that the device(s) described herein were tested as described in this report and that the data included is that which was obtained during such testing. Authorised Signature: Les Dickenson Branch Manager EMC Technologies Pty Ltd Issued by EMC Technologies Pty Ltd, Unit 16/6 Gladstone Road, Castle Hill, NSW, 2154, Australia. Phone: +61 2 9899 4599 Fax: +61 2 9899 4019 FCC ID: Q47-CID1BReport No. T31109 _F Page 4 of 21 EMC Technologies Pty Ltd 16/6 Gladstone Rd Castle Hill NSW 2154 Australia Tel: +61 2 98994599 Fax: +61 2 98994019 EMI TEST REPORT FOR CERTIFICATION of FCC PART 15.225 & FCC PART 15.207 TRANSMITTER on the Card Interface Device (CID1B) 1. SUMMARY of RESULTS This report details the results of EMI tests and measurements performed on the Card Interface Device (CID1B), Model: 18186, in accordance with the Federal Communications Commission (FCC) regulations as detailed in Title 47 CFR, Part 15 Rules for intentional radiators. All results are detailed in this report. The EUT complied with the requirements of Part 15.225 and the conducted emision requirements of FCC Part 15.207. Section 15.225(a) Carrier Signal Field Strength: Complied, margin of > 10dB. Section 15.209 Radiated Emissions Complied, margin of 1.1dB. Section 15.225(c) Frequency Tolerance: Complied. Section 15.207 Conducted Emissions: Complied, margin of 1.0dB. 2. GENERAL INFORMATION 2.1General Description of Test Sample Manufacturer:ERG Ltd Test Sample:Card Interface Device Model:18186 Serial No:03222860 FCC ID:Q47-CID1B Equipment Type:Intentional Radiator 2.2 Test Sample Functional Description The CID1B is used on buses. It allows the patron to pay for their fare by tagging on and tagging off the bus. The test sample features a diagnostic application that exercises internal sections (memory, comms ports, wlan, display, etc) during test loops. 2.3 Technical Specifications and System Overview RF Control Chip: Input Supply:24V, 15W max Microprocessor:Motorola MC68340 Crystal Frequency MHz:32.768kHz, 5.0688MHz, 7.3728MHz, 20.000MHz Refer to Appendix H (User Manual), Appendix I (Installation Guide) and Appendix E (Block Diagram/Operational Description). FCC ID: Q47-CID1BReport No. T31109 _F Page 5 of 21 EMC Technologies Pty Ltd 16/6 Gladstone Rd Castle Hill NSW 2154 Australia Tel: +61 2 98994599 Fax: +61 2 98994019 2.4 Test Sample Support Equipment Data communications cable to talk to a test PC to exercise the RS232 interface. The EUT was powered from a AC to DC Convertor during testing. 2.5 Test Sample Block Diagram Refer to Appendix E – Test Sample Block Diagram/Operational Description. 2.6 EUT Configuration CID1B has a 128x64 backlit LCD. The unit has a 13.56MHz contactless card reader and connects to a Driver Console. Refer to Appendix E (Block Diagram/Operational Desc…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 2 APPENDIX A OF TEST REPORT T31109_F Instrumentation Calibration Details FCC ID: Q47-CID1B Manufacturer:ERG Ltd Test Sample:Card Interface Device (CID1B) Model: 18186 Serial No:03222860 Date:13 th November 2003 EMC Technologies Pty Ltd A.C.N. 057 105 549 16/6 Gladstone Rd Castle Hill, NSW 2154 Ph: + 612 9899 4599 Fax: + 612 9899 4019 email: [email protected] HTTP: www.emctech.com.au FCC ID: Q47-CID1BReport No. T31109_F Appendix A Page 2 of 2 APPENDIX A MEASUREMENT INSTRUMENTATION DETAILS Equipment TypeMake/Model Serial Number Last Cal. DD/MM/YY Due Date DD/MM/YY EMI ReceiversHP8546A CISPR Receiver S/N: 3549A00288 HP8574B CISPR Receiver S/N 3146A01339 22/07/03 11/07/03 22/07/04 *2 11/07/04 *2 LISN:EMCO 3825/2 SN 94112274 Rohde & Swartz ESH3-Z5 S/N 832479/014 15/10/03 10/4/03 15/10/04 *3 10/4/04 *3 AntennasEMCO 3146 Log Periodic S/N 9603-4415 300-1000MHz EMCO 3110B Biconical S/N 9603-2350 20-300 MHz EMCO 3115 Horn Antenna S/N: 3823 1-18GHz 08/03/03 30/04/03 29/01/02 08/03/04 *3 30/04/04 *3 29/01/05 *3 Note *1 : National Measurements Laboratory calibration Note *2 : NATA Calibration by Hewlett Packard (Aust) Ltd Note *3 : In-house calibration. Traceable to Australian National Standards. TEST SITES Equipment TypeMake/Model Serial Number Last Cal. DD/MM/YY Due Date DD/MM/YY Shielded Room/ Test Laboratory 7.23m × 4.83m × 2.45m N/AN/A Open Area Test Site (OATS) 3/10/30 metre site. 1-4 metre antenna mast. 1.2 metre/1.2 Tonne turntable. (Situated at Upper Colo, NSW) 13/11/0213/11/03

Test Report

Page 1 of 8 APPENDIX G OF TEST REPORT T31109_F Graphs of EMI Measurements FCC ID:Q47-CID1B Manufacturer:ERG Ltd Test Sample:Card Interface Device (CID1B) Model: 18186 Serial No:03222860 Date:13 th November 2003 EMC Technologies Pty Ltd A.C.N. 057 105 549 16/6 Gladstone Rd Castle Hill, NSW 2154 Ph: + 612 9899 4599 Fax: + 612 9899 4019 email: [email protected] HTTP: www.emctech.com.au FCC ID: Q47 - CID1B Report No. T31109_F Appendix G Page 2 of 8 Graphs of EMI Measurements Graph 1:Conducted Emissions, Active 0.15 MHz to 30 MHz, EUT Transmitting Graph 2:Conducted Emissions, Neutral 0.15 MHz to 30 MHz, EUT Transmitting Graph 3:Emissions, 0.009 MHz to 30 MHz, EUT Transmitting Graph 4: Carrier Zoom, EUT Transmitting Graph 5:Vertical Emissions, 29 MHz to 1000 MHz, EUT Transmitting Graph 6:Horizontal Emissions, 29 MHz to 1000 MHz, EUT Transmitting EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:T31109 Test Date: 07-11-2003 GRAPH No. 1 r:\PCF\T31109_1.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019ERG Transit Group Card Interface Device Model No: 18186 Conducted Emissions (dBuV) \T31109c Limits: Legend: Source: _ FCCN_BQP FCC CLASS B QP CONDUCTED LIMITS (CISPR) _ FCCN_BAV FCC CLASS B AV CONDUCTED LIMITS (CISPR) __ Active Line 1 2 3 Ver 5.5 Build 74 t:L0111003 c1:C0020904 c2: p:NONE a:L0100304Site ID: Syd Room#2,16/6 Gladstone Rd. Castle Hill, NSW Test Officer:Kumar Thambiaiah Peaks:No Freq Peak Qp Val FCCN_BQP dL1 Av Val FCCN_BAV dL2 (MHz) (dBuV) (dBuV) (dB) (dBuV) (dBuV) (dB) 1 13.56 62.6 62.7 60.0 2.7 62.7 50.0 12.7 2 27.12 48.3 48.9 60.0 -11.1 49.0 50.0 -1.0 3 0.576 37.4 37.9 56.0 -18.1 36.4 46.0 -9.6 4 0.576 36.8 38.0 56.0 -18.0 36.4 46.0 -9.6 5 0.288 40.9 41.5 60.6 -19.1 41.0 50.6 -9.6 6 4.394 36.2 36.6 56.0 -19.4 35.7 46.0 -10.3 7 0.934 36.6 35.6 56.0 -20.4 32.5 46.0 -13.5 Frequency (MHz) 1 10 .145 30.5 0 10 20 30 40 50 60 70 80 v ^ 1 ~ * v ^ 2 ~ * v ^ 3 ~ * v ^ 4 ~ * v ^ 5 ~ * v ^ 6 ~ * v ^ 7 ~ * EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:T31109 Test Date: 07-11-2003 GRAPH No. 2 r:\PCF\T31109_2.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019ERG Transit Group Card Interface Device Model No: 18186 Conducted Emissions (dBuV) \T31109c Limits: Legend: Source: _ FCCN_BQP FCC CLASS B QP CONDUCTED LIMITS (CISPR) _ FCCN_BAV FCC CLASS B AV CONDUCTED LIMITS (CISPR) __ Neutral Line 7 8 9 Ver 5.5 Build 74 t:L0111003 c1:C0020904 c2: p:NONE a:L0100304Site ID: Syd Room#2,16/6 Gladstone Rd. Castle Hill, NSW Test Officer:Kumar Thambiaiah Peaks:No Freq Peak Qp Val FCCN_BQP dL1 Av Val FCCN_BAV dL2 (MHz) (dBuV) (dBuV) (dB) (dBuV) (dBuV) (dB) 1 13.56 62.2 63.0 60.0 3.0 63.0 50.0 13.0 2 27.12 44.7 45.3 60.0 -14.7 45.1 50.0 -4.9 3 0.579 38.6 39.3 56.0 -16.7 38.2 46.0 -7.8 4 0.579 38.8 39.3 56.0 -16.7 38.2 46.0 -7.8 5 0.290 42.3 42.8 60.5 -17.7 42.5 50.5 -8.0 6 0.507 36.8 36.5 56.0 -19.5 35.8 46.0 -10.2 7 0.939 37.6 36.9 56.0 -19.1 34.3 46.0 -11.7 Frequency (MHz) 1 10 .145 30.5 0 10 20 30 40 50 60 70 80 v ^ 1 ~ * v ^ 2 ~ * v ^ 3 ~ * v ^ 4 ~ * v ^ 5 ~ * v ^ 6 ~ * v ^ 7 ~ * EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:T31109 Test Date: 12-11-03 GRAPH No. 3 C:\reports\pcf\T31109_3.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019ERG Transit Group Card Interface Device Model No: 18186 Radiated Emissions (dBuV) T31109r1T31109r1 # = Ambient Limits: Legend: Source: _ FCC_loop_3m FCC Pt15 3 METRE LIMITS FOR LOOP ANTENNA __ Ambients __ Emissions 6 7 8 1 2 3 Ver 5.5 Build 70Colo Radiated Test Setup Active Loop t:A0081204E c1:C0200904 c2:NONE p:NONE a:NONESite ID: OATS#1,1247 Upper Colo Rd. Colo, NSW Test Officer:Bruce Holdsworth Peaks:No Freq Peak Qp Val FCC_loop_3m dL1 (MHz) (dBuV) (dBuV) (dB) 1 13.56 73.5 73.5 120.0 -46.5 Frequency (MHz) .1 1 10 .009 30 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 v ^ 1 ~ # # # # # # # # # # # # # # # # # EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:T31109 Test Date: 12-11-03 GRAPH No. 4 C:\reports\pcf\T31109_4.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019ERG Transit Group Card Interface Device Model No: 18186 Radiated Emissions (dBuV) T31109r1 # = Ambient Limits: Legend: Source: _ FCC_loop_3m FCC Pt15 3 METRE LIMITS FOR LOOP ANTENNA __ Carrier 5 Ver 5.5 Build 70Colo Radiated Test Setup Active Loop t:A0081204E c1:C0200904 c2:NONE p:NONE a:NONESite ID: OATS#1,1247 Upper Colo Rd. Colo, NSW Test Officer:Bruce Holdsworth Peaks:No Freq Peak Qp Val FCC_loop_3m dL1 (MHz) (dBuV) (dBuV) (dB) 1 13.56 73.2 72.5 120.0 -47.5 Frequency (MHz) 13.55 13.57 -10 0 10 20 30 40 50 60 70 80 90 100 110 120 130 v ^ 1 ~ EMC Technologies Pty. Ltd. - Global Product CertificationFCC Class B Job No:T31109 Test Date: 10-11-03 GRAPH No. 5 C:\reports\pcf\T31109_5.PCF Melbourne- 57 Assembly Drv Tullamarine, 3043, Vic, Australia Ph+(613) 9335 3333 Fax+(613) 9338 9260Sydney---- 16,6 Gladstone Rd Castle Hill, 2154, NSW, Australia Ph+(612) 9899 4599 Fax+(612) 9899 4019ERG Transit Group Card Interface Device Model No: 18186 Radiated Emissions (dBuV/m) \Amb1710\T31109r # = Ambient Limits: Legend: Source: _ FCC-B3 FCC CLASS B RAD 3M LIMITS __ Vertical Ambients __ Vertical Emissions 1 2 3 4 5 11 1 2 3 4 5 12 Ver 5.5 Build 70Colo Radiated Test Setup t:A0690304 c1:C0200904 c2:NONE p:A0961103 a:NONESite ID: OATS#1,1247 Upper Colo Rd. Colo, NSW Test Officer:Bruce Holdsworth Peaks:No Freq…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: Q47-CID1BReport No. T30218_F Appendix B1 Page 1 of 3 APPENDIX B1 OF TEST REPORT T31109_F Test Setup Photographs FCC ID: Q47-CID1B Manufacturer:ERG Ltd Test Sample:Card Interface Device (CID1B) Model:18186 Serial No:03222860 Date:13 th November 2003 EMC Technologies Pty Ltd A.C.N. 057 105 549 16/6 Gladstone Rd Castle Hill, NSW 2154 Ph: + 612 9899 4599 Fax: + 612 9899 4019 email: [email protected] HTTP: www.emctech.com.au FCC ID: Q47-CID1B Report No. T31109_F Appendix B1 Page 2 of 3 CONDUCTED EMI – TEST SETUP EUT Front EUT Side FCC Q47-CID1BReport No. T31109_F Appendix B1 Page 3 of 3 RADIATED EMI – TEST SETUP EUT Rear EUT Side
