Q4VFS42R-1719-ECHANNELIZED BDA

Rev A Page 1 of 25 FS42R-1719E Dual Band Fiber Fed Outdoor Das System Series FS42R User Manual RF On Fiber ® Signal Distribution Products for Outdoor DAS Coverage Extension Applications Fiber-Span Rev A Page 2 of 25 Information in this document is subject to change without notice. All rights reserved. Please send comments to: E-mail [email protected] PHONE: 908-253-9080 Fax: 908-253-9086 Revision History Version Author Description Date Release A J. Stewart 20-Jan-2010 Fiber-Span Rev A Page 3 of 25 Table of Contents 1. SUMMARY............................................................................................................................................................................... 5 2. GENERAL DESCRIPTION ...................................................................................................................................................... 5 3. DUAL BAND OUTDOOR DAS REMOTE FIBER NODE (RFN) [STANDARD CONFIGURATION].............................. 7 3.1 REMOTE FIBER NODE MODEL DRAWING.................................................................................................................................... 7 3.2 REMOTE FIBER NODE BLOCK DIAGRAM (COMMON TO ALL CONFIGURATIONS) ......................................................................... 7 3.3 REMOTE FIBER NODE DETAILED DESCRIPTION.......................................................................................................................... 8 3.4 REMOTE FIBER NODE (RFN) EXTERNAL INTERFACES (STANDARD CONFIGURATION) ............................................................... 8 3.4.1 Remote Fiber Node Interface Description ......................................................................................................................... 8 3.4.2 Remote Fiber Node Front Panel Drawing ......................................................................................................................... 9 4. DUAL BAND OUTDOOR DAS FIBER TRANSCEIVER UNIT (FTU) ................................................................................ 9 4.1 FIBER TRANSCEIVER UNIT MODEL DRAWING (SHOWN WITH OPTIONAL DUPLEXED INTERFACE) .............................................. 9 4.2 FIBER TRANSCEIVER UNIT DETAILED DESCRIPTION................................................................................................................. 10 4.3 FIBER TRANSCEIVER UNIT BLOCK DIAGRAM........................................................................................................................... 11 4.4 FIBER TRANSCEIVER UNIT EXTERNAL INTERFACES (WITH OPTIONAL DUPLEXED PORTS) ........................................................ 12 4.4.1 FTU Interface Description ............................................................................................................................................... 12 4.4.2 FTU Front Panel Description (show with optional Duplexed Ports) ............................................................................. 12 5. DUAL BAND OUTDOOR DAS SYSTEM CONNECTIONS ............................................................................................... 14 6. DUAL BAND OUTDOOR DAS ELECTRICAL SPECIFICATIONS................................................................................... 15 7. MONITORING & CONTROL................................................................................................................................................ 15 8. GRAPHIC USER INTERFACE (GUI) ................................................................................................................................... 16 9. MECHANICAL SPECIFICATIONS ...................................................................................................................................... 20 10. ENVIRONMENTAL SPECIFICATIONS .............................................................................................................................. 20 11. REGULATORY STATEMENTS: .......................................................................................................................................... 20 12. APPENDIX A : INSTALLATION INSTRUCTIONS ............................................................................................................ 21 Preparing for Installation ................................................................................................................................................................ 21 Safety Precautions ........................................................................................................................................................................... 21 System Installation .......................................................................................................................................................................... 23 Remote Fiber Node Installation ....................................................................................................................................................... 25 Remote Fiber Node Verification Testing.......................................................................................................................................... 25 Fiber-Span Rev A Page 4 of 25 List of Figures Figure 1: DAS System Diagram ................................................................................................................................................................ 5 Figure 2: Dual Band Outdoor DAS System Diagram ................................................................................................................................ 6 Figure 3: Remote Fiber Node Model Drawing .......................................................................................................................................... 7 Figure 4 Remote Fiber Node Block Diagram ..........................................................................................................................…

Text truncated - open the document above for the full version.

Fiber-Span ●3434 Rt 22W, Suite 140, Branchburg, NJ 08876 Tel: 908.253.9080 ● Fax 908.253.9086 ● www.fiber-span.com DATE : April 16, 2010 Timco Engineering 849 N.W. State Road 45 PO Bo x 370 Newberry, FL 32669 Attn: Director of Certification Authority to Act as Agent FCC On our behalf, I authorize Nemko USA, Inc., 802 N. Kealy, Lewisville, TX 75057, to act as our agent in the preparation of this application fo r equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Federal Communications Commission regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Timco Engineering still resides with Fiber-Span 343,4 Rt. 22W, Suite 140., Branchburg, New Jersey 08876. Dated this 16 Day of April 20 10 Agency agreement expiration date: 31-DEC-2011 By: James Stewart Signature Printed Title: Engineering Manager On behalf of : Fiber-Span Telephone: 908-253-9080

y3434 Rt. 22W, Suite 140. y Branchburg, NJ 08876 y 908-253-9080 y Fax 908-253-9086 y www.fiber-span.com P 1 of 1 Fiber-Span_User_Tune_Statement. Name Rev A, Rev by: J. Stewart 12-May-2010 Re: Fiber-Span tune up information statement Fiber-Span has designed the submitted fiber optic repeater equipment such that there is no requirement for tune up beyond the content of the user manual. Tuning of any type must only be done by Fiber-Span or by a Fiber-Span authorized agent whom consults the user manual. Sincerely, Fiber-Span James Stewart Engineering Manager

y3434 Rt. 22W, Suite 140. y Branchburg, NJ 08876 y 908-253-9080 y Fax 908-253-9086 y www.fiber-span.com P 1 of 1 Doc. Name Rev A, Rev by: M. Carloni Request for Confidentiality April 16, 2010 Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 888-472-2424 Re: Certification Application FCC ID: Q4VFS42R-1719E Product Name: FS42R-1719E Please be advised that under the provision of 47 CFR 0.459, the following exhibits are to be held confidential on behalf of Fiber-Span. Fiber Span is also requesting the internal photos be p ermanently confidential. This non-consumer device is inaccessible to the general public, and shall be kept in a secured and locked environment. The equipment is only serviceable by the licensee or designated technicians, or at the factory. ¾ Operation Description (Theory of Operation) ¾ Internal Block Diagrams ¾ Schematics ¾ Parts List (BOM) ¾ Internal Photos The bullet list exhibit items are to be held confidential . The application contains technical information that Fiber-Span deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, James Stewart Engineering Manager

y3434 Rt. 22W, Suite 140. y Branchburg, NJ 08876 y 908-253-9080 y Fax 908-253-9086 y www.fiber-span.com P 1 of 1 Fiber-Span_NDA_for_Confidentiality. Name Rev A, Rev by: J. Stewart RESTRICTED ACCESS OF EQUIPMENT AND DOCUMENTATION NOTICE This Restricted Access of Equipment and Documentation Notice is to inform (insert name of FCC licensee) that access to equipment and related documentation supplied by Fiber‐Span is to be restricted to only authorized users by means to ensure the security of the equipment and confidentiality of related documentation at all tim es, and only designated professionals shall be allowed to maintain or service the equipment. Fiber Span is also requesting the internal photos be permanently confidential. This non-consumer device is inaccessible to the general public, and shall be kept in a secured and locked environment. Th is notice includes, but is not limited to (list all confidential documents to be held confidential and out of the public) ¾ Operation Description (Theory of Operation) ¾ Tune‐Up Procedure (DAS GUI User Manual) ¾ Internal Block Diagrams , Test Diagrams ¾ Schematics ¾ Parts List (BOM) ¾ Internal Photos Fiber‐Span By: ______________________________ Name: ___James Stewart_____________ Title: ____Engineering Manager________ Date: ____12‐May‐2010______________ Place: ____Branchburg, NJ____________

RFN (Remote Fiber Node) AWS and PCS Certification ID Label Placement Fiber-Span, 2010. Images are not to be used without express written consent of Fiber-Span FCC/IC Label Placement

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:43.00(dBm) Maximum peak output power at antenna input terminal:19952.62315(mW) Antenna gain(typical):14(dBi) Maximum antenna gain:25.11886432(numeric) Time Averaging:100(%) Prediction distance:500(cm) Prediction frequency:2130(MHz) MPE limit for uncontrolled exposure at prediction frequency:1 (mW/cm^2) Power density at prediction frequency:0.159533(mW/cm^2) Margin of compliance:-8.0(dB) 2 4R PG S π =

Nemko Test Report: 44421RUS1 Applicant: Fiber-Span 3434 Rt. 22W, Suite 140 Branchburg, NJ 08876 USA Equipment Under Test: FS42R-1719E (E.U.T.) FCC Identifier: Q4VFS42R-1719-E In Accordance With: CFR 47, Part 24, Subpart E Broadband PCS Repeaters Tested By: Nemko USA, Inc. 802 N. Kealy Lewisville, TX 75057-3136 TESTED BY: DATE: 27 April 2010 David Light, Senior Wireless Engineer APPROVED BY: DATE: 04 June 2010 Tom Tidwell, Telecom Direct Number of Pages: 39 Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44421RUS1 Page 2 of 39 Table of Contents Section 1. Summary of Test Results ......................................................... 3 Section 2. General Equipment Specification ............................................. 5 Section 3. RF Power Output ...................................................................... 7 Section 4. Occupied Bandwidth................................................................. 8 Section 5. Spurious Emissions at Antenna Terminals ............................. 17 Section 6. Field Strength of Spurious ...................................................... 30 Section 7. Test Equipment List ................................................................ 31 ANNEX A - TEST DETAILS ....................................................................... 32 ANNEX B - TEST DIAGRAMS ................................................................... 37 Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44421RUS1 Page 3 of 39 Section 1. Summary of Test Results Manufacturer Fiber-Span Model No.: FS42R-1719E Serial No.: R006330010141001 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with CFR 47, Part 24, Subpart E. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA, Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety, for use by the company’s employees only. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Nemko USA, Inc. is a NVLAP accredited laboratory. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA, Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44421RUS1 Page 4 of 39 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. RESULT RF Power Output 24.232 100W Complies Occupied Bandwidth 2.1049 Input/Output Complies Spurious Emissions at Antenna Terminals 24.238(a) -13 dBm Complies Field Strength of Spurious Emissions 24.238(a) -13 dBm E.I.R.P. Complies Frequency Stability 24.235 NA Footnotes: (1) Modulation characteristics were not tested since the E.U.T. processes but does not produce a modulated waveform. Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44421RUS1 Page 5 of 39 Section 2. General Equipment Specification Supply Voltage Input: Frequency Bands: Downlink: Block A : 1930 – 1945 MHz Block D : 1945 – 1950 MHz Block B : 1950 – 1965 MHz Block E : 1965 – 1970 MHz Block F : 1970 – 1975 MHz Block C : 1975 – 1990 MHz Frequency Bands: Uplink: Block A : 1850 – 1865 MHz Block B : 1865 – 1870 MHz Testing was not performed on the Uplink because the Uplink is connected to a BTS only through fiber and coaxial cable. Block C : 1870 – 1885 MHz Block D : 1885 – 1890 MHz Block E : 1890 – 1895 MHz Block F : 1895 – 1910 MHz (F9W) (GXW) (DXW) (G7W) Modulation Designator(s): System Gain: 40 dB Output Impedance: 50 ohms NA W RF Output (Rated): Uplink NA dBm 20 W RF Output (Rated): Downlink 43 dBm F1-F1 F1-F2 N/A Frequency Translation: Software Duplexer Fullband Band Selection: Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44421RUS1 Page 6 of 39 Description of EUT The Fiber-Span fiber fed Distributed Antenna System (DAS) is a wireless optical network which can be used to expand network and capacity needs and to overcome site location constraints involving zoning issues, limited space availability or prohibitive BTS based site lease costs . It provides connectivity between a BTS site and several Remote Antenna sites through a fiber optic link. The DAS is made up of two main components; one FTU and three Remote Fiber Nodes. Shown below are the FTU and the three Remote Fiber Nodes. The FTU is located near the BTS site and the Remote Fiber Node is located at the antenna site. System Diagram Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44421RUS1 Page 7 of 39 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 24.232 TESTED BY: David Light DATE: 27 April 2010 Test Results: Complies. Measurement Data: Direction Modulation Output per Channel (dBm) Composite Power (dBm) Composite Power (W) Uplink CDMA NA Downlink CDMA 40 43 20 Uplink EDGE NA Downlink EDGE 40 43 20 Uplink GSM NA Downlink GSM 40 43 20 Uplink W-CDMA NA Downlink W-CDMA 40 43 20 Equipment Used: 1036-1082-1472-1469 -1824 -1053 Measurement Uncertainty: +/- 1.7 dB Temperature: 22 °C Relative Humidity: 35 % Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44421RUS1 Page 8 of 39 Section 4. Occupied Bandwidth NAME OF TEST: Occupied Bandwidth PARA. NO.: 24.238 T…

Text truncated - open the document above for the full version.

Nemko Test Report: 44421RUS2 Applicant: Fiber-Span 3434 Rt. 22W, Suite 140 Branchburg, NJ 08876 USA Equipment Under Test: FS42R-1719E (E.U.T.) FCC Identifier: Q4VFS42R-1719-E In Accordance With: CFR 47, Part 27, Subpart C Miscellaneous Wireless Communication Services AWS Repeaters Tested By: Nemko USA, Inc. 802 N. Kealy Lewisville, TX 75057-3136 TESTED BY: DATE: 28 April 2010 David Light, Senior Wireless Engineer APPROVED BY: DATE: 04 June 2010 Tom Tidwell, Telecom Direct Number of Pages: 40 Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44422RUS1 Page 2 of 40 Table of Contents Section 1. Summary of Test Results ......................................................... 3 Section 2. General Equipment Specification ............................................. 5 Section 3. RF Power Output ...................................................................... 7 Section 4. Occupied Bandwidth................................................................. 8 Section 5. Spurious Emissions at Antenna Terminals ............................. 17 Section 6. Field Strength of Spurious ...................................................... 30 Section 7. Test Equipment List ................................................................ 31 ANNEX A - TEST DETAILS ....................................................................... 32 ANNEX B - TEST DIAGRAMS ................................................................... 38 Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44422RUS1 Page 3 of 40 Section 1. Summary of Test Results Manufacturer Fiber-Span Model No.: FS42R-1719E Serial No.: R006330010141001 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with CFR 47, Part 27, Subpart C. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA, Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety, for use by the company’s employees only. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Nemko USA, Inc. is a NVLAP accredited laboratory. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA, Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44422RUS1 Page 4 of 40 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. RESULT RF Power Output 27.50(d)(1)3280 W EIRP Complies Occupied Bandwidth 2.1049 Input/Output Complies Spurious Emissions at Antenna Terminals 27.53(h) -13 dBm Complies Field Strength of Spurious Emissions 27.53(h) -13 dBm E.I.R.P. Complies Frequency Stability 27.54 Must stay in band NA Footnotes: (1) Modulation characteristics were not tested since the E.U.T. processes but does not produce a modulated waveform. Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44422RUS1 Page 5 of 40 Section 2. General Equipment Specification Supply Voltage Input: Frequency Bands: Downlink: 2110 to 2155 MHz Frequency Bands: Uplink: NA (F9W) (GXW) (DXW) (G7W) Modulation Designator(s): System Gain: 40 dB Output Impedance: 50 ohms NA W RF Output (Rated): Uplink NA dBm 20 W RF Output (Rated): Downlink 43 dBm F1-F1 F1-F2 N/A Frequency Translation: Software Duplexer Fullband Band Selection: Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44422RUS1 Page 6 of 40 Description of EUT The Fiber-Span fiber fed Distributed Antenna System (DAS) is a wireless optical network which can be used to expand network and capacity needs and to overcome site location constraints involving zoning issues, limited space availability or prohibitive BTS based site lease costs . It provides connectivity between a BTS site and several Remote Antenna sites through a fiber optic link. The DAS is made up of two main components; one FTU and three Remote Fiber Nodes. Shown below are the FTU and the three Remote Fiber Nodes. The FTU is located near the BTS site and the Remote Fiber Node is located at the antenna site. System Diagram Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44422RUS1 Page 7 of 40 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 24.232 TESTED BY: David Light DATE: 28 April 2010 Test Results: Complies. Measurement Data: Direction Modulation Output per Channel (dBm) Composite Power (dBm) Composite Power (W) Uplink CDMA NA Downlink CDMA 40 43 20 Uplink EDGE NA Downlink EDGE 40 43 20 Uplink GSM NA Downlink GSM 40 43 20 Uplink W-CDMA NA Downlink W-CDMA 40 43 20 Equipment Used: 1036-1082-1472-1469-1824-1053 Measurement Uncertainty: +/- 1.7 dB Temperature: 22 °C Relative Humidity: 35 % Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44422RUS1 Page 8 of 40 Section 4. Occupied Bandwidth NAME OF TEST: Occupied Bandwidth PARA. NO.: 24.238 TESTED BY: David Light DATE: 28 April 2010 Test Results: Complies. Test Data: See attached plot(s). Equipment Used: 1036-1082-1469-1472-1824 Measurement Uncertainty: 1X10 -7 ppm Temperature: 22 °C Relative Humidity: 35 % Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS REPEATERS EQUIPMENT: FS42R-1719E PROJECT NO.: 44422RUS1 Page 9 of 40 Test …
