Q639555AIridium Handset Model 9555

9555 Satellite Phone User’s Manual © Copyright 2009 Iridium Communications, Inc. All rights reserved. (version H2UG1001) web: www.iridium.com email: [email protected] toll free: +1.866.947.4348 phone: +1.480.752.5155 ii Iridium 9555 Satellite Phone User Manual Iridium 9555 Satellite Phone User Manual iii Legal Notices This User Manual provides user information and is provided “as is.” Iridium and its affi liated companies, directors, offi cers, employees, agents, trustees or consultants (“Iridium”) assume no responsibility for any typographical, technical, content or other inaccuracies in this User Manual. Iridium reserves the right to revise this User Manual or withdraw it at any time without prior notice. You can fi nd the current version of this 9555 Satellite Phone User Guide at www.iridium9555.com. IRIDIUM MAKES NO REPRESENTATIONS, GUARANTEES, CONDITIONS OR WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY IMPLIED REPRESENTATIONS, GUARANTEES, CONDITIONS OR WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT, SATISFACTORY QUALITY, NON-INTERFERENCE, ACCURACY OF INFORMATIONAL CONTENT, OR ARISING FROM A COURSE OF DEALING, LAW, USAGE, OR TRADE PRACTICE, USE, OR RELATED TO THE PERFORMANCE OR NONPERFORMANCE OF ANY PRODUCTS, ACCESSORIES, FACILITIES, SERVICES OR USER INFORMATION, EXCEPT AS EXPRESSLY STATED IN THIS USER MANUAL. ANY OTHER STANDARDS OF PERFORMANCE, GUARANTEES, CONDITIONS AND WARRANTIES ARE HEREBY EXPRESSLY EXCLUDED AND DISCLAIMED TO THE FULLEST EXTENT PERMITTED BY LAW. THIS DISCLAIMER AND EXCLUSION SHALL APPLY EVEN IF THE EXPRESS LIMITED WARRANTY CONTAINED IN THIS USER MANUAL FAILS OF ITS ESSENTIAL PURPOSE. FURTHER, THIS LIMITED WARRANTY COVERS THE 9555 SATELLITE PHONE (INCLUDING HARDWARE, SOFTWARE AND/OR FIRMWARE, BUT EXCLUDING LEATHER CASE) AND ACCESSORIES ONLY, AND NO WARRANTY IS MADE AS TO USER INFORMATION AND/OR COVERAGE, AVAILABILITY OR GRADE OF SERVICE PROVIDED BY IRIDIUM SEPARATELY FOR IRIDIUM SATELLITE SERVICES. IN NO EVENT SHALL IRIDIUM BE LIABLE, WHETHER IN CONTRACT OR TORT OR ANY OTHER LEGAL THEORY, INCLUDING WITHOUT LIMITATION STRICT LIABILITY, GROSS NEGLIGENCE OR NEGLIGENCE, FOR ANY DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE 9555 SATELLITE PHONE (INCLUDING HARDWARE, SOFTWARE AND/OR FIRMWARE) AND/OR ACCESSORIES AND/ OR THE COST OF IRIDIUM SATELLITE SERVICES PROVIDED, INCLUDING ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF PRIVACY, LOSS OF USE, LOSS OF TIME OR INCONVENIENCE, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS CAUSED BY THE 9555 SATELLITE PHONE (INCLUDING HARDWARE, SOFTWARE AND/OR FIRMWARE) AND/OR ACCESSORIES AND/OR THE IRIDIUM SATELLITE SERVICES, OR ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE 9555 SATELLITE PHONE (INCLUDING HARDWARE, SOFTWARE AND/OR FIRMWARE) AND/OR ACCESSORIES AND/OR THE IRIDIUM SATELLITE SERVICES TO THE FULLEST EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW AND WHETHER ADVISED OF THE POSSIBILITIES OF SUCH DAMAGES. Please refer to Chapter 17 of this User Manual for Limited Warranty, Product and Satellite Service Terms and Warranty Support, Conditions of Use and Software License. Third Party Information This User Manual might refer to third party sources of information, hardware or software, products or services and/or third party web sites (“third party information”). Iridium does not control, and is not responsible for, any third party information, including without limitation the content, accuracy, copyright compliance, compatibility, performance, trustworthiness, legality, decency, links, or any other aspect of third party information. The inclusion of such third party information does not imply endorsement by Iridium of the third party information. ANY THIRD PARTY INFORMATION THAT IS PROVIDED WITH IRIDIUM’S FACILITIES, SERVICES, PRODUCTS OR USER INFORMATION IS PROVIDED “AS IS.’’ IRIDIUM MAKES NO REPRESENTATIONS, GUARANTEES OR WARRANTIES IN RELATION TO THIRD PARTY INFORMATION AND IRIDIUM SHALL NOT BE LIABLE FOR ANY LOSSES, DAMAGES, LIABILITIES, JUDGMENTS, FINES, AMOUNTS PAID IN SETTLEMENT, EXPENSES OR COSTS OF DEFENSE SUSTAINED IN RELATION TO ANY SUCH THIRD PARTY INFORMATION. iv Iridium 9555 Satellite Phone User Manual Intellectual Property, Trade Secret, Proprietary or Copyrighted Information To protect Iridium proprietary and confi dential information and/or trade secrets, this User Manual may describe some aspects of Iridium technology in generalized terms. Iridium products may include copyrighted Iridium and third party software. Any such copyrighted software contained in Iridium products may not be modifi ed, reverse engineered, distributed or reproduced in any manner to the extent provided by law. The purchase of any Iridium products shall not be deemed to grant either directly or by implication or otherwise, any license under copyrights, patents, or patent applications of Iridium or any third party software provider, except for the normal, nonexclusive, royalty free license to use that arises by operation of law in the sale of a product. Please refer to Chapter 18 of this User Manual for Limited Warranty, Product and Satellite Service Terms and Warranty Support, Conditions of Use and Software License. Content Copyright You are exclusively responsible for the use of the 9555 Satellite Phone, including proper use of third party copyrighted materials. If you violate these terms you agree to defend, indemnify and hold Iridium harmless with respect to any claims or actions by third parties related to your improper use of copyrighted materials and to pay all costs, damages, fi nes and other amounts incurred by Iridium, or on its behalf, in the defense of any such claims or actions. Iridium 9555 Satellite Phone User Manual v Contents 1: Introduction ................................................................................…

Text truncated - open the document above for the full version.

Front Overview Front Overview – Antenna Extended Rear Overview Rear Overview – Battery Removed

IRIDIUM CONFIDENTIAL MATERIAL FINISH/PROCESS The Barn, Ives Gate Lane Great Milton, Oxford, OX44 7NJ, United Kingdom DRAWN ENGINEER CHECKED DATE(dd/mm/yy) DATE(dd/mm/yy) DATE(dd/mm/yy) PROJECT NUMBER DRAWING TITLE SIZE DRAWING/PART NUMBER ENG. REV. Model DATE(dd/mm/yy)APPROVALCHANGED DATECHANGED BYCHANGE DESCRIPTIONCHANGE NoREV P620188A4 H2 LABEL REG 9555(H2) SHEET 1 OF 1SCALE= 1.00 UNIT: mm DRAWING/INFORMATION ARE PROPRIETARY TO IRIDIUM. IT IS PROHIBITED TO COPY OR DISCLOSE WHOLLY OR IN PART WITHOUT PRIOR WRITTEN CONSENT OF IRIDIUM. SCALE 1.000 AJL22.08.08 NOTES: 1. Printed PANTONE Colours: PROCESS BLACK text on PANTONE 380 C Background 2. Main Label text to be printed in ARIAL 5-point, Regular 3. ‘To Contact’ text to be printed in ARIAL 4.5-point, Regular FCC ID: Q639555A IC: 4629A-9555 Assembled in Malaysia Model 9555 RoHS Compliant / Pb Free To Contact Iridium Satellite: +1.480.752.5155 N12037 34.40 19.40 R 2.70 17.40 R 1.50 R 2.70 R 2.70 16.40 R 2.10 P6TEXT ALTERATIONAJL 17.06.10

EUT Case Open PCBs Overview RF PCB RF PCB Cans Removed RF PCB Rear Control PCB Component Side Control PCB Keypad/Display Side Control PCB Keypad/Display Side – Display Removed

Page 1 of 61 SAR Test Report Report Number: M100558 Test Sample: Iridium Satellite Phone Model Number: 9555 Tested For: TRaC Date of Issue: 27 th May 2010 EMC Technologies Pty Ltd reports apply only to the specific samples tested under stated test conditions. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. EMC Technologies Pty Ltd shall have no liability for any deductions, inferences or generalisations drawn by the client or others from EMC Technologies Pty Ltd issued reports. This report shall not be used to claim, constitute or imply product endorsement by EMC Technologies Pty Ltd. This document is issued in accordance with NATA’s accreditation requirements. The results of tests, calibration and/or measurements included in this document are traceable to Australian/national standards. NATA is a signatory to the ILAC Mutual Recognition Arrangement for the mutual recognition of the equivalence of testing and calibration reports. EMC Technologies Pty Ltd ABN 82 057 105 549 176 Harrick Road Keilor Park Victoria Australia 3042 Ph: + 613 9365 1000 Fax: + 613 9331 7455 email: [email protected] Report No.: M100558 Page 2 of 61 This document must not be copied or reproduced, except in full without the written permission of the Manager, EMC Technologies Pty Ltd. The certificate on page 3 may be reproduced in full. www.emctech.com.au CONTENTS 1.0 GENERAL INFORMATION ............................................................................................................3 2.0 DESCRIPTION OF DEVICE ...........................................................................................................4 2.1 Description of Test Sample ................................................................................................. 4 2.2 Test sample Accessories .................................................................................................... 4 2.2.1 Battery Types ...................................................................................................................... 4 2.3 Test Signal, Frequency and Output Power ......................................................................... 4 2.4 Conducted Power Measurements....................................................................................... 4 2.5 Battery Status...................................................................................................................... 4 2.6 Details of Test Laboratory ................................................................................................... 5 2.6.1 Location............................................................................................................................... 5 2.6.2 Accreditations...................................................................................................................... 5 2.6.3 Environmental Factors ........................................................................................................ 5 3.0 DESCRIPTION OF SAR MEASUREMENT SYSTEM ................................................................... 6 3.1 Probe Positioning System ................................................................................................... 6 3.2 E-Field Probe Type and Performance ................................................................................ 6 3.3 Data Acquisition Electronics................................................................................................ 6 3.4 Calibration and Validation Procedures and Data ................................................................ 6 3.4.1 Validation Results (1640 MHz) ........................................................................................... 6 3.4.2 Deviation from reference validation values ......................................................................... 7 3.4.3 Liquid Depth 15cm ..............................................................................................................7 3.4 Phantom Properties (Size, Shape, Shell Thickness) .......................................................... 8 3.6 Tissue Material Properties .................................................................................................. 8 3.6.1 Liquid Temperature and Humidity ....................................................................................... 8 3.7 Simulated Tissue Composition Used for SAR Test ............................................................ 8 3.8 Device Holder for DASY4.................................................................................................... 9 4.0 SAR MEASUREMENT PROCEDURE USING DASY4 ................................................................. 9 5.0 MEASUREMENT UNCERTAINTY ............................................................................................... 10 7.0 SAR TEST METHOD.................................................................................................................... 13 7.1 Description of the Test Positions ...................................................................................... 13 7.1.1 “Touch Position” ................................................................................................................13 7.1.2 “Tilted Position” ................................................................................................................. 13 7.2 List of All Test Cases (Antenna In/Out, Test Frequencies, User Modes) ......................... 13 7.3 FCC RF Exposure Limits for Occupational/ Controlled Exposure .................................... 13 7.4 FCC RF Exposure Limits for Un-controlled/Non–occupational......................................... 13 8.0 SAR MEASUREMENT RESULTS ............................................................................................... 14 9.0 COMPLIANCE STATEMENT.............................................…

Text truncated - open the document above for the full version.

REPORT ON THE CERTIFICATION TESTING OF AN IRIDIUM SATELLITE LLC 9555 HANDSET WITH RESPECT TO FCC RULES CFR 47, PART 25 AND FCC RULES CFR 47, PART 15 TEST REPORT NO:TTR-000169WUS1 ISSUE NO:PDF FCC ID:Q639555A REPORT ON THE CERTIFICATION TESTING OF AN IRIDIUM SATELLITE LLC 9555 HANDSET WITH RESPECT TO FCC RULES CFR 47, PART 25 AND FCC RULES CFR 47, PART 15 TEST DATE: 10 th – 18 th June 2010 APPROVED BY:J CHARTERS RADIO PRODUCT MANAGER DATE:29 th June 2010 Distribution:Iridium Satellite LLC TCB: TRaC EMC & Safety TRaC Telecoms & Radio THIS DOCUMENT MAY BE REPRODUCED ONLY IN ITS ENTIRETY AND WITHOUT CHANGE TTR-000169WUS1Page 3 of 68 CONTENTS PAGE CERTIFICATE OF CONFORMITY & COMPLIANCE4 APPLICANT’S SUMMARY5 EQUIPMENT TEST CONDITIONS6 TESTS REQUIRED6 PRODUCT DESCRIPTION & STANDARDS REFERENCES7 TEST RESULTS RF Output Power - Conducted8 Emissions Limitations - Conducted9 Spurious Emissions - Conducted10 Spurious Emissions - Radiated 11 Frequency Stability -Temperature12 Frequency Stability -Voltage13 Unintentional Spurious Emissions - Radiated14 Conducted Emissions –AC Powerline Conduction15 ANNEX PHOTOGRAPHSA APPLICANT’S SUBMISSION OF DOCUMENTATION LISTB TEST EQUIPMENT LISTC EQUIPMENT CALIBRATIOND MEASUREMENT UNCERTAINTYE DUTY CYCLE F EMISSIONS LIMITATIONSG TRANSMITTER SPURIOUSEMISSIONS– ConductedH TRANSMITTER SPURIOUS EMISSIONS– RadiatedI FREQUENCY STABILITY – TemperatureJ FREQUENCY STABILITY – VoltageK UNINTENTIONAL RADIATED EMISSIONSL CONDUCTED EMISSIONS – AC POWERLINECONDUCTIONM DECLARATIONSN Notes:1.Component failure during test YES[ ]NO[X] 2.If Yes, details of failure: 3.The facilities used for the testing of the product contain in this report are FCC Listed. CERTIFICATE OF CONFORMITY & COMPLIANCE TTR-000169WUS1 FCC IDENTITY:Q639555A PURPOSE OF TEST:Certification TEST SPECIFICATION:FCC RulesCFR 47, Part25& Part 15 TEST RESULT:Compliant to Specification ITU EMISSIONS DESIGNATOR41K7Q7W EQUIPMENT UNDER TEST:9555 Handset EQUIPMENT TYPE:Satellite Telephone PEAKOUTPUTPOWER:8.81 dBW, 7.60 Watts MEAN OUTPUT POWER:-1.53dBw, 0.70 W CHANNEL SPACING:41.667 kHz NUMBER OF CHANNELS:252(240 Transmit Channels) MODULATION TYPE:Q7W POWER SOURCE(s):+3.7Vdc TEST DATE(s):6 th – 18 th June 2010 APPLICANT:IridiumSatellite LLC ADDRESS:6707 Democracy Blvd. Suite 300 Bethesda United States of America MD 20817 TESTED BY:D WINSTANLEY APPROVED BY:J CHARTERS RADIO PRODUCT MANAGER TTR-000169WUS1Page 5 of 68 APPLICANT’SSUMMARY EQUIPMENT UNDER TEST (EUT):9555 Handset EQUIPMENT TYPE:Satellite Telephone PURPOSE OF TEST:Certification TEST SPECIFICATION(s):FCC Rules CFR 47, Part 25 & Part 15 TEST RESULT:COMPLIANTYes No [X] [ ] APPLICANT’S CATEGORY:MANUFACTURER IMPORTER DISTRIBUTOR TEST HOUSE AGENT [X] [ ] [ ] [ ] [ ] APPLICANT’S CONTACT PERSON(s):Donna Bethea-Murphy APPLICANT:Iridium Satellite LLC ADDRESS:6707Democracy Blvd. Suite 300 Bethesda United States of America MD 20817 TEL:+1 301 571 6277 FAX:+1 301 571 6250 MANUFACTURER:Iridium Satellite LLC DEVELOPMENT AGENT:Cambridge Consultants Limited DEVELOPMENT AGENTS CONTACT PERSON(s):Mr S Hart E-mail address:[email protected] ADDRESS:Science Park Milton Road Cambridge CB4 4DW United Kingdom TEL:+44 (0)1223 420024 FAX:+44 (0)1223 423373 EUT(s) COUNTRY OF ORIGIN:United States TEST LABORATORY:TRaC Telecoms & Radio, Up Holland UKAS ACCREDITATION No:0971 TEST DATE(s):6 th – 18 th June 2010 TEST REPORT No:TTR-000169WUS1 TTR-000169WUS1Page 6 of 68 EQUIPMENT TEST / EXAMINATIONS REQUIRED 1.TEST/EXAMINATIONFCC Part 2FCC Part 25APPLICABILITYRESULT RF Power Output-25.204(a)YESPASS Emissions Limitations-25.202(f)YESPASS Spurious Emissions at Antenna Terminals 2.1051 25.202(f) 25.213 YESPASS Protection of the Radio Navigation Satellite Service - 25.216(c) 25.216(f) YESPASS Spurious Emissions Radiated2.1053 25.202(f) 25.213 YESPASS Frequency Stability Temperature2.105525.202(d)YESPASS Frequency Stability Voltage2.105525.202(d)YESPASS Note: The 9555 Handsetis subject to FCC Part 25 & Part 2 for FCC Certification for units marketed within the United States. The above tests, as specified in FCC Part 2,with limits as defined in FCC Part 25 were performed on the 9555 Handset. 2.Product Use:Satellite Telephone 3.Emission Designator:41k7Q7W 4.Temperatures:Ambient (Tnom) 20 o C 5.Supply Voltages:Vnom+3.7Vdc Note: Vnom voltages are as stated above unless otherwise shown on the test report page Single channel[ ] Two channel[ ] 6.Equipment Category: Multi-channel[X] 7.Channel spacing:Narrowband[X]41.667 kHz Wideband[ ] 8.Test Location:TRaC Telecoms & Radio Up Holland[X] Hull[ ] 9.Modifications made during test program No modifications were performed. TTR-000169WUS1Page 7 of 68 Product Description The satellite telephoneconsists of an L-Band Transceiver (LBT) capable of simultaneous transmit and receive (duplex) operation covering the frequency range of 1616MHz to 1626.5MHz. The frequency accesses used for duplex channels are organised into sub-bands each of which contains eight frequency accesses. Each sub-band, therefore occupies 333.33 kHz (i.e. 8x41.667kHz). Up to 30 sub-bands containing 240 frequency accesses may be used for duplex channels. Standard References 47 CFR 2Code of Federal Regulations, Title 47, Part 2, “Frequency allocations and Radio Telemetry Matters; 10-1-03 EditionGeneral Rules and Regulations” 47 CFR 25Code of Federal Regulations, Title 47, Part 25,”SatelliteCommunications” Subpart C, 10-1-03 Edition “TechnicalMatters” 47 CFR 15Code of Federal Regulations, Title 47, Part 15,”Radio Frequency Devices” Subpart B, 20-09-07 Edition “Unintentional Radiators” C63.4-2003American National Standards Institute (ANSI), “Methods of Measurement of Radio Noise Emissions from Low Voltage Electrical and Electronic Equipment in the Range 9 kHz to 40 GHz” TTR-000169WUS1Page 8 of 68 COMPLIANCE TESTS TRANSMITTER TESTS RF OUTPUTPOWER – CONDUCTED – PART 25.204(a) Ambient temperature=23 o CRadio Laboratory Relative humidity=58% Supply voltage=+3.7Vdc Channel number=See test results See…

Text truncated - open the document above for the full version.

Radiated Emissions Output Power AC Powerline Conduction
