Q78-AD3812WCDMA WIRELESS DATA TERMINAL

WCDMA Module This manual is applicable for AD3812 module. AT Command Manual For ZTE Corporation’s AD3812 Module Version: V1.0 WCDMA Module 1 Copyright Statement Copyright © 2010 by ZTE Corporation All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. is the registered trademark of ZTE Corporation. All other trademarks appeared in this manual are owned by the relevant companies. ZTE Corporation reserves the right to make modifications on print errors or update specifications in this manual without prior notice. ZTE Corporation keeps the right to make the final explanation to this manual. WCDMA Module 2 Table of Contents 1 Definitions and abbreviations...................................................................................... 5 1.1 Command line ....................................................................................................................5 1.2 Information responses and result codes .............................................................................5 1.3 Abbreviations......................................................................................................................6 2 General commands .................................................................................................... 7 2.1 +CGMI Request manufacturer identification ....................................................................7 2.2 +CGMM Request model identification ................................................................................7 2.3 +CGMR Request revision identification ..............................................................................7 2.4 +CGSN Request product serial number identification......................................................8 2.5 +CSCS Select TE character set .........................................................................................8 2.6 +CIMI Request international mobile subscriber identity......................................................9 2.7 +WS46 select wireless network ..........................................................................................9 2.8 +GCAP Capabilities List +GCAP ......................................................................................10 2.9 +CMEE Repor Mobile Equipment Errors..........................................................................10 2.10 +ZHWV Request hardware revision identification.............................................................10 2.11 +ZDRNT Request status of dormant ................................................................................11 2.12 +ZSSPA Request System Status and System Parameter ................................................11 2.13 +ZMDS Request System Set Network Mode....................................................................11 2.14 +ZGMS Request System Service Type............................................................................11 2.15 +ZUCT Request System Service Type .............................................................................12 2.16 +ZGVT Request UE Voice channel Type .........................................................................12 3 Call control commands and methods........................................................................ 13 3.1 ATD\ATA\ATH\ATS0 ........................................................................................................13 3.2 +CSTA Select type of address..........................................................................................13 3.3 +CMOD Call mode...........................................................................................................14 3.4 +CHUP Hangup call.........................................................................................................14 3.5 +CBST Select bearer service type....................................................................................15 3.6 +CRLP Radio link protocol ...............................................................................................16 3.7 +CR Service reporting control...........................................................................................17 3.8 +CEER Extended error report ..........................................................................................18 3.9 +CRC Cellular result codes ..............................................................................................18 3.10 +CVHU Voice Hangup Control .........................................................................................20 3.11 +VGR Receive gain selection ...........................................................................................20 3.12 +CMUT Mute control ........................................................................................................20 3.13 +VTD Tone duration.........................................................................................................21 3.14 +VTS DTMF and tone generation.....................................................................................21 3.15 +CLCC List current calls ...................................................................................................21 3.16 S<X> Basic S-Register ..................................................................................................23 3.17 +ZFLSH Send Flash/Flash with Information .....................................................................24 3.18 +VGT Transmit gain selection ..........................................................................................24 3.19 +ZCORG ORIGINATE CALL ............................................................................................25 WCDMA Module 3 3.20 +ZCCNT: CALL CONNECT..............................................................................................25 3.21 +…

Text truncated - open the document above for the full version.

Date: March 27, 2011 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The ZTE Corporation, the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the ZTE Corporation solely in matters relating to the application for an FCC equipment authorization for FCC ID: Q78-AD3812 including the signing of documents in connection with this Application. Necessary acts carried out by ZTE Corporation on our behalf of the ZTE Corporation in connection with the Application shall have the same effect as acts of the ZTE Corporation. The ZTE Corporation also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, Royce Wang ZTE product approval manager

Date: March 27, 2011 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 RE: ZTE Corporation FCC ID: Q78-AD3812 FCC Part 22&24 Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. IONIT Global Inc. requests that the following documents regarding this submission for FCC ID: AD3812 be kept confidential: Exhibit Type File Name Block Diagram Q78-AD3812_Block Diagram.pdf Schematics Q78-AD3812_Schematics.pdf Operational Description Q78-AD3812_Operational Description.pdf Part list Q78-AD3812_BOM.xls Those documents contain detailed system and equipment description and related information about the product which ZTE Corporation considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis from which future technological products will evolve, ZTE Corporation considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Thank you for your attention to this matter. Yours Sincerely, Royce Wang ZTE product approval manager

Request for Modular Approval FCC ID: Q78‐AD3812 Item Requirements EUT 1 The final device is designed for mobile or fixed operation (Portable is not permitted – Reference TCB Exclusion List (17 July 2002) II (g)). There is shield present on the PCB, covering the section of reader. 2 The maximum antenna gain to allow compliance with RF exposure requirements is listed on the Grant of Certification for the module. There is no antenna in this modular, it provides a antenna connector. 3 The licensed module must have a FCC ID label on the module itself. That FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily removed. If not, a second label must be placed on the outside of the final device that contains the following text: Contains “FCC ID: Q78‐AD3812” Please refer to the FCC ID label format. Labeling instruction has been provided in the OEM installation instruction. 4 The Grant should include the following words in the device description or grant notes: “modular transmitter” or “transmitter module”. Modular approval is requested for this application. 5 The module must comply with RF exposure requirements. See FCC Rules. Spread Spectrum transmitters must comply with RF exposure limits in 15.247. The module has very low levels of RF energy that it is deemed to comply without testing of specific absorption ratio (SAR). 6 The modular transmitter will be labeled with the FCC ID: Q78‐AD3812, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior FCC ID Label will use wording, “Contains RFID Transmitter Module FCC ID: Q78‐AD3812”.

Q78-AD3812 External Photos

FCC Label Label Location

Q78-AD3812 Internal Photos

Report No.: SZ1103001702 Page 2 of 29 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 3 1.1 EUT Description ......................................................................................................................... 3 1.2 Test Standards and Results ........................................................................................................ 5 1.3 Facilities and Accreditations ...................................................................................................... 6 2. 47 CFR PART 2, PART 22H & 24E REQUIREMENTS ........................................................ 7 2.1 Conducted RF Output Power .................................................................................................... 7 2.2 99% Occupied Bandwidth ....................................................................................................... 11 2.3 Frequency Stability ................................................................................................................... 16 2.4 Conducted Out of Band Emissions ......................................................................................... 19 2.5 Band Edge ................................................................................................................................. 25 Change History Issue Date Reason for change 1.0 March 25, 2011 First edition Report No.: SZ1103001702 Page 3 of 29 1. GENERAL INFORMATION 1.1 EUT Description EUT Type ............................. : WCDMA wireless data terminal Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : AD3812V2IB_E Software Version .................. : Manufacturer ........................ : AD3812_V2_OMBC6250 ZTE Corporation ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park,Nanshan District, Shenzhen, Guangdong, P.R.China Frequency Range .................. : GSM 850MHz: Tx: 824.20 - 848.80MHz (at intervals of 200kHz); Rx: 869.20 - 893.80MHz (at intervals of 200kHz) GSM 1900MHz: Tx: 1850.20 - 1909.80MHz (at intervals of 200kHz); Rx: 1930.20 - 1989.80MHz (at intervals of 200kHz) WCDMA 850MHz Tx: 826.4- 846.6MHz (at intervals of 200kHz); Rx: 871.4 – 891.6MHz (at intervals of 200kHz) WCDMA 1900MHz Tx: 1852.4 – 1907.6MHz (at intervals of 200kHz); Rx: 1932.4 – 1987.6MHz (at intervals of 200kHz) Modulation Type................... : GPRS/GSM Mode with GMSK Modulation WCDMA Mode with QPSK Modulation Emission Designators ........... : GSM:265KGXW, WCDMA:4M18F9W Power supply ......................... Powered by a DC power Rated Voltage: 3.7V Note 1: The transmitter (Tx) frequency arrangement of the Cellular 850MHz band used by the EUT can be represented with the formula F(n)=824.2+0.2*(n-128), 128<=n<=251; the lowest, middle, highest channel numbers (ARFCHs) used and tested in this report are separately 128 (824.2MHz), 190 (836.6MHz) and 251 (848.8MHz). Note 2: The transmitter (Tx) frequency arrangement of the PCS 1900MHz band used by the EUT can be represented with the formula F(n)=1850.2+0.2*(n-512), 512<=n<=810; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately 512 (1850.2MHz), 661 (1880.0MHz) and 810 (1909.8MHz). Note 3: The GPRS was tested under 4 uplink time slots mode. Note 4: The transmitter (Tx) frequency arrangement of the WCDMA 850MHz band used by the EUT can be represented with the formula F(n)=826.4+0.2*(n-4132), 4132<=n<=4233; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately Report No.: SZ1103001702 Page 4 of 29 4132 (826.4MHz), 4175 (835MHz) and 4233 (846.6MHz). Note 5: The transmitter (Tx) frequency arrangement of the WCDMA 1900MHz band used by the EUT can be represented with the formula F(n)=1852.4+0.2*(n-9262), 9262<=n<=9538; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately 9262 (1852.4MHz), 9400 (1880MHz) and 9538 (1907.6MHz). Note 6: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ1103001702 Page 5 of 29 1.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 2, Part 22 and Part 24 for the EUT FCC ID Certification: No. Identity Document Title 1 47 CFR Part 2 (10-1-09 Edition) Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 47 CFR Part 22 (10-1-09 Edition) Public Mobile Services 3 47 CFR Part 24 (10-1-09 Edition) Personal Communications Services Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 2.1046 Conducted RF Output Power PASS 2 2.1049 20dB Occupied Bandwidth PASS 3 2.1055 22.355 24.235 Frequency Stability PASS 4 2.1051 2.1057 22.917 24.238 Conducted Out of Band Emissions PASS 5 2.1051 2.1057 22.917 24.238 Band Edge PASS 6 22.913 24.232 Transmitter Radiated Power (EIPR/ERP) (n.a.) Note 1 7 2.1053 2.1057 22.917 24.238 Radiated Out of Band Emissions (n.a.) Note 1 NOTE1: Because the sample have not the antenna. NOTE2：Measurement method according to TIA/EIA-603. Report No.: SZ1103001702 Page 6 of 29 1.3 Facilities and Accreditations 1.3.1 Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2 Test Environment Conditions During the measurement, the…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CSE 2. RSE
