Q78-E821WCDMA/GSM(GPRS) Dual-Mode Digital Mobile Phone

1 E821 User Manual E821 User Manual 2 LEGAL INFORMATION Copyright © 2011 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. Version No. : R1.0 Edition Time : 2011.1.13 Manual No. : E821 User Manual 3 Contents Welcome .......................................................................................................................................... 6 Your E821 .................................................................................................................................... 6 Specifications ............................................................................................................................... 7 Getting Started ................................................................................................................................. 8 Installing the Battery .................................................................................................................... 8 Removing the Battery .................................................................................................................. 8 Charging the Battery .................................................................................................................... 9 Installing and Removing the SIM Card ....................................................................................... 9 Inserting and Removing the microSD Card ............................................................................... 10 Powering On/Off ........................................................................................................................ 11 Calibrating the Touch Screen ..................................................................................................... 11 Setting the Time and Date .......................................................................................................... 11 Starting from Standby Mode ...................................................................................................... 11 Indicator Icons ............................................................................................................................ 12 Basic Operation .............................................................................................................................. 14 Menu Navigation ........................................................................................................................ 14 Locking the Screen and Keypad ................................................................................................ 14 Securing Your Phone ................................................................................................................. 14 Running Multiple Applications .................................................................................................. 15 Using the Hardware Keyboard to Enter Text ............................................................................. 16 Personalizing Your Phone .............................................................................................................. 17 Screen ......................................................................................................................................... 17 Profiles ....................................................................................................................................... 17 General Settings ......................................................................................................................... 17 Using the Phone ............................................................................................................................. 18 Making a Call ............................................................................................................................. 18 Making a Voice Call .............................................................................................................. 18 Making a Video Call .............................................................................................................. 18 Making a Call from Contacts ................................................................................................. 18 Making a Call from Call History ........................................................................................... 18 Making a Call from Messages ................................................................................................ 18 Making a Speed Dial Call ...................................................................................................... 19 Answering a Call ........................................................................................................................ 19 In-call Options ............................................................................................................................ 19 Call History ................................................................................................................................ 19 Using SIM Card Services ........................................................................................................... 19 Call Settings ............................................................................................................................... 19 Messaging ...................................................................................................................................... 21 Writing and Sending a Message ................................................................................................. 21 Deleting Messages .......................................…

Text truncated - open the document above for the full version.

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Feb 25, 2011 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Feb 25, 2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-E821 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

Q78-E821 external photo Battery Battery Charger Label of Charger Headset Data cable

Q78-E821, label placement

Q78-E821 internal photos Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly

No.2011TAR013 Page 1 of 16 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2011TAR013 for ZTE Corporation WCDMA/GSM (GPRS) Dual-Mode Digital Mobile Phone Model Name: ZTE E821 FCC ID : Q78-E821 with Hardware Version: w5Da Software Version: E821 V1.0 Issued Date: 2011-01-29 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2011TAR013 Page 2 of 16 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 6 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 6 5. LABORATORY ENVIRONMENT .............................................................................................. 7 6. SUMMARY OF TEST RESULTS .............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED ............................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 10 No.2011TAR013 Page 3 of 16 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Jan 10, 2011 Testing End Date: Jan 11, 2011 1.4. Signature Liu Baodian (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2011TAR013 Page 4 of 16 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE Corporation Address /Post: #68 Zijin Hua Road, Nanjing, Jiangsu Province, P. R. China City: Nan Jing Postal Code: 210012 Country: China Telephone: +86-25-52878232 Fax: +86-25-68897541 2.2. Manufacturer Information Company Name: ZTE Corporation Address /Post: #68 Zijin Hua Road, Nanjing, Jiangsu Province, P. R. China City: Nan Jing Postal Code: 210012 Country: China Telephone: +86-25-52878232 Fax: +86-25-68897541 No.2011TAR013 Page 5 of 16 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description WCDMA/GSM (GPRS) Dual-Mode Digital Mobile Phone Model Name ZTE E821 FCC ID Q78-E821 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version N03 356170040001050 w5Da E821 V1.0 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery 40041008071110344 AE2 Travel Adapter / AE1 Model Li3709T42P3h483757-H Manufacturer ZTE Capacitance 900mAh Nominal Voltage 3.7V AE2 Model STC-A22O50I700USBA-Z Manufacturer RUIDE Length of DC line 120cm *AE ID: is used to identify the test sample in the lab internally. No.2011TAR013 Page 6 of 16 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices July 10, 2008 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2003 No.2011TAR013 Page 7 of 16 ©Copyright. All rights reserved by TMC Beijing. 5. LABORATORY ENVIRONMENT Semi-anechoic chamber (23 m…

Text truncated - open the document above for the full version.

E821 FCC test setup photo 1． Radiated Spurious Emission 2． Conducted Emission(Charging) 3． Conducted Emission(USB) 4． Radiated Emission(Charging) 5． Radiated Emission(USB) 6. part15C
